Samsung 225BW - SyncMaster - 22" LCD Monitor User manual

ii
LCD MONITOR
quick start guide
225BW

Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local deale
r
to bu
y
o
p
tional items.
Unpacking
Type 1
Monitor & Slidin
g
Stand
Type 2
Monitor & Speaker(option)
& Slidin
g
Stand
Manual

Quick Setup Guide
Warranty Card
(Not available in all
locations)
User's Guide,
Monitor Driver,
Natural Color software,
Ma
g
icTune™ software
Cable
D-sub Cable Power Cord DVI Cable
(
o
p
tion
)
S
p
eaker
p
acka
g
e
(
o
p
tion
)
S
p
eaker
Front
MENU button [ ]
Opens the OSD menu. Also use to exit the OSD menu or return to
the previous menu.

MagicBright™
[]
MagicBright™ is a new feature providing optimum viewing
environment depending on the contents of the image you are
watching. Currently six different modes are available: Custom,
Text, Internet, Game, Sport and Movie. Each mode has its own
pre-configured brightness value. You can easily select one of six
settings by simply pressing MagicBright™ control button.
1) Custom
Although the values are carefully chosen by our engineers,
the pre-configured values may not be comfortable to your eyes
depending on your taste.
If this is the case, adjust the brightness and contrast by using
the OSD menu.
2) Text
For documentations or works involving heavy text.
3) Internet
For working with a mixture of images such as texts and
graphics.
4) Game
For watching motion pictures such as a game.
5) Sport
For watching motion pictures such as a sport.
6) Movie
For watching motion pictures such as a DVD or Video CD.
>>Click here to see an animation clip
Brightness button
[]
When OSD is not on the screen, push the button to adjust
brightness.
Adjust buttons [ ] Adjust items in the menu.
Enter button [ ] /
Source button
Activates a highlighted menu item. /
Push the ' ', then selects the video signal while the OSD is off.
(When the source button is pressed to change the input mode, a
message appears in the upper left of the screen displaying the
current mode -- analog or digital input signal.)
Note : If you select the digital mode, you must connect your monitor
to the graphic card's DVI port using the DVI cable.
AUTO button Use this button for auto adjustment.
Power button [ ]/
Power indicator
Use this button for turning the monitor on and off. /
This light glows blue during normal operation, and blinks blue
once as the monitor saves your adjustments.
See PowerSaver described in the manual for further information regarding power saving
functions. For energy conservation, turn your monitor OFF when it is not needed, or when
leaving it unattended for long periods.
Rear

(The configuration at the back of the monitor may vary from product to product.)
POWER IN Connect the power cord for your monitor to the power port on the back
of the monitor.
DVI IN Connect the DVI Cable to the DVI port on the back of your monitor.
RGB IN Connect the signal cable to the 15-pin, D-sub port on the back of your
monitor.
ON [ | ] / OFF [O]
Switch the monitor on and off.
Kensington Lock The Kensington lock is a device used to physically fix the system
when using it in a public place. (The locking device has to be
purchased separately. )
For usin
g
a lockin
g
device, contact where
y
ou
p
urchase it.
See Connecting the Monitor for further information regarding cable connections.

Connecting the Monitor
1. Connect the power cord for your monitor to the power port on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
2. Use appropriate connection for your computer.
2-1. Using the D-sub (Analog) connector on the video card.
Connect the signal cable to the 15-pin, D-sub port on the back of your monitor.
[ RGB IN ]
2-2. Using the DVI (Digital) connector on the video card.
Connect the DVI Cable to the DVI Port on the back of your Monitor.
[ DVI IN ]
2-3. Connected to a Macintosh.
Connect the monitor to the Macintosh computer using the D-sub connection cable.
If the monitor and the computer are connected, you can turn them on and use them.

Connecting a Speaker
When connecting a speaker, be careful that the grooves of the monitor and the speaker
( ) are aligned with each other.
Adjust the aligned positions until you hear a ‘click’. If a speaker is connected correctly, you
can hear a ‘click’.If a speaker is connected without you hearing a ‘click’, the holding part
may become damaged.
1. Connect the power line connected to the speaker to the black terminal of the monitor.
This speaker is not connected to an external power source. It is connected to a monitor for
the required power.
2. Connect the light green cable of the cables provided when purchasing the speaker to the
audio output terminal at the back of the computer.
Connect the other end of the cable to the light green terminal at the back of the speaker.
3. Connect the red cable of the cables provided when the speaker was purchased to the audio
output terminal at the back of the computer.
Connect the other end of the cable to the red terminal at the back of the speaker.
4.
By turning part ( ) in the direction shown in the figure below, the speaker turns on and the
volume increases.
5.

For removal, push and lift up part ( ) towards the inside and remove it. Failing to do so may
damage the unit.
6.
Connect a headphone to the black terminal at the right of the speaker.
Connect a microphone to the red terminal at the right of the speaker.
Using the Stand
Slidin
g
Stand
Stand Stopper
Swivel stand

Using ( ),You can swivel the monitor left and right at an angle of 330 ° to set the monitor
lengthwise. The rubber under the stand is to avoid the monitor slide.
Tilt an
g
le
Using ( ), You can adjust the tilt angle forward and backward for the most comfortable viewing
angle.
Removin
g
the base
1. Turn off your monitor and unplug its power cord.
2. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the
screen.
3. Remove two screws ( ) and then remove the Stand from the LCD monitor.

Attaching a Base
This monitor accepts a 100 mm x 100 mm VESA-compliant mounting interface pad.
A. Monitor
B. Mounting interface pad (Sold separately)
1. Turn off your monitor and unplug its power cord.
2. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the
screen.
3. Remove two screws and then remove the stand from the LCD monitor.
4. Align the mounting interface pad with the holes in the rear cover mounting Pad and secure it
with four screws that came with the arm-type base, wall mount hanger or other base.
To mount the monitor on a wall, you should purchase the wall mounting kit that allows
you to mount the monitor at least 10 cm away from the wall surface.
Contact the nearest Samsung Service Center for more information.
Samsung Electronics will not be responsible for damages caused by using a base other
than those specified.
Please use Wall Mount according to the International standards.
