FETTO Deluxe User manual
External controls:
FETTO Deluxe
Owner’s Manual
Core:
Aects the character,
the feel, the core.
Start at 12 o’clock and
experiment.
The function of the Core
control equates to the
dierence in feel between
low and high wattage amps,
where the low wattage amp
(minimum) distorts more
quickly and the high wattage
amp (maximum) has more
headroom.
Tone/Treble:
Passive tone control. Start around
11 o’ clock. Counter clockwise
gives a treble cut.
Lowdrive:
Bass/overdrive character. Start
at 12 o’ clock and experiment.
The Lowdrive knob controls the
“oomph”of the pedal, similar to the
dierence between a 1x12 cabinet
(minimum) and a 4x12 cabinet
(maximum).
IN:
Connect your guitar or bass
guitar here.
OUT:
Connect your
amplier here.
Mid:
Toggle switch which gives more
or less mid. Try both positions
to nd out what’s best suited for
your equipment.
Drive:
Drive/distortion control.
Start at 10-12 o’clock.
Clockwise gives more.
Volume:
Output level. Start at
10-12 o’ clock.
GIMME:
ON/OFF push switch*. True
mechanical (not electronic)
bypass. ON is indicated by a
magical, blue LED.
1:2
MORE:
A boost/solo push switch* which gives
MORE of FETTO Deluxe. ON is indicated by
a sunny, yellow, LED. The amount of Drive/
Volume for this switch is adjustable inside
the box (explained on next page).
NB: MORE can only be activated when the pedal is ON
(blue LED on). It’s not a separate eect.
Himmelstrutz Elektro Art, Sweden. www.himmelstrutz.com
Doc: 6403002_om_001- (#001–)
Congratulations on your purchase of FETTO Deluxe, the distortion pedal which works well with both guitars
and bass guitars. With FETTO Deluxe you will get musical, shimmering harmonics regardless of volume with a
minimal coloration of your guitar and amplier.
It’s highly recommended to read this manual to get the best use and joy of FETTO Deluxe.
* The push switches in FETTO Deluxe is
not as stias the ones you’re probably
used to. So now you can play barefoot
without hurting yourself.
9V DC
External DC adapter.
Standard 2,1 mm barrel
jack, 9 volt regulated DC
with center-pin negative.
(BOSS standard). NEVER
power FETTO Deluxe with
more than 9 V DC!
The Himmelstrutz pedals are
designed to be used with straight
power cable plugs. Right angle plugs
may not make a secure connection
and are not recommended.
FETTO Deluxe tips & tricks:
It could take some time to get a grip about all possibilities in this pedal. We encourage you to try several dierent
combinations of outboard control setting as each will impart its own unique character on your tone. Also try to
adjust the volume control of your instrument and you will see how exible, responsive and ‘real’FETTO Deluxe is.
Our wish is that you’ll like what you hear.
Every pedal is tested and adjusted carefully by feel, ears and some technical knowledge. Because of this,the default
trimmer values (above) may vary between dierent copies of FETTO Deluxe.
More information is available at www.himmelstrutz.com.
Even though the power consumption is low (3-4 mA) the battery needs to be replaced when the LED’s gets weak or
if the tone changes or get quiet (even when the LED is ON). To change the battery, unscrew the four screws on the
bottom plate, bring out the old 9 volt battery (6LR61) and replace it with a new. Then attach the bottom plate with
the four screws. Never use FETTO Deluxe without the bottom plate!
If you play loud, always use ear protection. It’s easy to forget, but in the long run not a good idea!
Unplug the input cord when not using the pedal—if powered by a battery—to save the battery (and environment).
Don’t forget to have fun, why not with ear protection and a glass of milk.
Good luck!
Joakim Hedeby, Himmelstrutz Elektro Art, Sweden 2007
Warranty:
This pedal carries a 1 year warranty to the original owner. The warranty covers repairs due to manufacturer errors only. It does NOT
cover any damage from user/owner mishandling, shipping or abuse in any form. Errors caused by violence, wrong power supply,
internal adjustments, user modications, broken trimmers etc. voids the warranty.
Owner is to contact Himmelstrutz Elektro Art directly for all repairs. Any work done by anyone other than Himmelstrutz Elektro Art
voids the warranty. If you need to get in contact with Himmelstrutz Elektro Art send an e-mail to [email protected].
All shipping costs are the responsibility of the owner, and are to be paid in advance of any work performed on our products.
Disclaimer:
The owner assumes all responsibility for injury, and/or damages relating to the operation of this device (blown speakers, hearing-
impair etc). Always think and be careful AND ALWAYS REMEMBER: It’s easy to hurt your ears on high volumes, so be careful!
2:2
Internal controls:
If you for some reason need to change the character of FETTO Deluxe, four trimmers are available inside the box.
A lot of time has been spent to optimize the default settings so don’t change anything if you don’t have to. If you
have to trim anyway, use a small (1,7-2,0 mm) screwdriver and BE CAREFUL. No force is needed and all trimmers
run smoothly if properly done. Warning: Errors caused by internal adjustments voids the warranty!
DRIVE (MORE):
Trim clockwise to get
more DRIVE for the MORE
footswitch. Counter clockwise
gives less.
(Default 35%, tiny DRIVE
increase)
VOLUME (MORE):
Trim clockwise to get more
VOLUME for the MORE
footswitch. Counter clockwise
gives less.
(Default 50-75%, medium
VOLUME increase)
GAIN (GLOBAL):
Trim clockwise to get more
total (global) drive. Counter
clockwise gives less.
(Default 50%, perfect GAIN)
Counter clockwise will cut treble
frequencies.
(Default 100%, minimum CUT)
NB: The pedal can loose its focus, get
muddy if TREBLE CUT is adjusted. So
make sure your idea is brilliant before
you even think about adjusting this one.
Internal controls (box opened)
TREBLE CUT (GLOBAL):
t
t
t
t
