Exterior Lights LSTEL80 User manual

Pro Bollard Lighting
Marine Grade (316) Stainless Steel
Heavy Duty Commercial LED Bollard Light
20w
LED
20w
LED
Standard Mount 0.8m, 1.0m approx.
Ref: LSTEL80 / LSTEL100
20w LED Corn Bulb (Included)
Warm / Daylight White
www.exteriorlightsuk.co.uk
Thank you for your purchase.
Please read these instructions carefully before use to ensure safe and satisfactory
operation of this product and retain for future reference
INPUT: 220-240v - 50Hz
BULB SPECIFICATIONS ON PAGE 3
BULB HOLDER: ES/E27
MAX WATTAGE: 60w
MATERIALS: MARINE GRADE (316) STAINLESS STEEL - 3mm THICK
PROTECTION: Class 1
Warnings
Please read these instructions carefully before commencing any work.
- This is a Class 1 product and must be earthed.
- This unit must be fitted by a competent and qualified electrician.
- Install in accordance with IEE wiring regulations and current Building Regulations.
- To prevent electrocution switch off at mains supply before installing or maintaining this
fitting. Ensure other persons cannot restore the electrical supply without your knowledge.
- This light fitting should be connected to a circuit with a 30mA RCD fitted.
- If replacing an existing fitting, make a careful note of the connections.
- When changing a bulb, always switch off at the mains and allow the bulb to cool down
before handling.
- Always use the correct type and wattage bulb. Never exceed the wattage stated.
- The unit may get hot whilst on for a period of time.
BOLLARD GUARANTEE
The Pro-Bollard Lighting Range has been made to the highest of standards. In the unlikely event of a
fault developing within 5years from the purchase date, please contact Exterior Lights Uk Ltd to obtain a
returns reference. After obtaining the reference, please return to the supplier they provide details of
together with proof of purchase and it will be repaired or replaced.
In the case of accidental damage we may be able to supply spare parts or components.
See website for contact details.
5Year
Guarantee
BULB GUARANTEE
1Year
Guarantee
In the unlikely event of a fault developing with the 20w LED Bulb within 1year from the purchase date,
please contact Exterior Lights UK Ltd to obtain a returns reference.After obtaining the reference, please
return to the supplier given by us together with proof of purchase and it will be replaced.
The guarantees exclude accidental or malicious damage.
STELLEDR STELLED

www.exteriorlightsuk.co.uk
Safety Information
For your safety, always switch off the supply before changing light bulbs or cleaning the unit.
•The bollard head must be replaced immediately should the polycarbonate lens become cracked or damaged.
•This fitting must not be used without the polycarbonate lens fully intact.
Installation (Surface Mount)
Please refer to separate instructions if a professional root mount system model has been purchased
J-Bolts have been supplied for mounting the bollard into wet concrete if desired.
• Remove 4 x screws at the foot of the bollard with the larger 4mm Allen Key provided and lift the bollard body from
the base
•Position bollard base in the desired location, ensuring the supply cable is central to the base and sufficient cable is
available to easily connect to the bollard connection box. DO NOT USE IF CABLES ARE DAMAGED.
• Secure the base in place with 3 x heavy duty fixing screws / anchor bolts (available from Lumena) as appropriate
• Replace bollard body
Wiring
Please Note: For models with a Photocell / PIR, the fourth connection on the connection block will
already be wired to the Photocell / PIR and one connector will contain two neutral wires.
This should not be changed. Please test in darkness once wired.
For standard models, pull the supply wire up through the bollard and connect to the connection block as follows:
• Unscrew the 3 socket screws to remove the bollard head
• Remove the three screws that secure the bulb holder in place
• Remove bulb holder and turn over to reveal the black connection box
• Unscrew the 4 screws on the connection box and remove back to open, and remove connection block
• Push the cable through the grommet and complete wiring as follows:
- Connect Live input wire to the correct point of the connection block (marked ‘L’)
- Connect Neutral input wire to the correct point of the connection block (marked ‘N’)
- Connect Earth input wire to the correct point of the connection block (marked )
• Check that you have correctly identified the supply wires, the connections are tight, that no loose strands have
been left out of the connection block and all cables are fully intact
• Place terminal block back into the black connection box, replace back and screw in place
• Replace all removed components correctly (as per above) ensuring all screws are tight and secure
20w LED Bulb Specifications
Voltage: 220-240V
Lamp Type: LED (Epistar 2835)
Number of LEDs: 135
Wattage: 20W
Colour Temperature: 6500K (Daylight White) / 3000K (Warm White)
Lumen Output: 2100 lumens (Daylight) / 1600 lumens (Warm)
Cap Type: ES / E27
Average Life: 30,000 hours
Fitting / Replacing Bulbs
When changing a bulb,always switch off at the mains and allow the bulb to cool before handling.Use a soft cloth to handle
your light bulb and avoid directly touching the bulb as this may shorten its life.Always handle at the base of the bulb as
this will also prevent breakages. Do not exceed the wattage indicated on the fitting. Dispose of used bulbs carefully and
responsibly (see below for more details).
• Remove the 3 x screws from bollard head using the Allen Key provided.
• Remove head from bollard
• Remove / insert screw base lamp
• Replace head and 3 x screws - ensure screws are secure
Recycling and Disposal Advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling advice and waste disposal sites or contact the WeeCare
helpline on: 0844 8002004 quoting our Producer Registration Number: WEE/KC3440XY
Root Mount, Photocell & PIR options available for all STELLED Bollards
For more information please visit:
www.exteriorlightsuk.co.uk
If not mounting into wet concrete, this bollard should be securely fixed to a concrete base, paving slab, or quality
wooden decking. It should not be installed directly into soil. For fixing into existing paving slabs, concrete, or decking,
heavy duty fixing screws and bolts will be required. Ensure the fixing screws / bolts are stainless steel or zinc plated
to avoid corrosion.
•If using J-Bolts, use the set template to ensure they are fixed in the correct position.
20w
LED
20w
LED
CARE OF STAINLESS STEEL
Contrary to popular belief, stainless steel needs looking after; especially in exposed and coastal areas. If not
cleaned on a regular basis, the acid that is ever present in the air (and salt in coastal areas) can affect the
surface causing pitting and even rust like staining (known as ‘tea staining’ ) to appear. To keep stainless steel
lights looking fresh, simply wipe clean with a damp cloth and dry once a month (more frequently in coastal
areas if required). Specialist stainless steel cleaning products such as ‘Kilrock Stainless Steel Cleaner’ is
recommended and stocked by Lumena. Abrasive cleaners should never be used.
