EVS SYNAPSE CDV29 Manual

INSTALLATION AND
CONFIGURATION
MANUAL
CDV29
REFERENCE DISTRIBUTION
AMPLIFIER(S )

INSTALLATION AND CONFIGURATION MANUAL
CDV29
Copyright
EVS Broadcast Equipment S.A. – Copyright © 2001 – 2021. All rights reserved.
Disclaimer
The information in this manual is furnished for informational use only and subject to change
without notice. While every effort has been made to ensure that the information contained in this
user manual is accurate, up-to-date and reliable, EVS Broadcast Equipment cannot be held
responsible for inaccuracies or errors that may appear in this publication.
Improvement Requests
Your comments will help us improve the quality of the user documentation. Do not hesitate to
send improvement requests, or report any error or inaccuracy on this user manual by e-mail to
[email protected].
Regional Contacts
The address and phone number of the EVS headquarters are usually mentioned in the Help >
About menu in the user interface.
You will find the full list of addresses and phone numbers of local offices either at the end of this
user manual (for manuals on hardware products) or on the EVS website on the following page:
http://www.evs.com/contacts.
User Manuals on EVS Website
The latest version of Media Infrastructure manuals are available at: https://mi-sftp.evs.com/
The user manuals for other EVS products can be found at the EVS download center, on the
following webpage: https://www.evs.com/en/download-area.

EVS Broadcast E
q
ui
p
ment SA
1
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRICAL SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE
●ALWAYS disconnect your entire system from the AC mains before cleaning any component. The product
frame (SFR18 or SFR04) must be terminated with three-conductor AC mains power cord that includes an
earth ground connection. To prevent shock hazard, all three connections must always be used.
●NEVER use flammable or combustible chemicals for cleaning components.
●NEVER operate this product if any cover is removed.
●NEVER wet the inside of this product with any liquid.
●NEVER pour or spill liquids directly onto this unit.
●NEVER block airflow through ventilation slots.
●NEVER bypass any fuse.
●NEVER replace any fuse with a value or type other than those specified.
●NEVER attempt to repair this product. If a problem occurs, contact your local EVS distributor.
●NEVER expose this product to extremely high or low temperatures.
●NEVER operate this product in an explosive atmosphere.
Warranty: EVS warrants their products according to the warranty policy as described in the general terms.
That means that EVS Broadcast Equipment SA can only warrant the products as long as the serial numbers
are not removed.
Copyright © 2001 – 2021 EVS Broadcast Equipment SA
Date created: 07-01-2008
Date last revised: 07-01-2008
EVS, the EVS logo and Synapse are trademarks of EVS Broadcast Equipment SA
This product complies with the requirements of the product family standards for audio, video, audio-visual
entertainment lighting control apparatus for professional use as mentioned below.
EN60950
EN55103-1: 1996
EN55103-2: 1996
Safety
Emission
Immunity
EVS Broadcast Equipment
CDV29
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules
Operation is subject to the following two conditions:
(1) This device may cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.

INSTALLATION AND CONFIGURATION MANUAL
CDV29
2
Introduction to Synapse 4
An Introduction to Synapse 4
Local Control Panel 4
Remote Control Capabilities 4
Unpacking and Placement 5
Unpacking 5
Locating the card 5
A Quick Start 6
When Powering-up 6
Default settings 6
Changing parameters and settings 6
Front Panel Control 6
Example of changing parameters using front panel control 7
Synapse Cortex Software 8
Menu Structure Example 8
The CDV29 Card 9
Introduction 9
Back planes 9
Miscellaneous 9
Settings Menu 10
Introduction 10
Input_sel 10
Switch-Back 10
InputGain 10
Status Menu 11
Introduction 11
Analog-Inp1 11
Analog-Inp2 11
Active-Inp 11
Events Menu 12
Introduction 12
What is the Goal? 12

EVS Broadcast E
q
ui
p
ment SA
3
CDV29 Events 12
Announcements 12
Analog_Inp1 12
Analog_Inp2 12
What information is available in an event? 12
The Message String 12
The Tag 13
Defining Tags 13
The Priority 13
The Address 13
LED Indication 14
POWER LED 14
INPUT LED 1 14
INPUT LED 2 14
Block Schematic 15
Connector Panel 16

INSTALLATION AND CONFIGURATION MANUAL
CDV29
4
1 Introduction to Synapse
An Introduction to
Synapse
Synapse is a modular system designed for the broadcast industry.
High density, intuitive operation and high quality processing are
key features of this system. Synapse offers a full range of
converters and processing modules. Please visit the EVS
Broadcast Equipment SA Website at http://www.evs.com to obtain
the latest information on our new products and updates.
Local Control Panel The local control panel gives access to all adjustable parameters
and provides status information for any of the cards in the Synapse
frame, including the Synapse rack controller. The local control
panel is also used to back-up and restore card settings. Please refer
to the RRC18, RRC10, RRC04, RRS4, RRS18 manuals for a
detailed description of the local control panel, the way to set-up
remote control over IP and for frame related settings and status
information.
Remote Control
Capabilities
The remote control options are explained in the rack controller
(RRC18/RRC10/RRC04/RRS04/RRS18) manual. The method of
connection to a computer using Ethernet is described in the RRC
manual.
! CHECK-OUT: “SYNAPSE CORTEX” SOFTWARE
WILL INCREASE SYSTEM FLEXIBILITY OF ONE OR
MORE SYNAPSE FRAMES
Although not required to use Synapse Cortex, you are strongly
advised to use a remote personal computer or laptop PC with the
Synapse Cortex software as this increases the ease of use and
understandin
g
of the modules.

EVS Broadcast E
q
ui
p
ment SA
5
2 Unpacking and Placement
Unpacking The EVS Synapse card must be unpacked in an anti-static
environment. Care must be taken to NOT to touch component on
the card – always handle the card carefully by the edges. The card
must be stored and shipped in anti-static packaging. Ensuring that
these precautions are followed will prevent premature failure from
components mounted on the board.
Locating the card The Synapse card can be placed vertically in an SFR18 frame or
horizontally in an SFR04 frame. Locate the two guide slots to be
used, slide in the mounted circuit board, and push it firmly to
locate the connectors.
Correct insertion of card is essential as a card that is not located
properly may show valid indicators, but does not function
correctl
y
.
REMARK: On power up all LEDs will light for a few seconds,
this is the time it takes to initialise the card.

INSTALLATION AND CONFIGURATION MANUAL
CDV29
6
3 A Quick Start
When Powering-up On powering up the Synapse frame, the card set will receive basic
data and default initialisation settings. All LEDs will light during
this process. After initialisation, several LEDs will remain lit – the
exact number and configuration is dependant upon the number of
inputs connected and the status of the inputs.
Default settings In its default condition, the CDV29 will act as a Reference
distribution amplifier.
Changing
parameters and
settings
The front panel controls or the Synapse Cortex Software can be
used to change settings. An overview of the settings can be found
in chapter 5, 6 and 7 of this manual.
Front Panel Control Front Panel Display and Cursor
Settings are displayed and changed as follows;
Use the cursor ‘arrows’ on the front panel to select the menu and
parameter to be displayed and/or changed.
Press ►To
g
o forward throu
g
h the menu structure.
Press ◄To
g
o back throu
g
h the menu structure.
Press ▲To move up within a menu or increase the value of
a parameter.
Press ▼To move down through a menu or decrease the
value of a parameter.
REMARK: Whilst editing a setting, pressing ►twice will reset
the value to its default.
[No Alarms]

EVS Broadcast E
q
ui
p
ment SA
7
Example of
changing
parameters using
front panel control
With the display as shown below
Pressing the ►selects the SFS10 in frame slot 01.
The display changes to indicate that the SFS10 has been selected.
In this example the Settings menu item is indicated.
Pressing the ►selects the menu item shown, in this example
Settings.
(Pressing ▲or ▼will change to a different menu eg Status,
Events).
The display changes to indicate that the SFS10 Settings menu
item SDI-Format has been selected and shows that it current
setting is Auto.
Pressing the ►selects the settings item shown, in this example
SDI-Format.
(Pressing ▲or ▼will change to a different setting, eg Mode,
H-Delay).
The display changes to indicate that the SFS10 Edit Setting
menu item SDI-Format has been selected.
To edit the setting of the menu item press ▲or ▼.
All menu items can be monitored and/or changed in this way.
Chan
g
in
g
a settin
g
has an immediate effect.
RRC18 [Select Card]
>S01=SFS10
SFS10 [Select Menu]
>Settings
SFS10 [Settings]
>SDI-Format=Auto
SFS10 [Edit
Setting]

INSTALLATION AND CONFIGURATION MANUAL
CDV29
8
Synapse Cortex
Software
Synapse Cortex Software can be used to change the settings of
Synapse modules from a PC, either locally or remotely. The
software enables communication based on TCP/IP between the
setup PC and Synapse frames/modules.
Each Synapse frame is addressed through its rack controller’s
unique IP address, giving access to each module, its menus and
adjustment items. The Cortex software has access to data
contained within the Synapse module and displays it on a GUI.
The software has an intuitive structure following that of the
module that it is controlling.
A description of how Cortex works can be found in the Cortex
manual, which is downloada
b
le via our website.
Menu Structure
Example
Slot Module Item Paramete
r
Settin
g
▲
▲
S02 Identit
y
▲▲
S01 SFS10 ►Settings ►SDI-
Format
►Auto
▼▼▼▼
S00 RRC18 Status Mode 625
▼▼▼
Events Ref-Input 525
▼
H-Dela
y
▼
▼
REMARK: Further information about Front Panel Control and
Synapse Cortex Software can be obtained from the RRC18,
RRC10, RRC04, RRS04, RRS18 and Cortex operational manuals.

EVS Broadcast E
q
ui
p
ment SA
9
4 The CDV29 Card
Introduction The EVS CDV29 is an analog reference distribution amplifier
providin
g
a low loss electronicall
y
balanced input.
Back planes The CDV29 can be used with a BPL01 back plane. If the BPL01 is
used then the CDV29 have nine outputs.
Miscellaneous The CDV29 cards fit into the EVS SFR18 or SFR04 rack.
LEDs at the front of the board indicate the presence of power and
input signal.
The CDV29 can be controlled by EVS Synapse Cortex software.
Refer to menu structure for control.

INSTALLATION AND CONFIGURATION MANUAL
CDV29
10
5 Settings Menu
Introduction The settings menu displays the current state of each setting within
the CDV29 and enables the item to be changed or adjusted.
Settings can be changed using the front panel of the Synapse
frame (SFR18 or SFR04) or Synapse Cortex software.
Please refer to chapter 3 for information on the Synapse front
panel control and S
y
napse Cortex software
Input_sel This setting allows the user to determine which reference input is
distributed to the outputs. Choices are Ref1 or Ref2. Input 1 is
the uppermost input of the RRC18 rack controller connection
panel at the rear of the SFR18; 2 is the bottom input. The SFR04
has only one reference input, so the input selection has no
influence on the outputs of the card when using an SFR04.
The option Auto makes the input selection automatically with
Ref1 as priority (so when there is a reference on both inputs, Ref1
will be selected). Whenever Ref1 is lost, Ref2 is automatically
selected.
When the input which you selected with Input_sel is lost, the
CDV29 will automaticall
y
use the othe
r
input.
Switch-Back Switch-Back can be set On or Off.
When Switch-Back is set to On and Input_sel is set
auto, and a change over to channel 2 has occurred (so input 1
was lost), the card will immediately switch back to Ref1 when
Ref1 is OK again.
When Switch-Back is set to Off and a change over to Ref2
has occurred, the input_sell will stay on Ref2 no matter if Ref1 is
back up again, so in this state the card will always stay on Ref2
when a switch-over has occurred (unless Ref2 is lost).
The default setting is Off.
InputGain With GainCtrl set to manual InputGain allows the signal
present at the input to be amplified or attenuated within the range
–6dB to 6dB. The default setting is 0dB.

EVS Broadcast E
q
ui
p
ment SA
11
6Status Menu
Introduction The status menu indicates the current status of each item listed
b
elow
Analog-Inp1 This status item displays if there is a signal present or not (NA)
on reference input 1.
Analog-Inp2 This status item displays if there is a signal present or not (NA)
on reference input 2.
Active-Inp This status item displays the currently used reference input
(Ref1 or Ref2). This status will display NA shortly after the
start-up of the card, shortly after the correct reference input will
b
e indicated.

INSTALLATION AND CONFIGURATION MANUAL
CDV29
12
7 Events Menu
Introduction An event is a special message that is generated on the card
asynchronously. This means that it is not the response to a request
to the card, but a spontaneous messa
g
e
What is the Goal? The goal of events is to inform the environment about a changing
condition on the card. A message may be broadcast to mark the
change in status. The message is volatile and cannot be retrieved
from the system after it has been broadcast. There are several
means b
y
which the messa
g
e can be filtere
d
CDV29 Events The events reported by the CDV29 are as follows;
Announcements ‘Announcements’ is not an event. This item is only used for
switching the announcement of status changes on/off. 0=off,
other =o
n
Analog_Inp1 Analog_Inp1 can be selected between 0 .. 255. 0= no event,
1..255 is the priorit
y
settin
g
.
Analog_Inp2 Analog_Inp2 can be selected between 0 .. 255. 0= no event,
1..255 is the priorit
y
settin
g
.
What information is
available in an
event?
The message consists of the following items;
1) A message string to show what has happened in text, for
example: “INP_LOSS”, “REF_LOSS”, “INP_RETURN”.
2) A tag that also shows what happens, but with a predefined
number: e.g. 1 (= loss of input), 2 (= loss of reference), 129(=
1+128 = return of input). For a list of these predefined tags
see the table on the next page.
3) A priority that marks the importance of an event. This value is
defined by the user and can have any value between 1 and
255, or 0 when disabled.
4) A slot number of the source of this event.
The Message String The message string is defined in the card and is therefore fixed. It
may be used in controlling software like Synapse Set-up to show
the event.

EVS Broadcast E
q
ui
p
ment SA
13
The Tag The tag is also defined in the card. The tag has a fixed meaning.
When controlling or monitoring software should make decisions
based on events, it is easier to use the tag instead of interpreting a
string. The first implementation is the tag controlled switch in the
GPI16.
In cases where the event marks a change to fault status (e.g. 1 for
Loss of Input) the complement is marked by the tag increased by
128 (80hex) (e.
g
. 129 (81hex) for Return of Input).
Defining Tags The tags defined are:
Event Menu Item Ta
g
Descriptio
n
Announcements 0 or NA 0 or NA Announcing of report
and control values
Input 01hex=INP_LOSS 81hex=INP_RETURN primary input lost or
returned
The Priority The priority is a user-defined value. The higher the priority of the
alarm, the higher this value. Setting the priority to Zero disables
the announcement of this alarm. Alarms with priorities equal or
higher than the Error Threshold setting of the RRC will cause the
error LED on the S
y
napse rack front panel to li
g
ht.
The Address Together with the message string or the tag, the slot number or
address of the card is relevant to be able to assign the event to a
certain card.

INSTALLATION AND CONFIGURATION MANUAL
CDV29
14
8 LED Indication
POWER LED The power LED indicates the presence of power on the CDV29.
INPUT LED 1 This LED indicated the presence of a valid analog video signal on
the input 1.
INPUT LED 2 This LED indicated the presence of a valid analog video signal on
the input 2.

EVS Broadcast E
q
ui
p
ment SA
15
9 Block Schematic
Ra c k
controller
CDV2 9
I N TERN A L SYN A PSE BU S
REFEREN CE O U T 1
µP
REFEREN CE O U T 2
REFEREN CE O U T 3
REFEREN CE O U T 4
REFEREN CE O U T 5
REFEREN CE O U T 6
REFEREN CE O U T 7
REFEREN CE O U T 8
SI GN A L
RESTORE
GAIN
REFEREN CE O U T 9
Re f e r e n c e
inputs
12

INSTALLATION AND CONFIGURATION MANUAL
CDV29
16
10 Connector Panel
The CDV29 can be used with the following backplanes: BPL01.
!Unused outputs must be terminated with the
correct impedance!
BPL01
REFERENCE OUTPUT 1
REFERENCE OUTPUT 2
REFERENCE OUTPUT 3
REFERENCE OUTPUT 4
REFERENCE OUTPUT 5
REFERENCE OUTPUT 6
REFERENCE OUTPUT 7
REFERENCE OUTPUT 8
REFERENCE OUTPUT 9
