Excel Technology EXO150XG1 User manual

Open Frame TFT LCD Monitor
EXO150XG1
Operating Manual
Excel Technology International Corporation
4 Stryker Lane
Suite 5
Hillsborough, NJ 08844
Tel: [phone]
Fax: [phone]
Toll Free: [phone]
Email: [e-mail]
This Technical Specification is subject to change without notice

Excel Technology International Corporation
- 1 -
MODEL NO.EXO150XG1
Installation
Before Installing the TFT-LCD Monitor
When you open the package, check the following items.
1. DC Adaptor
2. R.G.B. Cable 15 pin D-Sub cable
3. Video Cable
4. Audio Cable
5. Power Cord (220V or 120V AC)
Back and Side of the Monitor (Name & Purpose)
1. D-Sub 15 pin R.G.B. Analog input Terminal
* Connect the enclosed D-Sub Signal Cable
2. Video Input Port
* Connect the enclosed RCA phone jack
3. Audio Input Port
* Connect the enclosed Audio Cable with Audio Output Port of the
Computer.
4. Audio Out Port
* Connect the enclosed Audio Cable with Audio Input Port of the Speaker.
5. Power Input Socket
* Connect the enclosed DC Power Adaptor (12V DC)
Installing the Monitor
1. Make sure that the computer and the monitor are turned off.
2. Connect one side of signal cable with the 15 pin D-Sub port of the
computer and screw down.
3. Connect the other side of cable with the 15 pin D-Sub connect terminal at
the rear of the monitor and screw down.
4. Connect one side of Video Signal cable with the RCA phone jack port of
the DVD player and PAL or NTSC system.
5. Connect the other side of cable with the Audio Connect terminal at rear of
the monitor. (Input & Output)

Excel Technology International Corporation
- 2 -
Front of the Monitor and Monitor Adjustment
Control Unit of the Monitor (Name & Purpose)
1. MENU button: This makes the On Screen Display (OSD) appear and
Disappear.
2. UP(!), DOWN(") button: This is used to adjust the selected value up
and down, also used as Volume up and down.
3. LEFT(#), RIGHT($) button: This is used for OSD function selection.
4. Power Switch button: When the power switch is on, the power is
supplied and the power light is on. Press again to turn off the monitor.
Direct Adjustment:
This is a direct shortcut function by pressing buttons, when you press the
MENU button after adjusting, the OSD will disappear.
Volume Adjustment:
1. When you press UP(!) or DOWN(") button when the OSD is not
displayed, volume adjustment will appear
2. UP(!) button turns up the volume and DOWN(") button turns down
the volume.
Auto-Config (Automatically adjust the size and noise of the screen to the
optimal condition.)
Screen is displayed connecting the computer with the monitor when you
press AUTO button or LEFT button (#) (without OSD active). The current
VGA signal, screen location, size, and noise will be adjusted automatically.

Excel Technology International Corporation
- 3 -
Menu Adjustment
Select items to adjust from the Main Menu. When you press MENU button
after adjusting, OSD will disappear.
Brightness Adjust the brightness level of image or the background of
letters. (The brightness of image or letter itself is changed.)
1. Press MENU button without OSD. Press #or $button until is
selected.
2. DOWN(") button will darken the screen and UP(!) button will lighten
the screen.
Contrast Adjust the contrast of an image or letter.
1. Press MENU button without OSD. Press #or $button until is selected.
2. DOWN(") button will dim the image and UP(!) button will clarify the
image.
Horizontal Position Move the screen in the horizontal direction.
1. Press MENU button without OSD. Press #or $button until is
selected.
2. After selecting , press UP(!) or DOWN(") button to move the screen
to right or left side.
Vertical Position Move the screen in the vertical direction.
1. Press MENU button without OSD. Press #or $button until is
selected.
2. After selecting , press UP(!) or DOWN(") button to move the screen
to upward or downward.
Image CLK Adjust detailed clarity of the screen or the horizontal size.
1. Press MENU button without OSD. Press #or $button until is
selected.

Excel Technology International Corporation
- 4 -
2. After selecting , increase or decrease the selected item by pressing
UP(!) or DOWN(") button to adjust it to the optimal level.
Phase Adjustment Adjust the vertical direction phase.
1. Press MENU button without OSD. Press #or $button until is
selected.
2. After selecting , increase or decrease the selected item by pressing
UP(!) or DOWN(") button to adjust it to the optimal level.
The Proper value of this item during monitor adjustment is 35% - 85%.
1. Unless the Phase is adjusted, unstable horizontal noise appears on
the screen and the thick traces are displayed.
2. These can be removed by adjusting Phase.
(If this is not easy, press the AUTO-Config button.)
Screen Color Customize the background color of the screen.
1. Press MENU button without OSD. Press #or $button until is
selected.
2. When you press UP(!) or DOWN(") button after selecting button, the
Color adjustment appears. When you press #or $button again, the
screen color temperatures of 9,300K, 6,500K and USER(R.G.B) are
displayed. Users can adjust the color at the USER status. Press UP(!) or
DOWN(") button to adjust the color. USER colors are Red, Green, and
Blue.
Signal Level The input signals can be adjusted according to the size of
the output signal of the origin (user’s computer).
1. Press MENU button without OSD. Press #or $button until is
selected.
2. Select the item by pressing UP(!) or DOWN(") button.
Language Selection Select the language of the OSD.
1. Press MENU button without OSD. Press #or $button until is
selected.
2. Select the language by pressing UP(!) or DOWN(") button.
- Note: The explanation of OSD adjustment is based on the
English version. Thus, select English OSD if possible.
AUTO Screen Adjustment Adjust the screen size and remove the noise
automatically.
1. Press MENU button without OSD. Press #or $button until is
selected.

Excel Technology International Corporation
- 5 -
2. Select is adjusted automatically while pressing UP(!) or DOWN(")
button.
Menu Position of OSD Move the OSD position.
1. Press MENU button without OSD. Press #or $button until is
selected.
2. Press MENU button again and press #, $, !, "buttons to adjust the
OSD position.
3. When you press MENU button after finishing the adjustment, this menu is
released.
Current Status Information Informs user of the current status of the
monitor.
1. Press MENU button without OSD. Press #or $button until is
selected. The current horizontal and vertical frequency of the monitor will
be displayed on the screen.

Excel Technology International Corporation
- 6 -
Specification of TFT LCD Monitor (EXO150XG1)
LCD Panel 15” Color TFT-LCD Panel (Samsung : LTM150XH-
L04)
Type Active Matrix
Resolution 1024 x 768
Display Color 16 million color (Dithering ON)
Response Time 20ms
Color Tone 64 Tone
Face Finishing Anti-Glare Hard Coated
EXO150XG1
Viewing Angle (L/R, T/B) 15” Samsung : 70/70, 55/65
R.G.B. Analog Input 0.7V p-p R.G.B. Analog
Sync 2.5V to 4V p-p separated sync
Input Signal Audio Input Stereo L, R 2W output
Horizontal 15.75KHz to 69KHz (CGA/ EGA / VGA / SVGA /
XGA)
Scanning
Frequency Vertical 56Hz to 85Hz
Display Size H x V 304.1 x 228.1
Brightness 200 cd/m²
Gray Scale 64 Gray Scale
Optical
Characteristics Contrast Ratio 250 : 1
RGB Analog Input D-sub 15 pin
Audio Input Ear Phone Jack (Input and Output)
MTBF 15,000 Hr (typical)
Display Monitor DC12V 3APower Source AC Adapter AC100V – 240V
Weight Open Frame 5.5 Kg
Accessory DC Power Supply Adapter, RGB Signal Cable, Audio Cable
Safety Standard UL, FCC, CE, TCO99, CB, MPRII, Energy Star, GS
