Fatar Studiologic FP/50 User manual

Declaration of Conformity
Fatar Srl
Zona Ind.le Squartabue
62019 Recanati MC Italy
declares that this product complies with the following European
Directives and related standards:
2006/95/EC
Low Voltage Directive
EN 60065:
1998
Safety Requirements for Audio, Video and
audio-visual apparatus for professional
use
2004/108/EC
Electromagnetic Compatibility Directive
(EMC)
EN 55103-1/E1:
1997
Product Standard –Audio, Video and
audio-visual apparatus for professional
use, Electromagnetic compatibility of
audio equipment: Emission
EN 55103-2/E1:
1997
Product Standard –Audio, Video and
audio-visual apparatus for professional
use, Electromagnetic compatibility of
audio equipment: Immunity
Technical files are maintained at corporate headquarter of Fatar Srl,
62019 Recanati MC, Italy.
Above declarations are void by modifications of the device without
approval, or unauthorized servicing.
RoHS Conformity
This is to certify that the product is RoHS compliant and meet the
requirements and specified limits of restricted substances according to
2002/95/EC directive.
WEEE
This product is marked with the WEEE symbol to comply with the
European Union’s Waste Electrical & Electronic Equipment (WEEE)
Directive 2002/96/EC. The symbol indicates that this product should not
be treated as household waste. It must be disposed and recycled as
electronic waste. Please assist to keep our environment clean.
FATAR Srl
Zona Ind.le Squartabue
62019 Recanati MC
ITALY
www.fatar.com
© by FATAR Srl
No part of this manual may be reproduced or transmitted in any form
or by any mean without prior consent of the copyright owner.
Revision 11.2019
User Guide
FP/50

Welcome!
Thank you for choosing this volume / expression pedal. You have
obtained a state-of-the-art product made by the renowned manufacturer
Studiologic by Fatar.
Please read the entire user guide thoroughly and keep it for
further reference.
Intended use
This product is designed to operate as volume / expression pedal for
electronic musical instruments only.
Unauthorized conversion and/or modification of the device are
inadmissible because of safety and approval reasons (CE). Any usage
other than described above is not admitted and can damage the product
or the connected device and can cause risks such as short circuit, fire,
electric shock etc.
Important Safety Instructions
Never plug the device to high voltages, such as mains.
This may cause risks of severe injury and death.
This device is designed to be operated by foot, not by
hand. To avoid risk of bodily injury, keep your hands and
fingers away from moving parts (pedal lever).
Electronic devices and accessories must be stored away
from children.
Do not use the device for other purposes than as volume / expression
pedal for electronic musical instruments. Plug the device only to sockets
on your musical device, which are labelled with “Expression”, “Pedal”,
“Foot Controller” or similar.
Water / moisture:
To reduce the risk of fire or electric shock, do not expose the device to
water or moisture. If the device is moved from a cold place to a warm
room, condensation may occur inside. To avoid damage please allow
the device to reach room temperature before using it.
Warranty
Every Fatar Studiologic product has been carefully manufactured,
calibrated and tested. All this enables a period of warranty. Damages
due to incorrect transport, mounting or handling are not covered by this
warranty. All this is based on general terms and condition of the local
distributor / FATAR Srl, Italy. Compensation of more than the price of
the device is excluded.
State of the Art
To ensure maximum quality, all devices of Studiologic by Fatar are
always engineered to be state-of-the-art products. Therefore updates,
modifications and improvements are made without prior notice.
Technical specification and product appearance may vary from this user
guide.
Specifications
Organ style expression pedal.
Connector: 1x TRS jack, 6,3mm (1/4').
Cable length: 2 m
Weight: 1,1 kg
Dimensions: 25,5 x 12 x 10 / 16 cm (L x W x Hmin / Hmax).
Schematics
Compatibility
This product is compatible with most of the Studiologic instruments.
Please check the full list at:
https://studiologic-music.com/support/pedals/
Compatibility to other brands cannot be assured due to different wiring
and hardware standards employed.
Studiologic excludes the liability for damages, which derive from using
the pedal with devices not declared compatible.
Setting up
Plug the connector of your foot switch / sustain pedal to a socket of your
MIDI keyboard, sound expander or digital Piano.
Please refer to the manual of your MIDI device or digital Piano, if the
pedal is supported. In the manual of the MIDI device you will also find
remarks on which parameters you can control with the foot switch
/sustain pedal
Operation
While playing your keyboard, gently press the pedal to apply the desired
volume or expression value. The pedal remains in the last used position
until you change it again.
Cleaning / Maintenance
Never use any abrasive detergent, which may damage the surface. We
recommend a slightly moist micro-fibre cloth.
Do not open the chassis. There are no user serviceable parts inside.
