Essentials C60SHDX17 Service manual

60cm Cooker Hood
Installation / Instruction Manual
C60SHDX17
C60SHDX17_IB_RC_171121_grace.indd 1 21/11/17 3:52 pm

C60SHDX17_IB_RC_171121_grace.indd 2 21/11/17 3:52 pm

Contents
Safety Warnings...................................................................................................................................4
Unpacking............................................................................................................................................8
Product Overview................................................................................................................................9
The Main Unit.....................................................................................................................................................................9
Control Panel......................................................................................................................................................................9
Modes of Operation ..........................................................................................................................10
Air Extraction................................................................................................................................................................... 10
Air Recirculation............................................................................................................................................................. 10
Operation ...........................................................................................................................................10
To Select the Fan Motor Speed................................................................................................................................. 10
Cooker hood Lighting.................................................................................................................................................. 10
Cleaning and Maintenance...............................................................................................................11
Grease Filter (Washable Aluminium Filter)........................................................................................................... 12
Fitting and Replacing the Carbon Filter ................................................................................................................ 13
Changing the Internal Light ...................................................................................................................................... 14
Hints and Tips ....................................................................................................................................15
If cooker hood does not operate ............................................................................................................................. 15
Specications.....................................................................................................................................15
Product Fiche .....................................................................................................................................16
Installation .........................................................................................................................................17
Product Overview.......................................................................................................................................................... 17
Safety Distance Between Hob and Cooker hood............................................................................................... 18
Connection for Air Extraction ................................................................................................................................... 19
Mounting the Cooker hood....................................................................................................................................... 20
Extracted Air Installation..................................................................................................................20
Re-circulated Air Installation............................................................................................................23
C60SHDX17_IB_RC_171121_grace.indd 3 21/11/17 3:52 pm

4
Safety Warnings
• Pleasebecarefulwhenunpackingandinstallingthisapplianceassheetmetalandsharpmetal
edgescancauseinjuryifnothandledwithcare.
• Thisappliancecomplieswithallrelevantlocalandnationalsafetyrequirements.Inappropriateuse
can,however,leadtopersonalinjuryanddamagetoproperty.
• Toavoidtheriskofaccidentsanddamagetotheappliance,pleasereadtheseinstructionscarefully
beforeusingitforthersttime.Theycontainimportantinformationonthesafety,installation,use
andmaintenanceoftheappliance.
• Keeptheseinstructionsinasafeplaceandensurethatallusersarefamiliarwiththecontents.Pass
themontoanyfutureowneroftheappliance.
Correct application
• Thisapplianceisnotdesignedforcommercialuse.Itisintendedforuseindomestichouseholds.
• Itmustonlybeusedasadomesticappliancetoextractvapoursandremoveodoursfromcooking.
• Anyotherusageisnotsupportedbythemanufacturerandcouldbedangerous.
Themanufacturercannotbeheldliablefordamageresultingfromincorrectorimproperuseor
operationoftheappliance.
• Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswithreduced
physical,sensoryormentalcapabilitiesorlackofexperienceandknowledgeiftheyhavebeen
givensupervisionorinstructionconcerninguseoftheapplianceinasafewayandunderstandthe
hazardsinvolved.Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshall
notbemadebychildrenwithoutsupervision.Donotambéunderthecookerhood.
• Accessiblepartsmaybecomehotwhenusedwithcookingappliances.
• Ifthesuppliedcableisdamaged,itmustbereplacedbythemanufacturer,itsserviceagentor
similarlyqualiedpersonsinordertoavoidahazard.
Safety with children
• Thisapplianceisonlyintendedforusebyadultswhohavereadtheseinstructions.
• Thisapplianceisnotatoy!Toavoidtheriskofinjury,keepchildrenwellawayanddonotallow
themtoplaywithitortousethecontrols.Theywillnotunderstandthepotentialdangersposedby
it.Theyshouldbesupervisedwheneveryouareworkinginthekitchen.
• Olderchildrenmayusethecookerhoodonlywhenitsoperationhasbeenclearlyexplainedtothem
andtheyareabletouseitsafely,recognisingthedangersofmisuse.
Correct use
• Neveruseanopenamebeneaththecookerhood.Toavoidthedangerofre,donotambéor
grilloveranopenameunderthecookerhood.
• Whenswitchedon,thecookerhoodcoulddrawamesintothelter.Fatparticlesdrawnintothe
cookerhoodpresentarehazard.
C60SHDX17_IB_RC_171121_grace.indd 4 21/11/17 3:52 pm

5
• Whenusingthecookerhoodoveragashob,ensurethatanyburnersinusearealwayscoveredbya
pan.Switchthecookingzoneowhenapanisremoved,evenforashorttime.
• Regulatetheamesothatitdoesnotburnupthesidesofthepan.
• Donotallowthepanstooverheatexcessively(e.g.whenusingawok).
• Thecookerhoodcanbecomedamagedwhenexposedtoexcessiveheat.
• Alwaysswitchthecookerhoodonwhenacookingzoneisinuse,otherwisecondensationmay
collectinthehood,whichcouldcausecorrosion.
• Whencookingwithoilorfat,chippansanddeepfatfryersetc,donotleavethepansunattended.
Neverleaveanopengrillunattendedwhengrilling.Overheatedoilandfatcanigniteandcouldset
thecookerhoodonre.
• Donotusethecookerhoodwithouttheltersinplace.Thiswayyouwillavoidtheriskofacrylic
anddirtgettingintotheapplianceandhinderingitssmoothoperation.
• Theltersshouldberegularlycleanedorchangedasappropriate.Saturatedltersarearehazard.
See"CleaningandMaintenance".
• Thecookerhoodcangetveryhotduringcookingduetoheatrisingfromthehob.
Donottouchthehousingortheacrylicltersuntilthecookerhoodhascooleddown.
• Donotuseasteam-cleanertocleanthisappliance.Steamcouldreachtheelectricalcomponents
andcauseashortcircuit.
Technical safety
• Beforeinstallation,checkthecookerhoodforvisiblesignsofdamage.Undernocircumstances
shouldyouuseadamagedappliance.Itcouldbedangerous.
• Beforeconnectingtheappliancetothemainssupply,makesurethatthevoltageandfrequency
detailsgivenonthedataplatecorrespondwiththeon-siteelectricitysupply,otherwisethe
appliancecouldbedamaged.Consultaqualiedelectricianifinanydoubt.
• Theelectricalsafetyofthisappliancecanonlybeguaranteedwhencontinuityiscompletebetween
theapplianceandaneectiveearthingsystemcomplieswiththecurrentlocalandnationalsafety
regulations.Itismostimportantthatthisbasicsafetyrequirementispresentandtestedregularly,
andwherethereisanydoubt,thehouseholdwiringsystemshouldbeinspectedbyaqualied
electrician.Themanufacturercannotbeheldliablefortheconsequencesofaninadequateearthing
system(e.g.electricshock).
• Forsafetyreasons,thisappliancemayonlybeusedwhenithasbeenfullyinstalled.
• Onlyopenthehousingasdescribedintheinstructions.Undernocircumstancesshouldany
otherpartsofthehousingbeopened.Tamperingwithelectricalconnectionsorcomponentsand
mechanicalpartsishighlydangeroustotheuser,andcancauseoperationalfaults.
• Installation,maintenanceandrepairsmayonlybecarriedoutbyanauthorisedpersonin
accordancewiththecurrentnationalandlocalsafetyregulations.Repairsandotherworkby
unqualiedpersonscouldbedangerous.Themanufacturercannotbeheldliableforunauthorised
work.
• Faultycomponentsmustonlybereplacedbygenuineoriginalparts.
C60SHDX17_IB_RC_171121_grace.indd 5 21/11/17 3:52 pm

6
• Greatcareshouldbetakenwhenusingthecookerhoodatthesametimeandinthesameroom
orareaofthehouseasanotherheatingappliancewhichdependsontheairintheroom.Such
appliancesincludegas,oil,woodorcoal-redboilersandheaters,continuousoworotherwater
heaters,gashobs,cookersorovenswhichdrawairinfromtheroomandductexhaustgasesout
throughachimneyorextractionducting.
• Whenusedinextractionmode,theappliancedrawsairinfromtheroominwhichitisinstalled
andfromneighbouringrooms.
• Ifthereisinsucientair,anunderpressurewilloccur.Theheatingappliancemaybestarvedof
oxygen,impairingcombustion.
• Harmfulgasescouldbedrawnoutofthechimneyorextractionductingbackintotheroom,with
potentiallyfatalconsequences.
• Inordertoensuresafeoperation,andtopreventgasesgivenobytheheatingappliances
frombeingdrawnbackintotheroomwhenthecookerhoodandtheheaterareinoperation
simultaneously,anunderpressureof0.04mbar
(4pa)isthemaximumpermissibleintheroom.
• Duringinstallation,maintenanceandrepairwork,theappliancemustbedisconnectedfromthe
mainselectricitysupply.Itisonlycompletelyisolatedfromtheelectricitysupplywhen:
 –itisswitchedoattheisolator,or
 –themainsfuseisdisconnected,or
 –itisswitchedoatthewallsocketandtheplugwithdrawn,or
 –thefuseofthefusedspurconnectionunitiswithdrawn.
• Donotconnecttheappliancetothemainselectricitysupplybyamulti-socketunitoranextension
lead.Thesedonotguaranteetherequiredsafetyoftheappliance(e.g.dangerofoverheating).This
appliancemayonlybeusedinmobileinstallationsifariskassessmentoftheinstallationhasbeen
carriedoutbyasuitablyqualiedengineer.
• Inareaswhichmaybesubjecttoinfestationbycockroachesorothervermin,payparticular
attentiontokeepingtheapplianceanditssurroundingsinacleanconditionatalltimes.
Using at the same time as other heating
appliances that depend on the air from
the same room.
• Ventilationcanbemaintainedbyairinlets
whichmustnotbeblocked,inwindows,
doorsandoutsidewallvents,orbyother
technicalmeasures,suchasensuringthat
thecookerhoodcanonlybeswitchedon
whentheheatingapplianceisswitchedo
orviceversa.Aventilationbrickaloneisnot
generallysucienttoensuresafeventilation.
Warning
Dangeroftoxicfumes.
C60SHDX17_IB_RC_171121_grace.indd 6 21/11/17 3:52 pm

7
• Iftheonlywayofensuringadequateventilationisviaanopenwindow,awindowcontactswitch
shouldbettedtoensurethatthecookerhoodcanonlyoperatewhenthewindowisopened
suciently.Awindowcontactswitchkitisavailablefromgoodbuilders'merchants.Takecare
whenventilatingtheroomthroughanopenwindowthatventilationisnotimpairedbyaclosed
blindorcurtain.Ifthehoodisbeingoperatedinrecirculationmode,theaboverestrictionsdonot
apply.
Correct installation
• Refertothecookerorhobmanufacturer'sinstructionsastowhetheracookerhoodmaybe
operatedabovethecooker/hob.
• Theminimumsafedistancesbetweenthetopofthecookerorhobandthebottomofthecooker
hoodgivenintheInstallationsectionofthisbookletmustbemaintained,unlessthehob/cooker
manufacturerstatesthatagreatersafedistanceisrequired.
• Ifmorethanoneapplianceisttedbeneaththecookerhood,andtheyhavedierentminimum
safedistancestothecookerhood,selectthegreaterdistance.
• Safetyregulationsprohibitthettingofacookerhoodoversolidfuelstoves.
• Allducting,pipeworkandttingsmustbeofnon-ammablematerial.Thesecanbeobtainedfrom
builders'merchants.
• Theappliancemustnotbeconnectedtoachimneyorventuewhichisinuse.Neithershoulditbe
connectedtoductingwhichventilatesroomswithreplaces.
• Ifexhaustairistobeextractedintoachimneyorventilationductnolongerusedforother
purposes,seekprofessionaladvice.
Accessories
• Onlyusegenuineoriginalsparepartsandaccessorieswiththisappliance.
Theoverallventilationconditionofthedwellingmustbetakenintoaccount.Ifinany
doubt,theadviceofacompetentbuilderor,forgas,aqualiedgastter(GasSafe
registeredintheUK)mustbesought.
Ifinanydoubt,theadviceofaqualiedbuilder,gastter(GasSaferegisteredintheUK)or
electricianmustbesought.
Themanufacturercannotbeheldliablefordamagecausedbynon-compliancewiththese
WarningandSafetyinstructions.
C60SHDX17_IB_RC_171121_grace.indd 7 21/11/17 3:52 pm

8
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Nuts × 4Washer × 8
Drill Template
Air Outlet Adaptor × 1The Main Unit
4 × 35mm Screws × 4
Air Outlet Cover × 1
4 × 30mm Screws × 4
Plastic Wall Plug
Ф8×40mm × 4
Instruction / Installation manual
Instruction
Manual
Drill
Template
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational features it
oers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Steel Stick × 3
C60SHDX17_IB_RC_171121_grace.indd 8 21/11/17 3:52 pm

9
Product Overview
The Main Unit
Control Panel
1. Control Panel
2. Illumination
3. Aluminium Filter
1. Motor speed
selector
2. Lamp switch
1 2
1
3
2
C60SHDX17_IB_RC_171121_grace.indd 9 21/11/17 3:52 pm

10
Modes of Operation
Air Extraction
The air is drawn in and cleaned by the acrylic lters and directed outside.
The non-return ap supplied with the appliance must be tted in the
exhaust hole.
Having a non-return ap tted in the ducting ensures that air, once ducted
to the outside, cannot get back into the room again.
The ap is closed when the cooker hood is switched o.
When the cooker hood is switched on, the non-return ap opens for the
cooking vapours to be ducted away.
Operation
To Select the Fan Motor Speed
Your cooker hood has 3 levels of extraction. Depending on the cooking and frying vapours, you
should run the cooker hood with "1" low, "2" medium or "3" high speed. To run the cooker hood,
slide the motor speed selector to the desired extraction speed on the front panel.
Slide the motor speed selector to the "0" position to turn the unit o.
Air Recirculation
The air is drawn in and cleaned by a carbon lter (optional). The cleaned air
is then recirculated back into the kitchen through the recirculation vents in
the top of the cooker hood.
Cooker Hood Lighting
Slide the lamp switch to the on position ( 1 ) to switch the lamps on.
Slide the lamp switch to the o position ( 0 ) to switch the lamps o.
Ensure there is adequate ventilation in the room when the cooker hood is used at the
same time as other appliances burning gas or other fuels.
• Carbon lters are available as an optional extra, see rear page for ordering details.
• Before using the cooker hood in recirculation mode, ensure that the carbon lter is in
place. See“Cleaning and Maintenance”.
• Do not ambé under the cooker hood.
• CAUTION: Accessible parts may become hot when used with cooking appliances.
C60SHDX17_IB_RC_171121_grace.indd 10 21/11/17 3:52 pm

11
• All external surfaces and controls can be cleaned using a little washing-up liquid applied with a
soft sponge or cloth.
Cleaning and Maintenance
• Wipe dry using a soft cloth.
• Before any cleaning or maintenance work is carried out, disconnect the cooker hood
from the mains power supply. Ensure that it is switched o at the wall socket and the
plug is withdrawn.
• The surfaces and controls are susceptible to scratches and abrasions. Please observe
the following cleaning instructions.
Only use a damp cloth as water could get into the unit and cause damage.
Do not use:
• cleaning agents containing soda, acids, chlorides or solvents,
• abrasive cleaning agents, e.g. powder cleaners or cream cleaners and abrasive
sponges, as well as pot scourers or sponges which have been used previously with
abrasive cleaning agents as these will damage the surface material.
C60SHDX17_IB_RC_171121_grace.indd 11 21/11/17 3:52 pm

12
Grease Filter (Washable Aluminium Filter)
The re-usable metal grease lters in the appliance remove solid particles (grease, dust, etc.) from
the kitchen vapours, preventing soiling of the cooker hood.
The grease lters should be cleaned regularly (at least every 3-4 weeks).
1. To take out the grease lter, press the plastic
catch.
2. Pull the aluminium lter downwards.
Dirty lters are a re hazard.
• To avoid damaging the lters or the hob
below, make sure you hold the lters
securely at all times when handling them.
• Please be careful when replacing and
handling the lter as sheet metal and
sharp metal edges can cause injury if not
handled with care.
C60SHDX17_IB_RC_171121_grace.indd 12 21/11/17 3:52 pm

13
Fitting and Replacing the Carbon Filter
If the cooker hood is connected for recirculation, a carbon lter must be used.
2. Place the carbon lter at on the back of the aluminium lter. Take out the 3 steel sticks from
the packing. Secure the carbon lter in place with the 3 steel sticks. Insert the steel sticks into
the inner edge of the aluminium lter. You can bend the steel sticks to insert them into the
lter.
1. Remove the aluminium lter and place it securely on a at stable surface.
Carbon lters are available as an optional extra.
Replace the carbon lter when it no longer absorbs kitchen odours eectively. It
should, however, be replaced at least every 3 months to prevent a risk of re.
1
1
2
1
2
Steel Stick
Carbon Filter
Aluminium Filter
3. Replace the aluminium lter back to the unit.
C60SHDX17_IB_RC_171121_grace.indd 13 21/11/17 3:52 pm

14
Changing the Internal Light
Allow the cooker hood to cool for at least 30 minutes after use before changing the light bulb.
1. Press the plastic catch and take out the grease lter.
2. Unscrew the lamp cover.
3. Pull out the LED light box and you will nd a
connection box.
4. Disassemble the connection box and disconnect
the LED light box.
5. Replace with a new LED light box.
6. Screw the lamp cover and replace the grease lter.
Please be careful as sheet metal and sharp metal edges can cause injury if not handled
with care.
C60SHDX17_IB_RC_171121_grace.indd 14 21/11/17 3:52 pm

15
Hints and Tips
Problem Solution
Cooker hood does not operate
• Check Electric connection.
(The supply voltage should be 220-240 V)
• Check motor speed selector.
(Motor speed selector should be in position 1, 2 or 3)
Lamp does not light
• Check Electric connection.
(The supply voltage should be 220-240 V)
• Check lamp switch.
(Lamp switch should be in the on position)
• Check lamp bulbs.
Air suction of cooker hood is
weak
• Check acrylic lter.
(Acrylic lter should be replaced regularly (at least
every
3 months) under normal conditions)
• Check air outlet chimney.
(Air outlet chimney should be open)
• Check carbon lter.
(If it operating with a carbon lter, the carbon lter
should be replaced every 3 months)
If Cooker Hood Does Not Operate
Be sure that the mains plug is connected to the mains socket and the fuse in the installation is in
good condition. Check your cooker hood according to the above table. If the problem continues,
contact your retailer or an authorised service agent.
Specications
Model C60SHDX17
Rated Voltage 220-240V~
Rated Frequency 50 Hz
Rated Power 102.5 W
Extraction rate 192.4 m3/h
Lamp (E14) 1 x 2.5 W
Features and specications are subject to change without notice.
C60SHDX17_IB_RC_171121_grace.indd 15 21/11/17 3:52 pm

16
Product Fiche
Model no.: C60SHDX17
Symbol Value Unit
Annual Energy Consumption AEChood 58.7 kWh/a
Time increase factor f 1.8
Fluid Dynamic Eciency FDEhood 6.6
Fluid Dynamic Eciency class F
Energy Eciency Index EEIhood 91.3
Energy Eciency class D
Measured airow rate at the best eciency QBEP 100.5 m3/h
Measured air pressure at best eciency point PBEP 206 Pa
Maximum airow Qmax 192.4 m3/h
Air ow at working point (highest setting) 187.7 m3/h
Air ow at working point (lowest setting) 137.6 m3/h
Measured electric power input at best eciency point WBEP 86.6 W
Nominal power of the lighting system WL2.5 W
Average illumination of the lighting system on the cooking
surface Emiddle 86 lux
Lighting Eciency LEhood 34.4 lux/w
Lighting eciency class A
Grease Filtering Eciency (%) GFEhood 71.8
Grease Filtering Eciency (GFE hood ) class D
Measured power consumption on standby mode PS- W
Measured power consumption on o mode PO0 W
Sound power level LWA 68 dB
The above table indicate the information for the cooker hood. The test result is done as per the
relevant requirement of EU No 65/2014 and EU No 66 / 2014.
C60SHDX17_IB_RC_171121_grace.indd 16 21/11/17 3:52 pm

17
Installation
Product Overview
125 mm
600 mm
430 mm
500 mm
45 mm
360 mm
220 mm
600 mm
460 mm
135 mm
600mm
500mm
135mm
Please be careful when unpacking and installing this appliance as sheet metal and
sharp metal edges can cause injury if not handled with care.
C60SHDX17_IB_RC_171121_grace.indd 17 21/11/17 3:52 pm

18
Safety Distance Between Hob and Cooker hood
Min.700 mm
• Account should also be taken of the height of the person who will be using the hood most
often. The person should have sucient space to work comfortably at the hob, and also be
able to reach the hood controls with ease.
• Please be aware that if positioned too high, extraction will be inecient.
When planning the installation height of your cooker hood, the minimum safe
distance between the top of a cooker or hob and the bottom of the cooker hood is
700mm.
C60SHDX17_IB_RC_171121_grace.indd 18 21/11/17 3:52 pm

19
Connection for Air Extraction
Only use smooth pipes or exible hoses made from non-ammable materials for the extraction
ducting.
To achieve the greatest possible air extraction with the lowest noise level, please note the
following:
• To ensure ecient air extraction, the diameter of the exhaust ducting should not be less than
120mm.
• If at ducting is being used, the cross-sectional area must not be smaller than the cross
sectional area of the exhaust connection.
• All ducting, pipework and ttings must be made of non-ammable materials.
• The exhaust ducting should be as short and straight as possible.
• Only use wide radius bends.
• The exhaust ducting should not be kinked or compressed.
• Ensure that all connections are strong and airtight.
• Where ducting is horizontal, it must be laid to slope away at least 1cm per metre. This is to
ensure that condensate cannot drain back into the cooker hood.
• To avoid the danger of toxic fumes, please observe the safety warnings.
• This is especially crucial when using the cooker hood at the same time as another
heating appliance which relies on air from the same room.
• The cooker hood should be installed according to the local and national building
regulations. Seek approval from the building inspector where necessary.
If the exhaust ducting is to run through rooms, ceiling space etc. where there may
be great variations in temperature between the different areas, the problem of
condensation will need to be addressed. The exhaust ducting will need to be suitably
insulated.
C60SHDX17_IB_RC_171121_grace.indd 19 21/11/17 3:52 pm

20
Or top mounted by tting it to the underside
of a kitchen cupboard, as shown in the picture
opposite.
Min
140mm
Mounting the Cooker hood
The cooker hood can be rear mounted by tting
it to an open area of kitchen wall, as shown in
the picture opposite.
Extracted Air Installation
If you are tting the unit to an outside wall you need the following items:
• A minimum of 500mm of exible ducting, 120 mm in diameter.
• An external cooker hood.
1. There is a‘valve’ inside the cooker hood, which diverts the air so that it leaves through one of
the exhaust holes. Turn the valve lever download to position E, as shown in the picture A.
Min
650 - 750mm
R
E
A B
C60SHDX17_IB_RC_171121_grace.indd 20 21/11/17 3:52 pm
