Fiber Options S703V User manual

Instruction Manual
. . . light years ahead™
S703V & S7703V
TWO-CHANNEL
VIDEO MULTIPLEXERS

S703V & S7703V Instruction Manual
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used properly in strict accordance
with the instructions contained herein, may cause interference to
radio communication. It has been tested and found to comply with
the limits for Class A computing devices in accordance with the spec-
ifications found in Subpart J of Part 15 of FCC rules, which are
designed to provide reasonable protection against such interference
when the equipment is operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause
interference, in which case the user will be required to take whatev-
er means may be necessary to correct the interference at his own
expense.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This apparatus does not exceed the Class A limits for radio noise
emission set out in the Radio Interference Regulation of Industry of
Canada.
Cet appareil numérique de la Classe A respecte toutes les exigences
du Règlement sur le matériel brouilleur du Canada.
Federal Communications Commission
and Industry Canada Radio Frequency
Interference Statements
FCC PART 15
COMPLIANT

Fiber Options i
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.1 INSTALLATION CONSIDERATIONS. . . . . . . . . . . . .1
1.2 STANDALONE MODULES . . . . . . . . . . . . . . . . . . . .1
1.3 RACK CARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.3.1 515R1 AND 517R1 CARD CAGES . . . . . . . . . . .1
1.3.2 501R ENCLOSURES . . . . . . . . . . . . . . . . . . . . .1
2 SIGNAL CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . .2
3 OPTICAL CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . .2
4 ELECTRICAL CONNECTIONS . . . . . . . . . . . . . . . . . . . .2
4.1 RACKMOUNT CARDS . . . . . . . . . . . . . . . . . . . . . . .2
4.2 STANDALONE MODULES . . . . . . . . . . . . . . . . . . . .2
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . .2
6 CONTACTING FIBER OPTIONS . . . . . . . . . . . . . . . . . .2
7 SHIPPING AND PACKING . . . . . . . . . . . . . . . . . . . . . . .2
8 RETURNS TO FIBER OPTIONS . . . . . . . . . . . . . . . . . .2
Contents
Figures & Tables
FIGURE 1: STANDALONE TRANSMITTER . . . . . . . . . . . .ii
FIGURE 2: 501R ENCLOSURE . . . . . . . . . . . . . . . . . . . .ii
FIGURE 3: SYSTEM DIAGRAM . . . . . . . . . . . . . . . . . . . .1
FIGURE 4: S703V RACK CARD . . . . . . . . . . . . . . . . . . . .3
FIGURE 5: RACK CARD FRONT BEZELS . . . . . . . . . . . .3
FIGURE 6: RACK CARD CONNECTIONS . . . . . . . . . . . . .3
TABLE 1: POWER CONNECTION
STANDALONE MODULE . . . . . . . . . . . . . . . . . . . .ii
TABLE 2: POWER CONNECTION
502R ENCLOSURE . . . . . . . . . . . . . . . . . . . . . . . .ii
TABLE 3: TRANSMITTER LED DIAGNOSTIC . . . . . . . . . .
INDICATORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
TABLE 4: RECEIVER LED DIAGNOSTIC . . . . . . . . . . . . .
INDICATORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

CONNECTIONS, DIAGNOSTIC INDICATORS - STANDALONE MODELS
S703V & S7703V Instruction Manual
ii
TABLE 2: POWER CONNECTION
501R ENCLOSURE
TABLE 1: POWER CONNECTION
STANDALONE TRANSMITTER
FIGURE 1: STANDALONE TRANSMITTER
FIGURE 2: 501R ENCLOSURE
PIN CONNECTION
112 – 16 VAC
+12 – 16 VDC
2DC Ground
312 – 16 VAC
PIN CONNECTION
3 +13.5 – 16 VDC
2 ALARM / +5 VDC
1 Ground

Fiber Options 1
GENERAL
This manual is a guide to the installation and operation of the
S703V and S7703V series fiber optic two-channel video multi-
plexer systems. Please read the entire manual before installing
the equipment.
These two-channel video multiplexers offer simultaneous trans-
mission of two full-frame video signals (color or monochrome).
The S703V units use multimode fiber while the S7703V units
operate over single-mode fiber.
Note: The series numbers S703VT and S703VR will be used to
describe all models of transmitters and receivers unless noted
otherwise.
A complete system consists of a transmitter, S703VT, and a
receiver, S703VR. Units are designed for standalone operation
or for installation in Fiber Options’ 515R1 or 517R1 Card
Cages or 501R miniature enclosures. The S703VT transmitter
has two video inputs and one fiber output. The S703VR receiv-
er unit has one fiber input and two video outputs.
Unpacking the Unit
In the event that anything is missing from the following list, con-
tact your authorized Fiber Options dealer or representative.
S703VT Transmitter or S703VR Receiver
(S7703VT or S7703VR)
Instruction manual
Save the original packing materials in case it becomes neces-
sary to return the unit.
FIGURE 3: SYSTEM DIAGRAM
one
optical fiber
two
video
inputs
two
video
outputs
S703V-T
S703V-R
1 INSTALLATION
1.1 INSTALLATION CONSIDERATIONS
This fiber-optic link is supplied in two forms, as a stand-
alone module and as a rack card. Units should be
installed in dry locations protected from extremes of tem-
perature and humidity.
1.2 STANDALONE MODULES
Determine where the module is to be installed and
ensure that there is adequate space at both ends for
making the various cable connections and for reading the
diagnostic LEDs.
Standalone modules are provided with mounting holes
for four No. 6 screws (3-mm or 3.5-mm screws). The
type of screw chosen must be suitable for the surface on
which the module is to be mounted.
Some standalone modules consist of a rack card
installed in a standalone enclosure and are mounted in
the same manner. The rack card is normally installed in
the enclosure at the factory.
1.3 RACK CARDS:
Rack cards are designed to be installed in one of Fiber
Options’ 19-inch (483-mm) EIA standard card-cage
racks, either the 515R1 or the 517R1. They may also be
supplied in the 501R standalone rack-card enclosures.
1.3.1 515R1 AND 517R1 CARD CAGE RACKS
To install rack cards in a rack, follow these steps:
CAUTION: Fiber Options recommends that the power
switch on the rack power supply be turned OFF and that
the rack power supply is disconnected from any power
source.
Make sure that the card is oriented right-side up, and
slide it into the card guides in the rack until the edge con-
nector at the back of the card seats in the corresponding
slot in the rack’s connector panel. Seating may require
thumb pressure on the top and bottom of the card’s front
panel.
CAUTION: Take care not to press on any of the LEDs.
Tighten the two thumb screws on the card until the front
panel of the card is seated against the front of the rack.
1.3.2 501R STANDALONE ENCLOSURES
To install rack cards in standalone enclosures, follow
these steps:
CAUTION: The rack card module can ONLY be powered
by 13.5-16 VDC. AC power must not be used.
S703V AND S7703V: TWO-CHANNEL VIDEO MULTIPLEXERS
continued on page 2

S703V & S7703V Instruction Manual
2
CAUTION: Fiber Options recommends that the enclosure
not be connected to any power source during installation.
Look inside the enclosure to determine the location of the
socket for the edge connector on the card. Orient the
card so that it will seat in the socket, and slide it into the
enclosure until the edge connector at the back of the card
seats in the socket. Seating may require thumb pressure
on the ends of the card’s front panel.
CAUTION: Take care not to press on any of the LEDs.
Tighten the two thumb screws on the card until the front
panel of the card is seated against the front of the rack.
2 SIGNAL CONNECTIONS
All fiber-optic links convert electrical signals of some type
or types into a light signal at the transmitter and convert
the light back to electrical signals for output at the receiv-
er. These electrical signal connections to the S703V
series consist of two BNC connectors on the transmitter
and receiver.
CAUTION: Make sure all peripheral equipment that is to
be connected to the fiber unit is turned OFF during instal-
lation.
NOTE: Fiber Options recommends using Belden 9259
RG59/U coaxial cable between the video equipment and
the fiber units. For best image, do not exceed the cable
manufacturer’s recommendation for maximum distance.
NOTE: Coaxial cable must be terminated with female
BNC connectors to properly couple with the Fiber
Options equipment.
Connect two video sources, such as cameras, to the
S703VT transmitter using terminated coaxial cables.
Connect monitoring equipment to the S703VR receiver
with terminated coaxial cables.
3 OPTICAL CONNECTIONS
The standard optical connector on Fiber Options’ units is
the ST type. Connect the pre-terminated fiber to the two
fiber units.
4 ELECTRICAL CONNECTION
4.1 RACKMOUNT CARDS
Make sure the power switch of the power supply is OFF,
and plug the supplied power cord into a suitable outlet.
Press the power switch to apply power to the modules in
the rack.
4.2 STANDALONE MODULES
1. Identify the power connector and remove it from the
module.
2. Make sure the power supply is not connected to any
power source, and strip approximately 0.25-in (6-mm)
of insulation from the ends of the cable.
3. Taking care to observe correct polarization of the
cable (see table 1 for standalone transmitter modules,
table 2 for 501R standalones), insert one lead into one
of the screw sockets and tighten the screw. Repeat for
the other conductor. Confirm the security of the con-
nection by a light pull on the cable.
4. Seat the connector in its position in the fiber unit.
5. Plug the power supply into a suitable outlet.
CAUTION: The rack card module can ONLY be powered
by 13.5-16 VDC. AC power must not be used.
Power up the peripheral equipment and verify system
operation by observing video on the monitor at the
receiver end. If the system does not perform as expect-
ed, refer to Tables 3 and 4 for an explanation of how to
diagnose system faults using the LEDs built into the Fiber
Options units.
5 TROUBLESHOOTING
Refer to Tables 3 and 4 for LED system diagnostic infor-
mation.
6 CONTACTING FIBER OPTIONS
For technical assistance in the U.S. or Canada, call the
Fiber Options Headquarters in Bohemia, NY. If you are
outside the U.S. or Canada, call the closest international
office as listed on the back page of this manual.
Have the following information available: exact model
number of your fiber-optic links, and a listing of the diag-
nostic indicators and their respective color or condition.
7 SHIPPING AND PACKAGING
Before shipping or transporting your Fiber Options unit,
pack it securely to prevent damage that could occur in
transit. Take care to protect all connectors, LEDs, and
corners from possible damage.
8 RETURNS TO FIBER OPTIONS
If any equipment must be returned to Fiber Options for
repair or replacement, you must obtain authorization
from our Return Authorization department before ship-
ping the unit.
NOTE: Fiber Options will not accept return delivery of
any products without prior authorization.
Call Fiber Options at 631-567-8320 or 800-342-3748 and
ask to speak to a Return Authorizations representative.
You will be given full instructions for returning your prod-
uct at that time.
NOTE: All authorized returns must be clearly marked
with the Return Authorization information. Please follow
the instructions completely.
continued from page 1

CONNECTIONS, DIAGNOSTIC INDICATORS - RACK-MOUNT CARDS
Fiber Options 3
FIGURE 4: S703V RACK CARD
VIDEO IN
VIDEO IN
703-T
VIDEO IN
7703-T
VIDEO IN
VIDEO OUT
703-R
LVL/LOSS
VIDEO OUT
VIDEO OUT
7703-R
LVL/LOSS
VIDEO OUT
FIGURE 5: RACK CARD FRONT BEZELS,
TRANSMITTER (LEFT) AND RECEIVER (RIGHT)
FIGURE 6: RACK CARD CONNECTIONS,
TRANSMITTER (LEFT) AND RECEIVER (RIGHT)

INSTRUCTION
MANUAL
S703V AND S7703V: TWO-CHANNEL VIDEO MULTIPLEXERS
All specifications are subject to change without notice. Information furnished by FIBER OPTIONS is
believed to be accurate and reliable. However, no responsibility or liability is assumed by FIBER OPTIONS
for its use, nor for any infringement of patents or other rights of third parties which may result from its use.
No license is granted by implication or otherwise under any patent or other rights of FIBER OPTIONS.
11-0703VA
Copyright 2001 by FIBER OPTIONS.
All rights reserved.
010822
www.fiberoptions.com
80 Orville Drive, Bohemia NY 11716-2533
[email protected]
US Tel: [phone] Fax: [phone]
800-342-3748 877-FiberFax (877-342-3732)
UK Tel: [phone] Fax: [phone]
Australia Tel: [phone] Fax: [phone]
France Tel: [phone] Fax: [phone]
Germany Tel: [phone] Fax: [phone]
Hong Kong Tel: [phone] Fax: [phone]
Latin America Tel: [phone] Fax: [phone]
TABLE 4: RECEIVER LED DIAGNOSTIC INDICATORS
LED
NAME COLOR INDICATION / CORRECTIVE ACTION
LVL/ Green Sufficient optical power received. No action required.
LOSSTM Red Insufficient optical power received. Verify fiber connected & within optical budget, receiver power on.
VIDEO Green Video signal received from transmitter and video output functioning normally. No action required.*
OUT Red Video output not functioning. Verify video source is connected & operating at transmitting end of link.
TABLE 3: TRANSMITTER LED DIAGNOSTIC INDICATORS
LED
NAME COLOR INDICATION / CORRECTIVE ACTION
VIDEO Green Sufficient video signal received. No action required.*
IN Red Insufficient video signal received. Verify video source is connected & operating.
* NOTE: A blank monitor screen may be valid video.
* NOTE: A blank monitor screen may be valid video.
. . . light years ahead™
