Ferris 5900716 User manual

Parts
Rev. Date: 07/02/10
IS3100Z Series
Zero-Turn Riding Mower
Manual
5100543
5375 North Main Street
Munnsville, NY 13409 USA
800-933-6175
Briggs and Stratton Yard Power Products Group
TP 400-7282-BA-3Z-F
Models: Descri
p
tion:
5900613 32HP Briggs & Stratton w/ 61" Mower Deck & ROPS (IS3100ZBV3261)
5900716 32HP Briggs & Stratton w/ 61" Mower Deck & ROPS AUS/NZ (IS3100ZBV30/61 AUS/NZ)
5900717 32HP Briggs & Stratton w/ ROPS AUS/NZ (IS3100ZBV32 AUS/NZ)
5900736 32HP Briggs & Stratton w/ 61" Mower Deck & ROPS CAL (IS3100ZBV3261 CAL)
5900753 37HP Kawasaki w/ ROPS (IS3100ZKAV37SS)
5901183 32HP Briggs & Stratton w/ ROPS (IS3100ZBV32)
5900611 26HP Liquid-Cooled V-Twin w/ 61" Mower Deck & ROPS (IS3100ZLKAV2661)
5901186 30HP Briggs & Stratton w/ 61" Mower Deck & ROPS (IS3100ZBV3061)
5900612 30HP Kohler w/ 61" Mower Deck & ROPS (IS3100ZK3061)
5900752 37HP Kawasaki w/ 61" Mower Deck & ROPS (IS3100ZKAV3761SS)
5900718 72" Side Discharge Mower Deck AUS/NZ (3100/72 AUS/NZ)
5901184 72" Side Discharge Mower Deck (3100/72)
BARevision
Not for
Reproduction

Not for
Reproduction

Table Of Content
s
Tor
q
ue S
p
ecification Chart ............................................................................................. Inside Back Cover
MODEL COMPONENTS PAGE
Main Frame & Front Suspension Group - 61" Deck Model ................................................................................................ 4
Main Frame & Front Suspension Group - 72" Deck Model ................................................................................................ 6
Rear Bumper, Roll Bar & Seat Belt Group ......................................................................................................................... 8
Seat Mount & Floor Group ................................................................................................................................................. 10
Fuel Suppl
y
Hose & Tank Replacement Parts Group ........................................................................................................ 12
Fuel Tank & Mount Group .................................................................................................................................................. 14
Instrument Control Group ..................................................................................................................................................
.
16
En
g
ine & PTO Group - Bri
gg
s & Stratton 30HP
(
All
)
& 32HP
(
S/N: 2013556395 & Below
)
............................................... 18
En
g
ine & PTO Group - Kohler 30 HP ................................................................................................................................
.
22
Engine & PTO Group - Kawasaki 26 HP Liquid Cooled ..................................................................................................... 26
En
g
ine & PTO Group - Kawasaki 37 HP ............................................................................................................................ 30
Pump Drive Group
(
S/N: 2014192366 & Below
)
................................................................................................................ 34
Motion Control Group - Lower ............................................................................................................................................ 36
Motion Control Group - Upper ............................................................................................................................................ 38
H
y
draulic Group
(
S/N: 2013257171 & Below
)
.................................................................................................................... 40
H
y
draulic Group
(
S/N: 2013257172 & Above
)
................................................................................................................... 42
Reservoir Mount & Battery Group ...................................................................................................................................... 44
Parking Brake Group .........................................................................................................................................................
.
46
Rear Suspension Group -
(
S/N: 2012803266 & Below
)
..................................................................................................... 48
Rear Suspension Group -
(
S/N: 2012803267 & Above
)
..................................................................................................... 50
Deck Lift Group (S/N: 2000729893 & Below) ..................................................................................................................... 52
Deck Lift Group (S/N: 2000729894 & Above) .................................................................................................................... 56
Wheel & Tire Group ........................................................................................................................................................... 60
Decal Group - Brand & Model ............................................................................................................................................ 62
Decal Group - Safety & Operation .....................................................................................................................................
.
64
61" & 72" Mower Deck - Han
g
er Chains ............................................................................................................................ 66
61" Mower Deck - Housin
g
, Covers, Spindles & Blades ....................................................................................................68
61" Mower Deck - Pulleys, Belt & Idler Arm ....................................................................................................................... 70
61" Mower Deck - Rollers & Casters .................................................................................................................................. 72
61" Mower Deck - Rear Mount Bars ..................................................................................................................................
.
74
72" Mower Deck - Housin
g
, Covers, Spindles & Blades ....................................................................................................76
72" Mower Deck - Pulleys, Belt & Idler Arm ....................................................................................................................... 78
72" Mower Deck - Rollers & Casters .................................................................................................................................. 80
72" Mower Deck - Rear Mount Bars ..................................................................................................................................
.
82
61" & 72" Mower Decks - Han
g
er Chains ..........................................................................................................................
.
84
Electrical Schematics - Kawasaki 26HP LC ....................................................................................................................... 86-89
Electrical Schematics - Kohler 30HP .................................................................................................................................
.
90-93
Electrical Schematics - Bri
gg
s & Stratton 30HP & 32HP ................................................................................................... 94-97
Electrical Schematics - Kawasaki 37HP ............................................................................................................................
.
98-101
Not for
Reproduction

Main Frame & Front Suspension Group - 61" Deck Model
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 4 © Copyright Briggs and Stratton. All Rights Reserved.
5901186
(
IS3100ZBV3061
)
5900613
(
IS3100ZBV3261
)
5900612
(
IS3100ZK3061
)
5900611
(
IS3100ZLKAV2661
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900752
(
IS3100ZKAV3761SS
)
5900736
(
IS3100ZBV3261 CAL
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Main Frame & Front Suspension Group - 61" Deck Model
Footnotes
1 5400486B 1 WELD, MAIN FRAME, IS3000Z (Serial No.: 2013221685 & Below.)
2 5025293 4 WASHER 3/8" GD. 9 FLAT
3 5025394 4 NUT, 3/8-16 HEX NYLOCK FLANGE
4 5025013X16 2 BOLT, 3/8-16 X 2" GD5
5 5025013X18 2 BOLT, 3/8-16 X 2-1/4" GD5
6 5022039 4 BALL JOINT, 3/4-16 MALE
7 5022673 2 BUMPER, RUBBER 1/4-20
8 5025126 2 NUT, 1/4-20 HEX SERR. FLANGE
9 5023343 4 FLANGE BUSHING
10 5025203X10 2 PIN, COTTER, 1/8" X 1-1/4"
11 5020095 2 GREASE FITTING, 1/4-28 STR
12 5025160 2 WASHER, 3/4" SAE
13 5025104 2 NUT, 3/4-16 HEX SLOTTED
14 5020884 4 BEARING, TAPPERD ROLLER, 1"
15 5021072 2 SEAL, GREASE
16 5045769B 2 WELD, CASTER YOKE
17 5023436 2 COIL - OVER SHOCK ASSEMBLY
18 5021073 2 CAP, DUST
19 5025284 4 NUT, 3/4-16 HEX NYLON LOCK
20 5025093 4 NUT, HEX JAM, 3/4-16
21 5025265X24 2 BOLT, 3/4-16 X 3" GD 5
22 5025265X28 2 3/4-16 X 3.5" HHCS YZP GR 5
23 5047461 4 SPACER, .76 X 1.00 X .25
24 5046093 2 SPACER, .75 X 1.50 X 1.00
25 5046092 2 SPACER, .76 X 1.00 X .50
26 5047742B 1 ASSM, A-ARM, RH (Includes Ref. No. 9 and 11.)
27 5047743B 1 ASSM, A-ARM, LH (Includes Ref. No. 9 and 11.)
28 5020883 4 BEARING CUP
29 5402229B 1 WELD, A-ARM - RH - RED (Serial No.: 2000676809 & Above.)
30 5402230B 1 WELD, A-ARM - LH - RED (Serial No.: 2000676809 & Above.)
31 5100882 2 CAP, CASTER SPINDLE, LOW PROFILE (Serial No.: 2000676809 & Above.)
32 5025448 2 NUT, 3/4-16, HEX JAM NYLON LOCK (Serial No.: 2000676809 & Above.)
33 5025449 4 BELLEVILLE WASHER, 1.500 X .755 (Serial No.: 2000676809 & Above.)
34 5402207B 2 WELD, CASTER YOKE - RED (Serial No.: 2000676809 & Above.)
35 5025457 2 BOLT, 1/4-28 X 1/2, GD5 YZ (Serial No.: 2000676809 & Above.)
36 5404428B 1 WELD, MAIN FRAME, IS3100Z (Serial No.: 2013221686 & Above.)
The above parts group applies to the following Mfg. Nos.:
2010 5 © Copyright Briggs and Stratton. All Rights Reserved.
5901186
(
IS3100ZBV3061
)
5900613
(
IS3100ZBV3261
)
5900612
(
IS3100ZK3061
)
5900611
(
IS3100ZLKAV2661
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900752
(
IS3100ZKAV3761SS
)
5900736
(
IS3100ZBV3261 CAL
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

Main Frame & Front Suspension Group - 72" Deck Model
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 6 © Copyright Briggs and Stratton. All Rights Reserved.
5900717
(
IS3100ZBV32 AUS/NZ
)
5901183
(
IS3100ZBV32
)
5900753
(
IS3100ZKAV37SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Main Frame & Front Suspension Group - 72" Deck Model
Footnotes
1 5400486B 1 WELD, MAIN FRAME, IS3000Z (Serial No.: 2013221685 & Below)
2 5025126 2 NUT, 1/4-20 HEX SERR. FLANGE
3 5022673 2 BUMPER, RUBBER 1/4-20
4 5025265X28 4 3/4-16 X 3.5" HHCS YZP GR 5
5 5047461 4 SPACER, .76 X 1.00 X .25
6 5023343 4 BUSHING, 1.00 X 1.13 X 1.38, PLASTIC
7 5046093 4 SPACER, .75 X 1.50 X 1.00
8 5025093 4 WASHER 3/8" GR. 9
9 5025394 4 NUT, 3/8-16 HEX NYLOCK FLANGE
10 5025013X16 2 BOLT, 3/8-16 X 2" GD5
11 5025013X18 2 BOLT, 3/8-16 X 2-1/4" GD5
12 5022039 4 BALL JOINT, 3/4-16 MALE
13 5020883 4 BEARING CUP
14 5025203X10 2 PIN, COTTER, 1/8" X 1-1/4"
15 5020095 2 GREASE FITTING, 1/4-28 STR
16 5025160 2 WASHER, 3/4" SAE
17 5025104 2 NUT, 3/4-16 HEX SLOTTED
18 5020884 4 BEARING, TAPPERD ROLLER, 1"
19 5021072 2 SEAL, GREASE
20 5045769B 2 WELD, CASTER YOKE
21 5023383 2 COIL - OVER SHOCK ASSEMBLY
22 5021073 2 CAP, DUST
23 5025284 4 NUT, 3/4-16 HEX NYLON LOCK
24 5025093 4 NUT, HEX JAM, 3/4-16
25 5401522B 1 WELD, RH A-ARM, 72", IS3100Z
26 5401523B 1 WELD, LH A-ARM, 72", IS3100Z
27 5402212B 1 WELD, A-ARM - RH - RED -72" (Serial No.: 2000676809 & Above)
28 5402213B 1 WELD, A-ARM - LH - RED - 72" (Serial No.: 2000676809 & Above)
29 5100882 2 CAP, CASTER SPINDLE, LOW PROFILE (Serial No.: 2000676809 & Above)
30 5025448 2 NUT, 3/4-16, HEX JAM NYLON LOCK (Serial No.: 2000676809 & Above)
31 5025449 4 BELLEVILLE WASHER, 1.500 X 7.55 (Serial No.: 2000676809 & Above)
32 5402207B 2 WELD, CASTER YOKE - RED (Serial No.: 2000676809 & Above)
33 5025457 2 BOLT, 1/4-28 X 1/2, GD5 YZ (Serial No.: 2000676809 & Above)
34 5404428B 1 WELD, MAIN FRAME, IS3100Z (Serial No.: 2013221686 & Above)
The above parts group applies to the following Mfg. Nos.:
2010 7 © Copyright Briggs and Stratton. All Rights Reserved.
5900717
(
IS3100ZBV32 AUS/NZ
)
5901183
(
IS3100ZBV32
)
5900753
(
IS3100ZKAV37SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

Rear Bumper, Roll Bar & Seat Belt Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 8 © Copyright Briggs and Stratton. All Rights Reserved.
5900613
(
IS3100ZBV3261
)
5900612
(
IS3100ZK3061
)
5900611
(
IS3100ZLKAV2661
)
5901183
(
IS3100ZBV32
)
5901186
(
IS3100ZBV3061
)
5900736
(
IS3100ZBV3261 CAL
)
5900753
(
IS3100ZKAV37SS
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900752
(
IS3100ZKAV3761SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Rear Bumper, Roll Bar & Seat Belt Group
Footnotes
1 5100139 1 SEAT BELT RETRACTING
2 5025394 6 NUT, 3/8-16 HEX NYLOCK FLANGE
3 5025293 6 WASHER 3/8" GD9
4 5025013X10 4 BOLT, 3/8-16 X 1-1/4" GD5
5 5025013X8 2 BOLT, 3/8-16 X 1" GD5
6 5400844B 2 SEAT BELT BRACKET, IS3000 - RED
7 5023484 8 PLUG, PANEL, 1.25 BLACK
8 5401105B 1 SHIELD, KAWI, 3000 - RED (Kawasaki model only.)
8 5400513B 1 SHIELD, CARBURETOR - RED (Briggs & Stratton model only.)
9 5400495B 1 WELD, BUMPER 3000 - RED (Briggs & Stratton and Kawasaki model only.)
9 5401494B 1 WELD, BUMPER, 3100Z - KOHLER - RED (Kohler model only.)
10 5100267 2 SCREW, 1/2-13 X 1.00, SHCS
11 - 1 ROLL BAR POST, RH
12 5100189 1 ROPS COMPLETE IN BOX, IS3000 (SEE DRAWING NOTE.)
13 5025018X10 2 BOLT, 1/2-20 X 1-1/4" GRD5
14 5025098 2 NUT, 1/2-20 HEX NYLON LOCK
15 5025396 2 NUT, 1/2-13 HEX NYLOCK FLANGE
16 - 1 ROLL BAR TOP LOOP (SEE DRAWING NOTE.)
17 5100547 2 RUBBER CAP
18 5100079 2 PIN WITH LANYARD
19 5100378 1 HARDWARE BAG (Includes Ref. Nos. 18,19, 21, and 22.)
20 5100383 2 RUBBER BUMPER
21 5100545 2 RUBBER WASHER
22 - 1 ROLL BAR POST, LH (SEE DRAWING NOTE.)
23 5402350B 1 PLATE, HEAT SHIELD, BUMPER (Kawasaki & Briggs Models Only
24 5025011X6 4 BOLT, 5/16-18 X 3/4" (Kawasaki & Briggs Models Only
25 5025155 4 WASHER, 5/16" SAE (Kawasaki & Briggs Models Only
26 5025392 4 NUT, 5/16-18 HEX NYLOCK FLANGE (Kawasaki & Briggs Models Only
27 5101226 1 RETRACTOR, SEAT BELT (FOR SUSPENSION SEAT ONLY)
28 5101223 1 SUPER SLEEVE BUCKLE, SEAT BELT (FOR SUSPENSION SEAT ONLY)
The above parts group applies to the following Mfg. Nos.:
2010 9 © Copyright Briggs and Stratton. All Rights Reserved.
5900613
(
IS3100ZBV3261
)
5900612
(
IS3100ZK3061
)
5900611
(
IS3100ZLKAV2661
)
5901183
(
IS3100ZBV32
)
5901186
(
IS3100ZBV3061
)
5900736
(
IS3100ZBV3261 CAL
)
5900753
(
IS3100ZKAV37SS
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900752
(
IS3100ZKAV3761SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

Seat Mount & Floor Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 10 © Copyright Briggs and Stratton. All Rights Reserved.
5901183
(
IS3100ZBV32
)
5900613
(
IS3100ZBV3261
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900612
(
IS3100ZK3061
)
5900611
(
IS3100ZLKAV2661
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5901186
(
IS3100ZBV3061
)
5900753
(
IS3100ZKAV37SS
)
5900736
(
IS3100ZBV3261 CAL
)
5900752
(
IS3100ZKAV3761SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Seat Mount & Floor Group
Footnotes
1 5400509B 1 FLOOR PAN, 3000 - RED (S/N: 2013102109 & Below)
2 5025155 4 WASHER, 5/16" SAE
3 5025144X6 6 BOLT, 1/4-20 X 3/4", CARRIAGE
4 5100389 2 PLATE, SEAT, RUBBER FLAP
5 5025392 10 NUT, 5/16-18 HEX NYLOCK FLANGE
6 5025394 3 NUT, 3/8-16 HEX NYLOCK FLANGE
7 5025013X28 2 BOLT, 3/8-16 X 3-1/2" GD5
8 5600303 1 SEAT PLATE W/ DECALS, IS3100Z (Includes Safety Decals.)
9 5022955 1 SEAT, DELUXE, GRAY (COMPLETE) (NON SUSPENSION SEAT MODEL)
9 5022955X1 1 SEAT BOTTOM COVER (SV) (NON SUSPENSION SEAT REPLACEMENT
PARTS)
9 5022955X2 1 SEAT BACK COVER (SV) (NON SUSPENSION SEAT REPLACEMENT PARTS)
9 5022955X3 2 ARM REST SET (SV) (INCLUDES ARM REST PADS - NON SUSPENSION
SEAT REPLACEMENT PARTS)
9 5022955X4 2 ARM REST PADS (SV) (NON SUSPENSION SEAT REPLACEMENT PARTS)
9 5020930X3 1 SEAT ADJUSTMENT RAILS (SV) (SET OF 2 - NON SUSPENSION SEAT
REPLACEMENT PARTS)
9 5100652 1 SPRING, EXTENSION, 4" SEAT ADJUSTMENT (SV) (NOT SHOWN - NON
SUSPENSION SEAT REPLACEMENT PARTS)
10 5025011X8 4 BOLT, 5/16-18 X 1" GD5
11 5101007 1 SAFETY WALK, FLOOR REST
12 5100999 1 SAFETY WALK, FLOOR PLATE
13 5023310 1 MODULE, TIME DELAY
14 5100356 1 SPRING, .688 ID X .130 WIRE DIA 4.25
15 5021379 2 GROMMET, 7/8"
16 5021518 1 FUSE, BLOCK
16 5022805 1 COVER, VINYL FUSE BLOCK (Not shown.)
17 5022094 1 SWITCH PLUNGER N.C. / N.C.
18 5022612 2 BUMPER, RUBBER 5/16-18
19 5046586 1 SPACER, .38 X .50 X 5.06
20 5025326 1 WASHER 3/8" X 2
21 5025013X48 1 BOLT, 3/8-16 X 6" GD5
22 5025156 1 WASHER 3/8" SAE
23 5025029 2 NUT, 10-24 HEX
24 5025271 4 NUT, #10-24 HEX NYLON LOCK
25 5025179X4 6 SCREW, #10-24 X 1/2" ROUND SLOTTED
27 5025391 6 NUT, 1/4-20 HEX NYLOCK FLANGE
28 5025288 6 WASHER, 1/4" FENDER
29 5101214 1 SEAT, SUSPENSION TYPE, BLACK (SUSPENSION SEAT MODEL)
30 5101214X1 1 KIT, ARM REST, S/S (SV) (SUSPENSION SEAT REPLACEMENT PARTS)
31 5101214X2 1 CUSHION, BACK, S/S (SV) (SUSPENSION SEAT REPLACEMENT PARTS)
32 5101214X3 1 CUSHION, SEAT, S/S (SV) (SUSPENSION SEAT REPLACEMENT PARTS)
33 5101214X4 1 KIT, ADJUSTER, S/S (SV) (SUSPENSION SEAT REPLACEMENT PARTS)
34 5404101B 1 PLATE, FLOOR PAN, IS3100 - RED (S/N: 2013102110 & Above)
The above parts group applies to the following Mfg. Nos.:
2010 11 © Copyright Briggs and Stratton. All Rights Reserved.
5901183
(
IS3100ZBV32
)
5900613
(
IS3100ZBV3261
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900612
(
IS3100ZK3061
)
5900611
(
IS3100ZLKAV2661
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5901186
(
IS3100ZBV3061
)
5900753
(
IS3100ZKAV37SS
)
5900736
(
IS3100ZBV3261 CAL
)
5900752
(
IS3100ZKAV3761SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

Fuel Supply Hose & Tank Replacement Parts Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 12 © Copyright Briggs and Stratton. All Rights Reserved.
5901183
(
IS3100ZBV32
)
5900752
(
IS3100ZKAV3761SS
)
5900613
(
IS3100ZBV3261
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900611
(
IS3100ZLKAV2661
)
5901186
(
IS3100ZBV3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900736
(
IS3100ZBV3261 CAL
)
5900612
(
IS3100ZK3061
)
5900753
(
IS3100ZKAV37SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Fuel Supply Hose & Tank Replacement Parts Group
Footnotes
1 5023358 1 VALVE, FUEL, STR. OUTLET
2 5020835 5 CLAMP, HOSE, EXTERNAL, 1/2 - RED
3 5050831X49 1 HOSE, 1/4" FUEL, 49.00"
4 5022922 1 CLAMP, #4 HOSE, STAINLESS (Kawasaki model only.)
5 5050831X5 1 HOSE, 1/4" FUEL, 5.00" (Kawasaki model only.)
6 5050831X10 1 HOSE, 1/4" FUEL, 10.00" (Kohler model only.)
7 5050831X41 1 HOSE, 1/4" FUEL, 41.00" (Briggs & Stratton model only.)
8 5050831X12 1 HOSE, 1/4" FUEL, 12.00"
9 - 2 SEE REF # 14
10 5600050 2 KIT, BUSHING, FUEL
11 - 4 SEE REF # 14
12 - 2 SEE REF # 14
13 - 2 SEE REF # 14
14 5101144 2 HOSE ASSEMBLY (Includes Ref. Nos 9,10,11,12, and 13.)
The above parts group applies to the following Mfg. Nos.:
2010 13 © Copyright Briggs and Stratton. All Rights Reserved.
5901183
(
IS3100ZBV32
)
5900752
(
IS3100ZKAV3761SS
)
5900613
(
IS3100ZBV3261
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900611
(
IS3100ZLKAV2661
)
5901186
(
IS3100ZBV3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900736
(
IS3100ZBV3261 CAL
)
5900612
(
IS3100ZK3061
)
5900753
(
IS3100ZKAV37SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

Fuel Tank & Mount Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 14 © Copyright Briggs and Stratton. All Rights Reserved.
5900611
(
IS3100ZLKAV2661
)
5901186
(
IS3100ZBV3061
)
5900613
(
IS3100ZBV3261
)
5901183
(
IS3100ZBV32
)
5900753
(
IS3100ZKAV37SS
)
5900736
(
IS3100ZBV3261 CAL
)
5900612
(
IS3100ZK3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900752
(
IS3100ZKAV3761SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Fuel Tank & Mount Group
Footnotes
1 5401095B 2 PLATE, TANK BADGE - IS2000/COBALT - RED
2 5025386 8 SCREW, Allen Head, #10-24 x 3/8"
3 5025155 10 WASHER, 5/16" SAE
4 5025392 2 NUT, 5/16-18 HEX NYLOCK FLANGE
5 5025170 8 WASHER, 5/16" LOCK
6 5025011X6 8 BOLT, 5/16-18 X 3/4" GRD5
7 5400490B 2 WELD, TANK MOUNT - RED
8 5101651 2 CAP, FUEL TANK, 3-1/2" NECK
9 5022917X1 2 GROMMET, FUEL GAGE
10 5022917 2 GAUGE, FUEL 12"
11 5100176 1 TANK, FUEL, IS2000/IS3000-LH
12 5100175 1 TANK, FUEL IS2000 / 3000Z - RH
13 5023358 1 VALVE, FUEL STRAIGHT, OUTLET
14 5025011X8 2 BOLT, 5/16-18 X 1" GRD5 YZ
15 5401108B 1 FUEL, VALVE BRACKET - RED
16 5025013X8 8 BOLT, 3/8-16 X 1" GD5 YZ
17 5025156 8 WASHER, 3/8" SAE
18 5025394 8 NUT, 3/8-16 HEX NYLOCK FLANGE
19 5100342 1 DECAL, FUEL VALVE
20 5102224 1 FUEL TANK, RH, IS3100Z 37HP DFI (37HP Kawasaki DFI Models Only)
21 5102225 1 FUEL TANK, LH, IS3100Z 37HP DFI (37HP Kawasaki DFI Models Only)
22 5100587 1 VALVE, FUEL SHUT-OFF, 11765 (37HP Kawasaki DFI Models Only)
23 5100624 1 DECAL, FUEL VALVE, DFI (37HP Kawasaki DFI Models Only)
The above parts group applies to the following Mfg. Nos.:
2010 15 © Copyright Briggs and Stratton. All Rights Reserved.
5900611
(
IS3100ZLKAV2661
)
5901186
(
IS3100ZBV3061
)
5900613
(
IS3100ZBV3261
)
5901183
(
IS3100ZBV32
)
5900753
(
IS3100ZKAV37SS
)
5900736
(
IS3100ZBV3261 CAL
)
5900612
(
IS3100ZK3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900752
(
IS3100ZKAV3761SS
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

Instrument Control Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 16 © Copyright Briggs and Stratton. All Rights Reserved.
5900753
(
IS3100ZKAV37SS
)
5900612
(
IS3100ZK3061
)
5900611
(
IS3100ZLKAV2661
)
5900613
(
IS3100ZBV3261
)
5900736
(
IS3100ZBV3261 CAL
)
5900752
(
IS3100ZKAV3761SS
)
5901186
(
IS3100ZBV3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5901183
(
IS3100ZBV32
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Instrument Control Group
Footnotes
1 5025299X4 3 SCREW, ALLEN HEAD, 1/4-20X1/2
2 5025010X6 2 BOLT, 1/4-20 X 3/4" GD5 (S/N: 2012617338 & Below)
3 5021662 1 CABLE, THROTTLE CONTROL, 54" (S/N: 2012617338 & Below)
4 5025391 2 NUT, 1/4-20 HEX NYLOCK FLANGE (S/N: 2012617338 & Below)
5 5025035 1 NUT, HEX 3/8-24
6 5061533 1 CABLE, CHOKE CONTROL, 60" (SHORT BODY) (Kohler model only.)
6 5047779 1 CABLE, CHOKE CONTROL, 51" (Z) (Kawasaki Liquid Cooled model only.)
6 5046361 1 CABLE, CHOKE CONTROL, (51") (Kawasaki 37HP and Briggs & Stratton model
only.)
7 5022180 1 SWITCH, BLADE ENGAGEMENT
8 5102417 1 HOUR METER
9 5020927 1 SWITCH, IGNITION, 6 POST (Includes Ref. Nos 14, 15, and 16.)
10 5023393 1 GAUGE, WATER TEMPERATURE (Kawasaki Liquid Cooled model only.)
11 1709188 1 HOLE, PLUG DASH
12 5400979A 1 PANEL, CONTROL, IS3100Z LC - BLACK (Kawasaki Liquid Cooled model only -
S/N: 2012617338 & Below)
12 5401109A 1 PANEL. CONTROL, IS3100Z - BLACK (Kohler, Kawasaki 37HP and Briggs &
Stratton models only - S/N: 2012617338 & Below)
13 5022222 1 RING, SWITCH RETAINER
14 5022789 1 KEY, IGNITION MOLDED SET (Not shown)
15 5022790 1 COVER (Not shown)
16 5022791 1 PLASTIC NUT (Not shown)
17 5101537 1 LEVER, THROTTLE CONTROL, HEAVY DUTY (S/N: 2012617339 & Above)
18 5101072 1 CABLE, THROTTLE, 52" (S/N: 2012617339 & Above)
19 5046360X1 1 KNOB, THROTTLE CONTROL (SV) (S/N: 2012617339 & Above)
20 5025179X6 2 SCREW, #10-24 X 3/4" (S/N: 2012617339 & Above)
21 5025271 2 NUT, #10-24 HEN NYLON LOCK (S/N: 2012617339 & Above)
22 5403386A 1 PANEL, CONTROL, IS3000Z LC (Kawasaki Liquid Cooled model only - S/N:
2012617339 & Above)
23 5403387A 1 PANEL, CONTROL, IS3000Z (Kohler, Kawasaki 37HP and Briggs & Stratton
models only - S/N: 2012617339 & Above)
The above parts group applies to the following Mfg. Nos.:
2010 17 © Copyright Briggs and Stratton. All Rights Reserved.
5900753
(
IS3100ZKAV37SS
)
5900612
(
IS3100ZK3061
)
5900611
(
IS3100ZLKAV2661
)
5900613
(
IS3100ZBV3261
)
5900736
(
IS3100ZBV3261 CAL
)
5900752
(
IS3100ZKAV3761SS
)
5901186
(
IS3100ZBV3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5901183
(
IS3100ZBV32
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

Engine & PTO Group - Briggs & Stratton 30HP (All) & 32HP (S/N: 2013556395 & Below)
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 18 © Copyright Briggs and Stratton. All Rights Reserved.
5901183
(
IS3100ZBV32
)
5901186
(
IS3100ZBV3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900613
(
IS3100ZBV3261
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900736
(
IS3100ZBV3261 CAL
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Engine & PTO Group - Briggs & Stratton 30HP (All) & 32HP (S/N: 2013556395 & Below)
Footnotes
1 - 1 ENGINE, 32 HP BRIGGS & STRATTON (32HP Briggs & Stratton models only.)
2 5025011X8 3 BOLT, 5/16-18 X 3/4 GD5 YZ
3 5046416B 1 CLUTCH ANCHOR - RED
4 5025394 6 NUT, 3/8-16 HEX NYLOCK FLANGE
5 5043636 1 CLUTCH ANCHOR PAD
6 5025165 3 WASHER, 3/8" FENDER
7 5025392 5 NUT, 5/16-18 HEX NYLOCK FLANGE
8 5025155 2 WASHER, 5/16" SAE
9 5045938 1 BOLT, CRANKSHAFT, 7/16"X2-1/4
10 5045475 1 SPACER, .45 X 1.88 X .38 (32HP Briggs & Stratton models only.)
11 5023233 1 ELECTRIC CLUTCH (32HP Briggs & Stratton models only.)
12 5050407X16 1 KEY, 1/4 SQ. X 2 (32HP Briggs & Stratton models only.)
13 5042945 1 SPACER, 1.13 X 2.00 X .19 (32HP Briggs & Stratton models only.)
14 5047075 1 PULLEY, CRANKSHAFT (DOUBLE A) (32HP Briggs & Stratton models only.)
15 5050407X8 1 KEY, 1/4" SQ. X 1"
16 5101554 1 SPACER, 1.13 X 1.75 X 1.090, BLACK ZINC
17 5100875 1 CLUTCH, WARNER, # 5218-158 (30HP Briggs & Stratton models only.)
18 5044062 1 SPACER,1.13 X 1.75 X .50 (30HP Briggs & Stratton models only.)
19 - 1 ENGINE, 30 HP BRIGGS & STRATTON (30HP Briggs & Stratton models only.)
20 5100874 1 PULLEY, 5.25 OD X 1.126 ID (30HP Briggs & Stratton models only.)
21 5021500 1 CLAMP, VINYL
22 5048681 1 HOSE, OIL DRAIN
23 5025011X12 3 BOLT, 5/16-18 X 1-1/2" GD5 YZ (For front left engine mounting bolt refer to Ref.
No. 36)
24 5025170 4 WASHER, 5/16" LOCK
25 5025392 6 NUT, 5/16-18 HEX NYLOCK FLANGE
26 5025011X6 2 BOLT, 5/16-18 X 3/4" GD5
27 5025155 2 WASHER, 5/16" SAE
28 843906X1 1 MUFFLER
29 5025013X8 2 BOLT 3/8-16 X 1" GD5 YZ
30 5402351B 1 PLATE, HEAT SHIELD, FRAME
31 841238 1 ELEMENT, AIR CLEANER, SECONDARY (Not shown)
32 5025010X8 1 BOLT, 1/4-20 X 1", GD5
33 5025391 1 NUT, 1/4-20 HEX NYLOCK FLANGE
34 5025188 4 WASHER, 5/16" INT. TOOTH LOCK
35 5100366 1 METRIC ADAPTER, M14-1.5" TO 3/8 NPTF
36 5025011X16 1 BOLT, 5/16-18 X 2" GD5 YZ (Front left engine mounting bolt)
37 809268 1 RAIN CAP (Not shown)
38 809218 1 AIR CLEANER ASSEMBLY, COMPLETE (Not shown)
39 841237 1 ELEMENT, AIR CLEANER, PRIMARY (Not shown)
40 842921 1 FILTER, OIL, BRIGGS & STRATTON (Not shown)
41 5025470 1 SELF TAPPING SCREW (Not shown)
The above parts group applies to the following Mfg. Nos.:
2010 19 © Copyright Briggs and Stratton. All Rights Reserved.
5901183
(
IS3100ZBV32
)
5901186
(
IS3100ZBV3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900613
(
IS3100ZBV3261
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900736
(
IS3100ZBV3261 CAL
)
TP 400-7282-BA-3Z-F
Not for
Reproduction

Engine & PTO Group - Briggs & Stratton 30HP (All) & 32HP (S/N: 2013556395 & Below)
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2010 20 © Copyright Briggs and Stratton. All Rights Reserved.
5901183
(
IS3100ZBV32
)
5901186
(
IS3100ZBV3061
)
5900717
(
IS3100ZBV32 AUS/NZ
)
5900613
(
IS3100ZBV3261
)
5900716
(
IS3100ZBV30/61 AUS/NZ
)
5900736
(
IS3100ZBV3261 CAL
)
TP 400-7282-BA-3Z-F
Not for
Reproduction
