operation manual Xenon XL-A100 / Xenon XL-M100
table of contents page 1
file: Xenon XL-A100 - Xenon XL-M100.doc, date: 23. September 2003
1safety reference / place the equipment _______________________________________________________2
1.1 safety reference ..........................................................................................................................................2
1.2 place the equipment....................................................................................................................................2
2general advises / signs and symbols ________________________________________________________3
3description of the equipment _______________________________________________________________5
4operating elements _______________________________________________________________________6
4.1 operating elements on the frontpanel..........................................................................................................6
4.2 operating elements on the rear ...................................................................................................................7
5connecting and operating the equipment_____________________________________________________8
5.1 operating the equipment .............................................................................................................................9
5.1.1 operating the equipment without video input ..........................................................................................9
5.1.2 operating the equipment with video input (only Xenon XL-A100) ........................................................... 9
6service manual / maintenance of the equipment ______________________________________________11
6.1 possible causes / remedy..........................................................................................................................11
6.2 selection of the line voltage setting ...........................................................................................................11
6.3 exchanging the mains fuses......................................................................................................................12
6.4 replacing the lamp.....................................................................................................................................12
6.5 cleaning / desinfecting ..............................................................................................................................13
7technical data___________________________________________________________________________14
8spare parts _____________________________________________________________________________14
9table ‘technical service-information’ ________________________________________________________15

operation manual Xenon XL-A100 / Xenon XL-M100
safety reference / place the equipment page 2
1 safety reference / place the equipment
1.1 safety reference
normal use
The equipment may only be used with accessories, wearing parts and disposable items, which
have been designated by E.S.S., Inc as suitable for the instrument or the safety use of which is
proven.
user qualification
The equipment may only be used by persons, who have a corresponding specialised qualification
and who have been instructed in use of the equipment.
It is the user’s responsibility to make sure, the equipment is safe and operates properly before using
the equipment.
1.2 place the equipment
unpacking / items included
Carefully unpack the equipment and accessories and remove it from their packing.
Check for missing items and evidence of shipping damage.
File any complaints with the manufacture or supplier immediately.
Retain the original packing materials for later use. These can come in handy, when the equipment
must be transported.
Please verify immediately after having unpacked the equipment, whether the delivery is complete.
The standard extent of delivery includes of the following:
•control unit
•power supply cord
•manual
safety precautions at the site of installation
Always place the equipment on a solid base.
Make sure, that air circulation is sufficient.
Never cover the louver type slots of the unit.
The equipment may be used only in rooms having electrical installations conforming to applicable
national, state and local electronical codes.
The unit must be joined to the central potential equalisation of the operating theatre or of the
equipment trolley by means of a grounding cable.
The device must be connect to line voltage using the delivered protectively earthed power supply
cord.
The equipment may not be used in areas, where there are dangerous flammable gases.
The equipment may only be connect to devices, which also comply to the IEC601-1.
Never look direct in the lightbeam of a light source.
Comment:

operation manual Xenon XL-A100 / Xenon XL-M100
description of the equipment page 3
2 general advises / signs and symbols
Thank you for your expression of confidence in the E.S.S., Inc brand name.
Like all of our other products, this product is the result of years of experience and great care in
engineering and manufacture.
This manual is destined to learn you understanding the function and the operation of your equip-
ment.
Before you switch on the equipment for the first time, please thoroughly read this manual and pay
special attention to all safety instructions, so that endangering for the user and the patient is pre-
cluded.
Please always store this manual with the equipment.
data of the equipment
The type label (rear of unit) contains technical data, type and serial num-
ber of your unit. Please always indicate these data when ordering spare
parts or in case of any question.
Please enter here the technical data of your device! Î
Serial No.: ___________________
Type: _______________________
Date: _______________________
Class: ______________________
Hz:_________________________
Amp.:_______________________
Volt: ________________________
warranty
1 year according to our warranty conditions.
Opening the equipment or performance of any repairs or modifications of the equipment by unau-
thorised persons shall relive E.S.S., Inc of any liability for its performance. Any such opening, re-
pair or modification performed during the warranty period shall void all warranty.
Wear parts are not included in the warranty.
The firm of E.S.S., Inc shall be liable for failure or deterioration in the safe operation, operational
reliability and performance of this equipment only subject to the conditions, that all assembly op-
erations, system expansions, readjustments or repairs to same have been performed by a person
or persons duly authorised by E.S.S., Inc, that all electrical installations at the location of us meet
applicable national and local electrical codes and that the instrument has been used in accordance
with its operating instructions at all times.

operation manual Xenon XL-A100 / Xenon XL-M100
description of the equipment page 4
rights
All rights on this user manual, especially the rights of duplication and publication and the rights on
translation are reserved. No part of this user manual may be reproduced by any means (by photo-
static copy, microfilm or other methods) without preceding written consent of the E.S.S., Inc or be
reproduced, multiplied or published by means of electronic data processing.
The information given in this user manual can be changed or extended without notice and do not
represent any liability.
Errors and technical changes excepted.
© E.S.S., Inc November 1998
symbols
attention, important note!
safety note!
service
signs
please read the enclosed instructions
unit model BF
beware of dangerous electrical voltage
connection for ground potential
~
alternating voltage

operation manual Xenon XL-A100 / Xenon XL-M100
description of the equipment page 5
3 description of the equipment
The light source you have purchased offers high intensity 100W Xenon illumination for use with
almost every endoscopic discipline. The colour temperature equals daylight quality with a colour
temperature of 5.600 K and the life expectancy amounts to 500 hours.
A mechanical diaphragm is used to control the output intensity of the Xenon lamp without influence
on the colour temperature.
The lamp is especially designed for endoscopic applications.
The equipment complies with the latest safety standards for medical products and is approved to
CE.

operation manual Xenon XL-A100 / Xenon XL-M100
operating elements page 6
4 operating elements
4.1 operating elements on the frontpanel
main switch
LEDs remaining lamp life (only Xenon XL-A100)
LED lamp change (only Xenon XL-A100)
connector for lightguide
push button ‘decrease intensity’
push button ‘increase intensity’
push button ‘manual mode’ (only Xenon XL-A100)
push button ‘automatic mode’ (only Xenon XL-A100)
mains switch
The control unit is turned on by switching the mains switch.
The mains switch has two different switching positions:
Iswitched on
Oswitched off
When the control unit is switched on, this is indicated by the up-light green lamp inside the switch.
remaining lamp life indicator (only Xenon XL-A100)
Indicated the remaining life of the lamp (500h).
After the lamp has been ignited, the remaining lamp life indicator will also light up.
First of all it will execute a lamp-test, after that, one of the LED’s (either 500, 250, 100 or 50h) will
indicate the remaining life expectancy of the lamp.
If the recommended use of 500 hours has expired, this will be indicated by flashing of the red LED
(LAMP CHG). Then the lamp should be replaced with a new.
connector for lightguide
This connector is used to connect and adjust the lightguide to the lightsource. There is an inter-
changeable adapter screwed in. The adapter used has to match the lightguide fitting you are using.
Several adapters for all types of lightguides are available. Most of these adapters have an auto-
matic snap-in for the lightguide.
pushbutton ‘decrease intensity’
Use this button to decrease the output intensity of the lightsource. If the mechanical diaphragm is
completely closed, this is indicated by the yellow light inside the button.
pushbutton ‘increase intensity’
Use this button to increase the output intensity of the lightsource. If the mechanical diaphragm is
completely open, this is indicated by the yellow light inside the button.

operation manual Xenon XL-A100 / Xenon XL-M100
operating elements page 7
pushbutton ‘auto mode’ (only Xenon XL-A100)
Use this button to enable the light source in automatic mode. This will be indicated by the green
light inside the button.
pushbutton ‘manual mode’ (only Xenon XL-A100)
Use this button to enable the light source in manual mode. This is indicated by the green light inside
the button.
4.2 operating elements on the rear
pot. ground connector
video in connector (only Xenon XL-A100)
line voltage indicator
line connector
fuse holder
pot. ground connector
Basically, the control unit is protectively earthed by the 3-pin power supply cord when it is connect
to a protectively earthed wall socket, as prescribed.
When running the equipment in rooms which comply to class 1 or 2E according to MedGV, the
control unit must be joined to the central potential equalisation of the operating theatre or of the
equipment trolley by means of a grounding cable.
video in connector (only Xenon XL-A100)
You can attach external video input to the video in connectors.
The video signal can be connect in two different standards.
•The BNC-terminal require the videosignal as VBAS-signal (composit-signal, VHS-standard).
•The 4-pin-Y/C-terminal require the videosignal as Hosiden-signal (separate conductors for
chroma- and luminance-signal, S-VHS-standard).
fuse holder / line voltage indicator
Contains the mains fuses. The window inside the drawer shows the currently selected mains volt-
age. You have to control whether your mains voltage corresponds with the selection shown in the
window.
line connector
The plug of the power supply cord is connect to the mains terminal device.

operation manual Xenon XL-A100 / Xenon XL-M100
connecting and operating the equipment page 8
5 connecting and operating the equipment
Before you connect the mains plug, check on the back of the equipment that the voltage indicated
(in the square panel above the mains socket) is the correct one.
voltage = 230VAC Æindicator ‘230’
voltage = 115VAC Æindicator ‘115’
If the incorrect voltage is indicated then the equipment may under no circumstances be connect.
Before connecting a light cable into a light source adapter of the equipment, please ensure that
you have the correct plug and adapter. A plug that is too long or too thin can for example be
pushed too far into the equipment, and can damage the sensitive diaphragm or lens inside. This
will result moreover in considerable loss of light, in the same way as a plug that is too short, or a
plug of the wrong diameter, because of the wrong position of the contacts at the light entry.
All wiring has to be done before switching on the equipment.
After switching on a light source and the ensuing ignition of the lamp, the equipment should remain
switched on for at least ¼ hour. A shorter shining period will considerably shorten the life expec-
tancy of the lamp! After switching off a light source however, it may be immediately switched on
again. A waiting period or cooling off period is not necessary.
connect the power supply cord
Use the delivered protectively earthed power supply cord to connect the control unit to the mains.
connect the external input devices (only Xenon XL-A100)
As described before, there are several standards of video signal available on the rearpanel. Here
you can connect external input. If you are using standard VBS-signal (BNC-terminal), please al-
ways apply high-quality 75Ω-coaxial cables. If the external output device has a switchable 75Ω-
termination resistor, you should switch this on. If you connect several devices in a row, only the last
device in the line needs to be terminated by the termination resistor.
If the external device does not provide such a termination resistor, you should connect the coaxial
cable via a T-connection-adapter. The open end of the T-connection adapter is then terminated
with the 75Ω-resistor.
connect the potential equalisation conductor
Join the terminal device for potential equalisation on the rearpanel with the central potential equali-
sation of the operating theatre or of the equipment trolley.

operation manual Xenon XL-A100 / Xenon XL-M100
connecting and operating the equipment page 9
5.1 operating the equipment
5.1.1 operating the equipment without video input
switching on the equipment
After connecting the mains, the grounding conductor, the light cable and the endoscope, the
equipment is ready for use, and can be switched on at the mains switch. The green mains light
(Power) inside the switch will light up. After 5-10 seconds the lamp will automatically ignite. It will
burn with full power right from the start. At the same time the ventilator will start to run.
setting manual mode (only Xenon XL-A100)
Now you can set the mode: in this case manual regulation of light intensity. To set this mode, you
press the push button ‘MAN’ which will turn on this mode of operation. This will be indicated when
the green LED in the key lights up.
setting the light intensity
The output of light can now be adjusted either stronger or weaker by the push button ‘INTENSITY’.
If you press the push button ‘decrease intensity’, light intensity will decrease. Then intensity is
adjusted by a mechanical diaphragm with the result that the spectrum of white light does not
change when dimmed. When the diaphragm is completely open for maximum light intensity or
completely closed for minimum light intensity (when the respective key is pressed), this will be
indicated by the yellow LED light in the corresponding key.
5.1.2 operating the equipment with video input (only Xenon XL-A100)
switching on the equipment
Connections or wiring of the equipment: Besides the mains connection and the connection of the
light cable with endoscope, the video signal must now also be connect to the equipment.
The corresponding sockets are located on the rear panel of the equipment.
You can see the two sockets leading in (S-VHS Y-C, BNC).
The BNC socket is for connecting the standard so called Composite Video Signal, for example
CCIR-Norm, where there is colour and black/white information on a coaxial (two-lead cable). This
is the usual system with older colour and also black/white cameras, both of which can be connect
here.
The Y/C socket is for connecting the newer colour cameras, which work with the so called Super-
VHS System, or also Y-C signals. Here the picture brightness control (Y-signal) and colour control
(C-signal) are split, with the result that a 4-veined cable and a 4-pole plug is necessary.
Usually the signal coming from the video camera is fed into the VIDEO IN socket of the monitor
and then fed either from the VIDEO OUT socket of the monitor (if available) or using a T-
connection-adapter further on to the lightsource.
If shadow pictures appear on the monitor, because of a very long length of the cable, the video
signal must be terminated with a 75 Ω-termination-resistor so as to suppress the disrupting reflec-
tions in the cable.
In this case, the video signal is fed into the lightsource using a further T-connection-adapter. The
open end of the T-connection-adapter is fitted with the 75 Ω-resistor.
Basically only 75 Ωvideo cable should be used when connecting the equipment together, so that
you obtain the best picture quality.
After connecting the mains, the grounding conductor, the light cable and the endoscope, the
equipment is ready for use, and can be switched on at the mains switch. The green mains light
(Power) inside the switch will light up. After 5-10 seconds the lamp will automatically ignite. It will
burn with full power right from the start. At the same time the ventilator will start to run.
setting the camera
Standard video cameras usually have a so called AGC switch (Automatic Gain Control = automatic
control of the light). This switch should be switched of, when using the light source with video con-
trol, as otherwise there can appear uncontrollable variations in the picture brightness when in use,
because the AGC counteracts the control of the light source.
If the camera is a so called shutter-camera you should observe the following:
If the camera has only one possible shutter speed (e.g. 1/1000 sec.), then this should be set at off
during normal use, as otherwise the picture on the monitor will be very dark, because of much
shorter exposure time compared with normal use. If the shutter-camera, however, is fitted with a
floating shutter control, that means that it will, by changing the shutter speed, automatically adjust

operation manual Xenon XL-A100 / Xenon XL-M100
connecting and operating the equipment page 10
the brightness of the picture, with the result that the camera can operate without problem with the
video control of the light source. The electronic camera control must however operate very fast,
and then this co-operation of the equipment will give very good results (fast and exact adjustment
of brightness over the whole screen).
If the automatic control on the camera works relatively slowly, then variations can happen (coun-
teraction of the camera control against the control on the light source). In this case, the automatic
control on the light source must be switched off by pressing the button ‘MAN’. With the push but-
tons ‘INTENSITY’, the brightness of the light source must be adjusted (average brightness), so that
the shutter can then adjust the brightness of the whole area with its control.
setting automatic mode
With standard cameras, therefore, for automatic brightness control through the light source, you
set the automatic mode by pressing the push button ‘AUTO’, and the green LED in the button then
lights up. When you switch on ‘AUTO’, the electronics will also automatically switch to an average
brightness from then on.
setting the brightness on the monitor screen in auto-mode
If the automatically set picture brightness is not sufficient, or if it is too bright, then brightness can
be adjusted brighter or darker by the push buttons ‘INTENSITY’, as with manual operation. When
the brightness diaphragm on the light source is completely open or completely closed, this will be
indicated by the yellow LED light in the brightness buttons.
remaining lamp life indicator
After the lamp has been ignited, the remaining lamp life indicator will also light up.
First of all it will execute a lamp-test, after that, one of the LED’s (either 500, 250, 100 or 50h) will
indicate the remaining life expectancy of the lamp.
If the recommended use of 500 hours has expired, this will be indicated by flashing of the red LED
(LAMP CHG). Then the lamp should be replaced with a new.

service manual Xenon XL-A100 / Xenon XL-M100
service manual / maintenance of the equipment page 11
6 service manual / maintenance of the equipment
general maintenance and repair advice
The instructions and information given in this chapter are only for instructed personnel, who are
aware of the safety precautions necessary for repair and maintenance of medical electronic de-
vices.
E.S.S., Inc refuse any liability for unauthorised repair and modification.
The manufacturer will provide those circuit diagrams, itemised parts listings, descriptions, sets of
adjustment instructions and other items of available documentation to suitably qualified user per-
sonnel duly authorised by the manufacturer for their use in repairing those components of the
equipment that have been designated by their respective manufactures as reparable.
Only the supply of such technical documentation relating to the equipment shall not be construed as
constituting manufacturer’s authorisation of user’s personnel, regardless of their levels of technical
training, to open or repair the equipment.
Explicitly exempted herefrom are those maintenance and repair operations described in this man-
ual.
6.1 possible causes / remedy
In any case of malfunction, you should check the wiring at first. Most errors are based on wrong
wiring.
The last column shows the referring chapter.
symptom possible cause remedy
equipment doesn’t work
main switch doesn’t
shining
line cable not connect connect line cable
main switch off turn main switch on
both line fuses defective check line fuses / exchange
wrong line voltage adjusted adjust right line voltage with fuse drawer
equipment doesn’t work
main switch shining
lamp after changing wrong connect check connector of the lamp
lamp defective change lamp
one line fuse defective check line fuses / exchange
internal fuse defective check internal fuse / exchange
ventilator blocked / defective check ventilator / exchange
wrong line voltage adjusted adjust right line voltage with fuse drawer
intensity regulation
doesn’t work
no signal on the video-in connector (only
Xenon XL-A100)
check video-in and connection
intensity regulation control board defective change intensity regulation control board
wrong light cable in adapter change light cable or adapter
lamp sends only a flash
light but doesn’t work
ventilator blocked / defective check ventilator / exchange
lamp life worn-out / exceed change lamp
power supply defective change power supply
clock doesn’t work cor-
rect (only Xenon XL-
A100)
clock control board defective change
6.2 selection of the line voltage setting
To set the correct voltage proceed as follows:
•PULL OUT THE MAINS PLUG!
•Using a small screwdriver or other sharp instruments, the black rectangular board above the
socket can be lifted out.
•The white panel with the fuse can be taken out and turned 180°, and then put back into the
fuse container.
•After that the rectangular fuse board can be put back (the small nose of the board facing
downwards) and firmly pressed until it has completely snapped in.
•Now the small white panel should show the correct voltage.
•

service manual Xenon XL-A100 / Xenon XL-M100
service manual / maintenance of the equipment page 12
6.3 exchanging the mains fuses
mains fuses are located on the rearpanel of the control unit, right above the mains terminal device
in a small drawer. If you need to exchange the mains fuses, proceed as follows:
•PULL OUT THE MAINS PLUG!
•Loosen the drawer by unfastening the two clamps located to the left and to the right of the
drawer with a peaked tool and pull out the drawer.
•Take out the fuses.
•Check the fuses. A blown fuse is indicated by the blackened glass cylinder or the visibly melted
fuse conductor. If necessary, check the fuse with an ohmmeter.
•Install the corresponding fuses.
•Re-install the fuse-drawer.
•Switch on the equipment again. If you have exchanged a defective fuse against a new one and the
fuse blows again, the unit has an error. In this case, you must return the device to your dealer for
testing and repair.
6.4 replacing the lamp
The only part subject to wastage in the equipment are the lamps. The manufacturer of the Xenon
lamp estimates the minimum life expectancy as 500 hours. After that, the quoted light wattage
reduces drastically and there may be difficulties in igniting. In order to secure safe operation of the
equipment, the lamp should be changed after expire of this operation time. The life time indicator
(only Xenon XL-A100) built into the appliance shows the remaining operating time for the lamp.
When the operating time has expired, the lamp must be changed for a new one.
Since the lamp used is a high pressure Xenon-lamp, whose small combustion chamber is high
pressure, so the bulb can explode if you handle it incorrectly (danger of glass splinters)!
The lamp may only be changed by qualified personnel, and following the prescribed safety pre-
cautions. Send, therefore, for the qualified person, when it is necessary to replace the lamp.
PULL OUT MAINS PLUG!
When handling the lamp, proceed with great care. It is absolutely necessary to observe the fol-
lowing precautions:
•When handling the lamp, protective goggles and gloves, which also protect the arteries, must
be worn!
•The lamp must be stored in the original packing, when outside the equipment, never left lying
around!
•Never interfere with the contacts, the electrodes or the electrode connections, or exert pressure
or stronger action on other parts of the lamp!
•Send back old burnt out lamps in the original packing to the supplier for disposal!
•Never throw used lamps into the rubbish: Dangerous for playing children or other innocent
parties, who may not be aware of the danger!
If you observe the safety precautions, there is absolutely no danger and you can proceed to easily
change the lamp in the following manner:
•Loosen the 5 screws. Take off the cover and place it beside the unit.
•Attention: If the machine has been operating shortly beforehand the lamp could be very hot.
•All remaining current in the electronics will be, in a few seconds after switching off the equip-
ment, completely safely discharged, so there is no danger in handling the equipment here.
•Disconnect the Xenon lamp connector plug.
•Loosen the knurled head screw and push up the lamp guard.
•Pull up the Xenon lamp out of its support.
•Push the new Xenon lamp into the same position in the support.
•Push down the lamp guard and tighten the knurled head screw.
•The Xenon lamp is thus automatically correctly adjusted.
•Re-connect the plug that is attached to the new Xenon lamp. You cannot mix up the connectors
due to its non-symmetric design.
•Reset the operating time indicator (only Xenon XL-A100) to 500 hours. This is done by simply
pushing the small slide-switch on the operating time indicator panel into opposite position.
•Re-install the cover and tighten it with the 5 screws. Observe the grounding cable!

service manual Xenon XL-A100 / Xenon XL-M100
service manual / maintenance of the equipment page 13
Further servicing, which should be done in conjunction with lamp replacement
After 500 hours operation, dust may have been sucked through the ventilator blades into the equip-
ment, depending on the conditions in the environment. This dust should be removed from the
equipment with a vacuum cleaner using a small nozzle attachment. Dust can sometimes cling quite
firmly to the ventilator blades. This should then be cleaned with a cloth and a little alcohol/spirits.
Likewise dust settles on the heat protective filter (with lens, optional), this should also be cleaned
with a soft cloth or blotting paper and pure alcohol or spirits.
6.5 cleaning / desinfecting
NOTE: PULL OUT THE MAINS PLUG!
All parts of the outer surfaces of the equipment are totally insensitive to all the usual cleaning and
disinfecting materials, so that you can use any of these without limitation. Apply liquids using a soft
cloth or soft blotting paper, in order to avoid scratches on the surfaces and in order to be able to
control the amount of liquid.
With flammable liquids like alcohol especially, you should apply with a cloth. Do not let any liquid get
into the equipment. After cleaning with flammable liquids, leave the equipment to dry for one hour,
before it is switched on again. There is danger for example that an alcohol-air explosive mixture
could form after cleansing.

service manual Xenon XL-A100 / Xenon XL-M100
spare parts page 14
7 technical data
mains connections
115/230VAC ±10%, 50/60Hz, 1,6/0,8A
main fuses
fuses 5x20 mm, 2 fuses, T 2,5/1,25A
video brightness control (only Xenon XL-A100)
adjusts automatically the monitor brightness from the video signal.
light guide connection
through an adapter, all lamp guides can be fitted to the equipment
lamp operating hours indicator (only Xenon XL-A100)
The remaining lamp life is indicated by LED in stages of 500, 250, 100, 50 hours. When the
time is expired this will be indicated by a flashing red LED.
mode of operation
•manual: The picture brightness can be made brighter or darker by using two push buttons.
•automatic (only Xenon XL-A100) Guided by the video signal, the monitor screen brightness
is controlled automatically.
lamp
Xenon-high pressure lamp, which is built into a reflector, so that when you change the lamp, no
resetting is necessary. The life expectancy amounts to 500 hours, the light spectrum is daylight
of about 5600 °K, the power input is nominally 100 watt.
protective class
BF (CF)
dimensions
W = 355 mm, H = 110 mm, D = 325 mm
weight
8,5 kg
8 spare parts
lamp
type XBO R 100 W/45C
fuses
fine fuses, 5x20 mm
•line voltage 230VAC = 2 pcs. fuse T 1,25A.
•line voltage 115VAC = 2 pcs. fuse T 2,5A.
frontpanel controller
power supply
starter
clock card (only Xenon XL-A100)

service manual Xenon XL-A100 / Xenon XL-M100
table ‘technical service-information’ page 15
9 table ‘technical service-information’
date check signature
