Firefly X LITE FPV User manual

1
FIREFLY X LITE FPV CAM
4K 60FPS
Only 34g weight
Ambarella H22S85 chipset
Gyro 4.0 Image Stabilization
WiFi + BT4.1 Remote control
SONY IMX377 12 Mega WDR CMOS

2
Features ：
1. POWER BOTTON；
2. 2p power port(5V IN)；
3. Cooling hole；
4. Microphone hole；
5. TF card slot；
Performance and Specifications:
resolution
1080P60FPS/4K60FPS/2.7K60FPS
/2.5K60FPS…
RC and AV OUT
YES
Kind of MicroSD card
supported
U3(Note:Low speed sd card will
cause unstable)
Maximum size of MicroSD
card supported
512G
Specifications
Camera size
61×38×26 MM
Weight
34G
Compressed format
H.264
Video format
*.MP4
Optical Parameter-
Wide angle version
Diaphragm
F=2.8 ，7G1IR LENS
Angle
Diagonal 150 degrees
Electric Parameter
Working Voltage
5V
Power supply
1A
6. Type C USB port；
7. Video indicator（flash when recording）；
8. record button；
9. WiFi indicator（Light on when WiFi is on）;
10. Lens；

3
Button Functions
Name
Functions
Descriptions
Power Button
Turn on/off camera and
wifi
Press once, camera ON; Press and hold for 3
seconds to flip the image
Record Button
start/stop recording
Long press to switch four resolutions
Operating instructions:
Use the 5V power supply on the drone to supply power to the camera, then press the
power button to start the machine, and the buzzer will ring once. After power on, the
default resolution of the camera is 1080p60fps (the anti shake effect is the best, and the
image angle is relatively minimum). If you want to switch the resolution, long press the
recording key to switch. The switching sequence is: 1080p60 frame (buzzer rings once) /
4k60 frame (buzzer rings twice) / 2.7k60 frame ultra wide angle (buzzer rings three times )
/ 2.5k60 frame on anti shake (buzzer rings four times). If the camera needs to be flipped
180 degrees for installation, long press the power button for 3 seconds after turning on
the camera, and the camera will turn on the image flipping function. After the camera is
turned on, you can turn on the WiFi function by briefly pressing the power key, and then
connect the WiFi hotspot of the camera with your mobile phone (firefly_x_...) to connect
with Firefly app (the initial password of the app is 12345678). App can set camera time
and parameters, preview and download videos.
Description of buzzer sound:
After power on, if the card is not inserted or full, the camera will beep all the time; If there
is a plug-in card but no video recording, it will beep twice every 4 seconds to prompt the
pilot to record before taking off; A short press of the power key will sound once,
indicating that the WiFi function is on. Press it again, and sound twice, indicating that the
WiFi function is off. Long press the power key for 3 seconds, the buzzer rings three times,
indicating that the image flipping function is on. Long press for 3 seconds, the buzzer
rings four times, indicating that the image flipping function is off.
Three parameter adjustment methods:
1, The camera's own buttons are simple to adjust parameters;
2, Adjusting parameters through lite_config.txt document by computer;
3, Adjusting parameters through Firefly APP.
For more information, please visit the official website：www.Hawkeyefpv.com.cn.
Please download APP from:
Apple Store: Firefly Cameras
Google Play: Hawkeye Firefly

4
How to use power cables？
The power cables has been provided with the hardware function of anti connection. Only
when it is inserted in the right direction, the LED on the board will be on, and the wrong
direction will not burn the machine. Please feel free to use!
Note:
If there is an accidental power failure during the video recording process, the
video file will be damaged. You can re-power on, the damaged file to
automatically repair the damaged file!
