EVBIKE EVBAT36V10A User manual

Baery for electric bicycle drive
EVBAT36V10A
INSTALLATION AND OPERATING INSTRUCTIONS

www.EVBIKE.cz
Thank you for purchasing EVBIKE baery set. We believe that you will be fully saffied with its use.
Before installing and first use, read carefully the instrucons!
If you have found a fact, in the manual, that could prevent from use of the product, please return it before
installing in the undamaged original packaging back. For the current warranty condions and the possibility
of returning, please contact your dealer who will advise you how to proceed.
SPECIFICATIONS
Nominal Voltage: 36V
Cell material: Lithium (LiFePO4)*
Normal Capacity: 10 Ah
Charging Volatge: 43,8V
Charging Current: 2A
Cover Material: plasc
Dimensions (L x W x H): 37 x 13 x 9 cm
Baery Weight: 4,60 kg
Carrier Weight: 0,90 kg
Importer: Global World Logisc Ltd.,EU-VAT ID: CZ682998344
*Main Advantage of the baery compared to
Li-Pol is LiFePO4 composion. Life Li-pol baery
is 400-800 cycles. LiFePO4 baery has a life
of 2000 cycles and more. The baery is also
possible to use in extreme temperatures from -
15 ° C to 60 ° C without loss of performance.

www.EVBIKE.cz
BATTERY INSTALLATION
Importer: Global World Logisc Ltd.,EU-VAT ID: CZ682998344
For baery holder assembly, you need 4 pcs of M8 screws including pads and nuts. Lenght of screws depends
on your bike construcon. These screws aren’t part of package.
Fasten the lower spacer rods to carrier (Fig. 3). Rods allow set carrier to the three differnt posions (Fig. 2).
Select the opmal height to have carrier in horizontal posion. (Bolts aren't included in basic package).
Aach the rods to the bike frame using holes next to the chainrings cartridge (Fig. 4).
●
●
●
1
2 4
3
ABC
5 6

www.EVBIKE.cz
PROPER CHARGING
Lithium cells which contain EVBIKE baeries can be recharged at any level of charge or discharge - these
baeries have no memory effect. We recommend always aer the ride, to recharge the baery so you can
immediately enjoy full power and a long driving range. Aer recharge always unplug the baery from
the charger. Charge the baery only at room temperature (25 ° C). Charging at temperatures below freezing
and vice versa charging the baery exposed to excessive sunlight is prohibited.
Current state of charging is indicated by LED color lights on charger.
• RED – charging in progress.
• GREEN – charging finished (charger is now disconnected from baery).
The charging me is 3-6 hours depending on baery condion.
PROPER DISCHARGING
Recharge the baery to full capacity aer the the first disconnecon of protecve controller. Never try to
reuse the baery aer protecve disconnecon! Deep discharge of some cells and their unrepairable damage
may happen! Such baery usage may also cause unbalance of baery cells voltage and decrease their
capacity. In extreme cases, the baery can not be recharged again. This kind of damage can be easily
diagnosed and will result in avoiding your warranty.
Importer: Global World Logisc Ltd.,EU-VAT ID: CZ682998344
ON
OFF
UNLOCK
PUTTING INTO OPERATION
Default posion of ignitor is UNLOCK. Turn the possion
to PUSH and push the key inside. There is a lock
at the boom of baery, which lock baery to the
carrier. Then turn to OFF and right aer to ON. Now the
baery is locked to the carrier and system is powered
(Fig. 7).
Use Curved rods (Fig. 3) to aach carrier to bike frame under the seat. Use the supplied screws and lock
nuts (Fig. 5).
Choose correct distance and fix the rods to carrier using provided screws (Fig. 6).
When the carrier is aached to bike frame, aach the baery.
●
●
●
7

BALANCE CHARGING
Inside the baery is an electronic baery protecon - balance circuit (compensates the voltage of the cells to
the same value). When using the baery cells voltage is always soly unblanced and we recommend aer
about 8-10 charging cycles to leave the baery on the charger even aer charging is completed. The baery is
sll charged by a small maintenance current flow and balance circuit equals the voltage of cells to the same
level. Therefore double the charge me compared to standard me. Do not perform balance charging every
me you recharging the baery. It may shorten service life of the baery cells. We recommend balance
charging especialy before first ride and always, if you suppose that the baery has not its standard power!
STORAGE
If you do not use the bike for more than 1 hour, always disconnect the baery using its power switch. If you do
not use the bike for more than 24 hours, always remove the baery, recharge it and store in a safe dry place
at room temperature. Beware of short-circuit the baery terminals (contacts) when storing and handling. For
long-term storage, such as off-season, it is also necessary check baery every 14 days (using LEDs) and aer
1 month recharge the baery to its full capacity. If you do not perform this maintenance deep discharge of the
baery cells will occur. This irreparable baery damage is not covered by warranty.
www.EVBIKE.cz
Importer: Global World Logisc Ltd.,EU-VAT ID: CZ682998344
WARNINGS FOR BATTERY USE POSSIBLE DANGERS
•
•
•
Danger of shortcut and fire
Charged or uncharged cells contains a high amount of electric power, it may cause a electric sparks when
contacts are in shortcut. Baeries are not flammable, but fire may be created from sparks or high
temperature connectors (temperature caused by shortcut).
Danger of injury caused by DC current
When connecng more cells or baeries to serie, the danger of injury increases. Never touch the electric
wires or other componnents that are powered.
Danger of chemical material
Lithium cells and baeries does not contain any causcs or acids. Sll materials that are affecng human
body are inside. We recommend you to use following guidelines when manipulang with Lithium cells.
a)
b)
c)
Eye protecon: use eyewear to prevent intrusion of any chemicals in eye.
Skin protecon: use protecon clothing and gloves. Prevent contact of chemicals with your skin.
Inhale protecon: Manipulate with cells or baeries only in venlated areas.

www.EVBIKE.cz
END USER INSTRUCTIONS
Baeries and cells can be used only by person, instructed to use Lithium baeries and cells. This nstrucon
is done by last reseller. When the baeries are sold and shipped, instrucon is done via enclosed manual,
more details to be found at reseller website.
WARNINGS
• Protect against unqualified manipulaon, protect against kids.
• Protect against water or other liquids.
• Use the baeries with control or constant managment of Baery protecon/control system.
• Protect the cells and baeries against overcharge and deep discharge.
• Don’t brake baery case, don’t manipulate with damaged baeries.
Baery and cell recyclaon – legal obligaon informaons
a) Of the manner of re-collecon; for this purpose, the seller publishes actual list of affordable way to take
back and separated collect. Including at least name of the place and address.
Place to take back and separated collecon: i4wifia.s., Průmyslová 11, Praha 10, 102 19
b) About possible negave effects of materials used in baeries or accumulators to environment and human
health.
Baeries and cells contain chemical materials that have negave effect on environment and human health.
c) About meaning of graphical symbol for separated colleon or take back and about meaning of markings
Importer: Global World Logisc Ltd.,EU-VAT ID: CZ682998344
THIS IS GRAPHICAL SYMBOL FOR SEPARATED COLLECT OR TAKE BACK.
DO NOT PUT BATTERIES TO MUNICIPAL WASTE BUT HANDLE THEM IN PLACE
FOR SEPARATED COLLECT OR TAKE BACK.
Global World Logisc Ltd.,EU-VAT ID: CZ682998344, as legal enty authorized by manufacturer for EU,
hereby declares, that the device is in compliance with basic requirements and further relevant provisions
of direcve LOW VOLTAGE DIRECTIVE 2006/95/EC which sets technical requirements for electric devices
of low voltage. This declaraon is issued on documents provided by Manufacturer.
