EuropAce EHV W80 User manual

Thank you for purchasing EuropAce Products.
Please read this manual carefuly before rst use.
Keep this manual for further guidance in case.

1
2
……………………………………………………………………………………………
……………………………………………………………………………………………………………
………………………………………………………………………………………………
3
………………………………………………………………………………………………………
3
…………………………………………………………………………………………………………
3
………………………………………………………………………………………………
4
………………………………………………………………………………………………………
4
…………………………………………………………………………………………………………
4
…………………………………………………………………………………………………………………
5
………………………………………………………………………………………………
5
………………………………………………………………………………………………………………………6
…………………………………………………………………………………………………………6
……………………………………………………………………………………………………………
6
……………………………………………………………………………………………………
7
……………………………………………………………………………………………………………………
7
………………………………………………………………………………………………………
8
……………………………………………………………………………………………
8
………………………………………………………………………………………………………………
9
………………………………………………………………………………………………………………
9
………………………………………………………………………………………………………………
10
ContentsContents
Safety Instructions
Main Body
Product Installment
Install Cleaning Head
Install Extensive Tube
Remove And Install Dust Bin
Product Operation
Start The Vacuum Cleaner
Adjust The Suction
Charging And Indicator Lights
Notes
During Using
Before Using
Product Maintaining
Clean The Product
Replace And Wash Filters
Replace And Wash Cleaning Head
Troubleshooting
Product Specifications
Accessories

*
Safety InstructionsSafety Instructions
all these regular safety precautions
Battery
This appliance includes 22.2V rechargeable lithium battery, do not use other types of battery.
* Anything wrong about the battery, stop using it and contact the after-service.
* Gently pull out the plug after charging.
During using
1, Store indoors in a dry place out of the reach of children;
2, Always use responsibly. This appliance can be used by children aged from 10 years
and above and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concerning
use of the appliance safely and understand the hazards involved;
3, Don‘ t let children play with the appliance; supervise children using or maintaining
the appliance;
4, Use only manufacturer’s recommended attachments as described in this manual;
misuse or use of any accessory or attachment other than those recommended, may
present a risk of personal injury;
5, Take extra care when cleaning stairs;
6, Keep the appliance and accessories away from the hot surface;
7, Do not block the appliances openings or hinder airflow , keep openings free of any
objects including dust, lint, clothing, fingers (and all parts of the body);
8, Particularly keep hair away from openings and moving parts;
Warning:
1

Main BodyMain Body
Handle
ON/OFF Button
Suction Adjust Button
Dust Bin
Air Outlet
Dust Bin Release Button
Tube Lock
Aluminum Tube
Dust Bin Empty Button
Filter
Dust Bin
Motor Cleaning Head
2

3
1. Install Cleaning Head
To install the cleaning head, slot the head to the handheld part until it clicks.(pic 1)
12
press the lock button
Press the unlock button (pic 2) to remove the cleaning head.
2. Install Extensive Tube
Connect one side of the tube to the handheld part until it clicks, the other side to the
cleaning head until it clicks. (pic 3)
3
* Can clean on hardwood floor and carpets after installing the cleaning head.
* Can clean curtains or ceilings after installing the crevice tube
Product Installment

Product InstallmentProduct Installment
3. Remove And Install Dust Bin
a. To remove the dust bin, press the two unlock buttons on the side of the handheld part
at the same time. (pic A)
b. To install the dust bin, connect the bottom of the dust bin with the main body, push it
to the top of the handheld part until it clicks.(pic B)
unlock button
A
B
Product OperationProduct Operation
1. Start the Vacuum Cleaner
Press the ON/OFF button on the handle to start the vacuum cleaner. (pic A)
A

Product OperationProduct Operation
2. Adjust Suction
Press the speed control button (pic A) to adjust the suction.
A
3. Charging And Indicator Lights
Charging without home base: plug one side of the cable to the handheld part and the other to the
socket.
Charging with home base: plug one side to the base and the other to the socket.
Charging; 0~50% red light, 50%~90% orange light, 90%-100% green light
5
Product OperationProduct Operation
2. Adjust Suction
Press the speed control button (pic A) to adjust the suction.
A
3. Charging And Indicator Lights
Charging without home base: plug one side of the cable to the handheld part and the other to the
socket.
Charging with home base: plug one side to the base and the other to the socket.
Charging; 0~50% red light, 50%~90% orange light, 90%-100% green light
5

NotesNotes
1. During Using
2. Before Using
Keep the product away from sharp objects or dangerous items like oil.
Do not place the product near the cigarette, lighter, match or any flammable products.
When the vacuum cleaner gets stuck, turn off the power and clean away the tangled objects
before starting again.
6
NotesNotes
1. During Using
2. Before Using
Keep the product away from sharp objects or dangerous items like oil.
Do not place the product near the cigarette, lighter, match or any flammable products.
When the vacuum cleaner gets stuck, turn off the power and clean away the tangled objects
before starting again.
6

Product MaintainingProduct Maintaining
Daily Storage
When not using the vacuum cleaner for a long time, place it in a safe and dry place.
Do not expose it to direct sunlight.
Clean The Vacuum Cleaner
A. Empty And Clean The Dust Bin
1. Remove the dust bin first. (pic A)
2. Press the empty button (pic B) to empty the dust bin.
AB
empty button
7
Product MaintainingProduct Maintaining
Daily Storage
When not using the vacuum cleaner for a long time, place it in a safe and dry place.
Do not expose it to direct sunlight.
Clean The Vacuum Cleaner
A. Empty And Clean The Dust Bin
1. Remove the dust bin first. (pic A)
2. Press the empty button (pic B) to empty the dust bin.
AB
empty button
7

Product MaintainingProduct Maintaining
B. Replace And Wash Filter
Take out the filter and wash it in warm water with the soft brush.(Pic A)
Reinstall the filter after it is dry. We suggest washing it when the suction gets weak
A
Note: Make sure you have installed all the accessories before using the vacuum cleaner.
C. Replace And Clean The Cleaning Head
The cleaning head needs to be cleaned after using it for a long time.
Pull the lock button and take out the roller brush like pic B
B
8
Product MaintainingProduct Maintaining
B. Replace And Wash Filter
Take out the filter and wash it in warm water with the soft brush.(Pic A)
Reinstall the filter after it is dry. We suggest washing it when the suction gets weak
A
Note: Make sure you have installed all the accessories before using the vacuum cleaner.
C. Replace And Clean The Cleaning Head
The cleaning head needs to be cleaned after using it for a long time.
Pull the lock button and take out the roller brush like pic B
B
8

1
2
3
4
150W
Li-ion 2200mAh 22.2V
4~5H
68dB
1120*230*230mm
2.1kg/3.9kg
300ml
TroubleshootingTroubleshooting
Error Cause Solution
the machine doesn't work low power replace the battery
or recharging
weak suction
1.dirt cup is full
2.low power
1. empty the dirt cup
2. recharging
dust leakage
1.dirt cup is full
2.not install the dirt cup
right
1. empty the dirt cup
2. reinstall the dirt cup
doesn't vacuum dirt cup is full empty the dirt cup and wash it
Product SpecificationsProduct Specifications
Item Specifications
Power Voltage
Battery
Charging Time
Noise
Measurements
Net/Gross Weight
Dust Bin
9

Accessories
Charging Home Base
Place the handheld part into the home base when charging.
Charging
Plug one side of the cable to the home base and the other to the wall socket
10
