Specifications — AC Net AAP
1
Extron AC Net AAP AC Outlet and RJ-11/RJ-45 Architectural Adapter Plate • Specications
General
Power
AC Net AAP USA model � 125 VAC, 50/60 Hz, 5 A (max�), unswitched
AC Net AAP World models
220-240 VAC, 50/60 Hz, 5 A (max�), unswitched
Temperature/humidity���������������� Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount ������������������������������������ Yes, with optional faceplates or mounting frames; also furniture mountable
with optional AAP mounting frames
Enclosure type ������������������������������� Metal
Enclosure dimensions
AC Net AAP USA model
Faceplate��������������������� 1�4" H x 3�5" W x 0�1" D (3�5 cm H x 8�9 cm W x 0�3 cm D) (double space AAP
plate)
Isolation enclosure ���� 1�2" H x 1�4" W x 2�9" D (3�0 cm H x 3�6 cm W x 7�4 cm D)
With AC power cord attached, allow at least 5�0” (12�7 cm) depth in
furniture�
AC Net AAP World models
Faceplate��������������������� 2�1" H x 3�5" W x 0�1" D (5�3 cm H x 8�9 cm W x 0�3 cm D) (three space AAP
plate)
Isolation enclosure ���� 1�9" H x 1�8" W x 3�0" D (4�9 cm H x 4�6 cm W x 7�7 cm D)
With AC power cord attached, allow at least 5�0” (12�7 cm) depth in
furniture�
125V
~
50/60 Hz 5A
220V
~
50/60 Hz xA
AC Net AAP
USA model
AC Net AAP
World models
3.0"
2.9"
2.1"
1.9"
1.8"
3.5"
1.4"
3.5"
1.2"
1.4"

Specifications — AC Net AAP, cont’d
Extron AC Net AAP AC Outlet and RJ-11/RJ-45 Architectural Adapter Plate • Specications
2
Product weight
AC Net AAP USA model � 0�2 lbs (0�1 kg)
AC Net AAP World models
0�5 lbs (0�2 kg)
Shipping weight ���������������������������� 1 lbs (1 kg)
Vibration����������������������������������������� ISTA 1A in carton (International Safe Transit Association)
Listings (AC Net AAP USA)�������� UL, CUL
Compliances
AC Net AAP World models
CE, RoHS
MTBF����������������������������������������������� 30,000 hours
Warranty����������������������������������������� 3 years parts and labor
N All nominal levels are at ±10%.
N Specifications are subject to change without notice.
