Dunlop Hendrix 68 Shrine Octavio Fuzz Series User manual

This special edition of the Octavio Fuzz pays
tribute to the legendary Jimi Hendrix with a custom
nish that remixes prolic and celebrated rock
artist John Van Hamserveld’s famous 1968 Shrine
Auditorium concert poster art. Packed into an MXR
mini housing, this pedal updates the circuitry of the
original cheese wedge Octavio Fuzz for modern
players and pedalboards with an extra mode of
silicon saturation.
JHMS2
jimdunlop.com/jhms2
Authentic Hendrix
‘68 Shrine Series
Octavio
Fuzz
™
®

JHMS2 | AUTHENTIC HENDRIX™’68 SHRINE SERIES OCTAVIO®FUZZ 2
1LEVEL knob sets overall volume of effect
2OCTAVE switch toggles octave-up fuzz on/off (indicated by red LED)
3FUZZ knob sets intensity of fuzz effect
4FOOTSWITCH toggles effect on/bypass (white LED indicates on)
External Controls
1
2
3
4

JHMS2 | AUTHENTIC HENDRIX™’68 SHRINE SERIES OCTAVIO®FUZZ 3
Authentic Hendrix™’68 Shrine Series Octavio®Fuzz
is powered by the Dunlop ECB003 9-volt adapter
or an MXR®Brick™Series power supply (each sold
separately). This pedal cannot be powered by a
battery.
Power
1 Run a cable from your guitar to JHMS2’s INPUT jack and
another cable from JHMS2’s OUTPUT jack to your amplifier.
2 Start with LEVEL and FUZZ controls at 12 o’clock.
3 Turn effect on by depressing the footswitch.
4 Rotate LEVEL knob clockwise to increase overall volume or
counterclockwise to decrease it.
5 Rotate FUZZ knob clockwise to increase the amount of fuzz
or counterclockwise to decrease it.
6 To engage octave-up fuzz effect, push the OCTAVE switch
to its IN position, indicated by associated LED.
Directions
Basic Operation

JHMS2 | AUTHENTIC HENDRIX™’68 SHRINE SERIES OCTAVIO®FUZZ 4
Specifications
*Drive stage adjusted maximum CW
**With all controls at mid position
Input Impedance 10 kΩ
Output Impedance
Max Volume 400 kΩ
Mid Volume 50 kΩ
Max Output -3 dBV
Max Gain 43 dBV
Bypass True Hardwire
OCTAVE OFF
Input Impedance 10 kΩ
Output Impedance
Max Volume 20 kΩ
Mid Volume 30 kΩ
Max Output -2 dBV
Max Gain 31 dBV
Bypass True Hardwire
OCTAVE ON
Current Draw 5 mA
Power Requirements 9 volts DC
POWER REQUIREMENTS
