EXCURSION SHX User manual

SH HIGH POWER COMPONENT SPEAKERX
EASCA
E
UROPEAN
A S
UTO OUND
A
SSOCIATION
...is all you need ...is all you need
EXCURSION CHPW - A Division of
All Rights reserved - Intl. Trademark No: 010 640 597
Friedrich-Ebert-Str. 42 - D-92637 Weiden / Germany
3OHM

1
EXCURSION
CONGRATULATIONS !
Dealer's Name____________________________
Date of Purchase__________________________
Installaon Shop__________________________
Installaon Date __________________________
CAUTION !
You now own an High Power Component System, the product
of an uncompromising design and german engineering philosophy. A product made
from Car Audio fanacs who truely believe in the relentless pursuit of perfecon.
speakers are the result of several decades of product improvements,
compeon, innovaon and highest quality parts and control standards in industry.
When properly installed these speakers will provide you with many years of
listening pleasere and are the perfect balance between high fidelity, extreme
performance and long-lasng reliabilty.
Should your speaker ever need a service, Please record your informaon on
the following lines to refer to in the event that you may need it later.
At Intl. we are confident you will have many years of outstanding
enjoyment from your high performance investment. For maximum performance
we recommend that you have your new Speakers installed by
an exclusive Authorizied Dealer
To learn more about , please visit us on the World Wide Web at
hp://www.excursion.us
EXCURSION SHX
EXCURSION
EXCURSION
EXCURSION SHX
EXCURSION
EXCURSION
Connous exposure to sound pressure levels in excess of 100dB can cause permanent hearing loss. Speakers are capable
of producing sound pressure levels well over 170dB. Please observe all local sound ordinances while listening to your System.
Intl. acceptss no liability for hearing loss, bodily injury, or property damage due to the result of use or missuse of this product.
EXCURSION
EXCURSION
EXCURSION
2
2-Layer Wool Fibre Composite Cone: For the Sound Quality of our advanced
high efficient Upgrade Design we have researched carefully for an even lighter
vital wool fibre material. In composite with our proven paper former this is the
most natural material and choice. With a decrease aprox 10% in weight and an
increase of sffness and the vitality of the cone surface our cone Design step
up the already outstanding fine dynamic and resoluon of our well known Series.
Together with a 25% stronger motor set an even higher benchmark for the best
Upgrade Design for speakers up to 100 /300 Wa Music Power Handling.
effect in higher resoluon of vocal mid secon at none
axial or difficult speaker posion, while reducing unwanted distoron and losses.
The steel baskets are sized
for easy Upgrade Replacement. Their symmetrical design together with the
stamped logos ensure outstanding stac, aerodynamic and sffness.
Coated with black anvibraon colour the baskets are acouscal deaden to provide
best results. We at took especially care of maximum cooling of voice coil.
All baskets are symmetrical vented below the spider for maximum heat transfer,
knowing that a cool voice coil is able to take more power and handle more power.
For our advanced high efficient Upgrade Design we
have researched to lower the Voice Coil impedance to 3Ohm, which step up in aprox
25% more power supply from most amplifiers on the market. From the decrease of
impdeance we could benefit and balance with thicker copper wire of voice coil and
step up once more in higher power handling. But as we are and the
best is not enough, we have pole piece vented all motors for extra cooling and are
seng new standards with taking over aluminium former top venlaon technology
for all component and coaxial speaker from our High Power Subwoofers.
The outstanding performance of the
Tweeters set the biggest difference to the competors in the Car Audio market.
Using the finest materials of Pure silk with perfect lineary, the
Tweeters love to get compared with the leading audiophile`s in the world.
We at have designed the
smartest high quality crossover soluon possible. We focus on the most important
and are using best parts and cables which can get plugged in various combinaons.
Compareable to the Voice Coil we could increase the copper wire diameter of our
magnet core low pass coil caused of lowered 3Ohm impedance and step once more
up in Power Handling. With our Single way crossovers inliners and a range of level
resistors the system is prepared for demands of Bi-Wiring and level tuning on demand.
SHX
OEM
SHX
SX
SHX
OEM RMS
Phased Plug Dustcap Design:
OEM
DIN sized fully vented Steel Basket: EXCURSION DIN
OEM
EXCURSION
EXCURSION
3Ohm Voice Coils: SHX OEM
EXCURSION
SHX SHX
Pure Silk, So Dome Tweeter: EXCURSION
EXCURSION
EXCURSION
One way Hide Away Plug&Play Crossovers: EXCURSION
EXCURSION SHX SPEAKER FEATURE

3
EXCURSION
It is recommend that you have your new Series Automove
Speakers professionally installed by your authorizied dealer. This
will ensure use of proper installaon techniques and materials and save much
me and efforts. If you choose to perform your own installaon, the following
instrucon will give you direcon toward making your purchase complete. Read
the following informaon and precauons carefully.
EXCURSION SHX
EXCURSION
Failure to follow the stated
precauons may result in personal injury or damage the audio system or vehicle.
A.) Always make sure the speaker will easily fit into the intended mounng locaon
and that there is adequate cavity depth to accept the magnet structure.
B.) Check for adequate clearance between speaker and window, window crank,
power window mechanism, seat, glove box, rear deck torsion bars and other
items which may interfere with the speaker`s mounng. This is especially
important if any hole cung is required. Complete speaker, mounng size and
depth requirements can be found on page 9 of these instrucons. A good way to
confirm speaker place meet on a door or body panel is to place the speaker`s
die cast mounng ring onto the surface. Check for a flat mounng surface,
free from all obstrucon.
C.) The method of installaon choosen and level of execuon will effect the
overall performance of the Speakers. Thread each installaon
step with a high degree of aenon.
D.) Do not mount the speaker where water may splash the woofer cone.
A plasc cup or some heavy gauge plasc sheeng may be needed in some
locaons that are exposed to moisture from behind the body panel.
E.) Care must be taken to prevent low frequency cancelaon caused by air
leakage between the front and rear of the speaker (such as when mounted
on a curved or uneven surface, or when mounted in an oversized hole)
F.) Mounng panel reinformcement may be necessary in some cases in order
to prevent surface flex. This can be achieved by mounng the speaker on a
metal or wooden sub-baffle behind the body or door panel.
EXCURSION
Consult an installaon specialst for further direcon.
Pre-Installaon Instrucons:
4
G.) Unless you are replacing exisng speakers of same size, mounng locaons
will have to be cut into the doors, body panels or rear deck. In some cases
speaker mounng holes will be precut in the doors, bodypanels, or rear
deck steel. Due to their structural integrity and accessibility. These precut
mounng holes should be used whenever possible.
: IMPORTANT Never cut any metal that is an integral part of an automobile`s
safety or structural support system.
: NOTE EXCURSION strongly recommends that you operate the complete
audio system at low volume before final installaon of your Series
Automove Loudspeakers. This will allow a trial listening test before
securing the loudspeakers into their mounng locaons.
Make sure that all speaker wiring is fully protected from cung
or wear. Any short circuits developing as a result could severaley damage
the radio unit or amplifier. Make sure that all speaker wires easily reach the
speaker terminals without stress on the wire or connectors.
SX
CAUTION:
PREPARING FOR INSTALLATION
Note: The tools listed below may be required for proper installaon.
* An elecric drill with drill bits
* Phillips-head and standard screwdrivers
* Crimping tool and needle-nose pliers
* Silicon sealant or closed cell weather-stripping
* Metal file, Hole saw, Tin Snips, Wire strippers
INSTALLATION PRECAUTIONS
Note: Proceed only if you are a qualified installer otherwise let your dealer do it.
* Always wear protecve eyewear when using tools
* Turn all stereo and other electrical devices before you begin
* Disconenect the (-) negave lead from your vehicle`s baery.
* Keep the speakers in the package unl final installaon.
* Locate fuel lines, brake lines, oil lines, electrical cables when planning installaon.
* Check to see clearance behind the mounng surface before installing speakers.
* When running speaker wires through sheet metal, be sure to use gromments
to properly insualte the wires from metal edges.
OFF

146
EXCURSION LIMITED WARRANTY POLICY
EXCURSION EXCURSION Intl. offers limited warranty on products under normal use on the following terms:
.
This warranty applies only to products sold to consumers by Authorizied Dealers
in Germany. Products purchased by consumers from an dealer in another country are covered
only by that country´s Distributor and not by Intl.
This warranty covers only the original purchaser of product. In order to receive service, the
purchaser must provide with the receipt stang the consumer name, dealer, product and date
of purchase.
Products found to be defecve during the warranty period will be repaired or replaced (with a product
deemed to be equivalent) at Excursion`s discreon and will not be liable for incidental or consequenal
damages. will not warranty this product under the following situaons:
EXCURSION Speakers are to be free of defects in material and workmanship for a period of one year
EXCURSION EXCURSION
EXCURSION
EXCURSION
EXCURSION
EXCURSION
EXCURSION
* Speakers received with bent frames or water damages
* Abuse such as holes in the cone, surround or ripped spider
* Voice coil damage due to amplifier clipping or distoron
* Product that has not been installed according to this owner manual
Any implied warranes including warranes of fitness for use and merchantability are limited in duraon
to the period of the express warranty set forth above. No person is authorizied to assume for
any other liability in connecon with the sale of this product.
EXCURSION
Please call prior your authorizied dealerEXCURSION the product got purchased. In case they
are not accessible call ++49-9603-903-752 for Customer Service. You must obtain an EXCURSION
RA EXCURSION RA# (Return Authorizaon Number) to return any product to Intl. The number must
be prominently marked on the outside of the shipping carton or the delivery will be refused.
Please pack your return carefully! We are not responsibile for items damaged in shipping.
Return the defecve product along with a copy of the original dated retail sales receipt, plus 10,-
for handling and diagnosc evaluaon to:
EUR
EXCURSION CHPW Intl. - A Division of
An: Returns ( # ........................ )
Neustaedter Str. 20
D-92685 Floss / Germany
RA
EXCURSION
