Fanvision Legend User manual

Legend
LE-01VSM-S-RE
User Manual
1.1.1 Turning the Phone On and Off
To turn on or off the phone please hold down the Power key. If your USIM/SIM card have
set a PIN cord, input PIN cord to turn on.
To turn off the phone please hold down the Power key.
1.2 Screen control
You can through the screen of a series of operations to control your phone.
Click: you can choose the screen by clicking on the screen of the project, and
the open application, use the buttons below the screen input.
Sliding: you can pass on the screen horizontal or vertical sliding, realize the
pages up and down, or displayed around.
Long press: you can through the long by some projects get its available menu.
In the long press application programming interface program icon, can the
application shortcuts to add to the main screen.
Drag: you can drag on the screen through some projects achieve certain
operation.
Did screen switching: you can flip through mobile phone screen display of
switching namely. Did display function only in some interface effective, such as
text input interface, surf the web interface, etc.
2 Function Menu
2.1 Contact
You can use the phonebook function to save contact information. You can view or
management your contacts.
NOTICE: SIM card number of records storage capacity and its related
2.2 Phone features
2.2.1.1 Call using the contacts
1. Press the Home key, click on “ ” open the contact.
2. Press the Menu key -> Search, Search for the contacts in the contact list
3. Click on the contact -> select the SIM card call.
2.2.1.2 Answer a call
When you received a call from contacts, click on “ ” answer the call. If the

headset is plugged in, you can also use the button on the headset to answer the call.
2.2.1.3 End the call
When you received a call from contacts, click on ”” refused to call.Dial and call
in, click on the " " to end the current call.
2.3 WLAN
2.3.1 Open the WLAN and connect to a wireless network
1. Press the Home key, click on “ ” -> Settings-> Wireless & networks.
2. Select WLAN check box, to open Wi-Fi. The phone will automatically scan can be
used a wireless network.
3. Click on the Wi-Fi settings.
3 Application
3.1.1 New contact
Contacts->Menu key or click on” ”->new contact. Then enter the new Contact screen.
You can fill the items with contact’s corresponding information such as name,phone
number, address, and so on. To add more items, touch the icon” ”. Input the contact
information, click finish can.
NOTE:
1. Touch Big-head Photos to select a photo to set as the contact’s big-head photo.
2. You can add multiple phone numbers, e-mail addresses, and so on.
3.1.2 Send SMS
1. Messaging ->Compose new message.
2. In the recipient field, enter the recipient number. You can also click “ ” Select
recipients from your contacts.
3. Click on a column of input, enter the message content.
4. Click send.
5. Select SIM card.
3.2 Setting
3.2.1 WLAN
Wi-Fi: select on or off.
Wi-Fi settings: Set up and management wireless access points, etc.
Wi-Fi Direct settings: Set up and management WLAN Direct.
Tethering & portable hotspot: Will you move data connection through cell phone

USB or as a portable WLAN hot share.
VPN settings: Setup and manage virtual private network.
3.3 Camera
3.3.1 Camera
Your mobile phone and camera with dual, it is equipped with a high vivid camera picture
which you can use to take pictures at anytime or place and then save them on your mobile
phone.
1. During the view-finding mode, adjust the lens to allow what is being photographed to
appear in the viewfinder.
2. After framing the picture you wish to take, keep the camera steady and press” “ to
take pictures.
3. After taking photos. You can appear in the menu for the following operation:
3.4 Manage application
Click on management application, running services, storage space use can now
show the download, all, On SD card and running program, click on the program can
choose to stop operating procedures, etc.
1. Downloaded: Show the current already downloaded program.
2. All: Show all of the processes in cell phones.
3. On SD card: Show some of SD card program.
4. Running: Show the current operation procedure.
4 Troubleshooting
If anything unusual occurs while using your Smart Phone, please refer to the
following table.
Frequently
Occurring
Problems
Cause
How to Fix
Poor
reception
Using the Smart Phone in an area
with poor reception such as near
tall buildings or in a basement
where radio waves cannot be
transmitted.
Try to avoid.
Using the SmartPhone when
the network is busy, such as during
rush hour, when the lines are full
making it impossible to get through.
Try to avoid.

Related to the distance from the
base station built by the network.
You can request that the
network service provider
provide a service area plan.
Echo or noise
Caused by poor network relay, a
regional problem.
Hang up and redial, if the relay
is changed then the line may be
better.
Some calling regions have poor
lines.
Shortening of
the standby
time
Standby time is related to the
network system.
Please temporarily turn off your
Smart Phone, as you are
located in an area with poor
reception.
Batteries need to be replaced
Replace the batteries
When you cannot get a signal, the
phone will continue to transmit in
order to find a base station, thereby
expending large amounts of
electricity will cause the standby
time to decrease.
Please move to an area with a
strong signal or temporarily turn
off your Smart Phone.
Unable to turn
on the phone
The battery is empty.
Look at the remaining electricity
or recharge.
SIM card
malfunction
SIM card is damaged.
Contact your network service
provider.
SIM card is not properly inserted.
Confirm SIM card is properly
inserted.
There is a dirty substance on the
metal surface of the SIM card.
Use a clean cloth to wipe off the
metal contact point of the SIM
card.
Unable to
connect with
the network
Expired SIM card
Contact your network provider.
Outside the GSM service area
Consult your network provider
on the service area.
Poor signal.
Please move to a place with a
better signal and try again.
Unable to
make a call
Using the call bar function
Cancel the call bar function.
Using the fixed dial function.
Cancel the fixed call
setting.
Incorrect PIN
number
Consecutively enter the wrong
password three times.
Contact your network provider.
Unable to
charge
The Battery or charger is damaged.
Replace the battery or charger.
Recharging in the environment of
less than -10℃or higher than 55℃.
Change the charging
environment.
Poor contact
Check if the plug is properly
connected
Unable to add
new phone
The storage space of the phone
book is full
Delete a portion of the phone
number entries

book entries
Unable to set
certain
functions
Your network provider does not
support this function or you have
not applied for it.
Contact your network provider.
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
SAR Information Statement
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general population. The guidelines
are based on standards that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health. The exposure
standard for wireless mobile phones employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted
with the phone transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR level of the
phone while operating can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station antenna, the lower the power
output. Before a phone model is available for sale to the public, it must be tested and certified to
the FCC that it does not exceed the limit established by the government adopted requirement for
safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on

the body) as required by the FCC for each model. The highest SAR value for this model phone
when tested for use at the ear is 0.579W/Kg and when worn on the body, as described in this
user guide, is 1.078W/Kg(Body-worn measurements differ among phone models, depending
upon available accessories and FCC requirements). The maximum scaled SAR in hotspot mode is
1.188W/Kg. While there may be differences between the SAR levels of various phones and at
various positions, they all meet the government requirement for safe exposure. The FCC has
granted an Equipment Authorization for this model phone with all reported SAR levels evaluated
as in compliance with the FCC RFexposure guidelines. SAR information on this model phone is on
file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/
oet/fccid after searching on
FCC ID: 2AOHG-LEGEND Additional information on Specific Absorption Rates (SAR) can be found on
the Cellular Telecommunications Industry Asso-ciation (CTIA) web-site at
http://www.wow-com.com. * In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard
incorporates a sub-stantial margin of safety to give additional protection for the public and to
account for any variations in measurements.
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure
requirements, a minimum separation distance
of 10mm must be maintained between the user’s body and the handset, including the antenna.
Third-party belt-clips, holsters,
and similar accessories used by this device should not contain any metallic components.
Body-worn accessories that do not meet these requirements may not comply with RF exposure
requirements and should be avoided. Use only the supplied or an approved antenna.
