Euromaid UCB52S User manual

User Manual
UCB52S - 52cm Stainless Steel Undermount
UCB85S - 85cm Stainless Steel Undermount

2
Content
1…………………………………..………………………………Safety instructions
2…………………………………..………………………………Installation
3…………………………………..………………………………Start using your Rangehood
4…………………………………..………………………………Troubleshooting
5…………………………………..………………………………Maintenance and cleaning
6…………………………………..………………………………Environment protection

3
SAFETY INSTRUCTIONS
This manual explains the proper installation and use of your Rangehood, please read it
carefully before using even if you are familiar with the product. The manual should be kept in a
safe place for future reference.
These instructions shall also be available in an alternative format, e.g. on a website.
Do not do the following:
●Do not try to use the Rangehood without
the grease filters or if the filters are
excessively greasy!
●Do not install above a cooker with a high
level grill.
●Do not leave frying pans unattended
during use because overheated fats or
oils might catch fire.
●Never leave naked flames under the
Rangehood.
●If the Rangehood is damaged, do not
attempt to use.
●Do not flambé under the Rangehood.
●CAUTION: Accessible parts may become
hot when used with cooking appliances.
●The minimum distance between the
supporting surface for the cooking vessels
on the hob and the lowest part of the
Rangehood. (When the Rangehood is
located above a gas appliance, this
distance shall be at least 65 cm)
●The air must not be discharged into a flue
that is used for exhausting fumes from
appliances burning gas or other fuels.
Things to always do:
●Important! Always switch off the electricity
supply at the mains during installation and
maintenance such as light bulb
replacement.
●The Rangehood must be installed in
accordance with the installation
instructions and all measurements
followed.
●All installation work must be carried out by
a competent person or qualified
electrician.
●Please dispose of the packing material
carefully. Children are vulnerable to it.
●Pay attention to the sharp edges inside the
Rangehood especially during installation
and cleaning.
●When the Rangehood is located above a
gas appliance, the minimum distance
between the supporting surface for the
cooking vessels on the hob and the lowest
part of the Rangehood that distance must
be:
Gas cookers: 65 cm
Electric cookers: 65 cm
Coal or oil cookers: 75 cm
●Make sure the ducting has no bends
sharper than 90 degrees as this will
reduce the efficiency of the Rangehood.
●Warning: Failure to install the screws or
fixing device in accordance with these
instructions may result in electrical
hazards
●Warning: Before obtaining access to
terminals, all supply circuits must be
disconnected.
Things to always do:
●Always put lids on pots and pans when
cooking on a gas cooker.
●When in extraction mode, air in the room is
being removed by the Rangehood. Please
make sure that proper ventilation
measures are being observed. The
Rangehood removes odours from room
but not steam.
●Rangehood is for domestic use only.
●If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in
order to avoid a hazard.

4
●This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use
of the appliance by a person responsible
for their safety.
- Children should be supervised to ensure
that they do not play with the appliance.
Warning: Before obtaining access
to terminals, all supply circuits must
be disconnected.
Things to always do:
●Caution: The appliance and its accessible
parts can become hot during operation.
Be careful to avoid touching the heating
elements. Children younger than 8 years
old should stay away unless they are
under permanent supervision.
●There shall be adequate ventilation of the
room when the range hood is used at the
same time as appliances burning gas or
other fuels.
●There is a fire risk if cleaning is not carried
out in accordance with the instructions
●Regulations concerning the discharge of
air have to be fulfilled.
●Clean your appliance periodically by
following the method given in the chapter
MAINTENANCE.
●For safety reason, please use only the
same size of fixing or mounting screw
which are recommended in this instruction
manual.
●Regarding the details about the method
and frequency of cleaning, please refer to
maintenance and cleaning section in the
instruction manual.
●Cleaning and user maintenance shall not
be made by children without supervision.
●When the range hood and appliances
supplied with energy other than electricity
are simultaneously in operation, the
negative pressure in the room must not
exceed 4 Pa (4 x 10-5 bar).
●WARNING: Danger of fire: do not store
items on the cooking surfaces.
●A steam cleaner is not to be used.
●NEVER try to extinguish a fire with water,
but switch off the appliance and then
cover flame e.g. with a lid or a fire blanket.
INSTALLATION (VENT OUTSIDE)
1. The cooker hood should be placed at a distance of 65~75cm above the cooking surface for
best effect.
2. Drill a hole in the cupbpard, please refer to pic below for the hole wide. Make sure the hole
edge to the cupboard edge at least 35mm distance.

5
3. Put the hood into the cupboard, tighten up the screws by screwdriver, and make sure the
hood was fixed.
4. Install the expansion pipe:Dress the expansion pipe onto the outlet and tie it tight with cable
tie,then lead it to outdoor.

6
WARNING: For safety reason, please use only the same size of fixing
or mounting screw which are recommended in this
instruction manual.
Failure to install the screws or fixing device in accordance
with these instructions may result in electrical hazards.

7
Start Using Your Rangehood
Electronic button
1. Power on: Press power button one time, its indicator light will be lit, the hood works at low
speed, indicator light of low speed will be bright
Power off: Press power button again to close it, indicator light will off. All the function
operation of the hood will be closed, the hood enters into standby mode.
2. Light: Press the button “Light”, both lights start shining. Press the button again, the lights
are switched off. The speed buttons and light button can work separately and not
controlled by the power button.
3. Low speed: Press the button “Low”, the inner indicator light of switch starts shining, the
motor is running at low speed. Press the button again, the motor stops.
4. Mid speed: Press the button “Mid”, the inner indicator light of switch starts shining, the
motor is running at medium speed. Press the button again, the motor stops.
5. Hight speed: Press the button “High”, the inner indicator light of switch starts shining, the
motor is running at high speed. Press the button again, the motor stops.

8
TROUBLESHOOTING
Fault Possible Cause Solution
Light on, but motor
does not work
Fan switch turned off Select a fan switch position.
Fan switch failed Contact service center.
Motor failed Contact service center.
Light does not work,
motor does not work
House fuses blown Reset/Replace fuses.
Power cord loose or disconnected Refit cord to power outlet.
Switch power outlet on.
Lights not working
Insufficient suction
Broken/Faulty globes Replace globes as per this
instruction.
The distance between the
Rangehood and the gas top is too
fa
r
Refit the range hood to the correct
distance.
The Rangehood
inclines The fixing screw not tight enough Tighten the hanging screw and make it horizontal.
NOTE:
Any electrical repairs to this appliance must conform to your local, state and federal
laws. Please contact the service centre if in any doubt before undertaking any of the
above. Always disconnect the unit from the power source when opening the unit.
MAINTENANCE AND CLEANING
Caution:
• Before maintenance or cleaning is carried out, the Rangehood
should be disconnected from the main power supply. Ensure that the
Rangehood is switched off at the wall socket and the plug removed.
• External surfaces are susceptible to scratches and abrasions, so please
follow the cleaning instructions to ensure the best possible result is
achieved without damage.
GENERAL
Cleaning and maintenance should be carried out with the appliance cold especially when cleaning.
Avoid leaving alkaline or acid substances (lemon juice, vinegar etc.) on the surfaces.
STAINLESS STEEL
The stainless steel must be cleaned regularly (e.g. weekly) to ensure long life expectancy. Dry with
a clean soft cloth. A specialised stainless-steel cleaning fluid may be used.
NOTE:
Ensure that wiping is done along with the grain of the stainless steel to prevent any unsightly
crisscross scratching patterns from appearing.
CONTROL PANEL SURFACE
The inlay control panel can be cleaned using warm soapy water. Ensure the cloth is clean and well
wrung before cleaning. Use a dry soft cloth to remove any excess moisture left after cleaning.

9
Important
Using neutral detergents and avoid using harsh cleaning chemicals, strong household detergents or
products containing abrasives, as this will affect the appliance appearance and potentially remove
any printing of artwork on the control panel and will void manufactures warrantee.
GREASE MESH FILTERS
The mesh filters can be cleaned by hand. Soak them for about 3 minutes in water with a grease-
loosening detergent then brush it gently with a soft brush. Please do not apply too much pressure,
avoid to damage it. (Leave to dry naturally out of direct sun light)
Filters should be washed separately to crockery and kitchen utensils. it is advisable not to use rinse
aid.
INSTALLING GREASE MESH FILTERS
• To install filters for the following four steps.
- Angle the filter into slots at the back of the hood.
- Push the button on handle of the filter.
- Release the handle once the filter fits into a resting position.
- Repeat to install all filters.
NOTE:
Make sure the filter is securely locked. Otherwise, it would loosen and cause dangerous.
When activated carbon filter attached, the suction power will be lowered.
BULB REPLACEMENT
Important: The bulb must be replaced by the manufacturer, its service agent or
similarly qualified persons.
Always switch off the electricity supply before carrying out any
operations on the appliance. When handling bulb, make sure it is
completely cool down before any direct contact to hands.
When handling globes hold with a cloth or gloves to ensure
perspiration does not come in contact with the globe as this can
reduce the life of the globe.
Change the LED light
1. Switch off the appliance and unplug it.
2. Unscrew the 4 screws on the panel and 2 screws in the two sides of lamp plate by screwdriver.
3. Pull out the light wire, and take down the lamp plate assembly.
4. Unscrew the 4 screws on the light bracket and replace the light

10
5. Connect the light wire and assemble the panel by screw. See pic below.
• ILCOS D code for this lamp is: DSL-4-S-350 (52cm); DSL-7-S-650(85cm)
– Max wattage: 4W(52cm);7 W(85cm)
– Voltage range: DC 12V

11
ENVIRONMENTAL PROTECTION:
This product is marked with the symbol on the selective sorting of waste
electronic equipment. This means that this product must not be disposed of
with household waste but must be supported by a system of selective
collection in accordance with Directive 2012/19/EU. It will then be recycled
or dismantled to minimize impacts on the environment, electrical and
electronic products are potentially dangerous for the environment and
human health due to the presence of hazardous substances. For more
information, please contact your local or regional authorities.
NOTE:
The following shows how to reduce total environmental impact (e.g. energy use) of the cooking
process).
(1) Install the Rangehood in a proper place where there is efficient ventilation.
(2) Clean the Rangehood regularly so as not to block the airway.
(3) Remember to switch off the Rangehood light after cooking.
(4) Remember to switch off the Rangehood after cooking.
INFORMATION FOR DISMANTLING
Do not dismantle the appliance in a way which is not shown in the user manual. The appliance
could not be dismantled by user. At the end of life, the appliance should not be disposed of with
household waste. Check with you Local Authority or retainer for recycling advice.

12
MANUFACTURER GUARANTEE
This warranty is provided in Australia by Glen Dimplex Australia Pty Limited ABN 69 118
275 460 (Phone number 1300 556 816) and in New Zealand by Glen Dimplex New
Zealand Limited ACN 9429000069823 (Phone number 09 274 8265) in respect of the
Euromaid product.
1. Euromaid Express Warranty
Subject to the exclusions below, we warrant that the product will not have any electrical or
mechanical breakdowns within:
a) In the case of Euromaid products used for personal, domestic or household purposes, a period
of 2years from the date the product is purchased as a brand-new product from a retailer located
in Australia / New Zealand.
b) In the case of Euromaid products used for purposes other than personal, domestic or household
purposes (including business or commercial use), a period of 90 days from the date the product
is purchased as a brand-new product from a retailer located in Australia / New Zealand.
Euromaid products are designed and intended for domestic use only; and
c) All warranty repairs must be carried out by Glen Dimplex or their nominated service agent
Note: warranty periods detailed above may vary in line with agreements with select
retail and builder partners and may differ between Australia and New Zealand.
The benefits conferred by this express warranty are in addition to the Consumer
Guarantees referred to in section 3 and any other statutory rights you may have under the
Australian / New Zealand Consumer Law and/or other applicable laws.
2. Warranty exclusions
This express warranty does not apply where:
a) The product has been installed, used or operated otherwise than in accordance with the product
manual or other similar documentation provided to you with the product;
b) The product requires repairs due to damage resulting from accident, misuse, incorrect
installation, insect or vermin infestation, improper liquid spillage, cleaning or maintenance,
unauthorised modification, use on an incorrect voltage, power surges and dips, voltage supply
problems, tampering or unauthorised repairs by any persons, use of defective or incompatible
accessories or exposure to abnormally corrosive conditions, events independent of human
control which occurred after the goods left the control of Glen Dimplex;

13
c) The repair relates to the replacement of consumable parts such as fuses and bulbs or any other
parts of the product which require routine replacement;
d) You are unable to provide us with reasonable proof of purchase for the product;
e) the breakdown occurs after the expiry of the express warranty period set out in section 1 or
f) the product was not purchased in Australia / New Zealand as a brand-new product.
3. Consumer guarantees
Our goods come with guarantees that cannot be excluded under the Australian / New
Zealand Consumer Law. You are entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
4. How to make a claim
You may make a claim under this warranty through our website, contacting our customer
care line or via email. Contact details for Glen Dimplex Australia and New Zealand can be
found at the end of this document
To make a valid claim under this warranty, you must:
a) Lodge the claim with us as soon as possible and no later than 14 days after you first become
aware of the breakdown;
b) Provide us with the product serial number;
c) Provide us with reasonable proof of purchase for the product. This can take the form of a store
receipt, new home handover form or other payment receipt documentation; and
d) If required by us, provide us (or any person nominated by us) with access to the premises at
which the product is located at times nominated by us (so that we can inspect the product).

14
5. Warranty claims
If you make a valid claim under this warranty and none of the exclusions set out in section 2
apply, we will, at our election, either repair the product or replace the product with a product
of identical specification (or where the product is superseded or no longer in stock, with a
product of as close a specification as possible).
Goods presented for repair may be replaced by refurbished goods of the same type rather
than being repaired. Refurbished parts may be used to repair the goods.
Products are designed and supplied for normal domestic use. We will not be liable to you
under this warranty for business loss or damage of any kind whatsoever.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
www.glendimplex.com.au www.glendimplex.co.nz
Australia New Zealand
Ph: 1300 556 816 Ph: 09 274 8265
[e-mail] [email protected]

NOTES
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________

15
READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING THE APPLIANCE.
The manufacturer will not be responsible for any damage to property or to persons caused by
incorrect installation or improper use of the appliance.
The manufacturer is not responsible for any inaccuracies, due to printing or transcription errors,
contained in this manual. In addition, the appearance of the figures reported is also purely
indicative.
The manufacturer reserves the right to make changes to its products when considered necessary
and useful, without affecting the essential safety and operating characteristics.
Glen Dimplex constantly seeks ways to improve the specifications and designs of their products.
Whilst every effort is made to produce up to date literature, this document should not be regarded
as an infallible guide. Actual product only should be used to derive cut out sizes.
All appliances must be installed by a qualified person/s with adherence to the relevant electrical,
plumbing and building codes, with compliance being issued as required by state or national
legislation.
Additionally, all upright cookers must have the anti-tilt device installed correctly in adherence to the
relevant standards by a licenced installer.
For maximum effectiveness and efficiency all rangehoods should be installed with the use of
ductwork, by a licenced installer with adherence to the relevant state and national building codes
and regulations.
All Glen Dimplex appliances are for Domestic use only, and must be installed by a licence installer
into Domestic Applications only, without exception and to the required Authorities guidelines. Any
installation outside of this will VOID warranty. Alfresco areas are not a Domestic application.
Distributed by:
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
www.glendimplex.com.au www.glendimplex.co.nz
For service advice, please contact the Customer Care Centre by phone or email below.
Australia New Zealand
Ph: 1300 556 816 Ph: 09 274 8265
[email protected] [email protected]
VERSION 1 REVISION 20191209
