Eurogard ServiceRouter V3 User manual

eurogard GmbH
Technologiepark Herzogenrath
Kaiserstraße 100
D-52134 Herzogenrath
Tel [phone]
Fax [phone]
Mail [e-mail]
Info www.eurogard.de
Quick-Start
eurogard ServiceRouter V3
April 2019

Inial set up
Connect your computer directly to the
LAN side of the Router by means of the
cable included and allow the Router‘s
DHCP to assign an IP number.
IP of the Router: 192.168.155.1
Alternavely, you can start WiFi by
pressing the Setup buon for 2s. Now
you can connect to the network
‚eurogard‘ via smartphone using the
password ‚eurogard‘.
Start a browser and connect to the
Router by entering
hps://192.168.155.1
Accounts
The following administrator account is
set as default:
Admin: User: eurogard
Password: eurogard
Please make sure that these
passwords are changed in the
course of the conguraon process
in view of Internet security.
Warning and safety instrucons
The remote maintenance access to a plant represents a powerful tool and
has to be handled with great care and, as a general rule, with qualied sta
on site, prevenng any possible hazard to men and machines.
These notes are on the one hand intended as a guideline for the sta in-
volved in the project and on the other hand in order to prevent any damage
to the above product or any equipment connected to it.
Proper use, installaon and assembly
The device must only be used for purposes described in this manual and in
the technical instrucons and only in connecon with approved external de-
vices and components recommended by eurogard GmbH.
Please note
All funcons described in this manual apply only to the latest version.
The detailed operang manual can be found in the online help of your
Router and on our website in the download area:
(hps://eurogard.de/de/downloads/category/54-eg-handbuecher.html)
For any quesons and further informaon please contact the
eurogard Team.
[email protected]
www.eurogard.de

Forwarding in the target network - ServiceRouter in client mode
(in operaon with eurogard ServiceServers)
No forwarding of incoming telegrams has to be set up in the target network.
 Access to an NTP me server, via Intranet or Internet
 Access to the Internet (ServiceRouter-Server) outward
Forwarding in the target network - ServiceRouter in server mode
The Router has to be integrated into the target network by forwarding the
(incoming) ports described below.
 TCP 443 (SSL) for access to the conguraon interface and proxy funcon
 UDP 1194 (VPN) for the tunnelled connecon to the PLC network
 TCP 22 when required for rmware updates and Router support through
manufacturer eurogard
 Access to an NTP me server, via Intranet or Internet
 Access to DynDNS outward, if required
The SSL and VPN ports can be changed during conguraon. Access via ports 443
and 22 can be blocked.
Please use the online
help funcon in the
course of the parame-
terisaon process!
Disclaimer
We aim at keeping our soware as error-free as possible. However, the
general rule is: No soware is absolutely free of errors and the probability of errors in-
creases proporonally with the complexity of the program. For this reason we cannot
guarantee that this soware will run absolutely error-free in any context and with any
other applicaon. Liability for damage of any sort, direct or indirect, is hereby excluded
to that extent permied by the law. In any case, liability is limited to the purchase price
of the soware or the device. In parcular, we shall also not be held liable for any dam-
age incurred resulng, eg loss of producon or costs incurred by on-site work in the
event of a remote maintenance equipment breakdown.
While every precauon has been taken in the preparaon of this manual, eurogard can-
not guarantee total accuracy of all informaon contained herein and accepts no liability
whatsoever, be it for errors in this manual or for any potenal damage occurring as a
result of its ulisaon.
eurogard GmbH reserves the right to make improvements and alteraons, both to its
hardware and soware products, regarding funcon, applicaon and presentaon with-
out prior nocaon. Their descripon is of no binding or contractual character whatso-
ever. The specicaons described in this manual only apply to the current version.
The online documentaon regarding the Router is intended for technically qualied per-
sonnel, either those project planning personnel familiar with security concepts in the
area of automaon and network technology; or those trained as operang personnel
dealing with automaon equipment and network technology and familiar with the terms
used in this manual pertaining to their operaon; or, as commissioning and service per-
sonnel, having the necessary qualicaons for servicing facilies of this kind.
Products are designed, manufactured and tested according to the relevant VDE-
regulaons, VDE direcves and IEC-recommendaons.
Declaraon of Conformity
We herewith conrm that the design and construcon of the model family
ServiceRouter V3 ER 1501, ER 1501-WLAN, ER 1501-LTE, ER 1501-W/LTE complies with
the (EC) guidelines 1999/5/EC and 2011/65/EC. The model specic declaraons can be
found on the website below:
hps://eurogard.de/en/downloads/category/80-eg-ce-cercates.html

Technical specicaons
Supply voltage 12-30 VDC
Power consumpon 6-10W
Ambient temperature 5-50 °C
Humidity 0…95% rel. humidity, non condensing
Design DIN-rail
Dimensions (H x W x D) 178 x 50 x 168 mm
Mobile communicaon
ME909s-120
LTE (FDD) B1,B2,B3,B4,B5,B7,B8,B20
DC-HSPA+/HSPA+/HSPA/UMTS B1,B2,B5,B8
EDGE/GPRS/GSM 850/900/1800/1900 MHz
Upload DC-HSPA+ / LTE FDD 5,76 Mbps / 50 Mbps
Download DC-HSPA+ / LTE FDD 42 Mbps / 150 Mbps
Network
VPN OpenVPN-Server, OpenVPN-Client
WAN/LAN 2 x RJ 45 10/100 Mbit/s, full and half duplex
WLAN 802.11 b/g/n; Access-Point, WAN-Client
Security
VPN Cercate administraon, exclusively encrypted
data trac, ip switch ‘VPN ON/OFF‘
Addional funcons
USB USB 3.0 for tunnelling of USB devices
One-Click conguraon for ServiceServer
via USB sck
Message funcon Reports via email
Alarm messages via email and SMS (ISO-on- TCP,
Modbus TCP)
Fallback Internet access 4G to WLAN or WAN
Miscellaneous Buered real-me clock, watchdog, rmware
updates, dynDNS
Commissioning protocol
Host name _________________________________________________
Domain name _________________________________________________
Local IP _________________________________________________
WAN IP _________________________________________________
DYN DNS o ja / o nein____________________________________________
WLAN ESSID _________________________________________________
