FESLEY FED-1000 User manual

INSTRUCTION MANUAL
FED-1000
Electric Drum
To connect directly with our support team,
please email [email protected]
TO LEAD A NEW COOL

FUNCTION INTRODUCTION
1
MECHANICAL HAMMER KICK DRUM PEDAL
The mechanically simulated kick drum pedal brings
you a real feeling of pedaling
Thank you for choosing the Fesley electronic drum. The elegant and delicate Fesley electronic drum
is the perfect combination of modern and new electronic technology. It is strongly recommended
that you read this instruction before using it.
◆ Please store this instruction in a safe place for future reference.
● Six layers of force are adopted to make it closer to the acoustic drum playing.
● Supports double triggers with the edge-hit response.
● 30 drum kits and one custom drum kit.
● Number of timbres 225 and GM standard timbre library. (song use)
● Thirty songs, adjustable GM volume and drum volume .(for learning)
● Effect: reverberation type 0-5, two-band EQ equalization.
● Supporting adjustment of sensitivity parameters of drum discs.
● Speed control: 30-250 beats/minute.
● Metronome: 9 kinds.
● Other functions: customize settings, store and restore factory settings.
● Interpoles: USB MIDI, headphones, audio input, audio output, adding cymbal port.
REMARK！
● This product is an electro-acoustic instrument product. It is normal that there is a little current
sound in the speaker or earphone after power-on.
Keep away from "radio, TV, antenna receiver, router, refrigerator, TV, motor and other RF electrical
interference sources" during using.

CONTENTS
2
FUNCTION INTRODUCTION ------------------------------------------------------
CONTENTS ---------------------------------------------------------------------------
INSTALLATION GUIDE --------------------------------------------------------------
Check the attached items --------------------------------------------------------------------
Install the kick drum----------------------------------------------------------------------------
Install the hammer -----------------------------------------------------------------------------
Fix kick drum and kick drum pedal ------------------------------------------------------------
Install the module bracket----------------------------------------------------------------------
ASSEMBLY DRAWING-------------------------------------------------------------------------
Pipe fitting --------------------------------------------------------------------------------------
Drum pan intubation ---------------------------------------------------------------------------
Mounting stand---------------------------------------------------------------------------------
Install the support arm--------------------------------------------------------------------------
Install striking parts and sound module--------------------------------------------------------
Hi-hat stand ------------------------------------------------------------------------------------
Hi-hat parts introduction -----------------------------------------------------------------------
Detailed introduction of important parts -----------------------------------------------------
ILLUSTRATION OF MODULE SOCKET -------------------------------------------
Power cord connection ----------------------------------------------------------------------
USB MIDI port---------------------------------------------------------------------------------
Audio input port ------------------------------------------------------------------------------
Headphone port ------------------------------------------------------------------------------
Audio output port ----------------------------------------------------------------------------
Increase cymbal port -------------------------------------------------------------------------
OPERATION GUIDE ----------------------------------------------------------------
Power on --------------------------------------------------------------------------------------
Master volume -------------------------------------------------------------------------------
Drum kit timbre selection ------------------------------------------------------------------
Drum percussion ----------------------------------------------------------------------------
Metronome -----------------------------------------------------------------------------------
Built in song playback -----------------------------------------------------------------------
Playback speed -------------------------------------------------------------------------------
Drum sensitivity adjustment ----------------------------------------------------------------
Reverb/eq optimization -----------------------------------------------------------------------
Percussion recording --------------------------------------------------------------------------
Reset factory settings -------------------------------------------------------------------------
APPENDIX ---------------------------------------------------------------------------------
Drum timbre -----------------------------------------------------------------------------------
Preset drum kit --------------------------------------------------------------------------------
Demo song -------------------------------------------------------------------------------------
PRODUCT MAINTENANCE- ------------------------------------------------------
SAFETY PRECAUTIONS -----------------------------------------------------------
WARRANTY CARD -----------------------------------------------------------------
1
2
3
3
4
4
4
4
5
5
5
6
6
7
8
8
8
9
9
9
9
9
9
9
10
10
10
11
11
12
12
13
13
13
13
13
14
14
14
14
15
16
19

01
Check the attached items
Module Module bracket Hi-hat Crash*2
Tom
(3pcs)
Snare Cymbal arm
（3pcs）
Stick hammerSignal Connection
cable
Drum stick Power adapter Drum key
Screwdriver
● After opening the package, please check whether it contains all the items immediately. If
there are any missing, please contact us.
Ride
Fastening screw
2 2 6
3
Drum arm Drum Stool
Audio Cable
Headphone
Kick pedal
Front bracket KickConnecting
bracket
Rear support
● Please follow the instructions and read the "safety precautions" in the instruction manual carefully
before using.
● This product must be installed by an adult, please do not install by the minor independently,
don't let the minor install it independently.
REMARK！
INSTALLATION GUIDE

INSTALLATION GUIDE
4
05
Install the module bracket
● please insert it in place during installation.
02
Install the kick drum
● when installing, please tighten the screws and be careful to pinch your fingers.
Use a screwdriver to lock the
kit drum, fastener, and
support with small screws as
shown in the figure. Then
insert 2 springs into 2
anti-slip screws respectively
and lock them into the
bottom of the support piece
until they stand against the
ground.
Align the mainframe module
bracket with the mainframe module
track and insert it. After inserting it
to the bottom, you will hear the
snap pieces pop up.
Insert the hammer rod into the
round hole as shown in the figure,
rotate the wool hammer to align it
with the drum surface,
and then tighten it with
the drum key.
03
Install the
hammer bar
● the pole should be inserted in lace
and the screws should be tightened
to avoid loosening.
04
Fix the kick drum and kick
drum pedal
● the bottom drum and the step hammer should be fixed
and tightened to avoid falling off.
Insert the protruding edge
of the low drum into the
hammer fixing clip as
shown in the figure, and
tighten the screws.
Insert the fixed iron bar into the hole
as shown in the figure.

A B
E
07
B
D
5
G
DC
F
Installation sequence: first install the drum plate, and then install the stand
ASSEMBLY DRAWING
06
Pipe fitting
The pipe fittings are located in a separate small package in the packing box.
Drum pan intubation
Install the drumson the middle horizontal pipe.
H I
X2

INSTALLATION GUIDE
09
08
Install the support arm
● The support arm must to be inserted in place, and the plastic head screw should be
tightened to avoid falling.
6
During installation, tighten the screws and be careful to pinch your fingers.
Mounting Stand
Assemble the stand in the specified direction
A
G
C
E
B
H
I I
F
D
1.2 m
For safety reasons, the expansion width of the support should be less than 1.2 meters.

INSTALLATION GUIDE
Withdraw the nuts and circle cushions of arm the three cymbals' support arm, put the three
cymbals into the corresponding support arm, and screw on the nuts. Put 3 drums and 1
drum into the corresponding support rod respectively, and tighten the screws.
Note: the functions of each cymbal, drum and snare are different, so it is necessary to refer
to the accessory identification for correct installation!
10
Install striking parts and sound module
● Tighten the screws after the drum is inserted to avoid loosening.
● Don't screw the cymbale tightly, leave some space for them to shake up and down.
7

8
HI-HAT STAND
1
2
4
8
9
11
13
15
3
4
5
6
7
10
12
14
Small felt
Clutch nut
1Hi-hat parts introduction
Hi-hat arm
1
Wing screw
2
Clutch bolt
3
Lock nut
4
Large felt
5
Hi-Hat
6
Small felt
7
Clutch nut
8
Hi-hat controller
9
Cymbal support base felt
10
Cymbal support base
11
Locating clip
12
13
Regulating screw
14
Pedal
15
U-shaped support arm
Cymbal support base
When installing the bottom step, the step clutch assembly should be removed and
the step controller should be placed on the felt ring of the step support base.
Locating clip
Once the height of the bottom cymbal is determined, the positioning
clip can be used to mark the setting position for future installation and
setting, and prevent unexpected changes during music performance.
Tighten the locating clip in place with the drum key.
2Detailed introduction of important parts
Pedal clutch
When installing the top step, loosen the wing screw and remove the
entire step clutch assembly from the step lever. then remove the
clutch nut and place the cymbal between the two clutch felt.
After installation, tighten the clutch nut onto the clutch assembly to fix
the cymbal. (Note: the bottom of the clutch nut and the bottom of the
clutch bolt are on the same horizontal plane, and cannot exceed the
clutch bolt, as shown in the figure below) Place the entire assembly
on the step lever, and tighten the wing screw to fix the required top
scale position.

9
MANU
MP3
SONG
3
21 5
4
6
ILLUSTRATION OF MODULE SOCKET
1Power cord connection
Connecting headphones allows you to monitor changes in detail while playing, and does
not disturb others when playing without a speaker connected. (Figure 4)
4Headphone port
Audio output port can be connected to external active speakers (need special drum
speakers), and large audio equipment. (Figure 5)
5
This port allows you to add a cymbal for easy expansion. (Figure 6)
6Increase cymbal port
The audio input port allows you to connect an external audio source to the drum host
box for playback (e.g. MP3. linear audio signal input for cell phones, etc.). (Figure 3)
3Audio input port
2USB MIDI port
1. Access thepower cord as shown in thediagram, plug one end into thepower port of the
sound module. Plug the other end into a 100-240V household power outlet (Figure 1)
2. When the product is not used for a long time, please unplug thepower cord and store
it properly.
Using the MIDI USB interface of the electronic drum can be connected to music devices
with MIDI for interaction.
1. Learn or operate functions such as playing, composing, and storing through software
pre-installed on your computer or tablet. (Figure 2)
2. When connected to a computer or tablet, theaudio output onthedevice needs to be
connected to theaudio input port of thedrum host box in order to synchronize the
sound effects on thedevice. (Figure 5)
Translated with www.DeepL.com/Translator (free version)
Audio output port
In front of the module

10
OPERATION GUIDE
Use the "volume" wheel to adjust the total volume. Please adjust the volume to a
satisfactory position. (Figure 2)
2Master volume
1Power on
1. Press the "power" switch to enter the playing state. (Figure 1)
2. Please turn off the power when not in use for a while.
●This product processor chip is complex, similar to the computer system, sometimes there
is no response, please turn off the power switch and then turn it on to normal work.
Recording system
DOWN UP
VOLUME
REC R.PLAY
MENU
SAVE.
RESET
TONEPLAY
POWER
Metronome and music
Electronic drum
control box
CRASH2
DC9V AUDIO INAUDIO OUTUSB
METRO SONG
1
2
4 4
5
3
6

11
OPERATION GUIDE
This product has double trigger induction, which makes the striking sound effect closer to the original sound drum effect.
1. "snaredrum" can strike the drum surface and edge.
2. "crash cymbals" and "ride cymbals" can knock the cymbal surface and cymbal edge, and hold the
cymbal edge with your fingers to make sound.
3. Different combinations of "cymbal stepping cymbal piece" and "cymbal stepping pedal" will change the tone
of cymbal stepping.
● open cymbal timbre "openhat": single tap the cymbal surface.
● closed cymbal tone "closehat": step on the cymbal pedal and keep it closed, while knocking on the cymbal
surface.
● step on the cymbal tone "peak": step on the cymbal pedal without knocking on the cymbal surface.
4Drum Percussion
surface
edge
surface
edge
1. Press the "voice" button, the display will display (voice), and enter the drum kit adjustment mode. (Figure 3)
2. Use the "v" key to select the following options as adjustments. (Figure 4)
The display shows:
● (kit num 001-030): drum kit selection, a total of 30 preset drum kits.
● (kit vol 000-127): drum kit volume, 128 levels in total, adjustable.
● (kick 001-030): the timbre of the kick drum is selected, and a total of 30 timbres are adjustable.
● (snare 001-030): the timbre of the snare drum is selected, and a total of 30 timbres are adjustable.
● (snare rim 001-030): the timbre of the snare drum is selected, and a total of 30 timbres are adjustable.
● (tom1 001-030): drum 1 timbre selection, a total of 30 timbres can be adjusted.
● (tom2 001-030): drum 2 timbre selection, a total of 30 timbres can be adjusted.
● (tom3 001-030): drum 3 timbre selection, a total of 30 timbres can be adjusted
● (crash 001-030): selection of crash cymbal timbre, a total of 30 timbres can be adjusted.
● (crash rim 001-030): select the tone of the crash cymbal while hitting, and a total of 30 tones can be adjusted.
● (crash2 001-030): boom 2 timbre selection, a total of 30 timbres can be adjusted.
● rim 2-030, and 30 tones can be adjusted.
● (ride 001-030): select the timbre of the ride cymbal, with 30 timbres in total, which can be adjusted.
● (ride rim 001-030): select the timbre of the ride cymbal and a total of 30 timbres can be adjusted.
● (open at 001-030): open cymbal timbre selection, a total of 30 timbres can be adjusted.
● (close hat 001-030): closed cymbal timbre selection, a total of 30 timbres can be adjusted
● (pedal 001-030): select the tone of the cymbal and a total of 30 tones can be adjusted.
3. Turn the "quick selection wheel" to adjust the parameters of the above options. (Figure 5)
4. Short press the "save and reset" button to save the adjusted drum set, so that it can be called later(Figure 6).
5. Press and hold the "voice" button for more than 3 seconds to call the previously customized adjusted and
saved drum kit. (Figure 3)
3Drum kit timbre selection
stop the sound wave
by grabbing the cymbal

12
Recording system
DOWN UP
VOLUME
REC R.PLAY
MENU
SAVE.
RESET
TONEPLAY
POWER
Metronome and music
Electronic drum
control box
CRASH2
DC9V AUDIO INAUDIO OUTUSB
METRO SONG
4 4
5
6
11 12
810
9
7
1. Press the "metronome" button, the display will display (Metro), and enter the metro-
nome mode. (Figure 7)
2. Use the "v" key to select the following options as adjustments. (Figure 4)
THE DISPLAY SHOWS:
● (time 002-016): metronome speed, 4 levels in total, standard speed adjustable.
● (beat 001-009): there are 9 types of metronome, which can be adjusted.
● (metro vol 000-127): metronome volume, 128 levels in total, adjustable.
3. Turn the "quick selection wheel" to adjust the parameters of the above options. (Figure 5)
4. Press the "play" button to start playing the metronome, and press it again to stop. (Figure 8)
5Metronome
1.Press the "demonstration song" button, and the display screen will display (song), and enter
the demonstration song mode. (Figure 9)
2. Use the "v" key to select the following options as adjustments. (Figure 4)
THE DISPLAY SHOWS:
● (num 001-030): selection of 30 built-in demonstration songs.
● (gm vol 000-127): chord accompaniment volume, 128 levels in total, adjustable.
● (drm vol 000-127): drum group volume, 128 levels in total, adjustable.
3. Turn the "quick selection wheel" to adjust the parameters of the above options. (Figure 5)
4. Press the "play" button to start playing the demonstration song, and press it again to
stop.(Figure 8)
6Built in song playback
OPERATION GUIDE

13
Press and hold the "save. Reset" button for more than 3 seconds to reset all parameters and
restore factory settings. (Figure 6)
11 Reset factory settings
1. Press the "menu" button repeatedly until the display shows (utility), and enter the sub option
reverberation / equalization optimization mode. (Figure 10)
2. Use the "∨" key to select the following options as adjustment. (Figure 4)
THE DISPLAY SHOWS:
● (revtype 000-005): reverberation category, 6 kinds in total, adjustable.
● (revlevel 000-127): reverberation intensity level, 128 levels in total, adjustable. When the value
is "000", reverberation is turned off.
● (eq_h 000-127): high frequency equalization, 128 levels in total, adjustable.
Adjustable low frequency equalization (eu-000, l): 128 ●#.
3. Turn the "quick selection wheel" to adjust the parameters of the above options. (Figure 5)
4. Short press the "save. Reset" button to save the adjusted parameters for future use. (Figure 6)
9Reverberation / equalization optimization
1. Press the "recording" button to enter the percussion recording mode, and tap the drum to
start recording. Press again to stop recording. (Figure 11)
2. Press the "playback" button to play the percussion song just recorded. Press again to stop
playback. (Figure 12)
10 Percussion recording
In the demonstration song or metronome playing mode, adjusting the speed can control the speed
of demonstration song and metronome playing.
1. Press the "menu" button repeatedly until the display shows (tempo), and enter the sub option p
layback speed mode. (Figure 10)
THE DISPLAY SHOWS:
● (speed 030-250): playback speed selection, 221 levels in total, speed adjustable.
2. Turn the "quick selection wheel" to adjust the parameters of the above options. (Figure 5)
7Playback speed
1. Press the "menu" button repeatedly until the display shows (sensitivity), enter the sub option, and
enter the sub option percussion instrument component sensitivity adjustment mode. (Figure 10)
2. Tap the drum disc you want to adjust with a drum stick.
3. Use the "∨" key to select the following options as adjustment. (Figure 4)
THE DISPLAY SHOWS:
● (padsen 001-006): surface impact sensitivity, 6 levels in total, adjustable.
● (rimsen 001-006): side strike sensitivity, 6 levels in total, adjustable.
● (threhold 001-032): trigger threshold, 32 levels in total, adjustable.
● (xtalk 001-032): crosstalk threshold, 32 levels in total, adjustable.
● (retiger 001-032): repeated triggering, 32 levels in total, adjustable.
● (velocity 001-003): force curve, 3 levels in total, adjustable.
● (volume 000-127): drum volume, 128 levels in total, adjustable.
4. Turn the "quick selection wheel" to adjust the parameters of the above options. (Figure 5)
5. Short press the "save. Reset" button to save the adjusted parameters for future use. (Figure 6)
8Drum sensitivity adjustment
OPERATION GUIDE

14
KICK
01 Acoustic Kick
02 Military Kick
03 Original Kick
04 Funk Kick
05 Standard Kick
06 Dance Kick
07 Rock Kick
08 Jazz Kick
09 808 Kick
10 Songo Kick
11 909 Kick
12 Fairfax Kick
13 Dancehall Kick 3
14 70`s Kick
15 Clean Kick
SNARE
01 Acoustic Snare
02 Military Snare
03 Original Snare
04 Funk Snare
05 Standard Snare
06 Dance Snare
07 Rock Snare
08 Jazz Snare
09 808 Snare
10 Songo Snare
11 909 Snare
12 Fairfax Snare
13 Dancehall Snare
14 70`s Snare
15 Clean Snare
SNARE RIM
01 Acoustic Snare Rim
02 Military Snare Rim
03 Original Snare Rim
04 Funk Snare Rim
05 Standard Snare Rim
06 Dance Snare Rim
07 Rock Snare Rim
08 Jazz Snare
09 808 Snare Rim
10 Songo Snare Rim
11 909 Snare Rim
12 Fairfax Snare Rim
13 Dancehall Snare Rim
14 70`s Snare Rim
15 Clean Snare Rim
TOM 1
01 Acoustic Tom1
02 Military Tom1
03 Original Tom1
04 Funk Tom1
05 Standard Tom1
06 Dance Tom1
07 Rock Tom1
08 Jazz Tom1
09 808 Tom1
10 Songo Tom1
11 909 Tom1
12 Fairfax Tom1
13 Dancehall Tom1
14 70`s Tom1
15 Clean Tom1
TOM 2
01 Acoustic Tom2
02 Military Tom2
03 Original Tom2
04 Funk Tom2
05 Standard Tom2
06 Dance Tom2
07 Rock Tom2
08 Jazz Tom2
09 808 Tom2
10 Songo Tom2
11 909 Tom2
12 Fairfax Tom2
13 Dancehall Tom2
14 70`s Tom2
15 Clean Tom2
TOM 3
01 Acoustic Tom3
02 Military Tom3
03 Original Tom3
04 Funk Tom3
05 Standard Tom3
06 Dance Tom3
07 Rock Tom3
08 Jazz Tom3
09 808 Tom3
10 Songo Tom3
11 909 Tom3
12 Fairfax Tom3
13 Dancehall Tom3
14 70`s Tom3
15 Clean Tom3
CRASH 1
01 Acoustic Crash1
02 Military Crash1
03 Original Crash1
04 Standard Crash1
05 Funk Crash1
06 Dance Crash1
07 Rock Crash1
08 Jazz Crash1
09 808 Crash1
10 Songo Crash1
11 909 Crash1
12 Fairfax Crash1
13 Dancehall Crash1
14 70`s Crash1
15 Clean Crash1
CRASH 1 RIM
01 Acoustic Crash1 Rim
02 Military Crash1 Rim
03 Original Crash1 Rim
04 Standard Crash1 Rim
05 Funk Crash1 Rim
06 Dance Crash1 Rim
07 Rock Crash1 Rim
08 Jazz Crash1 Rim
09 808 Crash1 Rim
10 Songo Crash1 Rim
11 909 Crash1 Rim
12 Fairfax Crash1 Rim
13 Dancehall Crash1 Rim
14 70`s Crash1 Rim
15 Clean Crash1 Rim
CRASH 2
01 Acoustic Crash2
02 Military Crash2
03 Original Crash2
04 Standard Crash2
05 Funk Crash2
06 Dance Crash2
07 Rock Crash2
08 Jazz Crash2
09 808 Crash2
10 Songo Crash2
11 909 Crash2
12 Fairfax Crash2
13 Dancehall Crash2
14 70`s Crash2
15 Clean Crash2
CRASH 2 RIM
01 Acoustic Crash2Rim
02 Military Crash2 Rim
03 Original Crash2 Rim
04 Standard Crash2 Rim
05 Funk Crash2 Rim
06 Dance Crash2 Rim
07 Rock Crash2 Rim
08 Jazz Crash2 Rim
09 808 Crash2 Rim
10 Songo Crash2 Rim
11 909 Crash2 Rim
12 Fairfax Crash2 Rim
13 Dancehall Crash2 Rim
14 70`s Crash2 Rim
15 Clean Crash2 Rim
RIDE
01 Acoustic Ride
02 Military Ride
03 Original Ride
04 Standard Ride
05 Funk Ride
06 Dance Ride
07 Rock Ride
08 Jazz Ride
09 808 Ride
10 Songo Ride
11 909 Ride
12 Fairfax Ride
13 Dancehall Ride
14 70`s Ride
15 Clean Ride
RIDE RIM
01 Acoustic Ride Rim
02 Military Ride Rim
03 Original Ride Rim
04 Standard Ride Rim
05 Funk Ride Rim
06 Dance Ride Rim
07 Rock Ride Rim
08 Jazz Ride Rim
09 808 Ride Rim
10 Songo Ride Rim
11 909 Ride Rim
12 Fairfax Ride Rim
13 Dancehall Rim
14 70`s Ride Rim
15 Clean Ride Rim
HI-HAT OPEN
01 Acoustic Hi-hat Open
02 Military Hi-hat Open
03 Original Hi-hat Open
04 Standard Hi-hat Open
05 Funk Hi-hat Open
06 Dance Hi-hat Open
07 Rock Hi-hat Open
08 Jazz Hi-hat Open
09 808 Hi-hat Open
10 Songo Hi-hat Open
11 909 Hi-hat Open
12 Fairfax Hi-hat Open
13 Dancehall Hi-hat Open
14 70`s Hi-hat Open
15 Clean Hi-hat Open
HI-HAT CLOSE
01 Acoustic Hi-hat Close
02 Military Hi-hat Close
03 Original Hi-hat Close
04 Standard Hi-hat Close
05 Funk Hi-hat Close
06 Dance Hi-hat Close
07 Rock Hi-hat Close
08 Jazz Hi-hat Close
09 808 Hi-hat Close
10 Songo Hi-hat Close
11 909 Hi-hat Close
12 Fairfax Hi-hat Close
13 Dancehall Hi-hat Close
14 70`s Hi-hat Close
15 Clean Hi-hat Close
HI-HAT PEDAL
01 Acoustic Hi-hat Pedal
02 Military Hi-hat Pedal
03 Original Hi-hat Pedal
04 Standard Hi-hat Pedal
05 Funk Hi-hat Pedal
06 Dance Hi-hat Pedal
07 Rock Hi-hat Pedal
08 Jazz Hi-hat Pedal
09 808 Hi-hat Pedal
10 Songo Hi-hat Pedal
11 909 Hi-hat Pedal
12 Fairfax Hi-hat Pedal
13 Dancehall Hi-hat Pedal
14 70`s Hi-hat Pedal
15 Clean Hi-hat Pedal
Drum timbre
1 Acoustic
2 Military
3 Original
4 Funk
5 Standard
6 Dance
7 Rock
8 Jazz
9 808
1 Drum & Bass
2 Blues
3 Jazz1
4 Rock1
5 Electrophonic & Funk
6 Country1
7 R & B
8 Pop1
9 Pop2
10 Pop3
11 March
12 Pop Bossa
13 Fusion
14 Dance
15 Jazz Swing
16 Pop Rock
17 Country Blues
18 Pop4
19 Scotland
20 Latin Jazz
21 Swing1
22 Swing2
23 Country2
24 Modern Pop
25 Electrophonic
26 Swing3
27 Jazz2
28 Country3
29 Rock2
30 Pop5
10 Songo
11 909
12 Fairfax
13 Dancehall
14 70`s
15 Clean
16 Kit Num
Preset drum kit
Demonstration song
User defined drum kit
APPENDIX

15
Do not over expose the product to direct sunlight, or place it near air conditioning or extremely
hot place.
1
AVOID HEATING, DAMPNESS OR DIRECT SUNLIGHT
This product may cause video or audio interference to the reception of TV and radio. If this
happens, the product should be removed from the TV or radio.
2
DO NOT USE NEAR THE TV OR RADIO
Clean the product with a soft cloth wetted with weak water solution and neutral detergent.
Soak the cloth in a solution and wring it dry until it approaches drying.
3NO DILUENTS OR SIMILAR CHEMICALS SHOULD BE USED FOR CLEANING
When moving, the product should be handled carefully and lightly. Violent vibration and collision
are strictly prohibited in order to avoid damage to the shell or internal electronic components.
4
DO NOT SHAKE, AVOID COLLISION
Careful maintenance and protection of this product plays an important role in prolonging the
service life of the product and reducing the failure.
PRODUCT MAINTENANCE

16
USB
PHONE
AUDIO IN
AUDIO OUT
DC9V
SAFETY PRECAUTIONS
SIGN
POWER SUPPLY
To ensure that you use this product safely and correctly, to prevent harm to users and others and
financial damage, this manual and products are marked with a series of safety signs. The various
signs and their meanings are as follows:
This product can be powered by standard indoor wall sockets. Please only use the power cord
specified in this product. When not in use, please turn off the power supply. When not in use for a
long time, pull out the power cord and keep it properly.
WARNING
This sign indicates that there is a potential risk of death or serious injury if this mark is ignored and
the product is mishandled.
BE CAREFUL
This sign indicates that there is a potential danger of injury to personnel or other financial damage
if this sign is ignored and the product is operated incorrectly.
EXAMPLE OF LOGO
This triangle sign (△) indicates what users should pay attention to.
(The left example is careful shocks)
A circular sign ( ) with an oblique line indicates prohibitions. The icons in or beside the
logo indicate the contents specifically prohibited. (The example on the left is no
disassembly)
The round black bottom sign ( ) indicates what must be observed. The diagrams in this
sign indicate the contents of the specific matters that must be observed.
(The example on the left is that the power plug must be pulled out of the socket)

17
SAFETY PRECAUTIONS
BE CAREFUL
The improper use of power cord may cause
fire and electric shock. The following
precautions must be observed:
● Never put the power cord near the oven
or other heat source.
● Do not pull the cable when pulling out of
the power socket. The main body of the
plug must be grasped.
● The power cord plug must be inserted in
the socket to the end.
● Make sure the power supply is off before
connecting or disconnecting it.
● When thunderstorms occur or before
traveling or other long-term departure,
disconnect the power cord from the wall
outlet.
● At least once a year, remove the power
cord from the wall outlet and clean the
dust accumulated around the plug.
Do not burn this product
Do not put this product in the fire,
otherwise it will lead to product
combustion and explosion of internal
electronic components, which will cause
fire and personnel injury.
Water and foreign bodies
Water, other liquids and (metal sheets, etc.)
entering this product are in danger of
causing fire and electric shock. In case of
the above situation, the following
operations shall be performed immediately:
1. Turn off the power supply.
2. If you are using a power cord for power
supply, unplug it from the wall outlet.
3. Contact your distributor.
Disassembly and transformation
Do not disassemble or transform the
product in any way, otherwise there is a
risk of electric shock, scald or other
personal injury. All internal inspection,
adjustment and maintenance operations
should be entrusted to your distributor.
WARNING
Smoke, odor, overheating
When the product smokes, smells or
overheats, there is a danger of fire and
electric shock when it is used continually.
In case of the above situation, the following
operations should be performed immediately:
1. Turn off the power supply.
2. Pull the plug out of the power outlet.
3. Contact your dealer.
Power cord
1. The improper use of power cord may
cause fire and electric shock. The following
precautions must be observed:
● The special power cord designated for
this product must be used.
● The AC power supply with output
voltage within the rated voltage range
for household use must be used.
● Do not overload power sockets and
extension lines.
2. The improper treatment of power line
will lead to its damage or breakage,
which will cause fire and electric shock
hazards. The following precautions must
be observed:
● Do not place or heat heavy objects on
power lines.
● Do not attempt to alter or bend the
power cord too much.
● Do not twist or pull the power cord.
● If the power cord or plug is damaged,
please replace the same type of power
cord.
3. Do not touch the power cord and plug
with wet hands, otherwise there is a
danger of electric shock.
4. Please use the power cord where the
water will not splash. Water is in danger
of causing fire and electric shock.
5. Never place vases or any other container
containing water on this product. Water
is dangerous of causing fire and electric
shock.
6. Do not allow minors to unplug and touch
power lines or connection boards. Minors
have no common sense of electricity
safety, which may cause electric shock.

18
SAFETY PRECAUTIONS
Location selection
It should be avoided to place the product
in the following places, otherwise there is
a risk of fire and electric shock.
● High temperature or dusty places.
● Kitchen or other places with lampblack.
● Where the product is exposed to direct
sunlight, or any other place where the
product will produce high temperature.
Volume
Don't play music long and loud. Pay special
attention when using headphones.
Excessive volume can damage your hearing.
Heavy
Do not place heavy objects on this product.
Otherwise, the top of the product will be
overweight, causing the product to
overturn or drop objects on it, which will
lead to the risk of injury.
Correct assembly of scaffolds
The incorrect assembly of the bracket may
overturn, causing the product to fall off
and posing a risk of injury to personnel.
Therefore, it must be assembled according
to the instructions in the attached
installation guide to ensure that the
product is properly mounted on its
bracket.
Falling or colliding
If the product falls or is damaged by strong
impact, it will be in danger of causing fire
and electric shock. In case of the above
situation, the following operations shall be
performed immediately:
1. Turn off the power supply.
2. If you are using a power cord for power
supply, you need to unplug it from the
wall outlet.
3. Contact your distributor.
Plastic bag
Do not let anyone put plastic bags for this
product on his head or in his mouth.
Otherwise, there is a risk of asphyxia.
Families with young children should pay
special attention to it.
Keep a distance from the product
and the bracket
Climbing the bracket is dangerous of
overturning or damage. Families with
young children should pay special
attention to it.
Put
Avoid placing the product on an uneven
surface or any other unstable place.
Otherwise, it will cause the product to fall
down, which will lead to the risk of injury.
Product Mobility
Before moving this product, you must
unplug the power cord plug from the wall
outlet and pull out all other cables and
connecting wires. Otherwise, it will lead to
damage of power or connection wires,
resulting in fire and electric shock.
clean
Before cleaning this product, you must
unplug the power cord plug from the wall
outlet, otherwise there is a risk of fire and
electric shock.
Jack
The socket of this product can only be
connected to the designated equipment
and devices. Connecting non-designated
equipment or devices is dangerous of
causing fire and electric shock.

WARRANTY
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal
injury, property damage, or loss, whether direct, indirect, or incidental,
resulting from the incorrect attachment, improper use, inadequate mainte-
nance, or neglect of this product.
WARNING
To connect directly with our Support team,
[email protected]
All items can be returned for any reason within 60 days of the receipt and will receive a full
refund as long as the item is returned in its original product packaging and all accessories
from its original shipment are included. All returned items will receive a full refund back to
the original payment method. All returned items will not be charged a re-stocking fee.
Pictures may be required for some returns to ensure an item is not damaged prior to its
return. Items returned are not considered undamaged until they are received by Fesley and
verified as such. All damages to items are the customer’s responsibility until the item has
been received by and acknowledged by Fesley as undamaged.
19
