FläktGroup EQQA Technical specifications

EQQA Once-trough water
EQQA for circulated water
EQQZ-01 Humidifier cassette
EQQA Once-through water…………………………………2-5
EQQA for circulated water………………………………..6-15
EQQZ-01 Humidifier cassette
Ordering code……………………………………………………….16
HUMIDIFIER
EQQA, EQQZ
INSTALLATION AND MAINTENANCE INSTRUCTION
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice

HUMIDIFIER, ONCE-THROUGH WATER
Installation and maintenance instruction
2
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
CONNECTION
The water supply is regulated by a pulse valve and constant flow
valve, pos. 12. Connect the supply pipe, pos. 1, to the inlet pipe
(tab. 1). The supply must have a shut-off valve, pos. 2, and water
filter, pos. 10.
The drain pipe must be fitted with a cleanable water trap, pos. 3,
(EQAZ-08) and should be run, without reduction in diameter, to a
floor gulley.
Water trap EQAZ-08
Shut-off valve, water trap and water filter are not supplied
with EQQA.
CONNECTION
1. Water supply pipe
2. Shut-off valve (not included)
3. Water trap EQAZ-08 (accessory)
4. Drain pipe
5. Humidifier fill
6. Droplet eliminator
7. Spray pipe
8. End plug
9. side wall
10. Water filter, with a max mesh of 500 μm (not included)
11. Flushing hose
12. Pulse valve and constant flow valve
Important!
Use a pipe wrench to stop pipe couplings
rotating when connecting external piping.
Connection number/Diameter
Value
90 %, b = 1 60 %, b = 2 Inlet Outlet
009-045
056, 068
009-054
056, 068 No. 15 1/2” diam 32
072, 079 072, 079 No. 20 3/4” diam 2x32
050, 063 050, 063 No. 20 3/4” diam 2x32
090 090 No. 20 3/4” diam 2x32
Connection data – pulse valves
Size Number of
valves Date
009-090 1 Connection data 100-230 V
Current 0,5 A
Frequency 50-60 Hz
Protection class I I P65
Output 8 watts
Function Normally Closed
Table 1. Connection dimensions
9
8
7
9
5
6
2
10
11
121
4
3
aaa 008-045
054,056,
068
aaa 050,063,072,
079,090
4
5aaa 050, 063, 072,
079, 090
aaa 008-045
054, 056,
068

HUMIDIFIER, ONCE-THROUGH WATER
Installation and maintenance instruction
3
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
PRE-COMMISSIONING ADJUSTMENTS
Check:
A. that the droplet eliminator fills are correctly fitted for direction
of the air flow, see arrow.
B. that there are no water leaks at any of the couplings and
connections.
C. that water is being discharged from all holes in the spray pipe
or pipes. If any holes are clogged, use a needle to unclog them.
If the spray pipe(s) is/are extremely clogged, remove the end
plugs (8), brush inside using a round brush and then flush
them clean.
D. that the pulsing function operates correctly: open for ca 150
seconds and closed for ca 100 seconds.
MAINTENANCE
1. Water supply pipe
2. Shut-off valve (not included)
3. Water trap EQAZ-08 (accessory)
4. Drain pipe
5. Humidifier fill
6. Droplet eliminator
7. Spray pipe
8. End plug
9. side wall
10. Water filter, with a max mesh of 500 μm (not included)
11. Flushing hose
12. Pulse valve and constant flow valve
Check:
A. that the humidifier fills and droplet eliminator are correctly
fitted for the direction of air flow, see arrows.
B. that there are no water leaks at any of the couplings and
connections.
C. that water is being discharged from all holes in the spray pipe
or pipes. If any holes are clogged, use a needle to unclog
them. If the spray pipe(s) is/are extremely clogged, remove
the end plugs (8), brush inside using a round brush and then
flush them clean.
Water flow when the pulse valve is open is:
600 mm wide fill 90 %, 8 l/minute.
600 mm wide fill 60 %, 4 l/minute.
Water consumption according to table 2. If the flow deviates
from this the constant flow valve may be blocked, see instruc-
tions for cleaning constant flow valve, pos. 12.
Table 2. Water consumption, l/min
EQQA 60 % - humidifier water
l/min
90 % - humidifier water
l/min
009 1,5 2,5
011 2 4
014 2 4
018 2,5 5
020 2 4
023 2,5 5
027 2,5 5
032 4 6,5
036 2,5 5
041 4 6,5
045 3 6
047 4 6,5
050 4 6,5
054 4 6,5
056 3 6
063 5 9
068 4 6,5
072 5 10
079 5 9
090 5 10
9
8
7
9
5
6
2
10
11
121
4
3
aaa 008-045
054,056,
068
aaa 050,063,072,
079,090
4
5
SPECIAL CASES
In the event of power loss, e.g. during a holiday or long
weekend break, drain and clean the tray. If the humidifier
is likely to be out of operation for an extended period,
remove the humidifier fills from the humidifier, clean
them and put them somewhere safe.
aaa 008-045,
054, 056,
068
aaa 050, 063, 072,
079, 090

HUMIDIFIER, ONCE-THROUGH WATER
Installation and maintenance instruction
4
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
CLEANING THE HUMIDIFIER FILLS AND DROPLET
ELIMINATOR
A. Turn off the water supply.
B. Open the inspection door.
C. Slide the droplet eliminator and humidifier fills straight out of
the humidifier.
D. The humidifier fills are relatively fragile and should therefore
be handled very carefully. Clean by spraying with clean
water.
E. Check that the holes in the spray pipe are not blocked.
If necessary remove the end plugs from the pipe and clean it
internally.
F. Refit parts in the reverse order.
G. Check the position of the side wall and close the door.
If it is necessary to replace the humidifier block, separate
instructions will be supplied with the new block.
Important!
The innermost fills can be reached by stepping
carefully onto the edge of the tray.
Avoid stepping on the guides or base of the tray.
Humidifier fills
Droplet eliminator
Size 009 011
014
020
018
023
027
036
045
056
032
041,
047
050
054
068
Humidification
rate 90 %
4 6,5 8 10 11
Humidification
rate 60 %
2 3 4 5 6,5
Size 063
072
079
090
072
090
Humidification
rate 90 %
15 17
Humidification
rate 60 %
8 8,5
Outlet connection
Ø 32, out
Water connection,
ext. thread 1/2”
Constant
flow valve
End plug
Constant flow valve,
located inside
Table 3. Water flow through the constant flow valve and
the pulse valve.
CLEANING THE CONSTANT FLOW VALVE
A. Remove the valve.
B. Check that there is no contamination on the rubber
membrane. Clean carefully if needed.
C. Refit the valve with the arrow pointing in the direction of
the water flow, and check the water flow.
Min. water pressure in supply pipe 100 kPa.
Spray pipe

HUMIDIFIER, ONCE-THROUGH WATER
Installation and maintenance instruction
5
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
SERVICE INTERVALS
Component Action Interval, months
Casing (water tray, ends, top,
guide rais)
Drain the water tray. Clean the interior by flushing,
wiping or if necessary brushing.
3
Humidifier fills
Droplet eliminator
Cleaning. 3
Water filter Clean or replace the filter cartridge, if necessary.
(The mesh must not exceed 500 μm).
3
Constant flow valve Check that there is no contamination on the rubber
membrane. Clean carefully if needed.
3
Water flow Clean the spray pipes, if necessary. 3
Water trap Clean and refill. 6
Water quality Water pH should not be lower than 5 or higher than 8.5.
Drinking water is suitable.
12

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
6
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
CONNECT ON TO WATER SYSTEM
The water supply is regulated by a built-in solenoid valve.
Connect the supply pipe to inlet branch. Fit a shut-off valve,
pos. 2, in the water supply pipe.
Table 1. Connection sizes
To avoid clogging, a water filter, pos. 3 (with a max mesh of
500 μm), should be fitted between the shut-off valve and
the humidifier.
Connect the drain pipe, pos. 5, to the humidifier’s drain connec-
tion. This must be fitted with a cleanable water trap, pos. 4, and
must run without any reduction in diameter to a floor gulley. In
the case of model 072-090 two water traps coupled in parallel
should be used.
The shut-off valve, water trap and water filter are not supplied.
CONNECT ON TO THE ELECTRICAL SYSTEM
(Must be carried out by an authorized electrician.)
When wiring is carried out on the installation site the supply
cable must be run via an external high voltage switch to the
control box through the cable gland fitted in the casing. The con-
troller has an internal 2 A fuse. The pump(s) supplied is/are
always wired for 3 x 400 V. The pump motors meet protection
class S 33 (IP44) and insulation class B.
Table 2.
1. Controller box, external
2. Shut-off valve (not included)
3. Water filter, with a max mesh of 500 μm (not included)
4. Water trap EQAZ-08 (accessory)
5. Drain pipe
6. Humidifier fill
7. Droplet eliminator
8. Spray pipes
9. Pump
10. Flow controller
11. Valve with motor actuator
12. Overflow hose
13. Level sensor
14. Solenoid valve
15. Flushing hose
16. End plug
17. Spacer plate
17
3
2
16
15
14
1
9
7
8
10
11
12
13
6
4
4
5
5
Connection number/Diameter
Size Supply connection/
(male threads)
Drain connection
009-068 No. 15, R 1/2” No. 32, R 1 1/4”
female threads
072-090 No. 20, R 3/4” Two Ø 32
Water trap EQAZ-08
EQQA
Size/Humidification
grade
Number of pumps
Output:
0,37 kW
Voltage:
3 x 230/400 V
Current:
1,72/1,00 A
009-068 60 %-90 % 1
072-090 60 %-90 % 1

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
7
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
ITEMS TO CHECK WHEN MAKING ADJUSTMENTS
Water:
Determine the proportion of calcium and bicarbonate in the water,
and its pH level. This information can be obtained from a water
analysis or from the local water company. Enter the values obtai-
ned in chart 1 on page 4 to determine which zone the water can
be classified.
If the water quality is in zone 4 a water softener must be used.
Testing operation of humidifier:
– Turn on the external switch.
– Give the start signal to the humidifier by closing input TF1
(if this signal is interrupted the humidifier will stop and the water
will drain out).
– The tray should only start to fill with water when there is a need
for humidification, i.e. when the RH1 input closes.
Now check:
– that the humidifier starts to fill with water.
– that the pump starts and pumps water (input RH1 must be
closed). If there is no water flow, change the direction of rotation,
see figure 3.
– Preset the required supply water flow rate according to Table 3.
This is done by setting the adjustment screw on the flow con-
troller, see figure 4.
– that water sprays out of all the holes in the spray pipe(s).
Use a needle to clear any clogged holes. If the pipe is clogged
with dirt, remove the end plugs, pos. 16, fig. 1, clean the spray
pipe with a round brush, then flush it clean.
– that the supply flow stops when the water reaches level A.
– that the water bleed-off rate is correct. Open the outlet valve,
figure 2, by holding in the left arrow key on RC1. When the water
level has fallen below level B the valve should open fully and
the display should show ”Emptying”. When the water drops
below level C the water inlet should open, and after the preset
time the drain valve should start to close. When the water
reaches level C the pump should stop briefly. The tray will then
refill with water.
Droplet eliminator
The droplet eliminator must be installed in the correct direction of
the air flow, see the arrow on the droplet separator.
Table 3 gives the amount of water that the circulation pump must
be set to. It is not the water consumption.
EUQA 2;1
Closed
Open
Fig. 2
00
2
4
246
30
20
10
EUQA Pump
Fig. 3
Adjustment screw
Reading point
Fig. 5 Level sensor
Fig. 4
T1
Q1
K1
Q2
K2
RC1
OK
ESC
F1
11-15
1-9
PE N
T1, Transformator 230VAC/24VDC
RC1, Reglercentral (PLC)
K1-K2, Kontaktor
Q1-Q2, ÷verlastskydd
F1, S‰kring 2A
(55)(08)
YYYY/MM/DD
08
: 55
2006 / 03 / 07
Ex.
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
TID
ZEIT
TIME
08:55
YYYY/MM/DD
08
: 55
2006 / 03 / 07
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
TID
ZEIT
TIME
08:55
Bild 7. Inst‰llning av klockan.
INAKTIVITET
INACTIVITY
INAKTIVITÄT
T> 240 min
(55)(08)
YYYY/MM/DD
08
: 55
2006 / 03 / 07
Ex.
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
Size Water flow, l/min
Aluminium
90 % 60 %
009
014, 020
011
5
7
8
3
4
4
018, 027, 036
023, 045, 056
032
10
12
13
5
6
7
041, 054, 068
047, 050, 063, 079
072, 090
14
16
18
7
9
10

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
8
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
WATER BLEED-OFF
Water consumption consists of the useful evaporation and
essential water bleed-off flow. This bleed-off flow is necessary
to reduce the concentration of salts in the circulating water.
If the salt concentration becomes too high, salts are precipitated
out in the humidifier fills, which will reduce the performance and
working life of the humidifier.
Chart 1 can be used to determine the appropriate bleed-off flow,
by determining zone for the current water quality. Then set the
appropriate bleed-off flow to ensure that the water in the tray is
kept clean it is recommended that it is drained and flushed once
every 24 hours (timing is preset at factory for 12.00–12.15).
If high demands are made on hygiene or if humidification require-
ments are high for an extended period, i.e. Δ x > 8 gram per kg
of air (90 % humidifier) or Δ x > 5 gram (60 % humidifier), it is re-
commended that an extra drainage and flushing cycle is added
in each 24-hour period. It may be necessary to extend the dilu-
tion time, see table 4. The value (T) is set using the display.
Size
Time for dilution, seconds
Normal operation,
preset value
High humidification over
a long period
b = 1
90 %
b = 2
80 %
Δ x >8 gram
90 %
Δ x >8 gram
80 %
009
011
014
018
020
0
10
10
20
10
0
0
0
0
0
0
20
20
30
20
0
0
0
10
0
023
027
20
10
0
0
40
20
10
0
032
041
047
20
30
40
0
0
0
40
60
80
10
20
30
036 30 0 90 20
045
050
054
072
30
50
50
60
0
0
0
0
80
100
100
120
20
30
30
40
056
063
068
40
50
70
0
0
0
80
100
120
30
30
50
079
190
55
60
0
0
55
60
20
20
Table 5. Presetting the dilution period
AHU eQ
009
eQ
011
eQ
014
eQ
018
eQ
020
eQ
023
eQ
027
eQ
032
eQ
036
eQ
050
eQ
072
eQ
090
Airflow m3/s 0,8 1 1,5 1,7 2 2,5 3 4 4 5 7 9
Water content of entering air g/kg 5 5 5 5 5 5 5 5 5 5 5 5
Water content of leaving air g/kg 10 10 10 10 10 10 10 10 10 10 10 10
Tankvolume, level A l 30,8 50,4 45,5 60,3 45,5 75,2 60,3 80,1 85,6 148,4 169,3 169,3
Tankvolume, level B l 15,3 25,1 22,6 30 22,6 37,5 30 39,9 47,8 82,8 94,4 86,9
Tankvolume, level C l 10,3 16,9 15,2 20,2 15,2 25,2 20,2 26,9 26,6 46 52,5 52,5
Dilution time, T sek 0 10 10 20 10 20 10 20 30 50 60 60
Operation time/day
(average over the year) tim 3,6 3,6 3,6 3,6 3,6 3,6 3,6 3,6 3,6 3,6 3,6 3,6
Draining per day 1 1 1 1 1 1 1 1 1 1 1 1
Water cost €/m32 2 2 2 2 2 2 2 2 2 2 2
Calculated water consumption:
Water consumption due to
evaporation l/h 17,3 21,6 32,4 36,7 43,2 54,0 64,8 86,4 86,4 108,0 151,2 194,4
Water consumption due to
draining to level C l/h 5,6 7,0 10,5 11,9 14,0 17,6 21,0 27,9 48,5 60,6 84,6 81,2
Water consumption due to
dilution calc on T l/h 0,0 4,3 7,1 12,1 9,4 14,3 10,7 21,5 34,3 41,2 60,6 70,8
Water consumption due to rinsing l/h 8,6 14,0 12,6 16,8 12,6 20,9 16,8 22,3 23,8 41,2 47,0 47,0
Total water consumption l/h 31,4 46,9 62,6 77,5 79,2 106,8 113,2 158,1 192,9 251,0 343,4 393,4
Total water consumption m3/år 41,3 61,6 82,2 101,8 104,1 140,4 148,7 207,7 253,5 329,8 451,2 516,9
Water cost/year €/år 83 123 164 204 208 281 297 415 507 660 902 1034
Factor total consump/evaporation 1,82 2,17 1,93 2,11 1,83 1,98 1,75 1,83 2,23 2,32 2,27 2,02
WATER CONSUMPTION FOR HUMIDIFIER WITH CIRCULATING WATER
CIRCULATION FLOW
Dry air Humid air
Table 4. The water consumption per years is dependant on climate, operation hours, water quality and the quantity of moisture required.
this table gives an estimate for a typical case.

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
9
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
10 10 000
6000
2000
4000
1000
600
400
200
100
60
40
20
10
6
4
2
1
567898,5 9,5
42620 40 60 100 1000 10 000
BEFEUCHTER (Diagram)
Calcium Ca2+ mg/l pH value Max. pH aluminium
Bicarbonate HCO3 –mg/l
Precipitation zone
Transition zone
Safe zone
TO DETERMINE THE WATER QUALITY ZONE
The following information is needed to determine the water
quality zone:
• pH value
• Bicarbonate concentration (HCO3), mg/l
• Calcium concentration (Ca2+), mg/l
Information on the water can be obtained from the local water
works or by water analysis.
CHART 1
Zone 1 is the safe zone, where the water is soft or demi-
neralised.
Zone 2 is the lower part of the transition zone, where
the water is normally of drinking water quality.
Zone 3 is the upper part of the transition zone, where
the water is relatively hard.
Zone 4 is the precipitation zone, where the water is very
hard. The water must be partially demineralised so that
the result will be a quality that corresponds to zone 2–3.
The water should not however be demineralised so much
that it falls into zone 1.
EXAMPLE
Data from the local water works:
pH = 7,6
Bicarbonate 70 mg/l
Calcium 30 mg/l
Chart 1 indicates zone 1 (the safe zone)
Apart from the risk of lime precipitation, the concentrations
of chloride (Cl) and copper (Cu) must be checked.
The concentration in fresh water must not exceed 50 mg/l
for chloride and 0.02 mg/l for copper.
HOW TO USE THE CHART
Enter the chart on the right hand side with the bicarbonate
(A) rate and the Ph (B) and find the intersection (C). run a
line over the chart with the calcium rate (D) and find the
intersection in the applicable zone.
D B
A
C
4
3
2
1

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
10
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
TO SHUT DOWN THE HUMIDIFIER
A. Turn off the supply voltage.
B. Stop the fans, if they are operating.
CLEANING OR REPLACING THE HUMIDIFIER FILLS
AND DROPLET ELIMINATOR
A. Shut down the humidifier.
B. Open the inspection door.
C. Remove the spacer plate as shown in fig. 6A.
D. Slide the droplet eliminators and humidifier fills straight out of
the humidifier. See fig. 6A-B.
E. The humidifier fills are relatively fragile and should therefore
be handled very carefully. Clean by spraying with clean
water, if necessary using a cleaning agent such as ULCZ-01.
If it is necessary to replace the humidifier block, see the sepa-
rate instructions that are supplied with the new block.
F. Refit parts in the reverse order.
G. Check the position of the spacer plate and close the door.
SERVICE INTERVALS
TO CLEAN THE WATER TRAY
A. Shut down the humidifier.
B. Remove the humidifier fills and droplet eliminators.
C. Open the drain valve manually to drain the water tray.
D. The water tray is now exposed and can easily be
cleaned using the supplied flushing hose.
E. Refit parts in the reverse order.
F. Check the position of the spacer plate and close the door.
INTERRUPTED OPERATION
The control unit of the humidifier switches over to the emptying
mode as soon as the fan is shut down.
If the humidifier is not being used, e.g. during a holiday or long
weekend, the water tray must be cleaned.
If the humidifier is likely to be out of operation for an extended
period, remove the humidifier fills from the humidifier, clean
them and store them somewhere safe.
Important!
The inner humidifier fills can be reached by
stepping carefully onto the edge of the water tray.
Avoid stepping on the guide rails or bottom of
the tray, or electric cables.
Fig. 6 A Humidifier fills
Droplet eliminator
Fig. 6 B
Important!
Do not step on the bottom of the water tray,
guide rails or electric cables.
Component Action Interval, months
Casing
(water tray, ends, top, guide rais).
Drain the water tray. Clean the interior by flushing, wiping or
if necessary brushing.
3
Humidifier fills. Droplet eliminator. Cleaning. 3
Water filter Clean or replace the filter cartridge, if necessary.
(The mesh must not exceed 500 μm).
3
Level sensor Check the water sensor and adjust as necessary. 3
Water flow Clean the spray pipes, if necessary. 3
Water trap Clean and refill. 6
Water quality See ”measures when making adjustments”. 12

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
11
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
CONTROL EQUIPMENT
The control box is located on the exterior of the functional
section.
Internal components, such as the ultrasound sensor, solenoid
valve, actuator and circulation pumps 1 and 2 are wired to
the junction box.
ULTRASOUND SENSOR
The ultrasound sensor has an analogue output of 0–10 V, which
means that the water level can be read from the display to an
accuracy of a few millimetres.
MONITOR AND KEYPADS
MONITOR
The four-line display has 12 characters per line.
THE KEYPADS
The right arrow is used for navigation
between the 8 images on the screen that
show running information and other
settings. See below.
If the left arrow is held depressed,
this will force the drain pipe to open
(used for performance testing.)
All the arrow keys are used to move the
flashing cursor between the different
fields on the screen.
The plus and minus keys are used to:
- increase or decrease a flashing value
- choose between On and Off.
The Esc key is used to:
- advancing one step upward in the menu tree
- remove the flashing cursor
- reset an alarm or alarm output.
The OK key is used to:
- confirm a selection.
INFORMATION IMAGES
1. In-operation information in Swedish.
2. In-operation information in English.
3. In-operation information in German.
4. For setting water quality zone and time delay, T, for dilution.
5. For setting cleaning time for humidifier fills and tray.
(1–2 x 15 min./day)
6. For reading the factory preset values for each water level A,
B1, B2, B3 and C, sensor scaling factor F and pump function CP.
7. For setting time.
8. For setting inactive time.
IMAGE 1. IN-OPERATION INFORMATION IN SWEDISH
Line 1 shows: NOT RUNNING, RUNNING, HUMIDIFYING
Line 2 shows: DRAINING, DILUTION, FILLING, CLEANING
Line 3 shows: ALARM CP1-Q1, ALARM CP2-Q2, ALARM LEVEL
Line 4 shows: WATER 45 mm
IMAGE 2. IN-OPERATION INFORMATION IN ENGLISH
IMAGE 3. IN-OPERATION INFORMATION IN GERMAN
IMAGE 4. CHOOSING ZONE AND TIME DELAY
Do as follows to change zone.
Press arrow down until the figure 2 flashes. Use the + or – keys to
set the desired value, 1, 2 or 3. Press OK.
Selecting a lower value than 1 will still give zone 1.
Selecting a higher value than 3 will still give zone 3.
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
ESC
+
–
OK
- - - DRI FT- - - -
- Q 1
PÅFYLLNI NG
ALARM CP1
VATTEN 45mm
- - RN - - -
FI LLI NG UP
ALARM CP1
WA TER 45mm
UN
FI LLI NG
I NG
UP
ALARM CP1
WA TER 45mm
- Q 1
BETRI EB- AN
NACHFÜLLUNG
ALARM CP1
WA SSER 45mm
- Q 1
ZON/ ZONE : 2
( 1- 3 )
VERZÖGERUNG
DELAY T= 20

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
12
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
Do as follows to change the time delay.
Press arrow down twice until the value flashes. Change to
the desired value using the + or – keys. Press OK.
IMAGE 5. SETTING THE CLEANING TIME
The humidifier should be drained and flushed for 15 minutes once
or twice a day. The preset time is 12:00 - 12:15 (this can naturally
be changed if required).
One additional time can be entered. This is set by default to
00:00 - 00:00.
If, for example, you want to set the time to 18:30 -18:45 this is fine,
but remember to set the start time as ON and the end time as OFF
on the display. If the start time and end time are both OFF this
function is disabled. If the start time and end time are both OFF
this function is disabled.
Use the arrow keys to move the flashing field and change
the active value using the + and – keys.
Example: Setting start time to 18:30 On.
Press the arrow key three times until the field 00:00 flashes.
Press OK.
The timer program for the start time will now be shown.
Press arrow down twice to get to the last line, which reads
00:00 OFF.
The first field will be flashing. Enter 18 (h).
Select the next field. Enter 30 (min).
Select the next field. Set this to On.
The last line should now read: 18:30 On.
Press OK to return to Image 5.
ZON/ ZONE : 2
( 1- 3 )
VERZÖGERUNG
DELAY T= 20
15mi n CL EAN.
REI NI GUNG
12: 00- 12: 15
00: 00- 00: 00
Caution!
The period selected must cover a period of
15 minutes.
Example: Setting end time to 18:45 Off.
Press the arrow down key four times until the field 00:00 flashes.
Press OK.
The timer program for the end time will now be shown.
Press arrow down twice to get to the last line, which reads
00:00 OFF.
The first field will be flashing. Enter 18 (h).
Select the next field. Enter 45 (min).
Select the next field. Set this to OFF.
The last line should now read: 18:45 OFF.
Press OK to return to Image 5.
Caution!
Do not change lines 1–3.
Caution!
Do not change lines 1–3.
15mi n CL EAN.
REI NI GUNG
12: 00- 12: 15
18: 30- 18: 45

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
13
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
IMAGE 6. PRESET LEVELS AND PARAMETERS CHOSEN
TO SUIT HUMIDIFIER SIZE
(CAN BE CHANGED WITH PASSWORD)
Example
S = Installation height of ultrasound sensor above the
bottom of the water tray.
A = Max. water level for filling.
C = Min. water level (Pump stopped).
F = Adjusting/scaling sensor output.
B3 = Level for zone 3
B2 = Level for zone 2
B 1 = Level for zone 1
CP = 1-4 Function assigned to pump(s) when inputs for hygro-
stats RH1 and RH2 are closed.
1 pump, 1 step
CP = 1, RH1 starts CP1, RH2 is disconnected. Alarm from CP2 is
interlocked.
2 pumps in parallel
CP = 2, RH1 starts both CP1 and CP2, (default setting).
Can be used even if just CP1 is fitted.
2 pumps, in sequence (special)
CP = 3, RH1 starts CP1, RH2 starts both CP1 and CP2.
2 pumps, mode (special)
CP = 4, RH1 starts CP1, RH2 starts CP2, RH1+RH2 starts both
CP1 and CP2.
IMAGE 7. SETTING THE CLOCK
The clock must always be reset if power to the humidifier has
been cut off for around 100 hours or more.
The clock switches automatically between summer/winter time
according to EU standard.
To change the time, do as follows:
Press arrow down so that the clock time flashes. Press OK.
The date and time will now be displayed.
Use the arrow keys to move the flashing field and change
the relevant value using the + and – keys.
When the date and time are set, press the OK key.
IMAGE 8. TO SET THE INACTIVITY TIME SETTING
The water in the humidifier will be emptied if the humidifier has
been inactive for a period longer than the preset inactivity time
(no need for humidification).
When the RH1 input closes, the pump starts up (if the water level
is not too low). When the RH1 input opens, the pump stops and
a time counter begins counting the time that the humidifier is
inactive ”Not in operation” and the tray is emptied of water. When
the RH1 closes again, the time counter is reset to zero, the tray is
filled with water and the pump starts up.
To change the inactivity time setting, proceed as follows.
Press the arrow-down button to cause the value to flash in
the display. Press the + or – button to change the setting to
the value of your choice. Then press OK.
S=120 B3= 53
A= 73 B2= 33
C= 20 B1= 28
F=540 CP= 2
Caution!
The pumps are interlocked if the water level is
low, if the humidifier is not running and if there is
an alarm from the relevant overload protection.
T1
Q1
K1
Q2
K2
RC1
OK
ESC
F1
11-15
1-9
PE N
T1, Transformator 230VAC/24VDC
RC1, Reglercentral (PLC)
K1-K2, Kontaktor
Q1-Q2, ÷verlastskydd
F1, S‰kring 2A
(55)(08)
YYYY/MM/DD
08
: 55
2006 / 03 / 07
Ex.
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
TID
ZEIT
TIME
08:55
YYYY/MM/DD
08
: 55
2006 / 03 / 07
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
TID
ZEIT
TIME
08:55
Bild 7. Inst‰llning av klockan.
INAKTIVITET
INACTIVITY
INAKTIVITÄT
T> 240 min
(55)(08)
YYYY/MM/DD
08
: 55
2006 / 03 / 07
Ex.
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
T1
Q1
K1
Q2
K2
RC1
OK
ESC
F1
11-15
1-9
PE N
T1, Transformator 230VAC/24VDC
RC1, Reglercentral (PLC)
K1-K2, Kontaktor
Q1-Q2, ÷verlastskydd
F1, S‰kring 2A
(55)(08)
YYYY/MM/DD
08
: 55
2006 / 03 / 07
Ex.
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
TID
ZEIT
TIME
08:55
YYYY/MM/DD
08
: 55
2006 / 03 / 07
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
TID
ZEIT
TIME
08:55
Bild 7. Inst‰llning av klockan.
INAKTIVITET
INACTIVITY
INAKTIVITÄT
T> 240 min
(55)(08)
YYYY/MM/DD
08
: 55
2006 / 03 / 07
Ex.
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
OK
INAKTIVITET
INACTIVITY
INAKTIVITÄT
T> 240 min

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
14
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
TO ZERO CALIBRATE THE ULTRASOUND SENSOR
The sensor is zeroed by FläktGroup with an empty water tray.
If it is necessary to change the zero calibration to suit future
needs this can be done by adjusting position of the sensor by
means of the lock nuts.
The sensor must reach working temperature before calibration,
i.e. the humidifier must be allowed to run for at least 15 minutes
after switching on. The display may give a reading that is out by
a few millimetres during the warming-up period.
ALARMS
There is a potential-free group alarm output inside the junction
box. The alarms that appear on the monitor screen are:
Alarm level
The water level is continuing to rise above the maximum level
”A”. The most likely reason is that the solenoid valve MV1 is not
closing. The alarm stops after five minutes.
The water level does not reach the maximum level ”A” during
filling. The most likely reason is that the solenoid valve MV1 is
not opening, the water tap is turned off or the drain valve SV1 is
not closing. The alarm stops after 30 minutes.
The sensor has detected unreasonable values, outside its
detection rage, is not correctly aimed at the water surface or
has stopped working. This fault is also shown by the sensor
LEDs both glowing red. The alarm stops after five minutes.
Alarm CP1-Q1 or CP2-Q2
Has been initiated because the overload protection for circula-
tion pump CP1 or CP2 has tripped.
Resetting alarm
Press the Esc key to reset an alarm.
T1
Q1
K1
Q2
K2
RC1
OK
ESC
F1
11-15
1-9
PE N
T1, Transformator 230VAC/24VDC
RC1, Reglercentral (PLC)
K1-K2, Kontaktor
Q1-Q2, ÷verlastskydd
F1, S‰kring 2A
(55)(08)
YYYY/MM/DD
08
: 55
2006 / 03 / 07
Ex.
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
TID
ZEIT
TIME
08:55
YYYY/MM/DD
08
: 55
2006 / 03 / 07
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
TID
ZEIT
TIME
08:55
Bild 7. Inst‰llning av klockan.
INAKTIVITET
INACTIVITY
INAKTIVITÄT
T> 240 min
(55)(08)
YYYY/MM/DD
08
: 55
2006 / 03 / 07
Ex.
OK
ClockSet
OK
TID
ZEIT
TIME
08:55
Fig. 7 Components inside of the control box
F1, Fuse 2 A
T1, 230 VAC/24 DVDC Transformer
RC1, Controller (PLC)
K1-K2, Contactor
Q1-Q2, Overload protection

HUMIDIFIER, FOR CIRCULATED WATER
Installation and maintenance instruction
15
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
+
L NPE
-
SV 1
3
+ A
-
0-10V
B
Alarm
1 2
TF 1
643
Q 2
Q 1
7 8
RH 1
RH 2
MV 1
4
CP 2
CP 1
5 6
L1 L2 L3 N PE
K1 K2 Q1 Q2
T1
TERMINAL
SV 1 L1
2 4 6
13
14
12
1 3 11 7 8
RC1
A2
A1
95 96
CP1 CP2
2 4 6
51 3
Brown Blue
Shielded
White
Level sensor
PE
PEPE
M
3-phase 3-phase
M
Solenoid valve
GU1
5
Valve actuator
3 12
PE
N
L
N
MV1
SV1
Circulation pump(s)
Alarm output (Hygrostat RH2) Hygrostat RH1 Start signal from TF1
230VAC / 24VDC
Contactor Contactor
Overload protection Overload protection
Transformer
External high-voltage switch
3x400VAC+N+PE 50 Hz
9
15 Grey
2A
1.72/1.00A 1.72/1.00A
Max 250VAC 8A
Alarm
Normally-open
Normally-closed
F1
Black
Black
Black
Black
Black
Black
Black
Black
Black
Brown
Blue (Grey)
Brown
Black
Blue (Grey)
Light blue
Light blue
Light blue
Light blue
Dark blue
Grey
Green Green Brown Brown Blue(grey)
Black Brown Blue Brown
Red Yellow Violet Orange Orange Orange Grey Dark blue White
Ledarna skall ändmärkas
1
Controller (PLC)
2 64
1 3 5 A2 2 4 6 A1 2 9564 96
N
WIRING DIAGRAM

HUMIDIFIER, FOR CIRCULATED AND ONCE-THROUGH WATER
Installation and maintenance instruction
16
FläktGroup DC_8642GB 20180131_R0 Specifications are subject to alteration without notice
EQQZ-01 HUMIDIFIER CASSETTE
The humidifier block and distributor block in EQQZ- 01 are
installed in the relevant humidifier cassette as shown in
the figure above.
When the cassettes are installed in the humidifier the bevelled
corner must face downwards and against the direction of the
air flow.
ORDERING CODE
Humidifier EQQA-aaa-bb-c-d-e-f
Size (aaa)
008-090
Humidity level (bb)
1 = 90%
2 = 60%
Version (c)
1= circulating water
2 = once-through water
Control connection (d)
0 = without, 1 = with
Inspection side (e)
1 = right, 2 = left
Version number (f)
2= version 2 (new humidify fill)
Included in
EQQZ-01
Humidifier
block
Screen
strip
Distributor
block
The figure shows the cassette upside down.
Tape
NOTE!
Make sure that the tape on the inside of
the cassettes is intact.
