FINNSUB Short 750 User manual

////////////////////////////////////////////////////////////
Manufacturer:

FINNSUBs.r.o.
Rakovecka35,63500Brno
GSM:+420606603999
www.finnsub.com
////////////////////////////////////////////////////////////
////////////////////////////////////////////////////////////
User’smanualfordivinglights

FINNLIGHT
Short750
Short750Rings
Long750
Long750BlackRing
////////////////////////////////////////////////////////////


1.INTRODUCTION

CongratulationstoyourpurchaseofFINNLIGHTlamp.Itwillguideyourpathsto
adventure.TherearetwoversionsofFINNLIGHT750andtwoversionsofFINN
LIGHT750Ring/slamps.ThesmalleroneisSHORTandtheonewithacanisteris
LONG.Thetypeislabeledontheboxofyourlamp.


2.PACKAGEINCLUDES

ModelLONG750/LONG750BlackRing:
‐headwiththreadcover
‐canisterwithbatteriesandcable
‐batterycharger
‐Goodmanhandle/optionalSoftHandle
‐canisterholder
‐elasticcord(notincludedinSoftHandleversion)
‐allenkey
‐servicelubricant
‐user’smanual


ModelSHORT750/SHORT750Rings:
‐headwiththreadcover
‐bodywithbatteries
‐batterycharger
‐Goodmanhandle/optionalSoftHandle
‐elasticcord(notincludedinSoftHandleversion)
‐allenkey(notincludedinSoftHandleversion)
‐servicelubricant
‐user’smanual

3.BEFORETHEFIRSTUSE
Toachieveanidealinitialcapacitysetupofthelight,theaccumulatorsarestored
chargedataprox.50%oftheircapacity.Beforethefirstuseitisimportantto
chargethebatterytofullcapacity.



Serialnumberexplanation:
S=modelSHORT
L=canistermodelLONG
   
S1007151R
serialnumbermodel–Ring/s


Explanationofthetypeindication:
S=modelSHORT
L=canistermodelLONG    
L750
luminousflux~750lumen



4.CHARGING


‐ Unscrewtheheadfromthebody‐turn it clockwise (looking same way the light
shines).
‐Plugthecharger’sjackinthesocketinsidethelamp’sbody.
‐ Plugthechargerinthewallsocket.Thecharger’sLEDlightisred,whilethe
batteryisbeingcharged.OnceLEDturnsgreentheaccumulatorischargedon
approx.80%.Youcankeepitonthechargerlongertoreachthemaximum
capacity).Whenthelightiscompletelydischargedthechargingcyclelasts4
hoursinSHORTversion,8hoursinLONGversionand10hoursinSTRONG
version).
‐Unplugthechargerfromthewallandafterthatjackfromthelamp’sbody.Save
theenergy.

Alwaysuseonlytheoriginalbatterychargerthatisincludedinthepackage!

Importantnotice
Li‐ionbatteriesdon’thaveamemoryeffect.That’soneofthebasic
characteristics.Werecommendtochargetheaccumulatorafteranyusage.

!!Youhavetoavoidanysituationwhenyoukeepfullydischargedaccumulator
inafrostyenvironment.Forexample–Youputadischargedaccumulatorina
trunkofacarafterdiveandkeepitthereforthewholenight.Itwilllead
almostabsolutelytoirreversibledamageoftheaccumulator.Thetimeof
performanceofthelightmightbesignificantlyreducedbythisonlyonestep.
Thebadmaintenanceisnotcoveredbythewarrantyandtheclaimsof
damagedaccumulatorbecauseofthebadmaintenancewillberefused!!


5.MANUALFORFUNCTIONSANDUSAGE

−toswitchonthelightyouhavetoscrewtheheadon‐turnitcounter‐
clockwise(lookingsamewaythelightshines)untilthelightison.
−toswitchoffthelight,unscrewthehead‐turnitclockwise(looking
samewaythelightshines).Whenyou’reswitchingthelightoffunder
thewater,stopturningtheheadoncethelightisoff.WARNING!
Unscrewingtheheadcompletelyleadstofloodinganddamagingthe
lamp.Thereforewerecommendthatyoukeepthelightonuntil
surfaced.
−aftereachuseinsaltwateritisnecessarytowashthelampwithfresh
waterthoroughly.

Useinwater:
!!Warning‐neverturntheheadofthelampclockwise(lookingsamewaythe
lightshines).Unscrewingtheheadcompletelyleadstofloodinganddamaging
thelamp!Switchthemodesofthelamponlybyturningtheringonthehead!!

6.MAINTENANCE,STORAGE,TRANSPORTANDMANIPULATION
BEFORE/AFTERDIVE

Threadsando‐ringsarenecessarytobecheckedandlubricatedafterevery
dismountingandeveryrecharging.Ifthreadsoro‐ringsaredirty,theyhavetobe
cleanedandthenlubricated.
!Notice:Ifthreadsando‐ringsarenotlubricated,youriskwaterpenetration
anditwouldbedifficulttoswitchon/offthelightunderhydrostaticpressure!
!!Theclaimsofthefloodedlightbecauseofthebadmaintenancearenot
coveredbythewarranty!!

!!Removetheheadfromthebody/canisterfortransport!!
Thereistheriskofaccidentalswitchon.!Preventtheriskoffire!

Removetheheadfromthebody/canisterforthestorage!
!!Screwedheadreadytouseisinstandbymodeandtakesthesmallpower
fromtheaccumulator.Ifyoustorethelightcompletedtheaccumulatorloses
itscapacityandcanbedestroyed!!

Incaseoflongerstoragethelighthastobechargedtothefullcapacity.Don’t
storethelightdischarged!Ifstoredlongerthan1monththecapacitycould
significantlydecreaseortheaccumulatorcouldbedestroyed.Every3monthsit
isnecessarytodischargeandthenfullychargethelight!

Optimalstoragetemperatureis15‐18°C(59–65°F).Highertemperatures
accelerateself‐dischargeandearlierrechargeisneeded.


Aftereachuseinsaltwateritisnecessarytowashthelightwiththefresh
water.








7.TECHNICALSPECIFICATION
Luminousflux:750lumens
Temperatureoflight:coldwhite,5000–10000K
Cellstype:Lithium‐Ion
Inputvoltage:16,8V
Outputcurrent:700mA
Run‐times:Short:3hrs
Long:6hrs

Bothmodelsareguaranteedforusageupto‐200msw(655ft).


8.DISPOSALOFAGEDLAMPS

Disposefunctionlessandagedlampinaproperway.Bearinmindthatitisan
electronicwaste.Donotthrowitintoaregulartrash.Youcanreturnthe
appliancetoyourdealer.


9.SAFETYINSTRUCTIONS

!!Storeandtransportbothpartsofthelightseparated–unscrewthehead
fromthebodyofthelight.Otherwisethelightcouldbeaccedentallyswitched
oninthebagwhichcouldcausethefire!!

!!Don’tputswitchedonlightontheflammablesurfaces.Thereistheriskof
thefirepožáru!!

WARNING!Thelightwhichsiswitchedoffleftonthesunshinecouldreachvery
hightemperatures(over60°C).Thelightcanbedestroyedortheheatsurfaceof
thelightcouldburntheuser.

ThereforeNEVERleavethelightonthedirectsunshineiftheweather
temperatureishigh(forexampleinthecar).Thereistheriskofthedamageof
thelight,burnoftheuserorfire!
Donotputtheactivatedlamponflamablesurfacstopreventriskoffire.
