Extreme Networks SA201 Defender Adapter 3

1Overview
Package Contents
Power Connections
LEDs
SA201 Side Ports
The SA201 is an Open Networking Adapter IoT (Internet of Things) solution that is used to securely
deploy IoT devices. SA201 adapter can be used to provide proxy service for the Defender Adapter
Application. SA201 has a full layer 1-7 visibility and can be paired 1:1 with a medical or IoT device in a
hospital or campus environment. The SA201 solution capabilities include:
•Isolation of trac into encrypted zones using HyperSec technology set. This helps reduce the attack
surface and mitigates ill intended lateral movement toward sensitive areas of the network.
•Protection of IoT devices from being seen from harmful trac such as viruses and malware.
•Filteration of tarc flows by limiting what the device receives and transmits.
•Use of Follow Me profiles that are set centrally and applied on a by-device basis. This helps in
automatic assignment of profiles when the device is connected or disconnected from the network.
Note
The SA201 requires a minimum base firmware of Defender 3.1. For Cloud, the minimum base
firmware is ExtremeCloudTM Appliance 4.26.02.
Package Contents
Verify the box contents of the SA201 Adapter as listed:
•SA201 Defender Adapter
•Two M4 wood screws; the head may be up to 2.5mm thick. Screw dimension: 3.5x25.4mm
•Two screw-in wall anchors
•SA201 Quick Reference Guide
•ExtremeCloud™Quick Start Card
Power Connections
Power Sources
The SA201 Adapter uses Power over Ethernet (PoE) as follows:
Extreme Networks SA201 Defender Adapter 4

Table 1: Main Power Source
Power Source Description
Power over Ethernet Power is provided through the RJ45 Ethernet port
(LAN1 port) on the Network side of the SA201 adapter.
When the SA201 adapter is powered by 802.3AT, the
DEVICE port is capable of power sourcing (refer Figure).
Table 2: Optional Power Source
Optional Power Source Description
External 12V DC Power Supply (optional; #30512 - PWR
12VDC, 2A, 2.1mm x 5.5mm connector)
The SA201 can also be powered by an external DC
power supply plugged into an AC source. Plug the
supply’s input jack into the DC-In port.
Note
If the SA201 adapter is plugged into the PoE switch port and the 12V DC-In port, the unit will
use the DC input power source over the PoE port.
Note
The SA201 adapter requires a reboot when the input power source is changed.
LEDs
LEDs on SA201 Adapter
There are LEDs on four of the six sides of the SA201 unit. The figure below shows the LEDs on the front
cover of the adapter.
Overview
Extreme Networks SA201 Defender Adapter 5

Figure 1: LEDs on front cover of SA201
Power Status
PSE Client Port IoT (BLE or 802.15.4)
Table 3: SA201 LED Status
LED Icon LED Color Description
Power GREEN Normal power status
Status GREEN Normal operational status
AMBER Non-operational status
PSE Client Port GREEN Normal operational status (DEVICE
port is capable of providing PoE)
OFF Non-operational status
IoT (BLE) BLUE Indicates BLE is enabled
OFF Non-operational status
Overview
Extreme Networks SA201 Defender Adapter 6

SA201 Side Ports
The sides ports of SA201 are used to power up and connect the adapter.
Figure 2: SA201 Ethernet Port
Figure 3: SA201 12V DC Power Supply Port
Overview
Extreme Networks SA201 Defender Adapter 7

2Installation
Mounting the SA201 Adapter
Follow this procedure to install the SA201 adapter:
1 Match the model number on the purchase order with the model number in the packing list and on
the SA201 adapter.
Table 4: SA201 Product Information
Part Number Description
39505 Surge Adapter 201 IoT Solution; Ethernet Security
Device (QXO-SA201-FCC).
2Verify the box contents.
3 Review and follow the safety guidelines.
4 Mount the unit to a table, on a shelf, or to a wall.
5Connect the SA201 adapter to the network.
Mounting the SA201 Adapter
Use these instructions as guidelines for mounting the SA201 easily and safely.
Caution
Use ESD (Electrostatic Discharge) protection wrist strap when installing the SA201 adapter.
Important
The SA201 unit may become very warm during normal use. It complies with the user-
accessible surface temperature limits defined by the International Standards for Safety (IEC
60950-1 and IEC 62368).
SA201 mounting scenarios include:
1 Mounting on a table.
2 Mounting to a shelf.
3 Mounting to a wall.
Mounting on a table
To mount the SA201 adapter on a table:
1 Place the SA201 adapter on a table close to the Device and Network cables.
Extreme Networks SA201 Defender Adapter 8

2 Connect the Device and Network LAN cables.
Figure 4: Mounting the SA201 adapter on a table
Mounting to a shelf
To mount the SA201 adapter to a shelf:
1 Place the SA201 at a secure position close to the corresponding equipment.
2 Secure the unit using wire ties.
3 Connect the LAN cables.
Mounting to a wall
You can mount the SA201 adapter using the wall mount keyholes in the back of the unit. The keyholes
are bidirectional and let the adapter to be mounted in either direction. To mount the SA201 adapter to a
wall:
Installation
Extreme Networks SA201 Defender Adapter 9

Figure 5: Tools required
Table 5: Tools Required to mount to a wall
Number Description
1 Flat-head screwdriver
2 M4 screws and wall anchors
3 ESD-protective wrist strap (purchased separately)
1 Mark the two hole centers. The two screw centers should be 3.6” apart.
Installation
