EXTREME CCTV WZ Series User manual

Important
Please read this document carefully before installation and initial use. Keep for future reference.
• An unregulated power supply can cause damage to the camera. The use of an unregulated power supply with this camera will void
the product warranty.
• Do not attempt to disassemble the camera to gain access to the internal components. Refer servicing to Extreme CCTV.
• It is recommended that the camera be used with a monitor that has a CCTV quality 75Ωvideo impedance level. If your monitor is
switched to a high impedance level, then please adjust accordingly.
• Never direct the camera towards the sun or any bright or reflective light. Doing so may cause smearing on the picture and possible
damage to the CCD
Precautions
• Do not open or modify
• Do not put objects inside the unit. Make sure that no metal objects or flammable substances enter the camera. This may cause fire,
short-circuits and other damages.
• Be careful when handling the unit. To prevent damage, do not drop the camera or subject it to strong shock or vibration.
• Install the camera away from electric or magnetic fields.
• Protect the camera from humidity and dust.
• Do not subject the unit to high temperature. Be careful when installing close to ceilings, in a kitchen or a boiler room as heat rises
and will affect the camera.
• Dirt can be removed from the camera by wiping it with a clean soft moistened cloth and soft detergent solution.
• The mounting surface material must be strong enough to secure the camera.
Troubleshooting
Before sending the camera for repair, check the questions below. If the problem still persists, contact Extreme CCTV.
If no image appears
• Is the coaxial cable firmly attached?
• Is power and voltage at a normal level?
• Is there adequate illumination?
If the image is unclear
• Is the lens in focus?
• Is the lens dirty?
• Is the monitor correctly adjusted?
Installation
Installation Guide
WZ18-NV312-0

Installation (cont’d)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions.
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that my cause undesired operation
NOTE: This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If the camera turns on and off, try to correct the
interference using one or more of the following:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult Extreme CCTV for technical support.
Camera Specifications
Part Number WZ18-NV312-0
Signal Processing Digital signal processing (DSP)
CCD Camera 1/3” SuperHAD CCD with Mech Filter
Filter Dual-window mechanical type
Resolution High resolution 550 TVL
Effective Pixels (NTSC) 811 (H) x 508 (V)
Effective Pixels (PAL) 795 (H) x 596 (V)
Night-Time Sensitivity 0 Lux (infrared on)
Day-Night Switching Photocell-controlled, automatic
Electronic Iris (NTSC) 1/60 ~ 1/100,000s
Electronic Iris (PAL) 1/50 ~ 1/100,000s
Output Signal 1V P-P composite video, 75 Ohms
S/N Ratio Greater than 48dB
Gamma 0.45
Lens Varifocal 3.3-12mm, DC auto-iris
Lens Control Externally adjustable zoom and focus
LEDs Even-distribution infrared array
LED Control Photocell
Wavelength 850nm
Number of LEDs 18
Voltage 12 VDC or 24 VAC
Power Draw 4.8W or less (IR lamp OFF)
Construction Robust aluminum extrusion
Finish Anodized silver
Operational Temp -10ºC to 55ºC (14ºF to +131ºF)
Sunshield Included as standard
Bracketry Pan-tilt bracket included as standard
Power Supply Not included
Weight 0.85kg (1.9lbs)
Dimensions Φ76mm x 210mm (L)
Subject To Change Without Notice.
Contact Information
Extreme CCTV Inc.
Canada
3021Underhill Ave.
Burnaby, BC V5A 3C2
USA
3888 Sound Way
PO Box 9754
Bellingham, WA 98226
N.A. Toll Free : 1-888-409-2288 (N.A. toll free)
International: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.ExtremeCCTV.com
Lens Adjustments
• Remove cap
• Adjust the iris level.
• Re-attach cap
Camera Positioning
• Use provided alan key from box to make
adjustments
• Locate and loosen all 3 setscrews on bracket
• Setscrews are shown at (a), (b) and (c)
- picture on the left
• Pan (a), Tilt (b) and Rotate (c)
• Do not pan or twist beyond 360˚as shown
• Do not tilt beyond 90 ° as shown
• Do not apply excessive force when adjusting
camera positioning
(a)
(b)
(c)
