Evolve WR153ND User manual

Contents
Introduction······································································································ - 3 -
Section one Product Overview·········································································· - 4 -
1.1 Product Features ······························································································ - 4 -
1.2 Specification ···································································································· - 4 -
Section Two Hardware Installation ···································································· - 6 -
2.1 Panel layout ····································································································· - 6 -
2.1.1 Front panel············································································································· - 6 -
2.1.2 Rear panel············································································································· - 7 -
2.2 System Requirements························································································ - 7 -
2.3 Installation Environment ···················································································· - 7 -
2.4 Hardware Installation Steps················································································ - 7 -
Section Three Quick Installation Guide ······························································· - 8 -
3.1 TCP/IP configuration ·························································································· - 8 -
3.2 Quick Setup wizard ··························································································- 10 -
3.3 Operation mode·······························································································- 16 -
Section four Configuration Guide·····································································- 17 -
4.1 Login··············································································································- 17 -
4.2 Wireless Setting·······························································································- 17 -
4.2.1 Wireless Status······································································································- 18 -
4.2.2 Wireless Basic settings····························································································- 18 -
4.2.3 Repeater settings ···································································································- 19 -
4.2.4 Virtual AP settings···································································································- 20 -
4.2.5 WDS Settings········································································································- 20 -
4.2.6 Advanced Settings··································································································- 21 -
4.2.7 Access Control·······································································································- 21 -
4.2.8 WPS Settings ········································································································- 22 -
4.3 TCP/IP Setting ·································································································- 23 -
4.3.1 LAN Status············································································································- 23 -

4.3.4 WAN Interface Setup·······························································································- 25 -
4.4 Firewall···········································································································- 25 -
4.4.1 IP/Port Filtering······································································································- 25 -
4.4.2 MAC Filtering·········································································································- 26 -
4.4.3 Port Forwarding ·····································································································- 27 -
4.4.4 URL Filtering ·········································································································- 28 -
4.4.5 DMZ ····················································································································- 28 -
4.5 Management ···································································································- 29 -
4.5.1 QOS····················································································································- 29 -
4.5.2 DDNS Setting·········································································································- 30 -
4.5.3 Time Zone Setting ··································································································- 31 -
4.5.5 Log······················································································································- 32 -
4.5.6 Upgrade Firmware··································································································- 32 -
4.5.7 Save/Reload settings ······························································································- 33 -
4.5.8 Password setup ·····································································································- 33 -

I
In nt tr ro od du uc ct ti io on n
WR153ND Router is a hybrid design product which combines Ethernet technology and wireless
access into a single stand-alone unit. The device allows you to take advantages of both mobility and
fast connection. All PCs whenever on wireless LAN or Ethernet LAN can share files, printers and o
ther
network resources. Moreover, all users can share single account of Internet access by having this
device connect to a DSL/Cable modem.
It complies with IEEE 802.11n (Draft 2.0) standards, supports up to 150Mbps (1Tx-1Rx) wireless
connection speed, adopting MIMO technology to ensure a good performance, stability and coverage
to bring you an enjoyable new experience. It's wireless data transmission rate can be 3 times better
and coverage 4 times better than a normal 802.11g/b router. It is a high performance and cost-
effective solution for Home and Small office.
The router provides multiple security protection, which can protect the wireless access security
effectively. It is easy to install and configure with user friendly interface. For better application of the
router functions, please read this user manual carefully.
Package List
Open the box carefully, check the contents listed below:
Wireless Broadband Router
Power adapter
User Manual
UTP Lan Cable
1x 5dBi antenna
CD
N
No ot te e: :
I
If f a an ny y o of f t th he e l li is st te ed d c co on nt te en nt ts s a ar re e d da am ma ag ge ed d o or r m mi is ss si in ng g, , p pl le ea as se e c co on nt ta ac ct t t th he e
r
re et ta ai il le er r f fr ro om m w wh ho om m y yo ou u p pu ur rc ch ha as se ed d t th he e W Wi ir re el le es ss s R Ro ou ut te er r f fo or r a as ss si is st ta an nc ce e
T
Th ha an nk k y yo ou u f fo or r p pu ur rc ch ha as si in ng g t th he e 1 11 1N N W Wi ir re el le es ss s B Br ro oa ad db ba an nd d R Ro ou ut te er r. . T Th hi is s u us se er r g gu ui id de e w wi il ll l
a
as ss si is st t y yo ou u w wi it th h t th he e i in ns st ta al ll la at ti io on n p pr ro oc ce ed du ur re e. .

S
Se ec ct ti io on n o on ne e P Pr ro od du uc ct t O Ov ve er rv vi ie ew w
1.1 Product Features
Complies with IEEE 802.11n, 802.11g, 802.11b standard for 2.4GHz Wireless LAN
1 10/100M WAN RJ45 port, 4 10/100M LAN RJ45 ports
Supports Auto MDI/MDIX
Supports Wireless Roaming, can move among different AP and no break
Provides 64/128 bit WEP, WPA and WPA2 authentication and TKIP/AES encryption security
Supports wireless Relay/Bridging/WDS/WDS+AP mode, WPS Settings .
Provides wireless LAN ACL (Access Control List) filtering
Built-in NAT and DHCP server supporting dynamic IP address distributing
Supports Virtual Server, Special Application, and DMZ host
Built-in firewall supporting IP address filtering, Domain Name filtering, and MAC address filtering
Supports TCP/IP, PPPoE, DHCP, ICMP, NAT
Supports UPnP, Dynamic DNS, Static Routing,
Supports Flow Statistics
Firmware upgrade, and configuration file backup and restore
Supports Remote and Web management
1.2 Specification
Standard
IEEE802.11n current draft
、
IEEE 802.11g
、
IEEE 802.11b
IEEE 802.3、IEEE 802.3u、IEEE 802.3x
Protocol
CSMA/CA
、
CSMA/CD
、
TCP/IP
、
ICMP
、
NAT
、
PPPoE
、
DHCP
、
PPTP
、
UDP
、
NAT、DNS、DDNS、VPN
Port LAN
4*100BaseTX (Auto MDI/MDIX)
Port WAN
1*100BaseTX (Auto MDI/MDIX)
RF Frequency
2.4~2.4835GHz
Data Rate
11n: 150/135/121.5/108/81/54/40.5/27/13.5Mbps
130/117/104/78/52/39/26/13Mbps
72/65/58.5/52/39/26/19.5/13/6.5Mbps
11g: 54/48/36/24/18/12/9/6Mbps
11b: 11/5.5/2/1Mbps
Receive
Sensitivity
135M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER

Channels
1-11 (North America)
1-13 (General Europe)
1-14 (Japan)
Transmission
Technology
BPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM)
Antenna Type
1*2.4GHz Dipole Antenna
（
1TX*1RX
）
Operation Mode
Standard Access Point; Wireless WAN mode (Client Mode Wireless),
WDS，WPS
Wireless Security
SSID Enable/Disable; MAC Address, IP and URL Filter
；
64/128/152-bit
WEP Encryption
WPA/WPA2/WPA-PSK/WPA2-PSK (AES/TKIP) Encryption
RF power
11g:14-16dbm
11b:17-19dbm
11n:13-15dbm
Chipset
RTL8196BU+8191RE
LED
1*Power, 1*CPU Status,1*Wireless, 1*WAN, 4*LAN
Management
Local/Remote Web-based configuration
Operating
Temperature 0 ~ 55℃
Storage
-20 ~ 65
℃
Humidity
5 ~ 95% non-condensing
External Power
Adapter
Input 100V~240V
Output DC5V 1A;

S
Se ec ct ti io on n T Tw wo o H Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
2.1 Panel layout
2.1.1 Front panel
The front panel of the 11N Wireless Router consists of several LED indicators, which is designed to
indicate connections.
LED indicators:
Led Name
Action
Description
Power
off
no power
on
power on
CPU
off
the router has a hardware error
flashing
the router is working properly
WLAN
off
wireless function is disabled
flashing
wireless function is enabled
WAN /LAN1 、
2、3、4
off
there is no device connected to the corresponding port
on
there is a device connected to the corresponding port
flashing
there is an active device connected to the corresponding port

2.1.2 Rear panel
2.2 System Requirements
Broadband Internet Access Service (DSL/Cable/Ethernet)
One DSL/Cable modem that has an RJ45 connector (you do not need it if you connect the router
to Ethernet)
Each PC on the LAN needs a working Ethernet Adapter and an Ethernet cable with RJ45
connectors
TCP/IP protocol must be installed on each PC
Web browser, such as Microsoft IE 5.0 or later, Netscape Navigator 6.0 or later
2.3 Installation Environment
Not in direct sunlight or near a heater or heating vent
Not cluttered or crowded. There should be at least 2 inches (5cm) of clear space on all sides of
the router
Well ventilated (especially if it is in a closet)
Operating temperature: 0℃~40℃
Operating Humidity: 5%~90%RH, Non-condensing
2.4 Hardware Installation Steps
Before you install the router, you should connect your PC to the Internet through your broadband
service successfully. If there is any problem, please contact your ISP. After that, please install the
router according to the following steps. Don't forget to pull out the power plug and keep your hands dry.
Power off your PC(s), Cable/DSL modem, and the router.
Locate an optimum location for the router. The best place is usually near the center of the area in
which your PC(s) will wirelessly connect. The place must accord with the Installation
Environment Requirements.
Adjust the direction of the antenna. Normally, upright is a good direction.
Connect the PC(s) and each Switch/Hub on your LAN to the LAN Ports on the router.
Connect the DSL/Cable Modem to the WAN port on the router.
Connect the AC power adapter to the AC power socket on the router, and the other end into an
electrical outlet. The router will start to work automatically.
Power on your PC(s) and Cable/DSL modem.

S
Se ec ct ti io on n
T
Th hr re ee e
Q
Qu ui ic ck k
I
In ns st ta al ll la at ti io on n
G
Gu ui id de e
After connecting the 11N Wireless Router into your network, you should configure it. This chapter
describes how to configure the basic functions of your 11N Wireless Router. These procedures
only take you a few minutes. You can access the Internet via the router immediately after successfully
configured.
3.1 TCP/IP configuration
The default IP address of the Wireless Router is 192.168.0.1, and the default Subnet Mask is
255.255.255.0. These values can be seen from the LAN. They can be changed as you desire, as an
example we use the default values for description in this guide.
Connect the local PC to the LAN ports on the router. There are then two means to configure the IP
address for your PC.
Configure the IP address manually
1. Set up the TCP/IP Protocol for your PC(s).
2. Configure the network parameters. The IP address is 192.168.0.xxx ("xxx" is from 2 to 254),
Subnet Maskis 255.255.255.0, and Gateway is 192.168.0.1(The router's default IP address)
Obtain an IP address automatically

1. Set up the TCP/IP Protocol in "Obtain an IP address automatically"mode on your PC(s)
2. Power off the router and PC(s). Then turn on the router, and restart the PC(s). The built-in
DHCP server will assign IP addresses for the PC(s).
Now, you can run the Ping command in the command prompt to verify the network connection
between your PC(s) and the router.
Open a command prompt, and type ping 192.168.0.1, then press Enter.
If the result displayed is similar to that shown in the top of figure, the connection between your PC
and the router has been established.
If the result displayed is similar to that shown in the top of figure, it means that your PC has not
connected to the router. Please check it following these steps:
1. Is the connection between your PC and the router correct?
2. Is the TCP/IP configuration for your PC correct?
N
No ot ti ic ce e: :If the router's IP address is 192.168.0.1, your PC's IP address must be within
the range of 192.168.0.2 ~ 192.168.0.254, the gateway must be 192.168.0.1
N
No ot ti ic ce e: :
T
Th he e 1 1/ /2 2/ /3 3/ /4 4 L LE ED Ds s o of f L LA AN N p po or rt t o on n t th he e r ro ou ut te er r a an nd d L LE ED Ds s o on n y yo ou ur r P PC C' 's s a ad da ap pt te er r
s
sh ho ou ul ld d b be e l li it t

3.2 Quick Setup wizard
With a Web-based (Internet Explorer or Netscape® Navigator) utility, the 11N 150bps Wireless
Router is easy to configure and manage. The Web-based utility can be used on any Windows,
Macintosh or UNIX OS with a web browser.
Connect to the router by typing http://192.168.0.1 in the address field of web browser.
After a moment, a login window will appear similar to that shown in Figure. Enter admin for the
User Name and Password, both in lower case letters. Then click the OK button or press the Enter
key.
Click Setup Wizard, the Setup Wizard will appear.
NOTE:
If the above screen does not prompt, it means that your web-browser has been set to a proxy. Go
to Tools menu>Internet Options>Connections>LAN Settings, in the screen that appears, cancel
the Using Proxy checkbox, and click OK to finish it.
If the User Name and Password are correct, you can configure the router using the web
browser. Please click the Setup Wizard link on the left of the main menu and the Setup
Wizard screen will appear.

The router supports three modes: gateway, bridge, wireless ISP. You can setup different modes to
LAN and WLAN interface for NAT and bridging function.
Click next, Time Zone Setting will appear. You can select the time zone what you need.

Click next, LAN Interface setup will appear. In this page, you can set IP address, Subnet Mask.
IP Address - Enter the IP address of your router in dotted-decimal notation (factory default:
192.168.0.1).
Subnet Mask - An address code that determines the size of the network. Normally use
255.255.255.0 as the subnet mask.
Click next, WAN Interface Setup will appear. In this page is used to configure the parameters for
Internet network which connects to the WAN port of your Access Point.
WAN Access Type: Here you can select the access method to static IP, DHCP, PPPoE or PPTP by
click the item value of WANAccess type.
If you choose "PPPoE", the router will automatically receive the IP parameters from your ISP without
needing to enter any parameters.
N
No ot ti ic ce e: :All PCs’ Subnet Mask is the same with router in you LAN.

User Name and Password - Enter the User Name and Password provided by your ISP.
If you choose " DHCP", the router will automatically receive the IP parameters from your ISP without
needing to enter any parameters.
If you Choose "PPTP", the Static IP settings page will appear, shown in the figure.

You can get IP Address Subnet Mask, server IP Address, User Name and Password from your ISP. If
you Choose "Static IP", the Static IP settings page will appear, shown in figure.
IP Address - This is the WAN IP address as seen by external users on the Internet (including your
ISP). Enter the IP address into the field.
Subnet Mask - The Subnet Mask is used for the WAN IP address, it is usually 255.255.255.0
Default Gateway - Enter the gateway into the box if required.
DNS - Enter the DNS Server IP address into the boxes if required.
Click next, Wireless Basic Setting will appear.
【This page is used to configure these parameters】
Band - Indicates the current mode 2.4GHz(B+G+N) , 2.4GHz(G+B),2.4GHz(B)
N
No ot ti ic ce e: :The IP parameters should have been provided by your ISP.

Mode- Default is AP, you can select Infrastructure Client or AP
SSID - Enter a value of up to 32 characters. The default SSID is Noganet, but it is recommended
strongly that you change your networks name (SSID) to a different value.
Channel –This field determines which operating frequency will be used. It is not necessary to
change the wireless channel unless you meet interference problems with another nearby access
point.
Click next, Wirelss Basic Settings will appear. This page allows you to setup the wireless security.
Turn on WEP or WPA by using Encryption Keys could prevent any unauthorized access to your
wireless network. You can select Open, WEP, WPA-PSK, WPA2-PSK.
Click Finished to finish the configuration
WPA-psk：Provides TKIP [Temporal Key Integrity Protocol] or AES [Advanced Encryption Standard].
The default is TKIP mode
WPA2-psk ：(Wi-Fi Protected Access version 2) provides higher security than WEP (Wireless
Equivalent Privacy) and WPA (Wi-Fi Protected Access).
N
No ot ti ic ce e: :If you change the parameters of wireless, The router will reboot automatically.

3.3 Operation mode
Gateway：(default) In this mode, the device is supposed to connect to internet via ADSL/Cable
Modem. The NAT is enabled and PCs in LAN ports share the same IP to ISP through WAN port. The
connection type can be setup in WAN page by using PPPOE, DHCP client, PPTP client or static IP.
Bridge: In this mode, all ethernet ports and wireless interface are bridged together and NAT function
is disabled. All the WAN related function and firewall are not supported.
Wireless ISP: In this mode, all ethernet ports are bridged together and the wireless client will
connect to ISP access point. The NAT is enabled and PCs in ethernet ports share the same IP to
ISP through wireless LAN. You must set the wireless to client mode first and connect to the ISP AP
in Site-Survey page. The connection type can be setup in WAN page by using PPPOE, DHCP client,
PPTP client, L2TP client or static IP..

S
Se ec ct ti io on n f fo ou ur r C Co on nf fi ig gu ur ra at ti io on n G Gu ui id de e
4.1 Login
After you login successful, Browser will show administrator WEB. on the left is contents. it contains:
Wireless setting, WAN Settings, LAN Settings, Network Security, System Services, Management,
Status Show ect..
4.2 Wireless Setting
It contains Wireless Basic settings, Repeater settings, Virtual AP settings, WDS Settings, Advanced
Settings, Access Control and WPS

4.2.1 Wireless Status
This page shows the current status and some basic settings of the device. you can check system
Information, Repeater Interface Information, WLAN Interface Information.
4.2.2 Wireless Basic settings
This page is used to configure the parameters for wireless LAN clients which may connect to your Access
Point. Here you may change wireless encryption settings as well as wireless network parameters.

WEP (Wired Equivalent Privacy), a basic encryption method, usually encrypts wireless data using a
series of digital keys (64 bits or 128 bits in length). By using the same keys on each of your wireless
network devices, you can prevent unauthorized wireless devices from monitoring your transmissions
or using your wireless resources. Select Mixed WEP to enter the following window
Security ： From the drop-down menu select the corresponding security encryption modes.
WEP ： Set the WEP key with the format of ASCII and Hex. You can enter ASCII code (5 or 13 ASCII
characters. Illegal character as “/” is not allowed.) Or 10/26 hex characters..
4.2.3 Repeater settings
This page is used to configure the parameters for wireless LAN clients which may connect to your Access
Point. Here you may change wireless encryption settings as well as wireless network parameters.
Mode: Default is AP
SSID: Enter a value of up to 32 characters. The same name (SSID) must be signed to all wireless
devices in your network. The default SSID is repeater, but it is recommended strongly that you
change your networks name (SSID) to a different value.
Channel: This field determines which operating frequency will be used. It is not necessary to
change the wireless channel unless you notice interference problems with another nearby access
point.

4.2.4 Virtual AP settings
This page shows and updates the wireless setting for multipleAps
4.2.5 WDS Settings
Wireless Distribution System uses wireless media to communicate with other APs, like the Ethernet
does. To do this, you must set these APs in the same channel and set MAC address of other APs which
you want to communicate with in the table and then enable the WDS.
