Fireside Outdoor CB001 Reference guide

POP-UP PIT
CUSTOMER MANUAL

ASSEMBLING YOUR POP-UP PIT
Open your Pop-Up Pit frame to its fully seated
position. Pay close attention to which Ember Guard has the badge, this should be set aside until
Step 3. Two Ember Guards should be placed
on the frame parallel from one another. Guide
the upright pole of the frame through the
precut holes in the Ember Guards.
Your Pop-Up Pit frame may fell ‘stiff’ upon
first use, this will subside after your first
fire.
Your Pop-Up Pit will come wrapped with
straps, keep these as they will aid in
storage and packing in the future!
FiresideOutdoor.com

ASSEMBLING YOUR POP-UP PIT
Repeat Step 2 with the remaining two Ember
Guards. Note that the Ember Guard with the
logo badge should be put on in this step.
Holding the Fire Mesh with the folded edges
facing down, each of the four grommets
should be placed over the upright poles of
the frame. Take care to not let any one corner
drop too far down the uprights.
Once the uprights are through the grommets,
slide the Fire Mesh down as one unit until the
Fire Mesh is fully seated on top of the Ember
Guards.
If you are having trouble applying the
Ember Guards or Fire Mesh, WD-40
can be used on the upright poles for
lubrication.
FiresideOutdoor.com

FiresideOutdoor.com
Remove the ashes from your pit. This can
be done by either dumping the pit, using
a shovel, or by removing the Fire Mesh.
To remove the Fire Mesh look for the two
bottom Ember Guards from Step 2 of
the assembly. Simply place your hands in
the middle of each Ember Guard and pull
straight up keeping the Ember Guards
parallel to the ground. This should remove
all four Ember Guards as well as the Fire
Mesh as one unit. The Fire Mesh can then
be funneled, and the ash dumped out
from it.
WARNING:
Ensure your fire is completely extinguished before handling or touching
the Pop-Up Fire Pit!
DISASSEMBLY AND PACKAGING
1

FiresideOutdoor.com
DISASSEMBLY AND PACKAGING
Place the Fire Mesh with the folded side up
on the ground. Place the frame and Ember
Guard construction on top of the Fire Mesh
and roll together tightly. Repeat for Heat
Shield if applicable.
Close the frame of the Pop-Up Pit and use the
Ember Guards to form a box around the frame.
Using the included straps, strap the top
and bottom of the packed Pop-Up Pit to
ensure the Fire Mesh does not uncoil. Place
the Pop-Up Pit back inside its carrying bag,
with the four poles from the frame towards
the opening of the bag.
4
3
2

FiresideOutdoor.com
Unroll your heat shield Place the heat shield reflective/
shiny side up.
Wrap the high temperature velcro
straps twice around the set screw
3 1/2-inches down from the Ember
Guards in the frame poles.
Push down the center of the heat
shield and roll the edges to form a
bowl shape.
HEAT SHIELD SET UP
There are more the 10 billion
outdoor outings every year in
the US alone. This can take a
huge toll on our environment,
be sure to pack out what you
pack in and always practice
‘leave no trace’ fires. 4
3
2
1

FiresideOutdoor.com
4
3
2
1
Tighten risers onto the rail,
do not over tighten.
Slide risers onto both sides of
the rails.
GRILL GRATE SETUP
Slide rails and risers onto the mounting
points in each corner of our Pop-Up Fire Pit. Unfold and place grill grates on
top of the rails.

Fire Color changers
should NEVER be
used on the Fire Mesh,
these will contaminate
and cause irreparable
damage to the Fire
Mesh.
When ever possible,
avoid the use of any
flammable liquids as
they may pass through
the Fire Mesh and cause
a fire hazard.
FIRE MESH
HEAT SHIELD
Before packing up and storing your
Pop-Up Fire Pit, you should ensure
that all the ash is removed from the
Fire Mesh. This should be done by
rinsing the mesh after each use. Any
excess ash left on the Fire Mesh may
degrade the steel over a long period
of time.
Note: Discoloration is to be expected
after use, this is not removable.
Ensure the heat shield is level with
the ‘X’ of the frame cross members.
Placing the heat shield too close to
the Fire Mesh will cause damage.
Note: The heat shield is fire resistant
and not fire proof.
FiresideOutdoor.com
Proper care is required to keep your Pop-Up Fire Pit performing
optionally. Be sure to read all of these instructions carefully to
ensure years of use out of your Pop-Up Fire Pit.
CARE AND MAINTENANCE

GRILL GRATE CARRYIING BAG
GRILLING GRATES
EMBER GUARDS
POP-UP FIRE PIT
The vinyl carrying case can be rinsed
with water and a light detergent to
remove any grease or dirt that may have
accumulated through use.
Stainless steel grill grates tolerate
intense heat and are rust resistant. It
typically only takes a quick brush to
keep them clean.
Any soot build up can be removed by
rising with a light detergent. A nylon
brush may be used.
Note: Fires should always be kept at
least 1” away from your Ember Guards
to ensure proper airflow.
No additional care needed. WD-40 can
be applied to contact pints on the frame
to ensure smooth opening and closing.
FiresideOutdoor.com

FiresideOutdoor.com
