Estuff Glowsound1 User manual

GlowSound1 Bluetooth speaker

Instruction Manual

SAFETY PRECAUTIONS

Read all the instructions carefully before using.

Check that the voltage marked on the rating label matches your mains voltage.

The speaker should not be taken apart or modified.

Do not place the speaker in constant sunlight or near naked flames such as wood stoves, lit candles, etc.

Never subject the speaker to high temperatures, damp or dusty environments, heavy vibration, or impacts.

Protect your hearing. Listening on high volume for prolonged periods can lead to permanent hearing loss.

The speaker must only be repaired by qualified service technicians,

This speaker is splash proof. Do not submerge under water, doing so will result in permanent damage.

Do not expose the speaker to water while charging.

SPECIFICATION

Input: DC5V/1A Speaker output: 5W

Driver: 1 x 2.5’’ Battery: 2200mAh

Material: plastic, PU leather h andle Bluetooth Operating frequency: 2402-2480MHz

1: Power on/off 2: USB charge port

3:USB player 4: AUX Po rt

Accessories

1 x Bluetooth speaker, 1 x Micro USB-cable, 1x remote control, 1 x User manual

Compatibility

This p roduct is compatible with Bluetooth enabled mobile phones and devices.

Charge

1. Con nect speaker with PC/Laptop/Mac or any 5V USB adapter (not included) by the USB cable included.

2. Red LED turns ON duringcharging, turns OFF after fully charged.

3. Unp lug USB cable after fully charged.

4. Red LED twinkles when low power (<21%), with a warning sound.

Turning ON/OFF

Hold the p ower button for approx. 2 seconds to turn on, you would hear a starting chime.

Hold it again for approx. 2 seconds to turn off.

Pairing

1. Turn o n the speaker to be ready for pairing. After 3-4 seconds, you wo uld hear a chimed Bluetooth sound.

2. Activate the Bluetooth function on your mo bi le p hone o r any Bluetooth devices, search the speaker and select the

name “GlowSound1”, and connect the speaker with the device via Bluetooth pairing

3. The Bluetooth soundis chimed once more after p aired.

Note:

1. Keep the range of 1 meter wh en pairing. If the pairing was not successful,turn off th espeaker and re-pair again.

2. After successful pairing, paired devices will remembereach other so there is no need to pair again unless pairing

information is deleted.

3. To pair with a new device, fo llowsteps 1-3 above after d isconnected from existing device.

TWS (True Wireless Stereo) Function: to pairone mobile phone with 2 speakers together

1. Make sure you have 2 GlowSound1 speakers at your hand,turn on both sp eakers together, then quickly double

click “Power” button s of bo th speakers, both speakers will into pairing mode to pair with each other first.

2. Wait for aro und 5-10 seconds until two speakers “beep” o nce in sequence, which means both speakers paired with

each oth er already.

3. Then, activate Bluetooth function of your device and pair with Bluetooth name GlowSound1. You would enjoy

music in True Wireless Stereo sound from two speakers simultaneously.

Warm notes:

1. You can only enjoy TWS function when you have 2 ES652800 speakers.

2. If you want to disconnect existingTWS connection, double click “Power” button of either speaker, the sub-speaker

will d isconnect, the host speaker will keep playing music.

3. If you want to establish TWS connection with 2nd speaker after your device connected with o ne speaker already,

please lo ng press” power “button to disconnect from your existingpaired device, then follow above steps 1-3.

Operation by remote control (please remove the plastic tab from the battery coverbefore use).

1.Standby: press to into/out of Standby mode afterpoweringon the speaker.

2.Change brightness.

3.Switch on/off the light.

4. Switch to Bluetooth mode.

5. Go to selected single color directly.

6. Repeatedly press it to change colors in a loop.

7. Switch light to Flash mode(Beats to music).

8. Switch light to Smooth mode(Breathing light slowly change colors)

9. Switch to white color directly.

10. Go to previous/next track (not workable under AUX mode).

13. Play and Pause.

14.Voice - and +

15. Switch to AUX or USB-play mode.

Notes:

1. Above operations andsequence based onfactory default setting.

2. Speaker memorizes previous lighting status before turn-off, when you turn it on again, it will display the same lighting

mode/color/brightness.

Warm notes 2:

3. Above operations and sequence based on factory default setting.

4. Speaker memorizes previous lighting status before turn-off, when you turn it o n again, it will display the same

lighting mode/color/brightness.

AUX connection

1. Con nect the AUX cable (not included) to th e AUX jack.

2. Insert the other end of the cable into the headphone or LINEOUT jack of the external device.

“W aste electr ical products should not be disposed of with household waste. All electr onic products wi th the W EEE log o m ust be collected and sent

to appr oved operators for safe disposal or recycling . Pl ease recycle where faciliti es exist. Many electrical/electr onic eq uipm ent r etailer s facili tate "Distributor

Take-Back scheme" of househol d W EEE. Check with your Local Authority or retailer s for Desig nated Coll ecti on Facilities (D CF) where consumer s may
