FILL-RITE 3200 Series Quick start guide

1
Owners Installation, Operation, and Safety Manual
3200 Series DC High Flow Fuel Transfer
Pump
Models FR3210B, FR3204
Tuthill Transfer Systems 8825 Aviation Drive Ft. Wayne, IN 46809 [phone] www.tuthill.com

2
Table of Contents
Table of Contents ..................................................................................................................2
Thank You! ............................................................................................................................2
About This Manual.................................................................................................................2
Safety Information..................................................................................................................3
Installation..............................................................................................................................3
Electrical Wiring .....................................................................................................................6
Wiring Diagram ......................................................................................................................9
Operating Instructions..........................................................................................................10
Pad Locking .........................................................................................................................10
Trouble Shooting .................................................................................................................11
Servicing the Bypass Valve .................................................................................................12
Technical Information ..........................................................................................................13
Fluid Compatibility ...............................................................................................................13
Kits and Parts, .................................................................................................................... 14
Accessories .........................................................................................................................15
Safety Approvals and Certifications.....................................................................................15
Motor Tag Information ...............................…………………………………………………..…15
Thank You!
Thank you for your purchase of the FR3200 series pump! Your Fill-Rite product comes
with over 80 years of pump manufacturing experience behind it, providing you the value
that comes with superior performance, user friendly design, long service life, and solid,
simple engineering. Experience that gives you peace of mind.
Excellence at work. Excellence in life.
About This Manual
From initial concept and design through its final production, your Fill-Rite pump is built to
give you years of trouble free use. To insure it provides that service, it is critical that
you read this entire manual prior to attempting to install or operate your new pump.
Become familiar with the terms and diagrams, and pay close attention to the highlighted
areas with the following labels:
WARNING! Emphasizes an area in which personal injury or even death could
result from failure to follow instructions properly. Mechanical damage may also
occur.
IMPORTANT! These boxes contain information that illustrates a point that
may save time or may be key to proper operation, or clarifies a step.
CAUTION! Failure to observe a “Caution” can cause damage to the
equipment.
At Tuthill, your satisfaction with our products is paramount to us. If you have questions or
need assistance with your product, please contact us at 1-800-634-2695 (M-F 8 AM–5
PM ET).

3
Safety Information
WARNING! Electrical wiring should be performed ONLY by a licensed
electrician in compliance with local, state, and national electrical code NEC/
ANSI/NFPA 70, NFPA 30, and NFPA 30A, as appropriate to the intended use of
the pump. Threaded rigid conduit, sealed fittings, and conductor seal should be
used where applicable. The pump must be properly grounded. Improper
installation or use of this pump can result in serious bodily injury, or death!
WARNING! To insure safe and proper operation of your equipment, it is critical
to read and adhere to all of the following safety warnings and precautions.
Improper installation or use of this product can cause serious bodily injury or
death!
 NEVER smoke near the pump, or use the pump near open flames when
pumping a flammable liquid! Fire can result!
 A Fill-Rite Filter should be used on the pump outlet to insure no foreign
material is transferred to the fuel tank.
 Threaded pipe joints and connections should be sealed with the appropriate
sealant or sealant tape to minimize the possibility of leaks.
 Storage tanks should be securely anchored to prevent shifting or tipping
when full or empty.
 To minimize static electricity build up, use only static wire conductive hose
when pumping flammable fluids, and keep the fill nozzle in contact with the
container being filled during the filling process.
 The pump motor is equipped with thermal overload protection; if
overheated, the motor will shut off to prevent damage to the windings. If
this happens, you must turn the power off to the pump to reset this safety
feature, and turn the pump back on when cool to continue use.
WARNING! This product shall not be used to transfer fluids into any type of
aircraft.
WARNING! This product is not suited for use with fluids intended for human
consumption or fluids containing water.
Installation
The Fill-Rite 3200 Series pump is designed to be mounted on a skid tank using the
threaded inlet flange supplied with the pump (see attached diagrams),
The FR3200 series pump features an integral bypass valve recirculate the fluid when the
pump is operating with the nozzle closed.
WARNING! In Skid Tank applications, be sure the tank is properly secured so it
cannot shift or move when the tank is empty or full.
CAUTION! Do not use additional check valves or foot valves unless they have a
proper pressure relief valve built into them. Note that additional check valves will
reduce rate of flow.

4
CAUTION! A pressure retaining fill cap can be used to reduce fuel loss through
evaporation, but note that it will reduce the flow rate.
Typical Skid Tank Installation
CAUTION! Threaded pipe joints and connections should be sealed with the
appropriate sealant or sealant tape to prevent the possibility of leaks.
WARNING! The 3200 series pump is designed primarily for use with stationary
tank applications. While the DC design makes it an excellent choice for mobile
applications, anchoring the tank to which the pump is mounted is paramount to
ensure no movement in transit. Failure to secure the tank to the vehicle can
cause uncontrolled movement, resulting in damage, injury, and potential fire.
The 3200 series pump mounts to the bung of a skid tank by way of the inlet flange. The
suction tube threads into the bottom of the inlet flange, and must be cut to a length that
positions it at least 3” from the bottom of the tank. The skid tank should be equipped
with a vent cap.
Pump
Tank
Vent Cap
3” Min

5
1. Thread the 1-1/4” pipe into
the tank adapter. Seal
threads liquid tight with
appropriate sealant.
(Figure 1)
Materials:
 1-1/4” pipe cut to a length that will extend to within 3” of the bottom of the tank
when screwed into the tank adapter with the tank adapter screwed into the tank
flange (see SKID TANK INSTALLATION diagram).
 Threaded pipe joint sealant appropriate for application.
Installation Procedure:
Typical Skid Tank Installation
Figure 1
Assembly View
Pump
Gasket
Screen
Tank Adapter
Suction Tube
(1-1/4” pipe)

6
Electrical Wiring
Wiring Procedure
2. Screw the inlet flange (with
suction pipe) into the tank
flange; seal threads liquid
tight with appropriate thread
sealant (Figure 2).
Typical Skid Tank Installation (cont’d)
Figure 2
3.Mount the pump on the
adapter; making sure
the seal and screen are
installed as shown.
(Figure 3).
Figure 3
CAUTION! The FR3200 series pump is designed to operate on 12 VDC. Use
the supplied battery cable to supply power to the pump from a 12 VDC battery.
A 50 amp fuse should be installed on the battery cable (see wiring diagram page
9) to protect the wire in case of electrical short.
CAUTION! Voltage drop across a wire varies depending on the distance from
the battery to the pump. If the distance is greater than 20’, refer to the National
Electrical Code (NEC) or local codes to ensure the wire is of the correct size
being used for this application.

7
1. Remove pump’s electrical junction box cover and straighten the 2 wires to make
the stripped wire ends accessible outside of the junction box.
2. Screw furnished cable connector into NPT conduit opening in pump junction box.
3. Strip 6 inches of the outer covering from one end of the furnished electrical cable
being careful not to damage the black and red wire insulation.
4. Loosen cable connector nut and pass the stripped end of the furnished cable
through the cable connector. Tighten the cable connector nut.
5. Strip ½ inch of the installation from the ends of the red and black cable wires.
Using the furnished wire nuts, connect these wires to the pump wires matching the
colors. Be sure no bare wire is exposed.
6. Fold wires into junction box and replace cover making sure the gasket is in place.
Make sure all screws are seated so there is no space between the cover and the
junction box.
Wiring To A Vehicle Electrical System (see Wiring Diagram, Page 9)
1. Pass the electrical wires to the source of the vehicle power system, supporting the
wires as necessary and protecting it from sharp edges, heat, and anything that
could damage the wires.
2. To determine if the vehicle electrical system is negative (-) or positive (+) ground,
check the battery marking of the terminal that is wired to the vehicle frame or
motor block. The red wire from the pump will connect to positive battery post and
the black wire from the pump will connect to negative battery post.
3. Attach one end of the fuse holder to the end of the ungrounded pump wire. Make a
solid electrical connection with the other end of the fuse holder to the ungrounded
side of the battery. Make a solid electrical connection to the grounded side of the
battery with the remaining pump wire. The battery terminal or the end of the
battery cable is recommended.
4. Check all connections to make sure they are connected per instructions and all
electrical codes. Install the 50 amp fuse in the fuse holder. The installation is now
complete.
Instructions Before Proceeding With DC Wiring
The pump needs to be electrically bonded to supply tank or vehicle frame. To electrically
bond pump, remove green bonding screw located next to junction box cover. Insert this
screw through eyelet of furnished green bonding wire assembly and refasten it securely
to the pump. The other end of the wire is to be stripped of insulation and the bare wire
securely bonded to the vehicle / trailer frame or skid tank.
WARNING! Do not connect the positive or negative power to the green screw or
wire as this could cause a fire.
Wiring Instructions (see Figure 4, Page 8)
WARNING! Do not attempt to power the pump from vehicle wiring smaller than
10 gage such as the cigarette lighter wire because these thin wires could
overheat and cause a fire.

8
DC Wiring (cont’d)
Figure 4
Wirein
Junction Box
For Skid Mounted Tanks
1. Pass the electrical wires to the power source, supporting the wires as necessary and
protecting them from sharp edges, heat and anything that could damage the wires.
2. Attach one end of the fuse holder to the red pump wire. Make a solid electrical
connection to the positive terminal of the power source with the other end of the
fuse holder. Make a solid connection with the black pump wire to the negative
terminal of the power source.
3. Check all connections to make sure they are connected per instructions and all
electrical codes. Install the 50 amp fuse in the fuse holder. The installation is now
complete.

9
Wiring Diagram
50 amp fuse located outside of hazardous area. See installation guidelines for size.
50 amp fuse located outside of hazardous area. See installation guidelines for size.

10
Operating Instructions
1. If so equipped, reset Meter to “0” (do not
reset while in use as this can cause
damage to the meter).
2. Remove dispensing nozzle from nozzle
boot.
3. Move the switch lever to the “ON”
position to power the pump (figure 5).
4. Insert the dispensing nozzle into the
container to be filled.
5. Operate the nozzle to dispense fluid;
release nozzle when the desired amount
of fluid has been dispensed. Figure 5
“ON” position
Figure 6
“OFF” position
CAUTION! Always keep the nozzle in contact with the container being filled
during the filling process to minimize the possibility of static electricity build up.
6. Move switch lever to the “OFF”
position (Figure 6) to turn off the
pump.
7. Remove the dispensing nozzle
from the container being filled
and store it in the nozzle boot.
Pad Locking
Your Fill-Rite pump nozzle can be
pad locked to the pump for added
security. With the pump turned off,
and the nozzle in the stored
position, a pad lock can be
inserted through the locking link
and the nozzle handle opening.
This configuration prevents the
nozzle from being removed from
the nozzle cover.
The locking link is located on the
nozzle side of the pump, and can
be pivoted into position to work
with a variety of nozzles (Figure 7).
Use the appropriate position and
hole to lock your nozzle securely
to your FR3200 series pump.
Figure 7
Locking Link

11
Trouble Shooting
The following Trouble Shooting guide is provided to offer basic diagnostic assistance in
the event you encounter abnormal service from your Tuthill product.
If you have questions regarding installing, operating, or servicing your product, please feel
free to contact our Customer Service Department at 1-800-634-2695 (M-F 8 AM–5 PM
ET). You can also reach us on the World Wide Web at “www.fillrite.com”.
WARNING! DO NOT open or attempt to repair the motor on your Tuthill pump.
Return it to the place of purchase for service. Opening the motor case can
compromise the integrity of the Explosion Proof construction and will void any
existing warranty and certification (UL listing).
WARNING! Be certain all power to the pump is disconnected prior to
performing any service or maintenance.
Symptom Cause Cure
Pump won't
prime.
1. Suction line problem. Check for leaks in suction line
2. Bypass valve open. Remove and inspect valve; must
move freely & be free of debris.
3. Vanes sticking. Check vanes and slots for nicks,
burrs and wear.*
5. Excessive rotor or vane
wear.
Inspect rotor & vanes for excessive
wear or damage; replace if
necessary.*
6. Outlet blocked. Check pump outlet, hose, nozzle &
filter for blockage.
7. Vapor Lock Reduce vertical and horizontal
distance from pump to liquid;
remove automatic nozzle.
Low capacity.
1. Excessive dirt in screen. Remove and clean screen.
2. Suction line problem. Check suction line for leaks or
restrictions; it may be too small,
too long or not airtight.
3. Bypass valve sticking. Remove and inspect valve; must
move freely & be free of debris.
4. Vanes sticking. Check vanes and slots for wear.
5. Excessive rotor or vane
wear.
Inspect rotor & vanes for excessive
wear or damage; replace if
necessary.*
6. Hose or nozzle damage. Replace hose or nozzle.
7. Plugged filter. Replace filter.
8. Low fluid level. Fill tank.
Pump runs
slowly.
1. Incorrect voltage. Check incoming line voltage while
pump is running.
2. Vanes sticking. Inspect vanes and slots for nicks,
burrs and wear.*
3. Wiring problem. Check for loose connections.
4. Motor problem. Return to place of purchase.
See page 12 for explanation of Bold text and *items.

12
Trouble Shooting (cont’d)
Motor stalls /
Fuse blows or
circuit breaker
trips repeatedly.
1. Bypass valve sticking. Remove and inspect valve; must
move freely & be free of debris.
2. Low voltage. Check incoming line voltage while
pump is running.
3. Excessive rotor or vane
wear. Check rotor & vanes for excessive
wear or damage.*
4. Debris in pump cavity. Clean debris from pump cavity.
Motor
overheats.
1. Pumping high viscosity
fluids.
These fluids can only be pumped
for short periods of time (less than
30 minutes duty cycle).
2. Clogged screen. Remove and clean screen.
3. Restricted suction pipe. Remove and clean pipe.
4. Motor failure. Return to place of purchase.
5. Pump rotor lock-up. Clean and check pump rotor and
vanes.
Motor
Inoperative.
1.No power Check incoming power.
2. Switch failure. Replace switch (KIT320SW).
3. Motor failure. Return to place of purchase.
4. Thermal protector
failure. Return to place of purchase.
5. Incorrect/loose wiring. Check wiring.
Fluid leakage.
1. Bad o-ring gasket. Check all o-ring gaskets.
2. Dirty shaft seal. Clean seal & seal cavity.
3. Bad shaft seal. Replace seal.
4. Incompatible fluid. Refer wetted parts list to fluid
manufacturer.
5. Loose fasteners.Tighten fasteners.
Pump hums but
will not operate. 1. Motor failure. Return to place of purchase.
2. Broken key. Remove all debris & replace key.
Bold text indicates repairs that are not serviceable by the owner; pump must be returned to the point of purchase for
repairs.
* Repairs marked with an asterisk (*) will require Repair Kit KIT320RG This kit includes a replacement rotor and new
vanes, as well as a number of other important seals and components to complete the repair. Details of this kit are on
page 14.
IMPORTANT! Removal of the bypass
valve in the FR3200 series pump requires
special attention; please adhere to the
replacement procedure in the kit
instructions to minimize the possibility of
damaging the pump housing during the
removal and reinstallation process. Kit
instructions are available at
www.fillrite.com
Servicing the Bypass Valve
WARNING! Disconnect electrical power
and relieve any pressure in the lines prior
to servicing this pump! Failure to do so
can result in damage to the equipment
and personal injury or death!

13
Motor
Power -AC 115, 230, 115/230 N/A
HZ 50, 60, 50/60 N/A
Power - DC 12, 24, 12/24 12 VOLT
HP (horsepower) rating 1/2 HP
Power cord length 20’
Power cord gauge 10 AWG
Power cord DC battery connectors N/A
Amps (FLA) 45 A
RPM 3600
Duty cycle 30 min.
Thermal protection switch Yes
Circuit protection fuse Yes (Circuit Breaker)
Certification UL/cUL Motor
Pump
Type- rotary, diaphragm, gear, vane Rotary Vane
GPM in supplied configuration Up to 28
GPM open flow - no hose or nozzle Up to 28.6
By-pass pressure rating (psi) - Max 22 psi
Dry vac (in Hg) 12
Head- Max 50.8
Anti-siphon valve None
Inlet - Size / Thread 1-¼”
Outlet – Size / Thread 1” NPT
Mount 2” Bung (NPT)
Materials of construction -pump housing Cast Iron
Materials of construction- wetted material BUNA-N
Rotor materials of construction Powdered Iron
Rotor vane material of construction Acetal
Compatible fluids Diesel, gasoline, BioDiesel up to B20,
E15, Kerosene
Warranty (yr) 2 Years
Strainer Mesh Size 20 x 20
Technical Information

14
Kit Number Description
KIT320RK Overhaul Kit
KIT320RG Rotor & Vane Kit
KIT320SL Seal Kit
KIT320BV By-Pass Service Kit
Parts
Rotor, rotor cover, vanes, O-ring seal, shaft
seal kit, bypass valve, inlet seal & screen,
rotor key, attaching hardware
Rotor cover, rotor, vanes, rotor key, O-ring
seal, attaching hardware
O-ring, shaft seals, retainer clip
Inlet gasket, screen, bypass valve, valve
spring, valve retainer
KIT120NB Nozzle Boot Kit Nozzle boot, attaching hardware
KIT320SK External Seal Kit O-ring seal, inlet gasket, electrical cover
seals
KIT320BG Inlet Flange Kit Inlet flange (bung), attaching hardware, inlet
seal, screen
KIT320SW Switch / Breaker Kit Breaker / switch assembly, switch mounting
bracket, attaching hardware, cover gasket
KIT320MK Motor Kit Complete motor assembly
Kits and Parts

15
Safety Testing Approvals
The Fill-Rite line of pumps have been safety tested for compliance to the standards set
forth by Underwriters Laboratories.
Motor Tag Information
The Motor Tag on your FR3200 series pump contains important technical and
performance information. Be certain this label remains affixed to the pump at all times.
Accessory Description
N100DAU13 1” Ultra High Flow Manual Nozzle
FRHMN100S 1” Manual Nozzle
900D 900D Digital Meter
NEW 900DP Digital Meter with Pulser (Coming Soon)
FRH10020 20’ x 1” Static Discharge Hose
FRH10012 12’ x 1” Static Discharge Hose
NEW 1” multi plane swivel (Coming Soon)
Accessories
WW / YY
Date stamp location

16DC000834-000 Rev 0
Visit us on the web at:
www.fillrite.com
Learn more about Tuthill Corporation and our family of high quality, value minded
products at:
www.tuthill.com
8825 Aviation Drive
Ft. Wayne, IN 46809
1-800-634-2695

1
Manual de instalación, operación y seguridad del propietario
Bomba de transferencia de combustible CC
con flujo alto de la serie 3200
Modelos FR3210B, FR3204
Tuthill Transfer Systems 8825 Aviation Drive Ft. Wayne, IN 46809 [phone] www.tuthill.com

1
Manuel d’installation, d’utilisation et de sécurité
Pompe CC de transfert de carburant à haut
débit de série 3200
Modèles FR3210B, FR3204
Tuthill Transfer Systems 8825 Aviation Drive Ft. Wayne, IN 46809 [phone] www.tuthill.com

1
Eigentümer-, Einbau-, Betriebs- und Sicherheitsanleitung
DC-Kraftstofftransferpumpe mit hohem
Durchfluss der 3200 Serie
Modelle FR3210B, FR3204
Tuthill Transfer Systems 8825 Aviation Drive Ft. Wayne, IN 46809 [phone] www.tuthill.com

2
Inhalt
Inhalt .................................................................................................................................. 2
Vielen Dank!....................................................................................................................... 2
Zu diesem Handbuch.......................................................................................................... 2
Sicherheitsinformationen .................................................................................................... 3
Einbau................................................................................................................................ 3
Verkabelung ....................................................................................................................... 6
Schaltplan........................................................................................................................... 9
Betriebsanweisungen ....................................................................................................... 10
Sicherung mit Vorhängeschloss........................................................................................ 10
Fehlersuche...................................................................................................................... 11
Wartung des Bypassventils............................................................................................... 12
Technische Daten............................................................................................................. 13
Flüssigkeitsverträglichkeit................................................................................................. 13
Sätze und Ersatzteile........................................................................................................ 14
Zubehör............................................................................................................................ 15
Sicherheitszulassungen und Zertifizierungen.................................................................... 15
Angaben am Motortypenschild .................…………………………………………………..…15
Vielen Dank!
Vielen Dank für den Kauf einer Pumpe der FR3200 Serie! Das Fill-Rite Produkt wird
durch mehr als 80 Jahre Erfahrung bei der Pumpenherstellung gestützt und bietet Ihnen
den besten Wert, überlegene Leistung, ein benutzerfreundliches Design, lange
Lebensdauer und solide, einfache Technik. Erfahrung, die Ihnen Sorgenfreiheit bietet.
Ausgezeichnet im Einsatz. Ausgezeichnet im Leben.
Zu diesem Handbuch
Vom anfänglichen Konzept bis zur endgültigen Produktion ist die Fill-Rite Pumpe für
problemlosen Betrieb auf Jahre hinaus ausgelegt. Um diese Funktionsweise zu
gewährleisten, müssen Sie dieses gesamte Handbuch durchlesen, bevor der Einbau
oder Betrieb der neuen Pumpe versucht wird. Machen Sie sich mit den Begriffen und
Diagrammen vertraut und achten Sie genau auf die hervorgehobenen Bereiche mit den
folgenden Bezeichnungen:
WARNUNG! Hebt einen Bereich hervor, in dem bei Nichtbefolgung der Anweisungen
schwere oder tödliche Verletzungen auftreten können. Es können auch mechanische
Schäden entstehen.
WICHTIG! Diese Textfelder enthalten Informationen, die auf Zeitersparnisse hinweisen,
für den korrekten Betrieb wichtig sind oder einen Arbeitsschritt weiter erläutern.
VORSICHT! Bei Nichtbeachtung eines „Vorsichtshinweises“ besteht die Gefahr von
Maschinenschäden.
Bei Tuthill ist Ihre Zufriedenheit mit unseren Produkten von höchster Bedeutung. Bei
Fragen oder wenn Sie Hilfe mit dem Produkt benötigen, kontaktieren Sie uns bitte unter
der Rufnummer ([phone] (Mo-Fr 8.00-17.00 Uhr EST).
