FieldServer FS-8700-80 Release note

Driver Version:
1.05
Document Revision:
6
A Sierra Monitor Company
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after November 2011
Driver Manual
(Supplement to the FieldServer Instruction Manual)
FS-8700-80 McQuay MicroTech® Open Protocol™

McQuay Micro Tech Open Protocol Driver Manual Table of Contents
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
TABLE OF CONTENTS
1McQuay Micro Tech Open Protocol Description.............................................................................................4
1.1 MicroTech Unit and System Controllers ........................................................................................................4
1.1.1 McQuay Equipment Types recognized by the driver..............................................................................4
1.1.2 McQuay equipment not currently recongnized by the driver: ...............................................................4
1.1.3 McQuay MicroTech network products used in conjunction with the driver: .........................................5
1.1.4 About MicroTech Network Architecture ................................................................................................6
1.2 Applying a FieldServer gateway to different MicroTech situations...............................................................6
1.2.1 Single standalone MicroTech 200 Series unit controller ........................................................................6
1.2.2 Multiple standalone MicroTech 200 Series unit controllers...................................................................7
1.2.3 Multiple standalone MicroTech “non-200 Series” unit controllers ........................................................7
1.2.4 Existing MicroTech network (Custom MicroTech Monitor software, NMP Panel, etc) ..........................7
1.2.5 Existing MicroTech Open Protocol network ...........................................................................................9
1.2.6 Replacing a BACdrop Gateway panel ....................................................................................................9
1.3 MicroTech Communication Port Configuration...........................................................................................11
1.4 Reference Documents .................................................................................................................................12
2Driver Features ............................................................................................................................................ 13
3Driver Scope of Supply ................................................................................................................................. 13
3.1 Supplied by FieldServer Technologies for this driver...................................................................................13
3.2 Provided by Supplier of 3rd Party Equipment...............................................................................................13
4Hardware Connections................................................................................................................................. 14
5Data Array Parameters................................................................................................................................. 15
6Configuring the FieldServer as a McQuay Micro Tech Open Protocol Client ................................................. 16
6.1 Client Side Connection Parameters .............................................................................................................16
6.2 Client Side Node Parameters .......................................................................................................................17
6.3 Client Side Map Descriptors.........................................................................................................................18
6.3.1 FieldServer Related Map Descriptor Parameters .................................................................................18
6.3.2 Driver Related Map Descriptor Parameters.........................................................................................18
6.3.3 Timing Parameters...............................................................................................................................18
6.3.4 Map Descriptor Example 1 –Read Everything.....................................................................................19
6.3.5 Map Descriptor Example 2 –Read a particular Data Field. .................................................................19
6.3.6 Map Descriptor Example 3 –Write......................................................................................................20
7Configuring the FieldServer as a McQuay Micro Tech Open Protocol Server ................................................ 21
7.1 Server Side Connection Paramaters ............................................................................................................21
7.2 Server Side Node Parameters ......................................................................................................................22
7.3 Server Side Map Descriptors........................................................................................................................22
7.3.1 FieldServer Specific Map Descriptor Parameters .................................................................................22
7.3.2 Driver Specific Map Descriptor Parameters .........................................................................................23
7.3.3 Timing Parameters...............................................................................................................................23
7.3.4 Map Descriptor Example –Strategy 1. ................................................................................................24
7.3.5 Map Descriptor Example –Strategy 2. ................................................................................................24
Appendix A. Useful Features................................................................................................................................ 25
Appendix A.1. Scaling ..............................................................................................................................................25
Appendix A.1.1. User Scaling:...........................................................................................................................25

McQuay Micro Tech Open Protocol Driver Manual Table of Contents
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Appendix A.1.2. Device Scaling: .......................................................................................................................25
Appendix A.2. Direct Addressing .............................................................................................................................26
Appendix A.3. Direct Addressing Example 1–Reading direct address. ...................................................................27
Appendix A.4. Direct Addressing Example 2 –Controlling Bytes per Field –Reading.............................................27
Appendix A.5. Advanced Map Descriptor Example 3 –Controlling Bytes per Field –Writing ................................28
Appendix B. Troubleshooting............................................................................................................................... 29
Appendix B.1. Connection Problems .......................................................................................................................29
Appendix B.2. Negative Acknowledgement - NAK ..................................................................................................29
Appendix B.3. Node ID problems.............................................................................................................................29
Appendix B.4. Server Side Configuration –Consecutive Addresses ........................................................................30
Appendix B.5. Configuring the OPM to enable communication between the FieldServer and McQuay devices ...30
Appendix B.5.1. Configuring multiple McQuay devices to communicate to a FieldServer without an OPM:...30
Appendix C. Reference......................................................................................................................................... 32
Appendix C.1. Error Messages .................................................................................................................................32
Appendix C.2. Statistics ...........................................................................................................................................34
Appendix C.3. McQuay Equipment Types recognized by the driver. ......................................................................35
Appendix C.4. Device Scaling Method .....................................................................................................................35
Appendix C.5. Data Field Name Tables....................................................................................................................35
Appendix C.5.1. Equipment Type: 200CFC 200 Series Centrifugal Chiller.........................................................35
Appendix C.5.2. Equipment Type: 050RPC Reciprocating Chiller .....................................................................37
Appendix C.5.3. Equipment Type: 100CFC 100 Series Centrifugal Chiller.........................................................38
Appendix C.5.4. Equipment Type : 001ASC Air Cooled Screw Chiller................................................................40
Appendix C.5.5. Equipment Type : Self-Contained Units (SCUs).......................................................................41

McQuay Micro Tech Open Protocol Driver Manual Page 4 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
1MCQUAY MICRO TECH OPEN PROTOCOL DESCRIPTION
This document describes the FieldServer driver used to transfer data between a FieldServer and MicroTech® unit
and/or network of controllers manufactured by McQuay International. Transfers are done using the controller's
Data Terminal Communications Protocol. In this document the protocol is referred to as the McQuay MicroTech®
Open Protocol. MicroTech controls are legacy products that may require the use of a FieldServer device in order to
support existing applications in need of unit or network controller replacements and/or integration into a Building
Automation System (BAS).
1.1 MicroTech Unit and System Controllers
McQuay International has provided BAS manufacturers licensed access to stand-alone MicroTech unit controllers.
The network access, which is called Open Protocol™, allows a BAS to monitor status and change limited control
parameters in McQuay International HVAC equipment. Monitoring and controlling MicroTech unit controllers may
have required the use of a MicroTech system panel, depending on the unit type, number of units and other
network requirements. There are multiple combinations of MicroTech unit controllers and/or system panels (i.e.
Open Protocol networks) that could use a FieldServer device. FieldServer-supported devices, McQuay Open
Protocol controller descriptions, and network architecture diagrams are all described in the following section.
The McQuay MicroTech® Open Protocol driver allows the FieldServer to transfer data to and from devices over
either RS-232 or RS-485 using McQuay MicroTech® Open Protocol. The FieldServer can emulate either a Server or
Client.
1.1.1 McQuay Equipment Types recognized by the driver.
Code
Description
200CFC
200 Series Centrifugal Chiller
100CFC
100 Series Centrifugal Chiller
001ASC
Air Cooled Screw Chiller –V2.2 Single Compressor Only
000SCU
Self Contained Unit
0050RPC
Reciprocating Chiller
Rooftop Unit
Water Cooled Screw Chiller
1.1.2 McQuay equipment not currently recongnized by the driver:
Code
Description
Global Scroll chiller
Unit Ventilator
Water Source Heat Pump (WSHP)
MicroTech 2000 WSHP (through MCG (MicroTech Communications Gateway panel)

McQuay Micro Tech Open Protocol Driver Manual Page 5 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
1.1.3 McQuay MicroTech network products used in conjunction with the driver:
1.1.3.1 MicroTech BACdrop™ panel
The MicroTech BACdrop gateway integrates a MicroTech network into a BACnet™ building automation system
(BAS) facilitating monitoring and control of McQuay International equipment from the BAS. The gateway
translates between BACnet objects on an Ethernet® network and McQuay memory locations on a proprietary
MicroTech network.
The BACdrop gateway is a passive device. It receives, translates, and re-transmits messages including both data
and control signals from one network to the other network in either direction but does not perform any
supervisory control for the various MicroTech controllers connected to it. Figure 1 shows the important features
of the BACdrop panel.
Figure 1. BACdrop Panel
CB
PS
SBC
J1 connector
RJ-45
J22
L2 L1
GRD
“Ethernet” port
“Network” port
“PC” port
Flash memory chip
Ethernet status LEDs
Speaker
5 Vdc power in
1.1.3.2 OPM –Open Protocol Master Panel
The OPM Panel is used when two or more MicroTech controllers need to be interfaced with a BAS by means of a
single-point connection. The OPM acts as a passive communications link between MicroTech controllers and the
BAS and does not perform any supervisory control for the various MicroTech controllers connected to it. When an
OPM is used, all supervisory control (scheduling, overrides, chiller sequencing) is handled by the BAS. The
maximum number of unit controllers per OPM depends on the BAS. For example, the OPM Panel could combine a
McQuay centrifugal chiller, a McQuay applied rooftop unit, and several unit ventilators into a network that a BAS
could connect to with a single cable. Figure 2 shows the important features of the OPM panel.

McQuay Micro Tech Open Protocol Driver Manual Page 6 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Figure 2. OPM Panel
PortA
PortB
HI
LO
F1
L1
Port A Select
1 2 3 3
21
Hex
switches
Communication
ports
Red status
LED
Green
status LED
1.1.3.3 Alternatives to the OPM Panel
The following MicroTech network controllers, which perform specific supervisory control tasks, can be used as
substitutes for the OPM Panel:
RMC (Remote Monitoring and Control panel –Applied Air product)
CSC (Chiller System Controller panel –chiller product)
RMS (Remote Monitoring and Sequencing panel –chiller product)
LWC (Loop Water Controller –WSHP product)
1.1.4 About MicroTech Network Architecture
All controllers in a MicroTech network are assigned a level: level 1, level 2, or level 3. All networks must have one
level 1 controller to coordinate communications. Multiple level 2 controllers connect to the level 1 controller with
a communications trunk. A trunk is defined as an isolated section of the daisy-chained network wiring. The
network wiring between all controllers is a trunk. Multiple level 3 controllers can be connected to a level 2
controller with a separate trunk; however, this is typically not done in BACdrop applications. The maximum
allowable length of a communications trunk is 5000 ft (1524 m). See Figures 6 and 7 for examples of field wiring.
1.2 Applying a FieldServer gateway to different MicroTech situations
There are multiple scenarios where a FieldServer gateway device may be applied to one or more MicroTech
controllers. The most common are listed below, followed by a brief description of each one.
1.2.1 Single standalone MicroTech 200 Series unit controller
When a FieldServer device is connected to a single MicroTech unit controller, the FieldServer connects to the “A”
port of the MicroTech controller. The unit controller is typically a level 2 device with a Comm Port Configuration of
“L2 TTY/Slave”. MicroTech Level 2 devices must have an address with a non-zero value to the left of the decimal
point and "00" to the right of the decimal point (for example, 01.00, 02.00, 03.00, etc). For a level 2 device, the left
side (the non-zero portion) of the address is set with the controller's rotary hex switches.

McQuay Micro Tech Open Protocol Driver Manual Page 7 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
1.2.2 Multiple standalone MicroTech 200 Series unit controllers
1.2.2.1 MicroTech Addressing and Network Architecture
When a FieldServer device is connected to two or more MicroTech controllers, a level 1 MicroTech controller is
required to coordinate communications. Typically the level 1 device in this situation is an Open Protocol Master
Panel (an "OPM"). However, the OPM Panel is no longer available from McQuay, so another MicroTech device
may function as the Level 1 device. A 200 Series MicroTech unit controller (for example, a Self-Contained Unit
(SCU) controller) can be re-configured as a level 1 device. Thus if a site has several SCUs, one of them can be re-
configured as level 1 and the FieldServer connects to the "A" port of that unit controller. A Level 2 daisy chain is
then connected from the “B” port of the level 1 SCU to the “B” port of the remaining Level 2 SCU's.
It is also possible to use a supervisory MicroTech network controller as the level 1 device which coordinates
communications between the FieldServer device and multiple level 2 MicroTech controllers. Examples of
supervisory controllers are the RMC, CSC, and RMS panels.
Another alternative is to use an NMP (Network Master Panel) controller. An NMP is the level 1 device used in a
MicroTech network (see Figure 3). The NMP coordinates communications of all level 2 and level 3 MicroTech
controllers in this type of network. The NMP also coordinates unit time scheduling, processes alarms, and does
other functions. If an NMP is used in this way, it is necessary to “corrupt” its checksums so that the NMP
application code no longer runs. The process of corrupting checksums can be performed with MicroTech Monitor®
software using the read/write screen. Please contact the McQuay Controls Customer Support group at 866-462-
7829 for more information about using Monitor software.
1.2.3 Multiple standalone MicroTech “non-200 Series” unit controllers
If a FieldServer gateway device is applied to a site that has several “standalone” unit controllers that have never
been networked together, there are certain guidelines that must be followed. First, a level 1 device is required to
coordinate the communications between the FieldServer device and the MicroTech unit controllers. Typically an
OPM Panel is used for this purpose. However, the OPM is no longer available from McQuay. If the multiple unit
controllers are “non-200 Series” MicroTech controllers such as Unit Ventilators (UVs) or Water Source Heat Pumps
(WSHPs), a Level 1 MicroTech controller must be added to the network to coordinate communications of the Level
2 UVs or WSHPs.
In addition, network wiring would be required to be installed. The FieldServer would be wired to the “A” port of
the Level 1 device. A “level 2 daisy-chain” would be required from the “B” port of the level 1 device to the “B” port
of each level 2 device. See Figures 6 and 7 for network wiring details.
1.2.4 Existing MicroTech network (Custom MicroTech Monitor software, NMP Panel, etc)
1.2.4.1 With level 3 devices (Unit Vents or WSHPs)
If a FieldServer gateway device is applied to a site that has an existing “MicroTech network” (meaning that it has
custom MicroTech Monitor software for that site and an NMP Panel) and Unit Vents or WSHPs, changes are
required as follows:
The checksums in the NMP’s application code must be corrupted so that the NMP no longer functions as a
Network Master Panel. The FieldServer device connects to the A port of the NMP.
Level 2 LMPs (Local Master Panel) must be removed from the network.
The RS-485 daisy chain connecting all of the Unit Vents or WSHPs must be connected directly to the “B”
port of the Level 1 NMP.

McQuay Micro Tech Open Protocol Driver Manual Page 8 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Different application code must be downloaded into all Unit Vents and WSHPs.
In the case of Unit Vents, the “Level 3 network code” for use in a MicroTech network must be
replaced with “Level 2 standalone” Unit Vent code.
In the case of WSHPs, the “Level 3” code for use in a MicroTech network must be replaced with
“Level 2 standalone” WSHP code.
See Figure 3 for details.
Figure 3. MicroTech Network Configurations with Level 1 NMP Supervisory Controller
T
M
M
S
T
S
T
S
Level 1 Laptop PC
RS 232
RS 485
T
S
Port B
Port A
NMP
LMP MCG RTU LWC
Port B
Port A
Port B Port B Port B
Port A Port A Port A
Level 2 Trunk
Level 2
Level 3
T
S
WSHP
Port B
Port A
T
S
WSHP
Port B
Port A
T
S
MT 2000
WSHP
Port B
Port A
T
S
Port B
Port A
MT 2000
WSHP
Port Configuration
M=Master
S=Slave
T=TTY (for PC connection)
Notes:
A PC running MicroTechMonitor connects to an NMP through it’s a Port configured as “TTY”
The A Port of a Level 2 MCG is configured as “USER” to communicate with the MCG’s SLTA.
MicroTech WSHP’s on a MicroTech network require a LMP (Level 2 Local Master Panel) above them.
MicroTech 2000 WSHP’s with LonWorks code (vs LonMark code) are installed below an MCG.

McQuay Micro Tech Open Protocol Driver Manual Page 9 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
1.2.4.2 With no level 3 devices
If a FieldServer gateway device is applied to a site that has an existing “MicroTech network” (meaning that it has
custom MicroTech Monitor software for that site and an NMP Panel) with only level 2 controllers and no level 3
devices (such as Unit Vents or WSHPs), changes are required as follows:
The checksums in the NMP’s application code must be corrupted so that the NMP no longer functions as a
Network master Panel. The FieldServer device connects to the “A” port of the NMP.
No network wiring changes are necessary
1.2.5 Existing MicroTech Open Protocol network
If a FieldServer gateway device is applied to a site that has an existing “Open Protocol network”, the following
assumptions are made:
The site has either an OPM Panel or some other level 1 MicroTech controller that is functioning as an
OPM.
Any Unit Vents or WSHPs in the network are already running the proper “Level 2” application code
required for an “Open Protocol” network.
No network wiring changes are necessary.
See Figure 7 for details
1.2.6 Replacing a BACdrop Gateway panel
1.2.6.1 Connected a Single MicroTech unit controller
When a FieldServer device is used to replace a BACdrop panel that has been connected to one MicroTech unit
controller, some re-wiring is necessary. The RS-485 network terminals of the BACdrop panel are connected to the
“B” Port of the MicroTech controller, but the FieldServer connects to the “A” port of the MicroTech controller. The
unit controller will be a level 2 device with a Comm Port Configuration of “L2 TTY/Slave”. MicroTech Level 2
devices must have an address with a non-zero value to the left of the decimal point and "00" to the right of the
decimal point (for example, 01.00). For a level 2 device, the left side (the non-zero portion) of the address is set
with the controller's rotary hex switches.
1.2.6.2 Connected to Multiple MicroTech unit controllers
When a FieldServer device is used to replace a BACdrop panel that has been connected to multiple MicroTech unit
controllers with no Level 1 supervisory panel such as an RMC, CSC, or RMS, a Level 1 device must be added. If the
unit controllers are 200 Series MicroTech, this can be accomplished by re-configuring one of the unit controllers to
be Level 1. The alternative to re-configuring one of the existing unit controllers to be a Level 1 device is to add a
level 1 device such as an OPM, RMC, CSC, or RMS, but this may be difficult because all of these control panels are
obsolete and no longer available. For a typical BACdrop network, the BACdrop panel is the level 1 controller and
the unit controllers are level 2 controllers. See Figures 4 and 6 for details.

McQuay Micro Tech Open Protocol Driver Manual Page 10 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Figure 4. MicroTech Architecture
RTU UV
Up to 63 MicroTech
controllers per BACdrop
BACnet on ISO 8802-3 (Ethernet), 10BaseT
MicroTech
BACdrop
(level 1)
Chiller UV UV UVSCU
Level 2
MicroTech
Level 1
BACnet BAS
by others
Main "front end"
PC for BAS
MicroTech network (RS-485)
1.2.6.3 Connected to multiple MicroTech unit controllers and a supervisory panel such as an RMC,
CSC, or RMS panel
When a FieldServer device will be replacing a BACdrop Gateway panel that was connected to multiple MicroTech
unit controllers with a Level 1 supervisory panel such as an RMC, CSC, or RMS, some re-wiring may be necessary.
The FieldServer device must be wired to the A Port of the Level 1 device. The B Port of the Level 1 device is then
wired to the B Port of all Level 2 devices with a daisy chain. See Figure 5 for details.
Figure 5. Level 2 BACdrop Panel with Level 1 Supervisory Panel
Chiller
Level 2
MicroTech
Up to 63 MicroTech
controllers per BACdrop
BACnet BAS
by others
BACnet on ISO 8802-3 (Ethernet), 10BaseT
MicroTech
BACdrop
(level 2)
Level 1
ChillerChiller
Main "front end"
PC for BAS
CSC
Chiller
MicroTech network (RS-485)
All data requests from BACnet BAS to
MicroTech level-2 controllers are routed
through level-1 MicroTech controller

McQuay Micro Tech Open Protocol Driver Manual Page 11 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
1.3 MicroTech Communication Port Configuration
In addition to the rules about MicroTech architecture and addressing, there is also a critical parameter called the
Comm Port Configuration. The Comm Port Configuration must also be set correctly for a unit controller to be able
to communicate. This comm port configuration for level 1 devices is different to level 2 devices. While it is
necessary to know this for proper unit controller setup and for troubleshooting communication problems, it is not
critical from the FieldServer side for programming or routing.
A level 1 device must have its communication port configuration set up as “Level 1 TTY/Slave”. To change this
configuration, connect to the unit controller with MicroTech Monitor software through the “A” port, proceed to
the “Read/Write” screen, read memory address “0A11”, and change the value to “C1” (Level 1 TTY/Slave). After
doing this, the controller must also have its rotary hex switches set to the Level 1 address of “00” to make the unit
controller’s network address 00.00. Please note that power must be cycled to the controller for this new hex
switch setting to take effect.
Figure 6. MicroTech Network with BACdrop Panel as Level 1 Device
TS2
BACdrop
Hot
Neutral 100 – 240 Vac
Power
L2
L1
GRD
Notes:
1. Twisted, shielded pair cable must meet the following
minimum requirements: 300 V, 60°C, 20 AWG, polyethylene
insulated, with a PVC outer jacket and drain wire (Belden
8762 or equivalent). Some local codesmay require the use
of plenum rated cable.
2. 10BaseT Ethernet cable. To directly connect a PC to the
Ethernet port, a hub or a special crossover cable must be
used.
3. Cable length must not exceed 5000 ft (1524 m).
4. Standard serial cable. A null modem isnot required.
See notes 1 & 3
Self-contained AC
PortB GND
TB7
Reciprocating chiller
PortB 139
TB4
Screwchiller
PortB 55
BLK
WHT
B+
B–
138 137
54 53
CommB
UVC(325)
1 2
PNK
GRY
CommB
UVC(125)
4 5
PNK
GRY
RJ-45
3rd-partyBAS
See note 2
TB1
Centrifugal chiller (series 200)
PortB 85
86 84
TB2
Applied rooftop
PortB 130
128 129
Legend Field wiring terminal
Field wiring: discrete
Factorywiring
Field wiring: twisted, shielded pair cable
with drain wire(see note 1)
B+
Crimp or solder splice
BLK
WHT BLK WHT BLK WHT BLK WHT BLK WHT
BLK
WHT BLK WHT BLK WHT BLK WHT
CommB
UVC(325)
1 2
PNK
GRY
CommB
UVC(325)
1 2
PNK
GRY
CommB
UVC(325)
1 2
PNK
GRY
Ethernet
DB9
PC
PC
+
–
GRD
Network
See note 4
Field wiring: 10BaseT Ethernet
Standard serial cable

McQuay Micro Tech Open Protocol Driver Manual Page 12 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Figure 7. MicroTech Network with OPM Panel as Level 1 Device
1.4 Reference Documents
Document
Description
Location
IM 474
Open Protocol Master (OPM) Panel
www.mcquay.com
IM 689
BACdrop Gateway for MicroTech
www.mcquay.com
IM 658
Network Master Panel (NMP)
Contact McQuay
CD 573875Y
Microtech Open Protocol Wiring Diagrams
Contact McQuay
IM 444
Remote Monitoring and Control (RMC) Panel
Contact McQuay
IM 498
Remote Monitoring and Sequencing (RMS) Panel
Contact McQuay
IM 618
MicroTech Chiller System Controller (CSC) Panel
Contact McQuay
*Or other Level 1 Device (CSC, etc.)

McQuay Micro Tech Open Protocol Driver Manual Page 13 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
2DRIVER FEATURES
When emulating a Client, the driver enables the FieldServer to request ‘Everything’ from the McQuay, allow
specific fields to be read or written and apply device scaling to be applied.
When emulating a Server, the driver provides an emulation of the byte memory of a device and responds to read
and write requests.
The following important points and limitations should be noted.
Arising from a feature of the McQuay MicroTech® Open Protocol is the peculiarity that when a multi-byte
value is written to a McQuay device, the write is done one byte at a time (one byte of data can be
transferred per poll/response message pair) allowing for the possibility that the multi byte value is only
partially correct until all the messages have been completed.
The vendor equipment is limited to a maximum of 9600 baud. Given that each message packet can only
transfer one byte of data and that some data of interest is multi-byte, users of this protocol should expect
low data transfer rates.
Port expansion is not supported for this driver.
Each MicroTech® controller is shipped from the factory with a unique job site password. The passwords
are provided by the McQuay International representative at the time of startup.
The driver does not validate passwords when configured as a Server. This means that requests to read or
write data will succeed even if the password supplied with the request is incorrect.
3DRIVER SCOPE OF SUPPLY
3.1 Supplied by FieldServer Technologies for this driver
FieldServer Technologies Part #
Description
FS-8917-16
RJ45 to terminal connector cable.
3.2 Provided by Supplier of 3rd Party Equipment
Part #
Description
McQuay Motor Mount Connector for Port A connection

McQuay Micro Tech Open Protocol Driver Manual Page 14 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
4HARDWARE CONNECTIONS
The FieldServer is connected to the McQuay device as shown below.
Configure the McQuay device according to manufacturer’s instructions.
FS-8917-16
RJ45-04
BLUE/WHITE
RJ45-08
ORANGE/WHITE
SERIES 200 CONTROLLER
FS-COM
RJ45-01
BROWN
FS-Tx/+
FS-Rx/-
FieldServer
Connect to one of the RS-232
Ports on the FieldServer
P1
18

McQuay Micro Tech Open Protocol Driver Manual Page 15 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
5DATA ARRAY PARAMETERS
Data Arrays are “protocol neutral” data buffers for storage of data to be passed between protocols. It is necessary
to declare the data format of each of the Data Arrays to facilitate correct storage of the relevant data.
Section Title
Data_Arrays
Column Title
Function
Legal Values
Data_Array_Name
Provide name for Data Array
Up to 15 alphanumeric characters
Data_Array_Format
Provide data format. Each Data Array can only take
on one format.
FLOAT, BIT, UInt16, SInt16,
Packed_Bit, Byte, Packed_Byte,
Swapped_Byte
Data_Array_Length
Number of Data Objects. Must be larger than the
data storage area required by the Map Descriptors
for the data being placed in this array.
1-10, 000
Example
// Data Arrays
Data_Arrays
Data_Array_Name
, Data_Array_Format
, Data_Array_Length
DA_AI_01
, UInt16,
, 200
DA_AO_01
, UInt16
, 200
DA_DI_01
, Bit
, 200
DA_DO_01
, Bit
, 200

McQuay Micro Tech Open Protocol Driver Manual Page 16 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
6CONFIGURING THE FIELDSERVER AS A MCQUAY MICRO TECH OPEN PROTOCOL CLIENT
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer. (See “.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a McQuay Micro Tech Open Protocol Server.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for McQuay Micro Tech Open Protocol communications, the driver independent FieldServer buffers
need to be declared in the “Data Arrays” section, the destination device addresses need to be declared in the
“Client Side Nodes” section, and the data required from the Servers needs to be mapped in the “Client Side Map
Descriptors” section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
6.1 Client Side Connection Parameters
Section Title
Connections
Column Title
Function
Legal Values
Port
Specify which port the device is connected to
the FieldServer
P1-P8, R1-R21
Baud*
Specify baud rate
300, 1200, 2400, 4800, 9600 (Vendor
limitation).
Parity*
Specify parity
Even (Vendor limitation)
Data_Bits*
Specify data bits
7(Vendor limitation)
Stop_Bits*
Specify stop bits
1
Protocol
Specify protocol used
MCQ, McQuay
Poll Delay*
Time between internal polls
0-32000 s, 1s
Example
// Client Side Connections
Connections
Port
, Baud
, Parity
, Data_Bits
, Protocol
, Poll_Delay
P1
, 9600
, Even
, 7
, McQuay
, 0.100s
1Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.

McQuay Micro Tech Open Protocol Driver Manual Page 17 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
6.2 Client Side Node Parameters
Section Title
Nodes
Column Title
Function
Legal Values
Node_Name
Provide name for Node
Up to 32 alphanumeric
characters
Protocol
Specify protocol used
MCQ, McQuay
Port
Specify which port the device is connected to the FieldServer
P1-P8, R1-R22
PLC_Type
The name of the McQuay Equipment type being polled. The
equipment type must be known for the driver to operate
correctly.
200CFC, 100CFC, 050RPC,
001ASC, 000SCU, Type-
Unknown
Password
Maximum of 8 characters.
Ascii characters only.
Node_Hi
Specify the rotary Hi address switch setting of the Mcquay
controller
0to F
Node_Lo
Specify the rotary Lo address switch setting of the Mcquay
controller
0to F
// Client Side Nodes
Nodes
Node_Name
, Node_Hi
, Node_Lo
, Protocol
, Port
, Password
, PLC_Type
Node_200CFC
, 3
, B
, McQuay
, P1
, 85760430
, 200CFC
2Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.

McQuay Micro Tech Open Protocol Driver Manual Page 18 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
6.3 Client Side Map Descriptors
6.3.1 FieldServer Related Map Descriptor Parameters
Column Title
Function
Legal Values
Map_Descriptor_Name
Name of this Map Descriptor
Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to be
stored in the FieldServer
One of the Data Array Names
specified in Section 5.
Data_Array_Offset
Starting location in Data Array
0 to maximum specified in Section 5.
Function
Function of Client Map Descriptor
Rdbc, Wrbc, Wrbx
6.3.2 Driver Related Map Descriptor Parameters
Column Title
Function
Legal Values
Node_Name
Name of Node to fetch data from
One of the Node
Names specified
in Section 6.2.
Length*
This parameter normally refers to the length of Map Descriptor. Since
one data field can be read or written per poll/response sequence, the
driver assumes a length of 1. When Bytes_Per_Field is specified, must be
set to 1. When used to read addresses (Appendix A.3), this parameter is
used to specify the number of data elements to be read.
Any positive
integer, 1.
Field_Name*
The name of the data field of interest. Each address with meaningful
data in the McQuay device has a name. The field names are defined in a
specification for each device type. If the field name is unknown, the
Address can be defined. Refer to Appendix A.2 for further information.
A field name
from Appendix
C.3, Everything,
Device_Scaling*
If set to No then the driver stores the raw values, if set to Yes, the data is
scaled before storing. Refer to Appendix A.1.2 for information on the
device scaling applied. Note that ‘Device_Scaling’ has no meaning when
writing to a McQuay device. The Device_Scaling keyword needs to be
used in conjunction with Field_Name
Yes, No
Address*
The address in the McQuay device that contains the data of interest. .
Used with direct addressing –refer to Appendix A.2.
Any positive
integer, -
Bytes_Per_Field*
This parameter is used with direct addressing. When reading, up to 4
consecutive address locations in the McQuay device can be combined
and stored in a single Data Array element. When writing, one value from
the Data Array may be sent to up to 4 consecutive address locations in
the McQuay device. Refer to Appendix A.2 for more information. If this
parameter is specified, length must be set to 1.
1, 2, 3, 4
6.3.3 Timing Parameters
Column Title
Function
Legal Values
Scan_Interval
Rate at which data is polled
>0.1s

McQuay Micro Tech Open Protocol Driver Manual Page 19 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [email protected]
6.3.4 Map Descriptor Example 1 –Read Everything.
In this example the Map Descriptor tells the driver to read all data fields known for the Node. The data fields are read sequentially and the values placed in the
Data Array at a location determined by the driver. Appendix C.3 outlines the data read and the Data Array location of each field. There is no way of telling this
command to read some fields more often than others. Each field is read in turn and when the end of the list is reached the driver starts at the beginning again.
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Length
, Scan_Interval
, Field_Name
, Device_Scaling
Read Chiller 1
, DA_CHILLER1
, 0
, Rdbc
, Chiller1
, 1
, 1.0s
, Everything
, Yes
6.3.5 Map Descriptor Example 2 –Read a particular Data Field.
This example illustrates how to read data for one particular field of interest. The data is read every 2.0 seconds and the value obtained is stored in the Data
Array named DA_OPERATIONAL_MODES at location 10.
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Scan_Interval
, Node_Name
, Length
, Field_Name
Chiller10_Op_Mode
, DA_OPERATIONAL_MODES
, 10
, Rdbc
, 0s
, Chiller10
, 1
, Chiller Operation Mode
Many validation or
error messages report
the name of the Map
Descriptor in the
message and, thus it is
strongly recommended
that unique names be
used.
Each field read has its
value stored in this
Data Array. The
location is dependent
on the field name. The
length of the Data
Array should be at least
200, so that all
parameters can be
stored.
The driver will read
every data field
known for the
device.
The values will be scaled
before storage.
Example: The ‘Evaporator
Refrigerant Pressure’ will be
stored by dividing the raw
value read by 10.
This parameter
connects the Map
Descriptor to a
Node which in turn
connects the Map
Descriptor to a port.
Ensure that the field name is spaced and spelled exactly as it is
printed in Appendix C.3

McQuay Micro Tech Open Protocol Driver Manual Page 20 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [email protected]
6.3.6 Map Descriptor Example 3 –Write.
In this example data is written to control fields in the McQuay device using the Wrbx (write on change) function. A write message will be generated each time
the data at index 0 in the Data Array changes. When writing multibyte fields, several messages are required to transfer the byte values to the McQuay devices.
Note that ‘Device_Scaling’ has no meaning when writing to a McQuay device. The user must ensure that valid numbers are written to the data fields.
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Length
, Field_Name
Chiller1_Op_Mode
, DA_MODES
, 0
, Wrbx
, Chiller1
, 1
, Chiller Operation Mode
The data is only written
when the contents of
element zero of the array
named DA_MODES
changes.
The name of the
data field to be
written to.
