Facina VKFCE2 User manual

INTRODUCTION
Congratulations on your purchase of this FACINA
product. This VKFCE2 is a high quality day / night ca era
with long range LED illu ination, externally adjustable
varifocal lens & a sturdy cable anaged ounting bracket.
The ca era can be used indoors or outdoors & has a
re ovable sun shield.
Please read this instruction anual carefully before
installation to ensure correct use of the product.
CONNECTIONS
PRODUCT FEATURES
*
* *
* Sensor (
((
( CCD )
))
)
COLOUR 1/3 " High Resolution CCD sensor.
*
* *
* Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The colour ca -
era can achieve high quality i ages in low Lux conditions
*
* *
* Auto Electronic Shutter (AES)
Built-in auto electronic shutter function. The colour
ca era’s AES speed can reach 1/1 , s.
*
* *
* Gamma Characteristic
Ca era Ga a characteristic is .45.
*
* *
* Scanning Mode
NTSC or PAL ode.
*
* *
* Night-time Vision
0 Lux with IR LED ON. High quality IR LED’s provide
night-vision effect.
DC12V Power Supply
Monitor
VKFCE2
TROUBLE SHOOTING
Cable Cores ：
Power
Video
Note :
: :
:
● Please note the ca era’s operating te perature and its using
environ ent require ent. Avoid using the ca era at too high or
too low te peratures. The operating te perature is -10 ℃ -50 ℃ .
(Reco endatory operating te perature is -5 ℃ --40 ℃ .)
● Never ake the ca era face the sun or bright object. Otherwise,
it will da age the CCD .
● Do not ount the ca era near by a radiator or heater.
1. No Picture after providing power
. May be the power supply. please check the power supply voltage and polar-
ity.
. Please check all the connecting cables to onitoring equip ent, especially
the ‘BNC’ connectors .
2. The picture shows ’rolling’ interference ripples
. May be caused by induced AC voltage on to video cables. Check for AC
cables near video cables & ove as necessary.
. Check the earth potentials at onitor and peripheral equip ents positions.
Earth potentials should be the sa e at each position.
3. The picture background colour changes continuously
. The fluorescent la p’s electro agnetic field causes colour roll. This is a
nor al pheno enon of the ca era.
. Reduce the fluorescent la p nu bers or increase the distance between the
ca era and the fluorescent la ps.
4. The picture ‘smear’s’
. The power supply’s voltage unstable .
. Cables not connected correctly or have high i pedance.
To prevent fire or shock hazarded. Do not i erse the unit
The sy bol is intended to alert the user to the presence of
The sy bol is intended to alert the user to the presence of
into water.
i portant operating and aintenance (servicing)
Instructions in the literature acco panying the appliance.
uninsulated ‘dangerous voltage’ within the product’s
enclosure that ay be of sufficient Magnitude to constitute
a risk of electric shock.
Notes ：
：：
：
● Please ensure the correct specification power supply is used. Check
voltage, polarity and operating te perature atch the ca era’s re-
quire ent .
● Lightning protection is reco ended for use with ca era equip ent. If
not installed, in electrical stor s, ca era equip ent should be
disconnected.
Video
12V DC
CAUTION:
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK
DO NOT REMOVE COVER OR BANCK NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
RISK OF ELECTRIC. DO NOT OPEN
CAUTION:
To prevent electric shocks and risk of fire hazards,
do NOT use other than specified power source.

VKFCE2
Weatherproof Day & Night IR Colour
Camera
Specification
Model
VKFCE2
Pick Up Element COLOUR 1/3
″ CCD
Effective Picture
Elements ( H*V ) 976×582
Horizontal Resolution
700 TV Lines
S/N Ratio
Clock Frequency (MHZ) 36
Scanning System
2:1 interlace
Minimum Illumination
0 Lux (with IR LED ON)
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
1/50s~1/100,000s
Gamma Characteristic
0.45
Video Output
1Vpp,75 Ω
Auto Gain Control
Auto
Power /
//
/ Current 12VDC(±10%)/ 1000 A
Lens
9-22
Dimension (mm) 186(W)×122(H)×118
( D)
Weight (g) 1500
Storage Temperature
-30~ +60 ℃ RH95% Max
Operating Temperature
-10~ +45 ℃ RH95% Max
More than 48dB
IR Distance
Up to 50 Meters ( with 6 Unit Infrared LED)
IR Status
Under 10 Lux by CDS
IR Power On
CDS Auto Control
Water Resistance
IP66
Packing List
No Na e Model Nu ber
2. User Guide 1
1. WeatherProof Day&Night IR Ca era VKFCE2 1
Notes :
::
: Please read this User Guide in
detail prior to installation.
Do not atte pt to disasse ble the ca era.
If the ca era does not work, please contact
Facina technical on Tel: [phone]
