Fitnest Sierra Starter Owner's manual

Fitnest Sierra Starter
Assembly instructions & User manual

101/
SAFETY INSTRUCTIONS
1. Keep all electrical components away from liquids.
2. Keep children away from electric height adjustable desks, control units and
3. People who do not have the knowledge of the product or have reduced
4. Before trouble shooting
• Stop the desk legs.
• Switch off the power supply and pull out the mains plug.
• Remove everything from the desk top which might contribute weight.
5. Before start-up:
• Make sure that the power supply is between 110v and 240v before plugging the
• The individual parts must be connected before the control box is connected to
6. During operation:
• If the control box makes unusual noises or smells, switch off the main power
• Take care that the cables are not damaged.
• Unplug the main power cable on mobile equipment before it is moved.
memory controller. There is a risk of injury and electric shock.
physical or mental abilities can’t use the product.Unless they are under
surveillance or they have been thoroughly instructed in the use of the apparatus.
control box into it.
the main power supply.
immediately.
There is a risk of injury and electric shock.

10
2/
×5
HI
× 1 ×1
J
M
A
×11
B
×9
C
×3 ×4
0
1
x
6
M
6
1
x
6
M
L
×7
0
2
x
6
M
EF
×8
G
ST4.8x19
D
×3
ST3.5x19
K
×4
0
1
x
6
M
EXPLODED DRAWING:
×1
×2
PARTS:
Control box Memory controller
×3

103/
6
1
x
6
M
G
M5
B
×8
Installation step by step
1. Assembly left/right legs
Please do not fully tighten screws
until all screws are in place.
NOTE

A
×8
0
1
x
6
M
4/10
G
M4
2.Assembly retractable tube

5/10
K
×4
0
1
x
6
M
G
M 4
4. Assembly right/left top brackets
3. Assembly the Wire rod.

6/10
02x6M
G
M4
L
×6
5. Attach the table top to the frame.
Make sure that the substrate is smooth and
soft base to keep table top no scratches.

7/10
C
×2
ST4.8x19
D
×2
ST3.5x19
7. Ready for use.
×2
6. Nail the system controller and handset.
Then, connect the power cable and handset.

Key Board Use Instructions
5-Key Touch Screen Handset Manual
Basic Operations：
1.Up and Down
8/10
Height Dispaly
Press“ ∧”key，desktop rises ，release the key the desktop will stop
moving；Press“ ∨”key, the desktop will fall down，release the key,
the desktop will stop moving.
2.Store a position
Adjust your desired height, press the M key for around 3 seconds, till the
screen flashes,then press any key of “ ”，the scree will stop flashing，
system will make”beep beep” and display the current height on screen，the
height will be saved. It is recalled even if the power is once off.
3. Reset procedure
It will need to reset operation when the system occurs abnormal status.
Procedures are as below：Press “ ∨”key around 5 seconds, the reset starts
until legs fall back to lowest height then rise back a little, meanwhile the
system will make two sound of beep, the screen shows “ RES”, reset is
successful. (During this process, if you release “∨“ key, re-press it to start
the reset operation again.)
4. Timer
The system is designed to inform users to stand up after a set period of time.
4.1.Enter timer setting：Press “ ”+“ ”keys around 5 seconds, the screen will
display ”ON” ,after the screen flashes 3 seconds to display default 60 minutes,
numbers will flash continuously, press”∧” or “∨” to adjust the number
(Minimum 10 minutes to Maximum 120 minutes) to your desired time, then,
press “M” key to save setting, the system will make two “beep” and display the
current height to finish this setting. (Default timer setting is 60minutes)
4.2. Quit Timer setting:Press“ ” +“ ”Key around 5seconds，The screen will
display ”OFF”，then, press “M”key to save setting, the system will make two
“beep” and display the current height to finish this setting.

Key Board Use Instructions
5．Anti-collision Strength rating setting .
9/ 10
4.3. variable reminder ：Press“M+ ”key around 5 seconds, the
screen will display “SET” flashing 3 seconds, then display”1”
press ”∧” or “∨” to set reminder quantity( variable from1-2-3) .
For example, default timer 60minutes, adjust to 3, the, every 60minutes
will reminder one time, Screen will display 60 flashing continuously,
system will make “beep” up to 10 seconds, in such a way, the end
user can press any key to cancel this reminder. Then, after second
60 minutes, the system will reminder 10 seconds “beep”, like this
3 times, the system will automatically cancel the timer reminder
function. (system default 60 minutes and only reminder one time).
The system has anti-collision function with 4 strength rating
of L1,L2, L3, L4 (L1-off, L2-Lightest , L3-Middle, L4-Strongest) .
Press “M+ ” keys around 5 seconds, the screen will
display “3” and flash continuously, Press ” ∧” and ” ∨”
key to get your desired strength rating, then press “M” key
to save , the system will make two “beep” sounds and show
current height to finish this setting.
6．Switch the unit between CM and Inch
Press “M+ ” keys around 5 seconds, the screen will
display“C-E” and flash continuously， If press “∧”
key the screen will display “ C” to be set as MM; if Press “∨”
key the screen will display “ E” to be set as INCH. Press M key
to save setting, the system will make two “beep” and display
current height to finish this setting.
∧

10/10
