eurotask SM-3DB Series User manual

For Day or Night Detection of Boats & Markers,
Navigation, SAR, & 24 hour observation
SM-3DB Series
Digital Day/Night Vision Binocular
SM-3DB 11x
www.busse-yachtshop.de | [email protected]

SM-3DB Series
Digital Day/Night Vision Binocular
The Models
The SM-3DB Series comprises 3 models
o The SM-3DB8 with 8 times magnification
o The SM-3DB11 with 11 times magnification
o The SM-3DB VARIO with variable
magnification 0.6 to 8 times
Benefits:
o Bright sunlight will not cause damage
o No damage from bright lights at night
o No blooming or night-light effects
o Tireless viewing with both eyes
o IR Illuminator for use in total darkness
o Large, 2.5” Hi res TFT-LCD Monitor
o Record using Standard Composite Video
o Battery charging via mains or car adaptors
Applications
Unlike many night vision devices which can only be used at
night, the SM-3DB digital binocular can be used day or night
without damage to the camera. The SM-3DB is perfect for long-
range detection, navigation assistance & surveillance at sea or
on land. It comes complete with an IR illuminator for use in
total darkness & has a standard composite video output for on
screen viewing or recording to DVR.
Technology
The binocular uses a silicon high sensitive state of the art CCD (Charge
Coupled Device) camera with an electronic accumulation & signal
multiplication system & built-in high resolution TFT-LCD monitor.
Using a four-stage automatic control & an anti-blooming system, the SM-
3DB operates successfully in a wide range of lighting conditions from
0.0005 lux (starlight) to 30,000 lux (sunny day,) without having to adjust
contrast or brightness.
The SM-3DB has similar performance to night vision devices of the 2+
generation, however it is more reliable & more cost-effective when
compared to 2+ or Gen 3 night vision devices.
IR-530-3 (800) Illuminator
Supplied as standard, & designed for use at night at ranges up to
400m, the IR-530-3 (800) is a powerful illuminator which comprises
an IR emitting LED with 800nm wavelength. Invisible to the naked
eye, the illuminator has output power adjustment & radiation
divergence control & is used to “light up” the surrounding area of the
target. The module is removable from the Binocular & is powered by a
separate 3v battery. (See options for longer range devices available)
SM-3DB 8x
SM-3DB
VARIO
IR-530-3 (800)
www.busse-yachtshop.de | [email protected]

SM-3DB Series
Digital Day/Night Vision Binocular—Features & Functions
Getting started
The binocular is supplied with pre-charged & installed batteries. To replace the AA batteries, remove the
two screws on the battery compartment cover .
Turn button
to switch the binocular “ON.” If you have external power available, connect to input 
using the power cable supplied. The binocular can operate using the external power source - AC/DC
adapter 230V/12V or via a car adapter. The red LED will light whilst charging.
Optimize performance with the easy to use function buttons
The binocular has automatic brightness control on the LCD but at night or in bright daylight it is
recommended to adjust the contrast, brightness & sharpness using "menu" button . At each press,
options for "brightness", "contrast", "sharpness" or "colour" (not engaged) will appear on the screen.
Select the required option & using buttons , press "+" or "-" to set the desired parameter of picture.
In order to increase the picture contrast & quality in sunlight, it is recommended to operate the binocular
with closed cover which has an opening (diaphragm).
To achieve maximum sharpness of the object turn the lens . The eyepiece is set to a fixed position &
is designed for range +/-3 of diopter vision.
Viewing & recording
Socket is the Video output & is used for connecting to a video recording or video-transmitting device,
using a standard video input.
Mount is used for mounting the IR-530 illuminator supplied with the unit. The IR Illuminator is for use with
the binocular for observation in extreme conditions (cloudy sky at night) or in complete darkness.





www.busse-yachtshop.de | [email protected]

SM-3DB Series
Binocular Technical Specification
All units come Complete with
IR illuminator
IR-530-3 adjustable (LED) 100mW (3v) 1
240v/12vDC Adapter 1
Rechargeable battery 4 Car Charger 1
Battery CR123 1 User Manual 1
Hard Carry Case 1
E u r o t a s k L t d ●L i t t l e M e a d o w ●H a m b l e d o n R o a d ●D e n me a d ●H a m p s h i r e ●P O 7 6 H D U n i t e d K i n gd o m
T e l + 4 4 ( 0 ) 2 3 9 2 2 6 7 7 5 5 ●w w w . e u r o t a s k l t d . c o m ●i n f o @ e u r o ta s k l t d . c o m
Performance SM-3DB 8x SM-3DB 11x SM-3DB VARIO
Visual Magnification 8x 11x 0.6 to 8x
Lens F1.6/80 mm F1.5/110 mm F1.6 / 5.5-82.5
Resolution: Day 420 TV lines
Night 100 .......420 TV lines
Field of View 6° 4° 4° to 48°
Range up to*: Day
Night
600m
400m
700m
500m
600m
400m
Display Options
Display 2.5” LTPS TFT LCD 960X240
Video Output Standard 1v, 75 Ohm. Composite video RCA connector
Power
Battery 4.8v, 4xAA size rechargeable
External Power Supply DC 10…12V,350mA
Battery Life 4 hours typical
Physical & Environmental
Operating Temperature -10 deg.C to +45 deg.C
Dimensions (mm) 230 x 160 x 85 250 x 170 x 95 230 x 160 x 85
Weight (kgs) 1.0 1.35 1.0
Options
IR Illuminators IR-530-810
Dealer Stamp
N.B. SPECIFICATIONS ARE SUBJECT TO CHANGE WITH OUT NOTICE
* Range will vary dependent on the user, environmental conditions & set up.
All specifications are believed to be accurate at the time of going to print. No responsibility can be accepted for any changes between this
Performance IR-530-3 (800) Standard IR-530-810 Option
Output radiation power 100 mW (adjustable) 250 mW (adjustable)
Wavelength 800 nm 810+/-5 nm
Radiation divergence 5 to 8° 2 to 5°
Range up to 400 m 1000 m
Power supply 3 V, CR 123
Battery lifetime Between 4 to 20 hours
Weight 0.140 kg
Dimensions 130 x 32 mm
Reliability 10,000 hours
Operating temperature -30°C to +40°C
IR Intensifier Technical Specification
