Teknion Leverage Operating and maintenance instructions

Overhead Upmount (KSU) Part and Product Identification
A - Overhead Body with Overhead
Upmount Back Panel Assembly
(KSF) x1
Section:
Description: Page No:
Date:
Rev. No: 1
OVERHEAD UPMOUNT INSTALLATION
MOUNTED STORAGE AND ACCESSORIES
May 2020 1 of 3
TLE_406
leverage Installation Guides
B - Overhead Upmount Bracket RH/LH
(A15-8024R/L) x1
C - Bracket Retainer Clip
(B07-0147) x2
D - Machine Screws 1/4-20 x 1"
Pax, Quadrex, Black
(E0-0081) x4

STEP 2: Mount the Screen onto one of the Slots in Table Rail as illustrated.STEP 1: Assemble Nut and Bolt arrangement as illustrated.
NOTE: Make sure the orientation of T-Nut is correct.
Section:
Description: Page No:
Date:
ASSEMBLE NUT AND BOLT ARRANGEMENT MOUNT THE SCREEN
TLE_406
2 of 3
May 2020
OVERHEAD UPMOUNT INSTALLATION
MOUNTED STORAGE AND ACCESSORIES
leverage Installation Guides
B
B
C
A
B
C
C
B

Section:
Description: Page No:
Date:
SECURE THE SCREEN
May 2020 3 of 3
TLE_406
OVERHEAD UPMOUNT INSTALLATION
MOUNTED STORAGE AND ACCESSORIES
leverage Installation Guides
STEP 3: Secure the Screen by rotating the T-Nuts from Horizontal position to Vertical position by using Allen Key as shown.
D
