WALRUS AUDIO MAKO R1 (High-Fidelity Stereo Reverb)
•Item: 58347
•EAN: 810424032774
•Packaging dimensions: 12.7 x 11.2 x 7 cm
•Weight: 0.54 kg
•Pictures | Translations | User Manual
Need to know for Retailers
•Second pedal to join MAKO series (high-end range)
•Six high-fidelity stereo reverb programs: Spring, Hall, Plate, BFR, Refract and Air
•Momentary sustain or latch for all programs
•Swell,Tune & Tweak control to fully customize all programs
•Stereo in and out
•Save up to 9 presets onboard, 128 via MIDI
•Built on powerful Mako platform with Analog Devices SHARC processor
Full Feature List
•Powerful and versatile multi-function stereo reverb
•Six studio-quality stereo reverb-programs: Spring, Hall, Plate, BFR, Refract, Air
oSpring emulates an excited spring reverb commonly found in tube amps
oHall provides the acoustics of large live sound spaces like concert halls
oPlate emulates a smooth analog plate reverb like EMT 140
oBFR is a no holds, Big F***** Reverb. More than a giant arena reverb
oRefract allows for glitch-like, reverse delay textures hovering over a largely diffused reverb
oAir offers a larger diffused reverb with more “crisp” clarity to its decay
•Each program is customizable to your taste and playing style
•Tweak knob controls Modulation and Pre Delay
•Swell knob controls a volume swell effect
•Tune shapes amount of low and high frequencies in the reverb signal
•Decay controls length of reverb
•Mix sets ratio of dry- to reverb-signal
•X Parameter is unique to program-specific features (size, drive, air, diffusion, …)
•Sus/Latch to momentarily sustain reverb or latch the present reverb decay
•Nine on-board presets
•128 presets accessible via MIDI
•MIDI In/Out DIN connections
•Stereo or Mono operation
•Three bypass modes: true bypass, DSP+ true bypass (trails) and DSP bypass (trails)
•Powerful MAKO platform with Analog Devices SHARC processor
•24-bit 48kHz A/D and D/A converters for high quality audio
•32-Bit floating point processing
•9-volt DC, Center Negative, 300mA minimum
•Power Supply not included
•Made in the USA

FACE BVBA • HOEK 76 - UNIT 301 - 2850 BOOM • [phone] • H.R. ANTWERPEN 291868 • VAT/TVA/BTW 0448 180 481 • [email protected]
Description
The R1 is an extremely powerful and versatile multi-function reverb that can quickly go from small intimate room
sounds to massive washes of experimental euphoria with six customized, studio-quality programs - Spring, Hall,
Plate, BFR, RFRCT (Refract), and Air. Every program can be tuned and tweaked and then saved to one of nine on-
board presets. The R1 boasts a volume swell effect that can be applied to any program, sustain and latching
momentary features, stereo in and out, MIDI control, and up to nine on-board presets (128 via MIDI). Players of all
styles and genres will be able to find eternal inspiration with the R1.
Programs
Spring - The Spring program emulates an excited spring reverb commonly found in tube amps with loads of
transducing drip. Easily go from subtle to full-on surf rock. Experiment with the decay knob to get more than
average amounts of reverb not found in traditional amp spring reverb tanks.
X knob adds a warm grit to the reverb decay.
Hall - The Hall program provides the acoustics of large live sound spaces like concert halls to arenas. Longer
decays and higher X knob settings result in a massive wash of ambiance. Shorter decay and lower X settings allow
for a more intimate reverb expression.
X knob controls the room's size; smaller at lower settings to larger room sizes as you increase X.
Plate –The Plate program emulates a smooth analog plate reverb with nice even diffusion inspired by famous
plates like the EMT 140.
X knob adds grit simulating overdriving the input to the plate reverb.
BFR - BFR is a no holds, big, f____, reverb. This is more than a giant arena reverb. It's a hall-esque reverb with rich
and lush decay in a vast cavern filled with choirs of angels.
X knob controls the amount of diffusion applied to the multi-tap delays used to form the program. At lower X
settings, you'll hear these delays bouncing around for a more textured sound. As you increase the X knob, the
delays are diffused, creating a smooth texture, and lifting your riffs and chords into the atmosphere. See ya.
RFRCT (Refract) - The RFRCT program allows for lovely, charming, glitch-like, and reverse delay textures hovering
over a largely diffused reverb. The Rate controls on RFRCT change how often the glitch and reverse effects occur
while Depth controls the overall volume of these elements.
X knob is used to shape the tone of the glitch and reverse effects. At zero, these elements will have a lo-fi, almost
tape-like sound to them. Increasing the X knob brightens these elements with more pristine details.
Air - The Air program offers a larger diffused reverb but has a more "crisp" clarity to its decay. Explore slow-
building sounds that don't get in the way of your playing. Air compliments keys and synths as well.
X knob introduces wispy and airy textures that move between the left and right channels. At zero, the effect will
be off. Turning clockwise will increase the volume of the air effect.
Presets
The R1 can save up to nine on-board presets, and up to 128 are accessible via MIDI. On-board presets are
accessible with the bank switch. Cycle between presets in each bank by pressing Bypass and tap at the same time.
You will see the right LED change from Red to Green to Blue. Any adjustments made in a preset will change the
tap LED to purple, indicating you have edited the preset. The R1 employs a powerful reverb engine that allows for
the true preset spill over. When you switch presets, the new preset loads, and the previous preset is allowed to
decay naturally.

FACE BVBA • HOEK 76 - UNIT 301 - 2850 BOOM • [phone] • H.R. ANTWERPEN 291868 • VAT/TVA/BTW 0448 180 481 • [email protected]
Tune
Use the Tune knob to shape the amount of low and high frequencies in the reverb signal. The X position is unique
to program-specific features listed above.
Tweak
Each program can be fully customized to your taste and playing style with the Tweak knob.
•Rate: Controls the rate of the LFO applied to the wet reverb signal.
•Depth: Controls the Depth of the LFO applied to the reverb signal.
•Pre Delay: Controls how long it takes after you play for the reverb to become audible.
Bypass Modes
The R1 has three different bypass modes.
•True Bypass
•DSP+True Bypass (trails)
•DSP Bypass (trails)
Momentary Functions
Press and hold the SUS/LATCH (Sustain/Latch) switch to momentarily sustain the current reverb and continue to
play over it through the same reverb algorithm. No dry signal here! Clicking the SUS/LATCH switch lets you latch
the present reverb decay while you play over it.
Specs
•The R1 comes in an anodized matte black finish with red, orange, cream, gold, green, purple and blue ink
•The enclosure’s exact size with knobs is 4.9” x 2.52” x 2.64”. Power requirements are 9VDC (300mA minimum)
•The use of an isolated power supply is recommended for powering all Walrus Audio Pedals. Daisy chain
power supplies are not recommended
•Power supply not included
•24-bit 48kHz A/D and D/A converters for high quality audio
•32-Bit floating point processing
•Sharc & ARM co-processors
