SPECIFICATION
AT W
Language
ENGLIS H
AUTO
More th an 52 dB (A GC Off)
1/3 INCH SO NY EXVIEW HA D CCD II
1020(H) x 508(V ) 520K pi xe ls (NTSC) ｜ 1020(H) x 596(V ) 610K pix els (PAL)
976(H) x 494(V ) 480K pixe ls (NTSC) ｜ 976(H) x 582(V ) 570K pi xe ls (PAL)
Resolution 700 TV Line
Sensor
Effio-ETM
Scanning System 2:1 Interlace
S/N (Y signal)
Total Pixels
Effective Pixels
White Balance
Frequency Horizontal: 15.734KHz / Vertical: 59.94Hz (NTSC) ｜ 15.625KHz / Vertical: 50.00Hz (PAL)
Video Output CVBS: 1.0Vp-p / 75ohm
Electronic shutter speed
AUTO (1/60sec ~ 1/100,000sec) (NTSC)
AUTO (1/50sec ~ 1/100,000sec) (PAL)
Day & Night
Power
DC12V
( AC24V / DC12V DualPower : option )
Operat ing Temperature / Humidity
-10'C ~ +50'C / 30% ~ 80% RH
Storage Temperature / Humidity
-20'C ~ +60'C / 20% ~ 90% RH
Above specifications may be changed without any notice.
3700-8384C [67]
INFRARED BALL DOME CAMERA 1/3 INCH S ONY EXVIEW HAD CCD II
High Resolution / High Sensitivity
Upgraded Weather proof Housing
0 Lux at IR On (IR LED 35 pcs)
External Zoom & Focus Control
Day & Night / SMART IR / Easy Installation
DC Auto IRIS Manual V/F Lens 2.8~12mm
DC Auto IRIS V/F Lens 2.8~12mm
FEATURES
Effio-E TM
700TVL (960H) DSP
CHIPSET 0 Lux a t IR On
Min.Illumination

DIMENSION
INSTALLATION
