Euphoria XPERT EXW10NCF User manual

USER MANUAL
TM
NEOD Y M I UM S E R I E S
EXW10NCF
EXW8NCF
NEO Carbon FiberSubwoofer

EXW10NCF 42.81Hz 3.2Ω+3.2Ω 2.708mH 0.502 0.424 10.893L 63.944 mm/N 27.216 216.112gr 84.2dB 28mm
EXW10NCF 10” / 254mm 2500 Watts 1250 Watts 3.2Ω+3.2Ω
32
PRODUCT SPECIFICATIONS
PRODUCT FEATURES
Introduction
Congratulations on your purchase of a Euphoria™ state-of-the-art subwoofer. Your selection of a
Euphoria™Car Audio product indicates a true appreciation of fine musical reproduction. Whether adding
to an existing system or including your Euphoria™ Subwoofer in a new system, you are certain to
notice immediate performance benefits.
Product Commitment
DB’s engineering professionals harnessed years of expertise, experience and passion, coupled
with exhaustive testing and creative design to develop the optimal product and performance for
your musical enjoyment. This is our commitment to you. It’s what you deserve and have come to
expect from Euphoria™. We appreciate the confidence and look forward to your positive experience.
Keep Your Sales Receipt
Take this time to attach your sales receipt to the manual and put in a safe place. In case of any
unforeseen reason this product may need warranty service, your receipt will be necessary to
establish purchase date.
Recommendation
A power subwoofer’s performance is only as good as its installation. Proper installation will
maximizethe system’s overallperformance.Itisrecommendedthatyou haveour product installed
by an authorized Euphoria™retailer. However, if you decide to install it yourself, please carefully read
through this manual and take your time to doa quality installation.
Optimal Product Choice
To get the Maximum performance out of your stereo system, we recommend using 100%
authentic Euphoria™ electronics and DB LINK wiring and accessories. Matching Euphoria amplifiers
and Speakers with your state-of the art electronics purchase is critical to optimize your system’s
performance. Wiring is the lifeblood of a system, make sure your audio system has the adequate
current and signal transfer it deserves and needs. DB Link has it all, from wiring rolls; Speaker,
power, ground and remote to amplifier kits, RCAs, and Fuse holders, distribution blocks and
battery connectors. Insist on getting the best, DB LINK. It’s what you deserve to get the optimum
performance from your audio System.
IMPORTANT!
Before making any connections, disconnect thecar’s battery until the installation is
completed to avoid possible damage to the electrical system.
WARNING!
Exposure to high power sound system can cause hearling loss or damange. Listenin
to your system at loud levels while driving will impair your ability to hear traffic sounds
and emergency vehicles. Use common sense when listening to your system.
____________________________________#laireS ___________________________________#ledoM
MODEL
EXW8NCF
STRUCTURE
8” / 203mm
MAX POWER
2000 Watts
NOMINAL POWER
1000 Watts
IMPEDANCE
MODEL
EXW8NCF
FS
52Hz
RE QMS
43.53mH
QES
.59
QTS
0.52
VAS
4.4L
CMS
67.7 mm/N
BL
11
MMS
137gr
SPL
82.1dB
X-MAX
20mm
• 2" Voice Coil (EXW8NCF) / 2.5" (EXW10NCF)
• Die-Cast Aluminum Basket
with Radial Venting
• Large Gauge Compression Terminals
• Rubber Surround
• Carbon Fiber Cone
• Neodymium Magnet
• Weather Resistant Cone
and Surround
+

54
FRAME DIAMETER MOUNTING DEPTH
CUTOUT DIAMETER
EXW8NCF
MODEL
8.76” / 222.56mm5.41" / 137.5mm 7.17" / 182.31mm
EXW10NCF 10.98” / 278.98mm 6.25" / 159.30mm9.16" / 232.86mm
Frame Diameter
Mounting Depth
Cutout Diameter
A
ABC
B
C
The purpose of the information below is to help you select the most appropriate type of enclosure for your
application. We have selected the two most popular enclosure types and their performance benefits.
Sealed Enclosure (Air-Suspension design): Characteristically simpler to make, sealed enclosures usually are
better at controlling the woofer’s excursion and performance at lower frequencies. The added control allows
for higher power handling or use of a bigger amplifier. The secret is to maintain a perfect seal. Using Glues
and sealants at all seams is recommended to prevent leaks and integrity of the enclosure. The size or volume
of the enclosure will directly affect the performance of the woofer. Smaller enclosures generally provide the
desired bump to the frequency response curb and Greater SPL. Larger enclosures will provide a lower but
flatter response for deeper bass. In general, the benefit to the sealed enclosure versus a ported enclosure
is a smaller foot print, simpler build with higher power handling, a more linear flat response, superior sound
quality and extended low frequency output.
Ported Enclosure (Bass-Reflex or Vented): A ported enclosure is simply a sealed enclosure with a port or
vent added to the sealed design for the purpose of tuning the enclosure to higher output at the desired
tuned frequency, typically 3db or higher. Another advantage of a ported enclosure is the reduction of cone
motion for the speaker, thus distortion at higher power levels within the tuned frequency response of the
port. A drawback is that building a ported enclosure is more complex than sealed. Having the wrong port or
vent could result in poor sound, and the potential of damaging a woofer when played too loud or out of the
tuning frequency. Thus we recommend not guessing, please follow the guidelineslisted in this manual or go
to a professional. In General, the benefit of a ported enclosure versus a sealed is higher volume output at the
tuned frequency, stronger bass output with lower power input.
Construction: We recommend using ¾” MDF (Medium Density Fiberboard) for the construction of an
enclosure. It is critical for the side walls of the enclosure not to flex due to the pressure generated by the
woofer, bracing might be required. The enclosure sides should be secured together with nails/screwed. We
also recommend the use of glues and sealants to maintain the integrity of the enclosure and eliminate leaks.
B
A
It is difficult to give exactbox dimensions that areuniversal for all cars and trucks. It is for this
reason that you mustbe able to calculate thespace in which you haveavailable in order to achieve
the proper air volume required.
It is recommended to build your enclosure from 3/ 4” thick MDF (medium density fiberboard).
Make sure the enclosure is sealed airtight.
Calculating External Volume
To calculate box volume, measure the outside Width x Height xDepth of
the enclosure. Example12” x 14” x 9”=1512 ÷1728” Cubic feet
Nextyou must convert cubic inches into cubic feet. To do this, you must
divide the cubic inches total by 1728”. Example 1512 ÷ 1828=.875 Cubic feet
Calculating Internal Volume
To calculate the internal (net) volume of the above boxyou must first multiply
the thickness of the wood you are using by Two(2). Example 3/4” x 2= 1.5“
Nextsubtract 1.5 from each of the outside measurements ofthe box.
Width
Height Depth
12 - 1.5 = 10.5 14 - 1.5 = 12.5 9 - 1.5 = 7.5
C
Sealed
Vented
7.17 in.
(182.31mm)
5.41 in.
(137.49mm)
0.44 cuft.
(12.459 L)
0.86 cuft.
(24.352 L)
8.29 sq in
(53.48 cm2)
20 in.
(50.8 cm)
36Hz
1000 Watts
2000 Watts
9.16 in.
(232.86mm)
6.25 in.
(159.30mm)
0.70 cuft.
(19.82 L)
0.96 cuft.
(27.18 L)
10 sq in
(64.51 cm2)
24 in.
(61 cm)
35Hz
1250 Watts
2500 Watts
ENCLOSURES
Woofer Cutout
Mounting Depth
Sealed Box
Vented Box
Vent Area
Vent Length
Tuning
Dynamic Power
Nominal Power
Multiple the new totals (H x W x D) Example: 10.5 x 12.5 x 7.5 = .5696 Next you must convert cubic
divide the cubic inch total by 1728”.
Example 984.375 ÷ 1728=.5696 cubic feet.
inches into cubic feet. To do this, you must
PRODUCT DIMENSIONS
RECOMMENDED ENCLOSURE
RECOMMENDED ENCLOSURE
CALCULATING ENCLOSURES
EXW8NCF EXW10NCF

7
You can change the wiring configuration of your speakers (Series, Parallel and Series / Parallel)
to match the impedance loads that maximizes the power output of you amplifier. Wiring the
same woofer or multiple woofers in these three different wiring configurations will result in
different impedance loads.
Series: Is the method of wiring of alternate positive with negative terminals (string method)
(Illustration below)
Parallel: Is the method of wiring where you wire match 2 speaker terminals with positive to
positive terminal and negative to negative. (Illustration below)
Series/Parallel: This configuration is a combination of both series and parallel. We
recommend series for the terminal and parallel for the leads to amp. (Illustration below)
6
•SERIES •• SERIES/PARALLEL •• PARALLEL •
DVC WIRING CONFIGURATIONS
4DVC WIRINGCONFIGURATIONS
1 4
24 1
4
4
41 2 2.66 2
4444444
22
2
22
2
2 2
2 2 4 4
4
4
4 4
4
4
4
4 4
4
2
2
1.33
2
2 2 2 2 2
2 2 2 2
2 2
2 2
1

LIMITED WARRANTY
Euphoria™ warrants any products purchased in the U.S.A. from an authorized
Euphoria™ dealer.
All products are warranted to be free from defects in material and workmanship
under normal use and service for a period of two (2) years.
This warranty applies to the original purchase only.
Euphoria™ will either repair or replace (as its option) any unit that has been found
to be defective and under warranty provided the defect occurs within the two (2)
years warranty period.
This limited warranty does not extend to units have been subjected to misuse,
abuse, neglect, or accident. In Euphoria™’s judgment, products that show evidence
of having been altered, modified, or serviced without Euphoria™ authorization,
will be ineligible under this warranty.
taetisbewruotisivroreliaterruoytcatnocesaelpecivresytnarrawniatbooT
www.euphoriacaraudio.com for more details.
Euphoria is a Registered Trademark of DB Research L.L.P.
Designed and Engineered in the U.S.A. Made in China
