OPERATOR’S AND MAINTENANCE MANUAL
Multi-Spindle Rotary Mower
4895 RED BLUFF RD LORIS, SC 29569 [phone]
www.hardeebyevh.com [email protected]
DANGER
Read this manual and the
manual for your tractor
carefully to acquaint yourself
with both machines before
operating!
10126W

MODEL NUMBER
SERIAL NUMBER
DATE OF PURCHASE
Customer Pre-Operation Check List Reference

Read, understand and follow the general safety rules listed in
this manual. Page 2

Check gearbox lube level. Page 4

Check all blades and blade holder for sharpness and condition. Page 4

Check skids for wear and tightness. Page 5

Check decals for position and legibility Page 5

Hardee by EVH
Table of Contents
© Copyright 2004 All Rights Reserved
Hardee by EVH provides this publication “as is” without warranty of any kind, either expressed or implied. Every precaution has been taken in the design of this manual, however EVH
assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. EVH reserves the right to
revise and improve this product at any time. The illustrations in this manual are not intended for the safe and proper assembly or disassembly of this product, but for parts ordering
reference only.
10126W MULTI-SPINDLE ROTARY MOWER REVISED 5/12/2016
Section 1 INTRODUCTION
1
Owner’s Responsibility
1
Purpose of this Manual
1
Safety-Alert Symbol
1
Signal Words
1
Customer Assistance
1
Section 2 SAFETY INFORMATION
2
General Safety Rules
2
Safety Decals
3
Section 3 PREPARATION FOR USE
4
Check
4
Gearbox Lube Level
4
Blade and Blade Holder Condition
4
Blade Attaching Hardware
4
Skid Condition
5
Decal Condition
5
Attachment
5
Three-Point Hitch (Lift Type Mower)
5
Drawbar (Pull Type Mower)
5
Hydraulic System (Optional)
5
Driveshaft
5
Adjustment
6
Slip Clutch
6
Mowing Height
7
Leveling Lift Type Mower
7
Leveling Pull Type Mower
7
Adjusting Mowing Height (Lift and Pull Type)
7
Section 4 OPERATION INSTRUCTION
8
Cautions
8
Lights, SMV Emblems
8
Low Speed
8
Normal Procedures
8
Traveling (Lift Type Mower)
8
Traveling (Pull Type Mower)
8
Mowing
8
Reverse Operation
8
Slopes
9
Sharp Turns
9
Section 5 LUBRICATION
10
U-Joints
10
Driveshaft
10
Tail Wheel Bearings and Pivots
10
Section 6 MAINTENANCE
11
Blades
11
Check Blade Condition
11
Remove Blades
11
Remove Blade Holder
11
Replace Blade Holder
11
Replace Blades
11
Gearbox Lube Level
12
Gearbox
12
Gearbox Seals and Gasket
12
Input Shaft Seal and Cover Gasket
12
Output Shaft Seal
12
Gearbox Mounting Hardware
12
Slip Clutch
12
Safety Shields
12
Tail Wheel (Lift Type)
13
Replace Wheel
13
Replace Pivot
13
Wheel Bearings (Pull Type)
13
Section 7 REFERENCE
14-15
Gearbox Breakdown
16
Gearbox Breakdown
17
Driveshaft Breakdown
18
Driveshaft Breakdown
19
Driveshaft Breakdown
20
Bolt Torque
21
Checking Bolt Torque
21
Torque Specifications Coarse Thread
21
Torque Specifications Fine Thread & Head Markings
22
Warranty
23

Section 1
Hardee by EVH
INTRODUCTION
10126W MULTI-SPINDLE ROTARY MOWER 1
Owner’s Responsibility
The manufacturer has no control over the ultimate use
of the mower and therefore assumes no responsibility
or liability for damage or injury resulting from the use
of this machine.
The upkeep of the mower is the responsibility of the
user. This upkeep includes all shielding, guards, and
safety decals (OSHA Regulation 1928.57). You can
obtain replacement parts from any authorized Hardee
dealer.
Read this Operator's Manual before operating the
mower. Failure to do so could result in serious injury
or death to the operator or to others. Remember that
most accidents occur due to neglect or carelessness.
The operator is responsible for inspecting and making
repairs as may be necessary. Cleaning after each use
and storage under a shelter will extend the life of the
mower.
Purpose of This Manual
This manual provides information on safety, operation,
adjustments, troubleshooting and maintenance of your
new mower. Please read and follow all the
recommendations to help ensure that you get many
years of service from your new Hardee mower.
If you need additional copies of this manual, please
contact your local Hardee dealer or download a copy
from our website at www.hardeebyevh.com.
Safety-Alert Symbol
This symbol is the safety alert symbol. It
appears throughout this manual to call your
attention to instructions involving your personal
safety and the safety of others. Failure to follow
these instructions can result in injury or death.
Signal Words
Safety signal words are words that call attention to the
safety sign and designate a degree or level of hazard
seriousness. The signal words used throughout this
manual are DANGER, WARNING and CAUTION.
Please read and follow all safety messages that have
these signal words shown for your protection.
DANGER
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Customer Assistance
The Hardee by EVH sales team would like you to be
satisfied with your new MOWER. If for some reason
you have any questions about the information in this
manual or have a problem with your multi-spindle
rotary mower, please discuss the problem or question
with the management of your local dealership. If
further assistance is required, please contact:
HARDEE by EVH Manufacturing Company, LLC
Sales Department
4895 Red Bluff Road
Loris, SC 29569
843-756-2555
[email protected]

Section 2
Hardee by EVH
SAFETY INFORMATION
10126W MULTI-SPINDLE ROTARY MOWER 2
General Safety Rules
This section of your manual will address the safe
operation of your new mower. We, at Hardee, strive to
produce a machine that is both a quality product and
safe to operate. Please take the time to read,
understand and follow the safety rules listed below and
throughout this manual.
Your safety also depends on you becoming familiar
with the basic operation of your new mower. You can
find complete instructions for this mower in the
Operation Instruction section of this manual. We
believe that using your mower safely; in a safe
environment will give you great results!
DANGER
If your tractor has an open cab, then it MUST be
equipped with operator protective equipment in the
form of shielding from thrown objects to operate this
equipment safely.
DANGER
Mowers have the inherent ability to throw debris
considerable distances when the blades are allowed to
strike foreign objects. The operator must use caution or
serious injury may result. Be sure by-standers are at a
safe distance at all times when the mower is in use.
WARNING
ALWAYS keep your tractor level. Be careful to keep
ample distance between the rear tire and the top of the
ditch bank to avoid a cave-in of the bank.
WARNING
Failure to keep the tractor level may result in loss of
traction, tipping, rollover, property damage, personal
injury or death.
WARNING
 NEVER allow an UNQUALIFIED OR UNDERAGE
person to operate the mower.
 NEVER allow any person under the influence of
drugs or alcohol, or who is otherwise impaired, to
operate the mower.
DANGER
DO NOT look under the mower deck or attempt to
remove objects or branches from under the mower
deck while the tractor is running. Serious injury, loss of
limb or death may result.
DANGER
DO NOT reach under the mower deck at any time.
Cutting blades may cause serious injury, loss of limb or
disfigurement.
WARNING
All shielding, guards and safety decals must be in place
at all times while the mower is in operation. Consult
OSHA Regulation 1928.57 for further details.
WARNING
 NEVER operate the mower in an area where objects
can be thrown by the mower. Clear areas to be
mowed of all foreign objects before mowing.
 NEVER allow passengers to ride on the mower or the
tractor while the mower or any other implement is
operating.
 NEVER dismount the tractor from the rear.
 NEVER allow HORSEPLAY in the vicinity of the
tractor while the mower is operating.
WARNING
NEVER allow the mower to impact rock piles, piles of
gravel, steel guardrails or concrete abutments. Contact
with these objects could cause blade failure. Serious
machine damage, property damage or bodily injury
may occur. Check the area for these items BEFORE
mowing.
DANGER
NEVER attempt to use the mower to remove brush
larger than 3 inches in diameter.
DANGER
 ALWAYS disengage the PTO, set parking brake, turn
off the tractor engine, remove key and wait for all
rotary motion to stop BEFORE dismounting the
tractor.
 ALWAYS dismount the tractor FROM THE SIDE.
 ALWAYS keep blade holder and bolts tight.
 ALWAYS wear safety goggles when operating the
mower.

Hardee by EVH
SAFETY INFORMATION
10126W MULTI-SPINDLE ROTARY MOWER 3
Safety Decals
Your Hardee mower ships with all safety decals in
place. They are located in areas on the mower that
are potentially hazardous. Please locate, read and
follow the information you find on these decals.
By law, you must replace any safety decals that are
damaged or missing. You can order replacement
decals from any local Hardee dealer. Ask for part
number listed next to decal.
To apply the replacement decals:
 Clean the surface to place the new decal.
 Peel the decal away from the paper backing.
 Press firmly onto the clean surface.
 Squeeze out any air pockets using a straight
edge.
P/N 11004
P/N 11001
P/N 11006
P/N 11005
P/N 11002
P/N 11003
P/N 11845-15

Section 3
Hardee by EVH
PREPARATION FOR USE
10126W MULTI-SPINDLE ROTARY MOWER 4
CHECK
Danger
NEVER attempt any checks, repairs or adjustments
with the tractor engine running or the power take-off
engaged. Adjustment of rotating parts while the tractor
engine is running can result in serious personal injury or
death if the PTO accidentally engages.
Gearbox Lube Level
The gearbox is filled with lubricant at the factory. If a
shaft seal or cover gasket is damaged, the lubricant will
leak. After periods of heavy use (at least every 10 hours
of operation), or if lubricant leaks are observed, check
the lubricant level.
 Position mower on a level surface.
 Visual check and look for leaks in shaft and open
plate cover and check for oil in blade pan.
 Remove gearbox lubricant level inspection plug and
check lubricant level. Lubricant should be at or near
the hole.
 If lubricant is low, remove gearbox Fill/Pressure
Relief Plug (P/N 15664) and add SAE 85-140
lubricant until lubricant starts to flow from level
inspection hole. DO NOT OVERFILL. Overfilling will
induce leakage and cause damage to seals and
gaskets.
 Replace Lubricant Level Plug and Fill/Pressure
Relief Plug (P/N 15664).
Note: DO NOT OPERATE THE MOWER WHEN
LUBRICANT LEVEL IS LOW. Replace damaged seals
or gasket and add lubricant to the correct level. DO
NOT OVERFILL.
Checking Gearbox Lubricant Level
Blade and Blade Holder Condition
 Lift and support mower by an approved means.
Danger
The mowers weigh BETWEEN 1,525 and 3,590 pounds
and will cause severe injury or death if one falls on the
operator during maintenance. Support the mower with a
supporting device having a capacity for at least 1 ½
times the weight of the mower (e.g. – 2,170 pound
mower = 3,255 pound lifting device capacity).
 Check mower blades for sharpness and condition.
Replace worn mower blades in pairs only. Sharpen
dull mower blades in pairs only.
Note: It is a good practice to weigh blades after
sharpening to ensure balance.
Danger
Excessively worn or dull mower blades, or the
replacement or sharpening of only one mower blade,
can cause excessive mower vibration, resulting in
damage to the gearbox and structural damage to the
mower. Excessive vibration can cause rotating parts to
break and fly off the mower, causing serious injury or
death to the operator or bystanders.
 Lock blade holder so it will not turn.
 Remove blade holder shaft cotter pin.
 Check blade holder nut for tightness. Tighten as
required.
Danger
A loose blade holder shaft can cause the shaft to break,
causing the holder to fly out, damaging the mower and
causing serious personal injury or death to the operator
or bystanders. Ensure that the nut is tight on the shaft
and the cotter pin is securely in place.
 Replace blade holder shaft cotter pin.
 Remove supporting means and lower mower.
Blade Attaching Hardware
 Rotate blade bolt access cover (on top of mower
deck in front of the gearbox) from covering over the
access hole.
 Turn blade holder to position blade bolt under
access hole.
 Tighten blade bolt.
 Turn blade holder to position second blade bolt
under the access hole.
 Tighten blade bolt.
 Rotate blade bolt access cover over access hole.
LEVEL
PLUG
FILL/PRESSURE
RELIEF PLUG

Hardee by EVH
PREPARATION FOR USE
10126W MULTI-SPINDLE ROTARY MOWER 5
Checking Blade Bolts
Skid Condition
 Check skids for wear and tightness.
 Replace skids less than 1/16” thick.
Decal Condition
Check all decals for position and legibility before
attaching the mower to the tractor. Replace all decals
that have been removed, damaged or destroyed. See
the Safety Section for decal locations.
ATTACHMENT
Three-Point Hitch (Lift Type Mower)
 Position tractor in front of mower so that the tractor
hitch is in line with mower hitch.

Connect tractor lower hitch arms to mower hitch
points and lock pins in place.
Positioning Tractor for Hitching
 Connect tractor top hitch link to floating linkage on
mower hitch. Adjust linkage to a 45° angle.
Positioning Hitch Upper Arm
Drawbar (Pull Type Cutter)
Adjust the tractor drawbar so that the hole is 14 inches
behind the end of the PTO shaft and parallel to the
tractor centerline. The vertical distance for the drawbar
centerline to the driveshaft centerline should be 8 to 15
inches.
 Back tractor until drawbar is in line with mower
hitch.
 Connect mower to tractor drawbar with a A 1 inch
drawbar pin.
 Connect mower hydraulic system (if used) to tractor
auxiliary hydraulic system.
 Lower mower’s front jack all the way down.
HYDRAULIC SYSTEM (OPTIONAL)
 Be sure that all hydraulic connections are tight
before connecting mower to tractor
 Be sure all hydraulic lines and hoses are in good
condition before pressurizing hydraulic system.
 Be sure that the tractor hydraulic system is full
before operating mowers hydraulics.
Driveshaft
Danger
NEVER attach the mower to a 1000-RPM PTO unless
mower is rated for 1000-RPM. Operating the mower
over 540-RPM could result in severe damage to the
mower, and in parts flying off the mower resulting in
severe personal injury or death to the operator or
bystanders.
ACCESS
HOLE

Hardee by EVH
PREPARATION FOR USE
10126W MULTI-SPINDLE ROTARY MOWER 6
 Lift tractor PTO guard.
 Pull U-joint guard back along driveshaft.
 Press driveshaft yoke plunger in and slip driveshaft
U-joint yoke onto splined PTO shaft. Check that
plunger returns to locked position.
 Position U-joint guard over driveshaft U-joint.
 Lower Tractor PTO guard.
ADJUSTMENT
Slip Clutch
Mowers are equipped with a slip clutch on the driveshaft
to protect the tractor and mower drivetrain parts from
sudden overloads. When properly adjusted, the clutch
will slip to relieve excess loads and automatically reset
itself without interrupting the mower operation.
To compensate for clutch plate face wear and to maintain
capacity during continuous use, the slip clutch must be
adjusted periodically. Adjust the slip clutch at the
beginning of each use, and when the mower has been
idle for extended periods.
Danger
NEVER attempt any repairs or adjustments with the
tractor engine running or the power take-off engaged.
Adjustment of rotating parts while tractor engine is
running can result in serious personal injury or death if
the PTO accidentally engages.
 Remove slip clutch safety shield by removing the
retaining clip and sliding shield back along the
driveshaft.
 Loosen slip clutch adjusting nuts.
 Check clutch plate assembly. Free plates by lightly
tapping on flat edges of drive plates if required.
Note: Slip clutches have a tendency to seize if left idle for
extended periods.
Danger
Ensure that all bystanders are clear of the mower before
the tractor engine is started. Objects thrown by the
mower can cause severe personal injury or death.
 Start tractor engine and engage power take-off at low
rpm for one or two seconds to remove any rust or
other foreign material between the slip clutch plates.
 Disengage PTO, turn off tractor, set brake and
remove key. Ensure that all rotary motion has
stopped before dismounting the tractor.
 Remove clutch safety shield.
Adjusting Slip Clutch
 Tighten clutch adjusting nuts alternately and evenly
1/2 turn at a time until springs have compressed to
between 1 1/8” to 1” in length.
 Scribe a chalk line across clutch drive plate and
driven plate to mark their position relative to one
another.
Note: The drive plate is on the U-joint side of the slip
clutch. The driven plate is on the gearbox side.
Note: If plates still can be rotated by hand when springs
are compressed to the limit, new plates must be installed.
Refer to parts breakdown for correct part number.
 Replace clutch safety shield after adjustments are
complete.
 Operate rotary mower for three or four minutes under
normal load.
 Disengage PTO, turn off tractor, set brake and
remove key. Ensure that all rotary motion has
stopped before dismounting tractor.
 Remove safety shield.
 Observe chalk lines on clutch plates. If clutch is not
slipping under normal load, chalk marks will still be
aligned. Clutch is correctly adjusted. If clutch is
slipping, chalk lines will not be aligned.
Note: If chalk is not available, the following method may
be used to check for clutch slippage.
 Carefully check if clutch is overheating by holding
hand near clutch. If slipping has occurred, allow
clutch to cool before adjusting.
CLUTCH
ADJUSTING
NUT

Hardee by EVH
PREPARATION FOR USE
10126W MULTI-SPINDLE ROTARY MOWER 7
Warning
DO NOT touch the slip clutch with bare hands
immediately after operation. Severe skin burns and
component damage may result if the clutch is adjusted
while hot.
 Repeat above procedure until heating and slippage
are eliminated.
 Replace clutch safety shield after adjustments are
complete.
Mowing Height
Danger
The mower must be operated on a level plane at all
times to minimize the risk of objects being thrown out
from under the mower. Objects thrown by the mower
can cause severe personal injury or death.
Safety chain shielding is highly recommended to
minimize the danger of objects being thrown out from
under the mower. Safety chain shielding is available
from Hardee By EVH Mfg. and authorized Hardee
dealers and distributors. Safety belting comes standard
on all mowers.
Leveling Lift Type Mower
Hook mower to tractor, transport mower to level area if
not at one already. Lower the mower to about six (6)
inches above the ground. If not level adjust third arm of
tractor until front and rear of mower are equal heights
above the ground.
Danger
To minimize the possibility of personal or mechanical
injury from objects being thrown from under the mower,
it must be operated level at all times.
Leveling Pull Type Mower
For initial hook-up and leveling, hook mower tongue to
tractor’s drawbar, if they do not align use tongue jack to
move the tongue. Make sure that the two parking stands
are in the up position. After hook-up is achieved, if
optional cylinder is used, connect hydraulic lines to
tractor. Make sure hoses and fittings are tight and in
good condition. Raise mower with ratchet jack or with
optional hydraulic cylinder to travel height and move
mower to a level area if not already at one. Once at a
level area, lower mower to about six (6) inches above
the ground. Measure the height at the front and rear of
the deck to see if there are any differences in height. If
heights are within a half inch difference, install drive
shaft and shields and proceed with mowing. If heights
are more than a half inch, you must adjust leveling
turnbuckles. To do so, block mower at side skids about
six (6) inches above the ground to take the pressure off
the turnbuckles. To raise the front of the mower, shorten
rod length, to lower the front of the mower lengthen rod
length. Loosen lock nuts and start adjusting turnbuckles.
Note: You must adjust turnbuckles in equal increments
so one will not bind the other.
After adjusting turnbuckles, remove blocks and measure
heights again. If mower is still un-level, repeat process
above until level is achieved. When mower is level,
install drive shaft and shields and proceed with
operation. When mowing is completed, and mower is
ready for unhooking, lower parking stands to a height
that would allow tractor to easily connect to mower.
Tongue jack may be needed to allow parking stands to
line up parking stand holes.
This is an initial adjustment for parallel lift operation and
need not be repeated as long as the mower is used with
a tractor having the same drawbar height.
Adjusting Mowing Height (Lift and Pull
Type)
Cutting height is achieved by using the ratchet jack or by
the optional hydraulic cylinder. If ratchet jack is used,
jack cutter down until it is about two (2) inches above the
ground. This is the recommended cutting height. In
loose or moist soil additional clearance may be needed.
If hydraulic cylinder is used, lower the mower to two (2)
or three (3) inches above the ground. With the hydraulic
cylinder two (2) spacers are supplied, in two different
sizes. Measure the space between cylinder body and
the stop. Used spacer that comes closest to fitting and
this will lock your mower at the working mower height.
For more height add spacers.
Danger
Mowing with mower to high above the ground will cause
debris to be thrown from under the mower, causing
serious personal injury to operator or bystanders. Make
sure mower is at recommended height at all times when
mower is being operated.

Section 4
Hardee by EVH
OPERATION
10126W MULTI-SPINDLE ROTARY MOWER 8
CAUTIONS
Danger
Incorrect operation of the mower may produce
hazardous situations that can lead to serious injury or
death. The mower has been designed to minimize the
risks of accidents, but there is no substitute for a careful
operator.
Note: See SAFETY PRECAUTIONS in the
introduction section for a list of safety related cautions
to be observed while operating mower.
Lights, SMV Emblems
If operating along public roads, warning lights or slow
moving vehicle emblems should be used unless
prohibited by law. Check local and state codes.
Low Speed
Slow the tractor down when approaching trees, fences,
ditches or other obstacles. The flywheel effect of the
blade rotation will move some tractors forward after the
main drive clutch has been disengaged. To stop
forward movement, apply tractor brakes and throttle the
engine back to allow the engine to slow the rotor before
disengaging the PTO or drive clutch.
NORMAL PROCEDURES
Traveling (Lift Type Mower)
Raise the mower to its maximum height when traveling.
Additional ground clearance can be obtained by
shortening the tractor hitch center arm. NEVER engage
PTO while mower is in traveling position WITHOUT a
cutting load.
Mower in Traveling Position
Warning
Transporting the mower at maximum height changes
the center of gravity of the tractor. Do not travel at high
rates of speed with the mower in traveling position,
especially over rough or bumpy terrain. Tractor
instability during high-speed travel can cause a rollover,
resulting in serious personal injury or death.
Traveling (Pull Type Mower)
Raise the mower to its maximum height when traveling.
To do so, use ratchet jack or optional hydraulic cylinder
to bring mower to traveling position.
Mower in Operating Position
Mowing
 Watch for holes, rocks, roots or other hidden
hazards.
 Keep away from drop-offs.
 Do not cut near the edge of a gully or bank.
 Slow down before turning.
 Engage PTO as directed by tractor manufacturer.
Reverse Operation
Do not operate the mower in reverse unless absolutely
essential.
Caution
DO NOT operate mower in reverse unless absolutely
essential and is allowed by the tractor manufacturer.
Reverse PTO operation may damage tractor drivetrain.
Material may be thrown out through the front of the

Hardee by EVH
OPERATION
10126W MULTI-SPINDLE ROTARY MOWER 9
mower during reverse operation, posing a hazard to the
operator and bystanders. Mow in reverse only if
optional safety chain shielding or safety belting is
installed on the mower.
 Look behind mower before putting tractor in
reverse gear.
 Back tractor at lowest speed available
 Watch back of mower at all times while backing.
Slopes
Cut down, not across, steep slopes. Avoid sudden
starts and stops. Avoid mowing up steep slopes. Slow
down before changing direction on steep slopes.
Sharp Turns
When turning with the mower, ensure that the rear
tractor wheels do not strike any part of the mower.
Extremely short turns should be avoided to prevent
excessive U-joint wear.
HEIGHT ADJUSTMENT
Warning
The mower must be operated on a level plane at all
times to minimize the risk of objects being thrown out
from under the mower. Objects thrown by the mower
can cause severe personal injury or death.

Section 5
Hardee by EVH
LUBRICATION
10126W MULTI-SPINDLE ROTARY MOWER 10
LUBRICATION
Visually inspect the mower at least once a week.
Lubricate parts with good lithium EP grease at the
intervals specified. If heavy, long-duration operation is
expected, lubricate more frequently. Wipe off excess
grease after lubricating.
Lubricating Universal Joints
Lubricating Tail Wheel Bearings
Lubricating Driveshaft Slip Joints
Lubricating Tail Wheel Pivot
Interval Lift Type Pull Type
4 hours U-Joints U-Joints
10 hours
Driveshaft Joint
Tail Wheel Bearings
Tail Wheel Arm
Driveshaft Joint
Tail Wheel Arm
Yearly Ratchet Jack
Wheel Bearings

Section 6
Hardee by EVH
MAINTENANCE
10126W MULTI-SPINDLE ROTARY MOWER 11
MAINTENANCE
Danger
NEVER attempt any checks, repairs or adjustments
with the tractor engine running or the power take-off
engaged. Adjustment of rotating parts while tractor
engine is running can result in serious personal injury
or death if the PTO accidentally engages.
BLADES
Check Blade Condition
Danger
Excessively worn or dull mower blades, or replacement
or sharpening of only one mower blade can cause
excessive mower vibration, damage to the gearbox and
structural damage to the mower. Excessive vibration
can cause rotating parts to break and fly off the mower,
resulting in serious injury or death to the operator or
bystanders.
 Lift and support mower by approved means.
Danger
Lift and support mower by approved means only. The
mowers weigh BETWEEN 1,525 and 3,590 pounds and
will cause severe injury or death if it falls on the
operator during maintenance. Support the mower with a
supporting device having a capacity for at least 1 ½
times the weight or the mower (e.g. – 2,170 pound
mower = 3,255 pound lifting device capacity).
 Check mower blades for sharpness and condition.
Replace worn mower blades in pairs only.
Remove Blades
 Disconnect driveshaft from gearbox.
 Rotate blade bolt access cover (on top of the
mower deck in front of the gearbox) from over the
access hole.
 Turn blade holder to position blade bolt under
access hole.
 Remove blade bolt and blade.
Removing Blade Bolt
Remove Blade Holder
 Lock gearbox shaft by an approved means.
 Remove cotter pin from shaft.
 Back off set bolt.
Removing Blade Holder Nut
Danger
The blade holder is heavy and will cause serious
personal injury or death if it falls on the operator.
Support the holder by an approved means before
proceeding to the next step.
 Remove set bolt and nut.
 Remove slotted nut, washer and blade holder.
Replace Blade Holder
 Lift blade holder onto gearbox shaft.
 Install set bolt and nut.
 Install washer and slotted nut. Tighten the nut.
 Install cotter pin on gearbox shaft.
Danger
A loose blade holder could cause the gearbox shaft to
break under load, causing the holder to fly out from
under the mower. This could cause damage to the
mower and serious personal injury or death to the
operator or bystanders. Ensure that the slotted nut is
tight against the holder and that the cotter pin is in good
condition.
Replace Blades
 Rotate blade bolt access cover away from access
hole in mower deck.
 Position holder so that a blade-mounting hole is
directly beneath access hole.
 Position blade on holder.
 Install and tighten blade bolt.

Hardee by EVH
MAINTENANCE
10126W MULTI-SPINDLE ROTARY MOWER 12
 Turn blade holder to position second blade-mounting
hole under access hole.
 Install and tighten blade bolt.
 Rotate blade bolt access cover over access hole.
 Install driveshaft.
 Remove supporting means and lower mower.
Gearbox Lube Level
After periods of heavy use (at least every 10 hours of
operation), or after repairing the gearbox, or if lubricant
leaks are observed, check gearbox lubricant levels.
Caution
DO NOT operate the mower if lubricant level is low.
Replace damaged seals or gasket and add lubricant to
the correct level. DO NOT OVERFILL.
 Position mower on a level surface.
 Visually check and look for leaks in shaft and open
plate cover and check for oil in blade pan.
 Remove gearbox lubricant level plug and check
lubricant level. Lubricant should be at or near bottom
of hole.
 If lubricant is low, remove gearbox Fill/Pressure
Relief Plug (P/N 15664) and add SAE 85-140
lubricant until lubricant starts to flow from level
inspection hole. DO NOT OVERFILL. Overfilling will
induce leakage and cause damage to seals and
gaskets.
 Replace Lubricant Level Plug and Fill/Pressure
Relief Plug (P/N 15664).
Caution
FILL/PRESSURE RELIEF PLUG (P/N 15664) Must not
be CLOGGED OR RESTRICTED. Must be able to vent
gearbox.
Checking Gearbox Lubricant Level
GEARBOX
Gearbox Seals and Gaskets
Check the gearbox for leaks around the seals and
gasket daily when the mower is in use. If a shaft seal
or gasket is damaged, lubricant will leak out of the
gearbox.
 Disconnect driveshaft from gearbox.
 Remove lubricant drain plug and allow all of the
lubricant to drain.
Input Shaft Seal and Cover Gasket
 Remove gearbox cover.
 Replace shaft seal and cover gasket.
 Replace gearbox cover.
 Replace drain plug and refill with lubricant.
Output Shaft Seal
 Remove blade holder.
 Remove gearbox from top deck. Drain lubricant.
 Replace shaft seal.
 Install gearbox on top deck.
 Replace drain plug and refill with lubricant.
 Install blade holder.
Gearbox Mounting Hardware
Check that the gearbox is tight on the mower top deck
each day the mower is in use. If it becomes loose,
tighten the mounting bolts.
SLIP CLUTCH
Danger
NEVER attempt any repairs or adjustments with the
tractor engine running or the power take-off engaged.
Adjustment of rotating parts while tractor engine is still
running can result in serious personal injury or death if
the PTO accidentally engages.
See SLIP CLUTCH adjustment procedure in Section 1.
SAFETY SHIELDS
Check safety shields before each use. Check to see
that all attaching hardware is tight. Replace any length
of chain that has missing or damaged links. Replace
rubber belting if damaged. If mower has a haygate,
after cutting hay, replace gate, making sure all nuts
and bolts are in place and tight. To keep haygate bolts
in good condition when operating without gate, replace
nuts and bolts and tighten.
LEVEL
PLUG
FILL/PRESSURE

Hardee by EVH
MAINTENANCE
10126W MULTI-SPINDLE ROTARY MOWER 13
TAIL WHEEL (LIFT TYPE)
Replace Wheel
Caution
Adequately support the mower and the wheel before
removing the axle. Both the wheel and the mower are
heavy and could cause damage to the mower or serious
injury if dropped.
 Remove wheel axle nuts and axle.
 Remove wheel.
 Position wheel in pivot yoke.
 Install wheel axle and nuts.
Replace Pivot
 Raise and support mower using approved means.
Support mower high enough so that pivot shaft can
be removed from tail wheel pivot bracket.
Caution
Adequately support the mower and the tail wheel
assembly before removing the bolt. Both the tail wheel
and the mower are heavy and could cause damage to
the mower or serious injury if dropped.
 Remove collar bolt, nut and collar on top of pivot
bracket.
Removing Tail Wheel Pivot Collar Bolt
 Remove pivot from pivot bracket.
 Install replacement pivot in bracket.
 Install collar, collar bolt, and nut on pivot on top of
pivot bracket.
 Lubricate with lithium EP grease (See
LUBRICATION, Section 3).
WHEEL BEARINGS (PULL TYPE)
 Remove dust cap from wheel hub.
 Clean out old grease from dust cap.
 Pack dust cap with clean wheel bearing grease.
 Install dust cap.

Section 7 - Reference
14

Section 7 - Reference
15

Section 7 - Reference
16

Section 7 - Reference
17
