Exmark METRO User manual

PARTS MANUAL
METRO
Date Purchased
Engine Model No. and Spec. No.
Engine Serial No. (E/No)
Model No.
Serial No.
The Serial No. plate is located on the top front engine frame on
the right hand side of the machine. For ease of ordering and
reference, we suggest that you record the information requested.
Place Model No. And Serial No.
Label Here (Included in Literature
Pack) or Fill in Below
®
Part No. 4500-204 Rev. A
For Serial Nos.
720,000 & Higher

1
EXMARK PARTS PLUS®PROGRAM
EFFECTIVE DATE: September 1, 1995
Program
If your Exmark dealer does not have the Exmark part in stock,
Exmark will get the parts to the dealer the next business day or
the part will be FREE* Guaranteed!!
How the Program Works
1. If dealer does not have part in stock for a "down" unit
at the time of request by customer, the dealer contacts
his distributor by 1:00 p.m., local time, and requests
Exmark Parts Plus®shipment of six (6) line items or
less.
2. Distributor ships part(s) to dealer or customer, as requested by dealer, same day, overnight UPS Distributor bills
dealer for part and freight charges where applicable.
3. If distributor does not have the part(s) in stock to satisfy Exmark Parts Plus®order, he contacts Exmark by 3:00 p.m.,
central time, with an Exmark Parts Plus®order of six (6) line items or less.
4. If order is received by 3:00 p.m. central time, Exmark ships part(s) direct to dealer or customer, as requested by
distributor, same day, overnight UPS Exmark bills the distributor for parts and shipping charges, where applicable.
5. The customer pays for the part and freight if it is shipped under the Exmark Parts Plus®and if it arrive in accordance
to the program.
6. Who pays for the part and freight if it fails to arrive overnight in accordance to the program?
A. Under any circumstance the customer does not pay.
B. If the part does not arrive overnight due to:
1. The dealer not submitting the Exmark Parts Plus®order to his Exmark distributor by 1:00 p.m., the dealer
pays for the part and freight.
2. The Distributor being unable to ship the part the same day or not submitting the Exmark Parts Plus®order to
Exmark by 3:00 p.m., central time, the Distributor pays for the part and freight.
3. Exmark being unable to ship the part and the Exmark parts order is received by 3:00 p.m., central time,
Exmark pays for the part and freight.
4. If the part does not arrive overnight due to the shipper (UPS), the shipper pays for the freight and Exmark
pays for the part.
The following restrictions apply -- The Exmark Parts Plus®Program is available only through participating Exmark
Dealers and applies only to orders submitted on this program Monday through Thursday. Parts Plus service is available only
in the 48 contiguous United States. UPS has initiated a Saturday delivery program to many areas of the continental United
States and can be requested for an overnight shipment on Friday to be delivered Saturday. The next day air charge, plus the
Saturday delivery fee will be the responsibility of the purchaser. Exmark Mfg. will assume no responsibility for Saturday
delivery shipments. To qualify, all Exmark Parts Plus®orders must be received by Exmark by 3:00 p.m., central time. Orders
must be six (6) line items or less. Exclusions from the Exmark Parts Plus®Program are: Any wholegood or accessory in its
entirety, engines and engine replacement parts, 5-speed Peerless transmissions and 5-speed transaxles, hydraulic or
hydrostatic wheel motors, cutter decks and engine decks or any item exceeding United Parcel Service size and weight
restrictions.
Due to UPS restrictions, aerosol spray paint is considered a hazardous material and cannot be shipped via UPS next day or
Second Day Air.
Exmark Manufacturing stocks a limited supply of parts for transaxles, pumps and wheel motors. These parts can be ordered
for Next Day Air shipment but will not be guaranteed per the Parts Plus Program.

2
READ OPERATOR’S MANUAL BEFORE
OPERATING OR SERVICING EXMARK EQUIPMENT.
TABLE OF CONTENTS
Description Page
32" and 36" Mower Deck ............................................. 3-4
48" Mower Deck .......................................................... 5-6
Decals............................................................................15
Engine Deck Group.................................................... 7-10
Upper Handles & Controls, ECS .............................. 13-14
Upper Handles & Controls, Pistol Grip ..................... 11-12
Wiring Diagram ..............................................................16

32” and 36” MOWER DECK
3
Item Part No. Description Qty.
1 103-2312 Deck (103-2307-01) W/Decals
& Dogleg(36") ........................................1
103-2313 Deck (103-2301-01) W/Decals &
Dogleg (32")...........................................1
2 1-302189-01 Wld, Dogleg Baffle ................................. 1
3 322-2 Screw, HH 5/16-18 x 5/8 ........................ 7
4 32128-20 Nut, Whizlock 5/16-18 ............................22
5 103-3600 Asm, Engagement Arm W/Bushings ......1
6 302-52 Zerk, 1/8 NPT Straight ........................... 2
7 302-19 Zerk, 1/4-28 Straight ..............................1
8 1-323385 Knob, Belt Cover....................................4
9 1-809020 Quick Pin, 10" Caster.............................2
10 3296-29 Nut, Nyloc 5/16-18 ................................. 3
11 323-8 Screw, HH 3/8-16 x 1 1/2 .......................8
12 3290-357 Nut, Whizlock 3/8-16 ..............................16
13 1-323748 Ring, Push-On 7/16................................1
14 98-5975 Washer, Spring Disc 3/8.........................9
15 1-808280 Pin, Clevis 5/16 x 1 ................................ 1
16 1-303105 Yoke ......................................................1
17 1-806003 Hairpin, Cotter #2...................................3
18 32151-103 E-Ring....................................................1
19 702809 Screw, HH 3/8-16 x 1 7/8 .......................1
20 103-6584 Blade, Notched (36") ..............................2
103-6582 Blade, Mulching (36").............................2
103-6580 Blade, Low Lift (36")...............................2
103-1578 Blade, Solid (36") ................................... 2
103-6337 Blade, Extreme (36”) .............................. 2
103-6583 Blade, Notched (32") ..............................2
103-6581 Blade, Mulching (32) .............................. 2
103-2507 Blade, Low Lift (32")...............................2
103-1577 Blade, Solid (32") ................................... 2
103-6336 Blade, Extreme (32”) .............................. 2
21 1-513338 Washer, Special.....................................2
22 3253-7 Washer, Lock 1/2 ................................... 2
23 3217-9 Nut, Hex 1/2-13......................................2
24 325-20 Screw, HH 1/2-13 x 6 .............................2
25 1-303352 Washer, Spindle.....................................1
26 32120-35 E-Ring....................................................1
27 1-323733 Drive Belt (To Blades) 36" Model ........... 1
1-323734 Drive Belt (To Blades) 32" Model ...........1
281-803310 Setscrew, 5/16-18 x 3/8..........................2
29 322-6 Screw, HH 5/16-18 x 1 1/4 .....................9
30 3256-23 Washer, 5/16 SAE.................................. 1
31 1-303537 Stud, Belt Shield (Short)......................... 2
32 1-303536 Stud, Belt Shield (Long) .........................2
33 1-324208 Shield (1-302213-01) W/Decals, 36" ......1
1-324194 Shield (1-322149-01) W/Decals, 32" ......1
34 1-323417 Washer, Belt Cover Mount .....................4
35 1-322145-01 Wld, Caster Fork .................................... 2
36 103-1236 Asm, Caster Wheel Assembly................2
Item Part No. Description Qty.
37 1-302233-01 Chute..................................................... 1
38 3296-56 Nut, Nyloc 1/4-20 Thin ........................... 1
39 1-323729 Bearing .................................................. 2
40 323-4 Screw, HH 3/8-16 x 3/4.......................... 8
41 1-603843 Pulley, Idler............................................ 1
42■103-8387 Asm, Cutter Housing Complete.............. 2
43 322-5 Screw, HH 5/16-18 x 1........................... 2
44103-8280 Asm, Cutter Housing.............................. 2
45 302-61 Zerk, 45° 1/4-28..................................... 2
46 103-2535 Spacer ................................................... 2
47 1-403179 Tube, Pivot ............................................ 1
48 1-303314 Spacer, 10" Caster................................. 8
491-323529 Tube, Spindle ........................................ 2
50 321-4 Screw, HH 1/4-20 x 3/4.......................... 2
51 1-303514 Flange , Thrust Bearing ......................... 4
52 1-323339 Washer .................................................. 2
531-403183 Sheave, Blade Driven ............................ 2
54 3219-6 Nut, Hex 5/8-18 UNF ............................. 2
55 1-800861 Screw, HH 5/8-18 x 8............................ 2
56 1-807267 Key, 1/4 x 3/16 x 1 1/4 ........................... 2
57 1-323539 Spacer, Blade Drive............................... 8
58 1-513208 Washer, Spring Disc 5/8 ........................ 2
59 1-303434 Bushing, Engagement............................ 1
60 1-303348 Eye Bolt (Left Hand Thread) .................. 1
61 1-303236 Turnbuckle Body.................................... 1
62 1-303238 Eye Bolt (Right Hand Thread) ................ 1
63 1-322235 Arm, Assist ............................................ 1
64 322-10 Screw, HH 5/16-18 x 2........................... 1
65 1-323303 Linkage, Assist Arm ............................... 1
66103-1238 Asm , Caster/Mount Complete ............... 2
103-2281 Asm, Caster/Mnt Complete, Weighted ... 2
671-302203 Asm, Caster Whl Support W/Bearings ... 2
103-2296 Asm, Caster Wheel Support
W/Bearings, Weighted ........................... 2
681-302194-01 Wld, Caster Wheel Support.................... 2
103-2297-01 Wld, Caster Wheel Support, Weighted... 2
69 1-303334 Washer, Spring Disc 5/16 ..................... 9
70 1-324372 Asm, Pad/Spring.................................... 1
71103-1330 Guard, Bearing Top ............................... 2
72 3256-3 Washer, 5/16 Std................................... 1
73 1-323715 Rod, Brake 36" ...................................... 1
1-323718 Rod, Brake 32" ...................................... 1
74 1-323071 Spring .................................................... 1
75 1-323747 Spring, Compression ............................. 1
76 1-323746 Spacer, Flanged .................................... 1
77 3296-42 Nut, Nyloc 1/4-20................................... 2
78 1-513547 Spacer, Front Caster.............................. 2
79 103-2171 Kit, Tire & Wheel Asm W/ Spacer .......... 2
80 1-513809 Roller Bearing........................................ 1
81 1-513810 Bushing ................................................. 4
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Use Pro-lock Nut Type (p/n 1-840022 .5 ml tube) on the setscrews.
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N’s MK322(32”) or MK362(36”)
Models with ECS handles only.
Models with Standard pistol grip handles only.
Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-sieze) between the spindles & bearings
and spindles & sheaves and under top bearing guard. DO NOT use a copper or nickel based anti-seize.
■Does not include items #4, #29, & #69

32” & 36” MOWER DECK
4

48” MOWER DECK
5
Item Part No. Description Qty.
1 109-2601 Deck (103-9818-01)W/Dcls & Dogleg..... 1
2 1-402107-01 Wld, Dogleg Baffle ................................. 1
3 322-2 Screw, HH 5/16-18 x 5/8 ........................ 4
4 32128-20 Nut, Whizlock 5/16-18 ............................12
5 3296-29 Nut, Nyloc 5/16-18 ................................. 3
6 323-7 Screw, HH 3/8-16 x 1 1/4 HH ................. 18
7 3290-357 Nut, Whizlock 3/8-16 ..............................19
8 98-5975 Washer, Spring Disc 3/8.........................12
9 1-808280 Pin, Clevis 5/16 x 1 ................................ 1
10 1-303105 Yoke ......................................................1
11 109-0977 Pulley, Idler Pulley.................................. 2
12 32151-103 E-Ring....................................................1
13 103-6583 Blade, Notched (48") ..............................3
103-6581 Blade, Mulching (48").............................3
103-2507 Blade, Low Lift (48”) .............................. 3
103-1577 Blade, Solid (48”) ..................................3
103-6336 Blade, Extreme (48”) .............................. 3
14 1-323303 Linkage, Assist Arm ............................... 1
151-803310 Setscrew, 5/16-18 x 3/8..........................3
16 323-13 Screw, HH 3/8-16 x 2 3/4 .......................2
17 3296-42 Nut, Nyloc 1/4-20 ................................... 2
18 1-513810 Bushing..................................................4
19■103-8387 Asm, Cutter Housing Complete ..............3
20103-8280 Asm, Cutter Housing .............................. 3
21 302-61 Zerk, 45° 1/4-28 ..................................... 2
22 103-2535 Spacer ...................................................3
23 1-513809 Bearing, Roller .......................................2
24 702809 Screw, HH 3/8-16 x 1 7/8 .......................1
251-323529 Tube, Spindle......................................... 3
26 32120-35 E–Ring................................................... 1
27 3296-39 Nut, Nyloc 3/8-16 ................................... 18
28 1-807267 Key, 1/4 x 3/16 x 1 1/4 ...........................3
291-403183 Sheave, Blade Driven ............................3
30 1-513208 Washer Spring Disc 5/8.......................... 3
31 1-800861 Screw, HH 5/8-18 x 8 .............................3
32 1-323539 Spacer, Blade Drive ...............................12
33 1-323339 Washer .................................................. 3
34 1-322235 Arm, Assist.............................................1
35 3219-6 Nut, Hex 5/8-18 UNF..............................3
36 1-303434 Bushing, Engagement............................1
37 1-303348 Eye Bolt (Left Hand Thread)...................1
38 1-303236 Turnbuckle Body ....................................1
39 1-303238 Eye Bolt (Right Hand Thread) ................1
40 1-323747 Spring, Compression.............................. 1
41 1-806003 Hairpin, Cotter #2...................................3
42 1-303352 Washer, Spindle.....................................1
43 322-10 Screw, HH 5/16-18 x 2 ...........................1
44 1-323729 Bearing .................................................. 2
45 1-303334 Washer, Spring Disc 5/16.......................1
Item Part No. Description Qty.
46 103-3600 Asm, Engagement Arm W/Bushings ...... 1
47 322-6 Screw, HH 5/16-18 x 1 1/4..................... 1
48 302-19 Zerk, 1/4-28 Str...................................... 1
49 3256-24 Washer, 3/8 SAE ................................... 2
50 323-20 Screw, HH 3/8-16 x 3 1/4....................... 1
51 3296-56 Nut, Nyloc 1/4-20 Thin ........................... 1
52 1-402106-01 Wld, Chute............................................. 1
53 1-403179 Tube, Pivot ............................................ 1
54 3256-3 Washer, Flat 5/16 Std ............................ 1
55 1-323714 Rod, Brake LH ....................................... 1
56 1-324372 Asm, Pad/Spring.................................... 1
57 3256-23 Washer, 5/16 SAE ................................. 1
58 1-603843 Pulley, Idler............................................ 1
59 1-403174 Belt, Drive (Main Deck) 48".................... 1
60 1-323746 Spacer, Flanged .................................... 1
61 1-403184 Bushing ................................................. 2
62 322-5 Screw, HH 5/16-18 x 1........................... 2
63 1-323071 Spring .................................................... 1
64103-1330 Guard, Bearing Top ............................... 3
65103-1238 Asm, Caster/Mount Complete ................ 2
103-2281 Asm, Caster/Mnt Complete, Weighted ... 2
661-302203 Asm, Caster Whl Support W/Bearings ... 2
103-2296 Caster Wheel Support
W/Bearings, Weighted ........................... 2
671-302194-01 Wld, Caster Wheel Support.................... 2
103-2297-01 Wld, Caster Wheel Support, Weighted... 2
68 302-52 Zerk, 1/8 NPT ........................................ 2
69 1-303514 Flange, Thrust Bearing .......................... 4
70 1-303314 Spacer, 10" Caster................................. 8
71 103-1236 Asm, Caster Wheel................................ 2
72 1-322145-01 Wld, Caster Fork.................................... 2
73 321-4 Screw, HH 1/4-20 x 3/4.......................... 2
74 1-323748 Ring, Push-On 7/16 ............................... 1
75 1-323417 Washer, Belt Cover Mount ..................... 5
76 323-4 Screw, HH 3/8-16 x 3/4.......................... 8
77 325-20 Screw, HH 1/2-13 x 6............................. 2
78 3217-9 Nut, Hex 1/2-13...................................... 2
79 3253-7 Washer, Lock 1/2................................... 2
80 1-513338 Washer, Special..................................... 2
81 1-809020 Quick Pin, 10" Caster............................. 2
82 1-303537 Stud, Belt Shield (Short) ........................ 2
83 1-303536 Stud, Belt Shield (Long) ......................... 3
84 1-323385 Knob, Belt Cover.................................... 5
85 1-404238 Shield (1-402100-01)W/Decals 48" ........ 1
86 1-403188 Spacer, Belt Guide................................. 1
87 323-8 Screw, HH 3/8-16 x 1 1/2....................... 8
88 1-513547 Spacer, Front Caster.............................. 2
89 103-2171 Kit, Tire & Wheel Asm W/ Spacer .......... 2
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Use Pro-lock Nut Type (p/n 1-840022 .5 ml tube) on the setscrews.
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N’s MK483.
Models with ECS handles only.
Models with Standard pistol grip handles only.
Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindles & bearings
and spindles & sheaves and under top bearing guard. DO NOT use a copper or nickel based anti-seize.
■Does not include items #6 and #27.

48” MOWER DECK
6

ENGINE DECK GROUP
7
Item Part No. Description Qty.
1 103-3499 Rear Deck (103-9897-01) W/Decals....... 1
2 1-323500 Transmission..........................................1
3 1-324340 Asm, Coupling, W/Guard And Zerk ........ 2
4 1-323502 Shaft, Transmission Output....................2
5 103-2587 Adapter, Oil Drain ..................................1
61-323252 Bearing, Transmission Shaft .................. 2
7 1-323254 Flange, Bearing Transmission Shaft....... 2
8103-6511 Sheave, 3 1/4" (36”&48”)........................2
103-6512 Sheave, 3 1/4" (32”) ...............................2
9 32151-62 Ring, Retaining ......................................2
10 1-805005 Washer, Lock 5/16 Heavy ...................... 4
11 1-373034 Washer, Flat ..........................................2
123245-41 Setscrew, 1/4-20 x 3/8 Cuppoint ............2
13 1-323280 Belt, Transmission..................................1
14 3290-357 Nut, Whizlock 3/8-16 ..............................3
15 3296-39 Nut, Nyloc 3/8-16 ................................... 1
16 103-3498 Shifter Plate (1-323387-03) W/Decals ....1
17 1-323389-03 Leg, Shifter Lever...................................2
18 3230-1 Bolt, Carriage 5/16-18 x 3/4 ................... 2
19 32128-20 Nut, Whizlock 5/16-18 ............................2
20 51-4220 Coupler, Guard ...................................... 2
21103-1666 Sheave, Trans. Drive, 2 3/4" ..................1
22103-1668 Sheave, Blade Drive (6.71")(36”)............1
103-1667 Sheave, Blade Drive(7.33")(32”&48”) .....1
23 5-1336 Key,1/4 Sq x 2........................................ 1
24 1-303334 Washer , Spring Disc 5/16......................4
25 32128-20 Nut, Whizlock 5/16-18 ............................4
26 322-7 Screw, HH 5/16-18 x 1 1/2 .................... 4
Item Part No. Description Qty.
27 323-13 Screw, HH 3/8-16x2 3/4......................... 1
281-803310 Setscrew, 5/16-18 x 3/8 Cuppoint .......... 2
29 1-633453 Spacer, Tube ......................................... 1
30 1-603610 Washer, Spring Disc 7/16 ...................... 2
31 9264964 Screw, HH 5/16-18 x 3/4 Tapping .......... 4
32 1-303186 Crank, Bell............................................. 1
331-323278 Sheave, Transmission Drive .................. 1
34 1-323379 Washer, Shifter Lever ............................ 1
35 98-5975 Washer, Spring Disc, 3/8 ....................... 1
36 3296-6 Nut, Nyloc 3/8-24................................... 1
37 3257-5 Key, Woodruff 3/16 x 3/4 ....................... 3
38 1-303282 Switch, Neutral....................................... 1
39 3231-6 Bolt, Carriage 3/8-16 x 2 SSN................ 1
40 3256-5 Washer , 7/16 Std .................................. 2
41 1-323285 Pulley, Transmission Drive..................... 1
42 3256-24 Washer , 3/8 SAE .................................. 1
43 321-3 Screw, HH 1/4-20 x 5/8.......................... 4
44 3296-42 Nut, Nyloc 1/4-20 .................................. 4
45 1-603403 Bolt, Shoulder 1/2 x 1............................. 1
463212-6 Screw, HH ,7/16-20 x 1 1/2 .................... 1
47 1-513051 Switch, Blade Engagement.................... 1
48 322-3 Screw, HH 5/16-18 x 3/4........................ 4
49 3290-500 Screw, PPH #10-24 x 5/8....................... 2
50 1-633181 Plate, Tapped ........................................ 1
51 103-1606 Asm Shift Lever, W/Grip ........................ 1
52 103-1733 Grip ....................................................... 1
53 302-19 Zerk, 1/4-28 Str...................................... 2
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Exmark black touch up spray paint – Gloss black
Use Pro-lock (Nut type) Part No. 1-840022 (.5ml tube) on setscrew threads and on sheave retaining bolt in engine
crankshaft.
Apply anti-seize compound to bore of blade drive and transmission drive sheaves on engine, drive sheave on
transmission, and bearings and sheaves on transmission output shafts.

ENGINE DECK GROUP
8

ENGINE DECK GROUP (cont.)
9
Item Part No. Description Qty.
1 103-1611-03 Wld, Brake Arm......................................2
2 302-19 Zerk, 1/4-28 Straight ..............................4
3 1-322117-03 Wld, Axle (36” & 48” Models)..................1
1-322141-03 Wld, Axle (32" Model).............................1
4 2412-104 Clip, Loom..............................................2
5 103-1615-03 Wld, Idler Arm (LH) ................................1
61-806003 Hairpin, Cotter #2................................... 4
 1-806003 Hairpin, Cotter #2...................................2
7 103-1616-03 Wld, Idler Arm (RH)................................ 1
832151-47 Klipring (For 3/8 Shaft) ........................... 6
 32151-47 Klipring (For 3/8 Shaft) ........................... 4
9 1-323288 Belt, Wheel Drive (36”&48” Models) .......2
1-323344 Belt, Wheel Drive (32" Model) ................2
10 32128-20 Nut, Whizlock 5/16-18 ............................4
11 1-323262 Band, Brake ...........................................2
12 110-5866 Wld, Brake Linkage Swivel.....................2
13 1-412358 Wld, Scraper (36”&48” Models)..............2
1-603430 Scraper (32" Model) ...............................2
14 3296-29 Nut, Nyloc 5/16-18 ................................. 4
15 1-323277 Pulley, Idler (36”&48” Models)................ 2
1-323352 Pulley, Idler (32" Model) .........................2
16 322-6 Screw, HH 5/16-18 x 1 1/4 .....................2
17 99-8664 Screw, HH 3/8-16 x 3 Tapping ............... 2
18 3290-357 Nut, Whizlock 3/8-16 ..............................14
19 3296-39 Nut, Nyloc 3/8-16 ................................... 4
20 1-323287-01 Shield, Wheel Drive................................2
21 1-323283 Spacer ...................................................4
22 1-603402 Spring, Drive ..........................................2
231-323548 Linkage, Brake.......................................2
 103-1619 Linkage, Brake (LH) ............................... 1
 103-1620 Linkage, Brake (RH)...............................2
Item Part No. Description Qty.
24 1-513959 Wingnut, Nyloc 5/16-18.......................... 2
25 323-39 Screw, HH 5/8-16 x 5............................. 4
26 1-523157 Spacer, Wheel (14 Ga.) .........................
A
s
Re
q
'd.
1-543436 Spacer, Wheel (18 Ga.) .........................
A
s
Re
q
'd.
27 98-5975 Washer, Spring Disc 3/8 ........................ 4
28 1-323307 Pin, Clevis 3/8........................................ 2
29 1-803051 Pushnut, 3/8 ......................................... 2
30103-1864 Swivel, Short Adjust............................... 2
 103-1618 Swivel, Short Adjust............................... 2
31 323-6 Screw, HH 3/8-16 x 1............................. 4
32 109-4721 Asm, Wheel Drive (36”&48” Models)...... 2
1-324193 Asm, Wheel Drive (32" Model) ............... 2
33 1-323349 Sheave (32”Model) ................................ 2
34 109-4359 Asm, Drum & Sheave (36”& 48” Model) . 2
35 1-323261 Drum, Brake (32" Model) ....................... 2
36 1-323719 Asm, Wheel & Tire (36”&48”Models)...... 2
1-323346 Asm, Wheel & Tire (32”Model)............... 2
37 1-323720 Tire, 13 x 6.50-6 (4-Ply) (36”&48”) ......... 1
1-323361 Tire, 13 x 5.00-6 (4-Ply) (32”)................. 1
38 1-323328 Asm, Wheel & Hub W/Brgs (36”&48”) .... 1
1-323360 Asm, Wheel & Hub W/Brgs (32”)............ 1
39 1-323329 Bearing, Flanged ................................... 4
40 322-5 Screw, HH 5/16-18 x 1........................... 8
41 1-805005 Washer, Spring Disc 5/16 ...................... 8
42 32120-47 E-Ring (For 1/2" Shaft)........................... 2
431-323245 Spring, Compression ............................. 2
44 1-808519 E-Ring (For 1" Shaft) ............................. 2
45 1-373034 Washer, Swivel (32" Model Only)........... 4
463256-23 Washer, 5/16 SAE ................................. 4
47 98-3259 Shield, Trailing....................................... 1
48 322-3 Screw, HH 5/16-18 x 3/4........................ 2
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Exmark black touch up spray paint – Gloss black
For units with ECS handles only.
For units with pistol grip handles only.

ENGINE DECK GROUP (cont.)
10

PISTOL GRIP UPPER HANDLES and CONTROLS
11
Item Part No. Description Qty.
1 109-4695 Kit, Handle (109-4682-03) W/Decals ......1
2 1-303097 Grip, Handle...........................................2
31-324279 Latch W/Grip (LH) ..................................1
4 1-303019 Grip, Latch .............................................2
5 1-302006 Drive Lever W/Grip.................................2
6 1-303021 Grip, Drive Lever....................................2
7 1-324280 Latch W/Grip (RH)..................................1
8 1-323229 Clip, Loom 3/8........................................1
9 1-303435 Washer, Spring Disc 1/4.........................6
10 1-323359 Linkage, Wheel Drive .............................2
11 3296-42 Nut, Nyloc 1/4-20 ................................... 3
12 3256-22 Washer, 1/4 SAE ...................................1
13 321-18 Screw, HH 1/4-20 x 2 1/4 .......................2
14 109-3958 Cable, Throttle ......................................1
15 103-1797-01 Bracket, Choke Cable ..........................1
16 1-303287 Tie, Plastic 5 1/2" ...................................5
17 3296-39 Nut, Nyloc 3/8-16 ................................... 5
18 3296-2 Nut, Nyloc 10-24 .................................... 2
19 1-807513 Bolt, Carriage 10-24 x 1/2 ......................2
20 1-806003 Cotter, Hairpin........................................4
21 1-808250 Pin, Clevis 3/16 x 1 3/4 .......................... 2
22 1-803001 Palnut, 3/16............................................ 2
23 1-806340 Rollpin, 5/16 x 1 .....................................2
24 1-323549 Spacer ...................................................2
251-412185-03 Lever, OPC (RH).................................... 1
261-803322 Setscrew, 5/16-24 x 5/16........................2
271-412183-03 Lever, OPC (LH) .................................... 1
28 323-6 Screw, HH 3/8-16 x 1 .............................4
29 1-303365 Bushing, Nylon.......................................2
30 1-322192-03 Rod, Connecting .................................... 1
31 1-403121 Switch, Key ...........................................1
1-603511 Key, Ignition .......................................... 1
103-2106 Key, Exmark Logo .................................1
32 1-303363 Spring, Actuator ..................................... 1
33 1-805004 Washer, Lock 1/4 Heavy ....................... 1
34 33114-016 Screw, HH M8-16 x 1.25 ....................... 1
Item Part No. Description Qty.
35 1-303088 Clip, Cable............................................. 1
36 1-303160 Spring, Compression ............................. 1
37 3256-23 Washer, 5/16 SAE ................................. 4
38 1-323298 Linkage, Blade Drive.............................. 1
39 1-322157 Engagmt. Lever, Blade W/Grip .............. 1
40 1-303020 Grip, Lever............................................. 1
41 3256-4 Washer, 3/8 Std..................................... 2
42 323-10 Screw, HH 3/8-16 x 2............................. 1
43 1-303335 Tie, Plastic Large .................................. 1
44 103-2893 Tank, Fuel W/Fitting............................... 1
45 109-0346 Cap, Fuel Tank...................................... 1
46 1-808286 Pin, Clevis ............................................. 2
47103-2605 Fitting, Fuel Bulkhead W/Screen............ 1
48 103-0498 Nut, Ignition Switch ............................... 1
49 1-303077 Clamp, Fuel Line .................................. 4
50 321-4 Screw, HH 1/4-20 x 3/4.......................... 1
51 109-0306 Line, Fuel 6” ......................................... 1
52 1-323430 Interlock, OPC ....................................... 1
53 1-413510 Clip, Loom 1/2” ..................................... 1
54 109-0293 Line, Fuel 8.5" ...................................... 1
55 1-543296 Grommet ............................................... 1
56 1-603770 Valve, Fuel ............................................ 1
57 33113-016 Screw, HH M6-16 x 1............................. 1
58 Kawasaki PN 41019-1055 W/6” Fuel Line ............. 1
59 321-3 Screw, HH1/4-20 x 5/8 .......................... 2
60 103-1610 Harness, Wiring .................................... 1
611-633023 Stud, Gas Tank...................................... 2
62 1-633349 Spring, Gas Tank................................... 2
63 1-513051 Switch.................................................... 1
64 1-633181 Plate, Tapped ........................................ 1
65 3290-500 Screw, PPH #10-24 x 5/8....................... 2
66 1-805005 Washer, Lock 5/16................................. 2
67 3296-47 Nut, Nyloc 5/16-18................................. 2
68 322-3 Screw, 5/16-18 x 3/4.............................. 2
69 32128-33 Nut, Whizlock 1/4-20 ............................. 2
70 103-1796 Cable, Choke ........................................ 1
NOTE: Use dielectric grease on all electrical connections.
Exmark black touch up spray paint – Gloss black
Not illustrated.
Use Pro-lock (Nut type) Part No. 1-840022 (.5 ml tube) on setscrew threads, and on fuel tank fitting.
Use Pro-lock (Retaining) Part No. 1-840023 (.5 ml tube) on inside of bore of OPC hub and on fuel tank studs going into
tank.

PISTOL GRIP UPPER HANDLES and CONTROLS
12

ECS UPPER HANDLES and CONTROLS
13
Item Part No. Description Qty.
1103-1566-03 Wld, Lever, OPC (LH) ............................ 1
2 1-303365 Bushing, Nylon.......................................2
31-803322 Setscrew, 5/16-24 x 5/16........................2
4 103-0769-03 Wld, OPC Rod ....................................... 1
5 1-303363 Spring, Actuator ..................................... 1
6 1-303335 Tie, Plastic 7 5/16” ................................ 1
7 1-807513 Bolt, Carriage 10-24 x 1/2 ......................2
8 3296-2 Nut, Nyloc #10-24 .................................. 2
9 109-3958 Cable, Throttle Control ..........................1
10103-1567-03 Wld, OPC Lever (RH)............................. 1
11 1-303020 Grip, Lever .............................................1
12 103-1629 Lever, Clutch W/Grip..............................1
13 3296-29 Nut, Nyloc 5/16-18 ................................. 2
14 3256-4 Washer, 3/8 Std .....................................1
15 103-0027 Spacer ...................................................2
16 1-806003 Cotter, Hairpin........................................2
17 103-1627 Linkage, Upper.......................................1
18 103-1604 Linkage, Wheel Drive .............................2
19 1-543296 Grommet................................................ 1
20 103-0815 Grip, Handle...........................................2
21 1-303435 Washer, Spring Disc 1/4.........................6
22 103-1631 Latch, Thumb (LH) (Not Shown)............. 1
103-1630 Latch, Thumb (RH).................................1
23 3296-42 Nut, Nyloc 1/4-20 ................................... 1
24 103-0770-03 Wld, Handle ...........................................1
25 1-303088 Clip, Cable ............................................. 1
26 323-6 Screw, HH 3/8-16 x 1 .............................4
27 109-0346 Cap, Fuel Tank ......................................1
28 103-2893 Tank, Fuel W/Fitting............................... 1
291-633023 Stud .......................................................2
30 1-633349 Spring, Fuel Tank................................... 2
31 1-805005 Washer, Lock 5/16 Heavy ...................... 2
32 3296-47 Nut, Nyloc 5/16-18 ................................. 2
33 322-3 Screw, HH 5/16-18 x 3/4 ........................ 2
34103-2605 Fitting, Fuel Bulkhead W/Screen ............1
35 103-0498 Nut, Ignition Switch ...............................1
36 1-303077 Clamp, Fuel Line ...................................4
37 33114-016 Screw, HH M8-16 x1.25 ........................1
38 1-603770 Valve, Fuel............................................. 1
39 1-805004 Washer, Lock 1/4 Heavy ........................1
40 Kawasaki PN 41019-1055 W/6” Fuel Line.............. 1
Item Part No. Description Qty.
41 103-1610 Harness, Wiring..................................... 1
42 3256-22 Washer, 1/4 SAE ................................... 1
43 321-4 Screw, HH 1/4-20 x 3/4.......................... 1
44 1-403121 Switch, On/Off ....................................... 1
1-603511 Key, Ignition........................................... 1
103-2106 Key, Exmark Logo ................................. 1
45 1-633181 Plate, Tapped ........................................ 1
46 3296-39 Nut, Nyloc 3/8-16................................... 5
47 3290-500 Screw, PPH #10-24 x 5/8....................... 2
48 1-513051 Switch, Neutral Lockout ......................... 1
49 1-323229 Clip, Loom 3/8 ....................................... 1
50 1-303287 Tie, Plastic 5 1/2”................................... 6
51 1-323430 Module, Wiring Harness......................... 1
52 323-14 Screw, HH 3/8-16 x 3............................. 1
53 322-9 Screw, HH 5/16-18 x 1 3/4..................... 2
54 1-413152 Bearing.................................................. 4
55 103-2466-03 Lever, Drive (LH) ................................... 1
56 3219-3 Nut, Hex 3/8-24 ..................................... 2
57 321-14 Screw, HH 1/4-20 x 2 3/4....................... 2
58 32128-33 Nut, Whizlock 1/4-20.............................. 12
59 103-0464 Pin, Spring 1/8 x 1/2 .............................. 2
60 3256-22 Washer, 1/4 SAE ................................... 10
61103-0235 Screw, 1/4-20 x 1 1/8 W/Nylon............... 2
62 103-2465-03 Lever, Drive (RH)................................... 1
63 3220-3 Nut, Jam 3/8-24..................................... 4
64 109-4934 Asm, Console (109-4649-03) 1
W/Decals ...............................................
65 3256-23 Washer, 5/16 SAE ................................. 4
66 321-3 Screw, HH 1/4-20 x 5/8.......................... 10
67 103-2513 Asm, Drive Lever (RH)........................... 1
103-2514 Asm, Drive Lever (LH) ........................... 1
68 103-2463 Joint, .375 Ball End................................ 2
69 103-0489-03 Bracket, OPC Axle................................. 1
70 103-1796 Cable, Choke Push/Pull......................... 1
71 103-1797-01 Bracket, Choke Cable............................ 1
72 1-633080 Bushing ................................................. 1
73 3256-14 Washer, #10 Std.................................... 1
74 109-0293 Hose, Fuel Line 8.5” .............................. 1
75 1-413510 Clip, Loom 1/2” ...................................... 1
76 109-0306 Hose, Fuel Line 6” ................................ 1
77 33113-016 Screw, HH M6-16 x 1............................. 1
NOTE: Use dielectric grease on all electrical connections.
Exmark black touch up spray paint – Gloss black
Use Pro-lock (Nut type) Part No. 1-840022 (.5 ml tube) on setscrew threads, thumb latch screws and on fuel tank fitting.
Use Pro-lock (Retaining) Part No. 1-840023 (.5 ml tube) on inside of bore of OPC hub and on fuel tank studs going into
tank.

ECS UPPER HANDLES and CONTROLS
14

DECALS
15
Item Part No. Description Qty.
1103-1623 Decal, Console ......................................1
2 103-1798 Decal, Throttle .......................................1
3 103-2882 Decal, Exmark Logo............................... 1
4 1-513746 Decal, Muffler.........................................1
5 1-323427 Decal, Belt Routing (32” & 36”)...............1
6 103-5626 Decal, Belt Routing (48”) ........................ 1
7 1-323410 Decal, Commercial (32") ........................ 1
8 1-323411 Decal, Commercial (36”) ........................ 1
9 1-403131 Decal, Commercial (48") ........................ 1
10 98-5954 Decal, Missing Cover ............................. 1
11103-1967 Decal, Console ...................................... 1
12 1-303518 Decal, Shifter .........................................1
Item Part No. Description Qty.
131-323550 Decal, Neutral/Brake.............................. 2
14 1-303520 Decal, TriVantage .................................. 1
15 103-2920 Decal, Metro Model................................ 1
16 1-303508 Decal, Discharge Warning ..................... 1
17 1-403005 Decal, Danger (32” & 36”)...................... 1
1-403005 Decal, Danger (48”) ............................... 2
18 1-303517 Decal, Belt Drive.................................... 1
19 1-403143 Decal, Sulky Warning............................. 1
20103-2245 Decal, ECS Instruction (RH) .................. 1
21103-2244 Decal, ECS Instruction (LH) ................... 1
103-2640 Decal, Kit ...............................................
Pistol Grip units only.
ECS units only.

WIRING DIAGRAMS
16

17
NOTES

18
SERVICE RECORD
Date Description of Work Done Service Done By

See Exmark’s Complete
Line of Accessories
Riding Accessories
Custom Ride Seat Suspension System
Deck Lift Assist Kit
Hitch Kit
Light Kit
Micro-mulch System
Roll Over Protection System (ROPS)
Snow Blade
Sun Shade
Trash Container
Turf Striper
Ultra Vac Collection System
Ultra Vac Quick Disposal System
Walk Behind Accessories
Grass Catcher
Micro-mulch System
Steerable Sulky
Sulky Hitch Kit
Turf Striper
Standon
Check Us Out On The Web:
www.exmark.com
©
1997
–
2007 Exmark Mfg. Co., Inc. Part No. 4500-204 Rev.
A
Industrial Park Box 808 [phone]
Beatrice, NE 68310 Fax [phone]
All Rights Reserved Printed In USA.
