Introduction
Thank you for your purchase of a Motic stereomicroscope. Motic stereomicroscopes are precision
instruments, subjected to meticulous examination to reach you in perfect condition. Their design combines
easy management and optimum functioning with minimum maintenance.
The information contained in this manual is likely to go beyond what the average user needs to know to use
the stereomicroscope, however, it is provided to answer any queries that may arise.
Stereomicroscopes are used to study three dimensional objects, examine small parts, or dissect biological
specimens. They also permit the observation of slide specimens.
These instructions should be read carefully before operating the microscope. They will permit you to use
your new stereomicroscope to its fullest capabilities. Terminology used to describe components and controls
can be found in the diagram on page 2.
These instructions are based on the assembly and use of the SMZ-140-N2GG model with additional notes
applying specifically for the other models in the series.
Unpacking
All components of the stereomicroscope have been carefully packed to make sure they reach you in perfect
condition. We recommend that you do not discard any packing containers in case you need to return the
microscope or store it for long periods of time; or should it become necessary to transport it to a technical
service for any repair, or maintenance procedure.
The box should contain the following components:
•SMZ-140-N2GG (Binocular): An illuminated base with a pole for a moveable head, also illuminated.
A black and white opaque stage, a binocular head with an eyepiece, eyepiece protectors, a frosted
glass stage, a blue filter, a protective cover and a 1,5mm hexagonal key.
•SMZ-143-N2GG (Trinocular): An illuminated base with a pole for a moveable head, also illuminated.
A black and white opaque stage, a trinocular head with an eyepiece, an adapter for a photographic
camera, and one for a CCD camera, eyepiece protectors, a frosted glass stage, a blue filter, a
protective cover and a 1,5mm hexagonal key.
Remove and handle all components of the microscope with extreme care.
Avoid touching the lenses of the optical elements and keep clear of contact with dust, water or other
contaminating agents, as they could stain, or damage the lens surface and affect the quality of the
image.
-3-
