Flight Display Systems FD220CV User manual

Rev:
C
Revision Date:
07/01/2012
Page 1 of 25
MAN –FD220CV
Manufactured by MILIC, LLC with marketing support from Flight Display Systems.
This product does not have FAA PMA approval.
FD220CV Ver HD
FD220CV Ver HDVC5
FD220CV Ver HDSDI
FD220CV Ver HDCV
Installation and Operation Manual
22” High-Definition Widescreen LCD
TECHNICAL SUPPORT
678-867-6717, or
www.FlightDisplay.com
All manuals and user guides at all-guides.com
all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 2 of 25
MAN –FD220CV
FD220CV Ver HD / FD220CV Ver HDVC5 / FD220CV Ver HDSDI / FD220CV Ver HDCV
22” High-Definition Widescreen LCD
© 2011 Flight Display Systems. All Rights Reserved.
Flight Display Systems
1765 Grassland Parkway
Alpharetta, GA 30004
678-867-6717 Phone
678-867-6742 Fax
[e-mail]
www.flightdisplay.com
For the most current copy of all product manuals, please visit our website at
www.flightdisplay.com
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 3 of 25
MAN –FD220CV
Table of Contents
General Information......................................................................................................................4
1. Front View..........................................................................................................................4
2. Additional Information....................................................................................................4
Specifications................................................................................................................................6
Installation Instructions .............................................................................................................6
1. Rear Connector Orientation ............................................................................................7
2. Power ..................................................................................................................................8
Wiring Instructions......................................................................................................................8
1. Wiring Suggestions...........................................................................................................8
2. S-Video/Composite and Audio Wiring ........................................................................8
3. VGA Wiring.......................................................................................................................9
4. RS-485 Wiring..................................................................................................................10
5. HDMI................................................................................................................................10
6. Power & Ground Wiring................................................................................................11
7. Power/Video ...................................................................................................................12
8. RS-485 Control.................................................................................................................12
9. RS-485 Network...............................................................................................................13
10. HDSDI...............................................................................................................................13
Operation Instructions..............................................................................................................14
1. Remote Control Button ..................................................................................................15
Technical Drawing.....................................................................................................................16
Troubleshooting.........................................................................................................................18
1. Video Noise......................................................................................................................18
2. VGA Shadowing .............................................................................................................18
3. Snow or Sweeping Lines................................................................................................18
4. No power to monitor, No video inputs .......................................................................18
5. Color Distortion...............................................................................................................18
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 4 of 25
MAN –FD220CV
6. Remote Control Inoperable ...........................................................................................18
Technical Support......................................................................................................................19
Instructions for Continued Airworthiness ...........................................................................19
Warranty ......................................................................................................................................20
Appendix A .................................................................................................................................21
1. FD220CV Ver HD/Ver HDSDI (DB-25 Pinout)..........................................................21
2. FD220CV Ver HDVC5 (DB-25 Pinout).........................................................................22
3. FD220CV Ver HDSDI (BNC Pinout) ............................................................................23
4. FD220CV Ver HDCV (DB-25 Pinout)...........................................................................24
Log of Revisions.........................................................................................................................25
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 5 of 25
MAN –FD220CV
General Information
The FD220CV Ver HD/FD220CV Ver HDVC5/FD220CV Ver HDSDI/Ver HDCV is a 1080p,
22” High-Definition Widescreen LCD which has features that allow installation in the
smallest of mounting areas with the minimum of interface equipment. Built with retrofit
aircraft integration in mind, this display can switch between up to five video input sources
using an infrared remote.
Front View
Additional Information
The FD220CV Ver HD utilizes FIVE video source inputs. They are in order of picture
quality: (2) HDMI, 1080p, (Hi-Def video, such as Blu-Ray DVD or Playstation 3), (1) VGA
(computer graphics like Moving Maps), (1) S-Video and (1) Composite Video (DVD,
camera or VCR). Both NTSC and PAL formats are auto-detected.
The FD220CV Ver HDVC5 has the same design features as the Ver HD but is designed to
integrate with the Flight Display Systems Cabin Management System Video Crosspoint
Switch (FDVCS) for VGA over Cat5 wiring. In this configuration, (2) HDMI and (1) VGA are
the only inputs available. (See Appendix A for wiring details.) It also works with the High-
Definition Video Crosspoint Switch (FDHDVCS) in order to accept HD signals via Cat5
wiring. Contact your local Flight Display Systems Sale Representative for further
information on integrating an FD220CV Ver HDVC5 into a Select CMS Cabin
Management.
The FD220CV Ver HDSDI has all of the same features as the Ver HD but is designed to
input HD video by using (2) BNC connectors mounted to the rear of the unit. Video inputs
include (2) HDSDI, (1) VGA, (1) S-Video, and (1) Composite.
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 6 of 25
MAN –FD220CV
The LCD is protected with a .060” Lexan lens to prevent scratching of the LCD and reduce
glare. FD220CV Ver HD/Ver HDVC5/Ver HDSDI/Ver HDCV is made of all metal
components. DO-160 testing documents are available upon request.
Specifications
Display Type
21.5” TFT Color LCD
Display Color
16.7 Million Colors
Screen Resolution
1920 x 1080
Brightness
300 cd/m2
Dimensions
19.5”(W) x 11.5” (H) x 1.675”(D)
Display Size
18.75”(W) x 10.55”(H)
Weight
9.75 lbs
Power
28V DC @ 3A
Operating Temperature
0-50° C (32-122° F)
Video Type Supported
NTSC/PAL
Screen Control
On Screen Display Menu
Viewing Angle
178° on Both Axis
Materials
Aluminum
DO-160 Testing
Section 21, Category B
Remote Control
IR, included
Pixel Pitch
248.25 x 248.25
Certifications
DO-160, Sec 21, Cat M –Emission of RF
Energy (In Process)
CSA –C22.2 No. 228-92/UL1418 -
Impact Test & Static Abuse (In Process)
DO-160, Sec 7, Cat B –Operational
Shock & Crash Safety (In Process)
Installation Instructions
All cabin entertainment equipment, such as the FD220CV Ver HD/Ver HDVC5/Ver
HDSDI/Ver HDCV, should be installed on a non-essential bus and have a dedicated circuit
breaker. It is a requirement that a switch be installed in the cockpit so that the pilot can de-
energize the entertainment system should it become necessary.
There are (10) 8-32 UNF mounting holes located on the sides and back of the display. Six
holes are located on the rear and two on each side of the bezel. It is sufficient to mount the
display by four attach points.
All manuals and user guides at all-guides.com
all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 7 of 25
MAN –FD220CV
Mounting against the bulkhead or on a bracket: The unit can be mounted internal,
external, or partially internal to the bulkhead. It is recommended that you leave about ¼
inch of space around the rear, top and bottom of the display for the exhaust fan to have
circulating air. When mounting from inside the bulkhead it is possible to have only the LCD
visible to the cabin. The unit will come on automatically upon power application and if using
an external video source selection box, the IR is not needed. If you are using the IR to
change the video source selection then you need to have the IR LED visible to the cabin.
Rear Connector Orientation –The rear connector of this monitor can be mounted
horizontally (connector perpendicular to rear of monitor) or vertically (connector
perpendicular to bottom of monitor) in order to give you the most convenient mounting
options. By default, this monitor's connector ships in the rear/horizontal position. Flight
Display Systems will ship the unit with the optional bottom/vertical mounting connector
configuration if specified at the time of order; contact your local sales representative for
assistance. It is possible to change the connector orientation at the time of installation.
For instructions on how to change the connector orientation please call Flight Display
Systems at [phone] and ask for Technical Support.
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 8 of 25
MAN –FD220CV
Power
This is a 28V DC monitor that requires 3.0 Amps (84 watts) of power.
Wiring Suggestions
All shields should be grounded to the connector at the source, and floating at the display.
Avoid routing video wiring parallel to:
AC wiring
Strobe wiring
DC motor supply cables
Inverter cabling
Or any other potential noise source
S-Video/Composite/Component Wiring
Recommended cable for s-video/composite and audio purposes is PIC 75 Ohm Coax, P/N
V76261. This is a lightweight, flexible, and low signal loss cable which meets FAA
flammability requirements of FAR 23.1359(d), FAR 25.853(a) and FAR 25.869(a)(4).
Similar aviation coaxial cable can be used from other vendors, as well.
Some aircraft are prone to AC noise - we recommend adding to the composite source a 75
Ohm video isolation transformer such as Deerfield Laboratory, Inc. Part No. 162-1
(www.deerfieldlab.com, [phone]). In most cases this should be added to the video
output of the source.
VGA Wiring
Recommended cable for VGA purpose is ECS P/N 453005. This is a single shielded cable
containing 5 separate coaxial cables, color-coded to match the functions of the wires.
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 9 of 25
MAN –FD220CV
We recommend coax cables be terminated using solder sleeve coaxial cable terminators
such as Raychem Part Number CWT-4174-W122-5/9.
RS-485 Wiring
Shielded twisted-pair 22 AWG wire is recommended for RS-485 wiring.
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 10 of 25
MAN –FD220CV
HDMI
HDMI (High-Definition Multimedia Interface) defines the protocol and electrical
specifications for the signalling, pin-out, electrical, and mechanical requirements of cable
and connectors used for transmitting High-Definition content .The Type A HDMI connector
(shown below) has 19 pins with bandwidth to support all SDTV, EDTV, and HDTV modes.
The plug’s outside dimensions are 13.9 mm wide by 4.45 mm high.
ECS manufactures an HDMI cable that is terminated at the factory. It is ordered as part
number 600-19786-XXX, where XXX is the length in inches for the desired cable.
Power and Ground Wiring
This is a 28VDC monitor that requires 3 amps of power to operate. To operate properly this
monitor requires an input voltage of 24-29VDC.
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 11 of 25
MAN –FD220CV
The rated current of the equipment and associated voltage drop should be taken into
consideration when selecting wire gauge. The following example is based on an install with
a 28VDC power system and a total of 50 feet of wire between the circuit breaker, monitor
and ground.
Example: 22awg wire has 16.2 Ohms per 1000 feet, this equates to .81 Ohms for 50 feet.
3 Amps of current on .81 Ohms will drop 2.43 Volts.
Resistance of Wire Type M22759/16-**
(** = Gauge)
Gauge (AWG)
OHMS/1000’
24
26.20
22
16.20
20
9.88
16
4.81
12
2.02
10
1.26
8
.70
Also, use short heavy gauge wire and a clean tight connection for ground.
It is the installer's responsibility to understand the product's requirements to install the
product in compliance with industry standards and safety.
All manuals and user guides at all-guides.com
all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 12 of 25
MAN –FD220CV
Power/Video
See Appendix A for Pinouts.
RS-485 Control (For FD220CV Ver HD & Ver HDVCD5 ONLY)
RS-485 is a two-wire communication interface that allows an external device such as a
computer or switching unit to control the monitor’s functions remotely. Up to 99 monitors
can be separately controlled by one unit.
Command sets for controlling the monitor:
Below are the command sets to control the power, source selection, and backlight brightness.
The 13 characters below are shown in hexadecimal. The communication system must be set
up for 19200 Baud, no parity, 8 bits of data, and 1 stop bit.
POWER
POWER OFF
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x01
0x01
0x00
CR
POWER ON
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x00
0x01
0x00
CR
SOURCE SELECTION
VGA
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x00
0x02
0x00
CR
Composite
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x01
0x02
0x00
CR
S-Video
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x02
0x02
0x00
CR
HDMI 1
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x06
0x02
0x00
CR
HDMI 2
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x07
0x02
0x00
CR
BACKLIGHT
0%
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x00
0x03
0x00
CR
Increment
by 1%
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
Increment
by 0x01
0x03
0x00
CR
100%
0xBE 0xEF 0x02 0x06 0x00 0x1F 0xD1 0x26 0x00
0x00
0x64
0x03
0x00
CR
Notes
1
2
3
4
5
Notes:
1. The first nine characters will remain the same for any command.
2. For connecting multiple monitors to one controller; the number can be set to0x00 to control all
monitors at once, 0x01 to control monitor number 1, 0x02 monitor number 2, and so on until
0x63 for monitor number 99.
3. The number will change depending on command.
4. Identifier for the group of commands.
5. All commands need to end with a Carriage Return
The RS-485 connector carries information between the Infrared received and the LCD controller
board. Any connections to the RS-485 bus must be tolerant to the existing control signals. Devices
connected to the RS-485 Bus should not send traffic that interferes with the existing RS-485
messages.
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 13 of 25
MAN –FD220CV
RS-485 Network:
If there is more than one monitor connected to the aircraft’s RS-485 controller system, it is
strongly recommended to connect the system in series, or daisy-chain, and terminate the
twisted pairs with a 120 OHM resistor. This configuration improves the reliability of the
system.
It is highly recommended to use 22 AWG twisted pairs for runs longer than 20 feet.
Connect all RS-485A pins together, all RS-485B pins together.
HD-SDI
HD-SDI Input & HD-SDI Output are panel mounted BNC receptacles that mate with
standard BNC plugs (Amphenol P/N 31-242 supplied).
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 14 of 25
MAN –FD220CV
Operation Instructions
The FD220CV Ver HD/Ver HDVC5/Ver HDSDI/Ver HDCV is continuously on but can be
de-energized by removing power from the entertainment system. No pilot or aircrew action
is necessary during flight or ground operation.
The passengers will be able to change the video output from the FD220CV Ver HD/Ver
HDVC5/Ver HDSDI/Ver HDCV using the video source select switch on the LCD monitor, or
remotely throughout the cabin with the included IR remote. Point the IR remote at the top
of the LCD to make changes.
When applying 28VDC power, the display will turn on and look for a valid input on the last
known source. If no input is found, the display will go to standby mode. Pressing the Select
button will select new video input.
Button Controls
Located at the top (center) of the FD220CV Ver HD/Ver HDVC5/Ver HDSDI/Ver HDCV
are 8 buttons. Their functions are shown below:
BUTTON
DESCRIPTION
POWER
Toggles the power ON or OFF. Also, wakes the display
up from SLEEP mode.
MENU
Opens the MENU.
AUTO
Auto-adjusts the display’s size and position.
DOWN
Moves to the next selection in the menu.
UP
Moves to the previous selection in the menu.
LEFT
Decrease the selection’s value in the menu.
RIGHT
Increases the selection’s value in the menu.
SOURCE
Switches between sources coming into the display.
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 15 of 25
MAN –FD220CV
Remote Control Buttons
Refer to Button Controls on previous page.
Remote required for FD220CV Ver HDSDI
Remote required for FD220CV Ver HD &
FD220CV Ver HDVC5
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 16 of 25
MAN –FD220CV
Technical Drawing
All manuals and user guides at all-guides.com
all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 17 of 25
MAN –FD220CV
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 18 of 25
MAN –FD220CV
Troubleshooting
Video Noise
Check for an incorrect ground in the installation wiring. See specific examples of video
noise below, or visit http://flightdisplay.com/Grounding.pdf
VGA Shadowing
Most of shadowing problems are due to shielding on the wire. Locate the point where all of
the shields are connected. Cut away the shields, one at a time, while viewing the display on
the screen to observe which shield is causing the noise. Cutting away one shield at a time
will allow you to focus and isolate the video noise issue.
Twisted pair wiring is prone to video noise. ECS VGA Wire
(Detailed under “Video Wiring Suggestions”) is recommended.
Snow or Sweeping Lines
Lines that slowly sweep up and down are a result of AC noise. This AC noise can be
generated by a power cart on the aircraft. Take the power cart off of the aircraft. Be careful
of inverter wiring, which can also cause noise. Stand off the wires, if necessary.
If snow or sweeping lines persist, it is possible that the ground is at an incorrect point in the
aircraft. Try moving the ground to another location.
No power to Monitor, or No video Input
• Verify correct wiring. Check the base receptacle connectors for possibly damaged pins.
• Check that the video source is:
1. Powered on,
2. In Play mode, and
3. Displaying video.
Color Distortion
• Adjust brightness and contrast settings using the buttons on the monitor.
Remote Control Inoperable
• Confirm that the infrared eye on the LCD screen is visible.
• Replace battery in remote control.
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 19 of 25
MAN –FD220CV
Technical Support
Should you have any questions concerning this product or other Flight Display Systems
products, please contact our Product Support representatives at [phone].
Flight Display Systems
1765 Grassland Parkway
Alpharetta, GA 30004
Phone: [phone]
Fax: [phone]
Email: [e-mail]
For further product information, technical data and sample wiring diagrams, please click on
the Dealers section of our website at www.flightdisplay.com
Instructions for Continued Airworthiness
The FD220CV Ver HD/Ver HDVC5/Ver HDSDI/Ver HDCV is designed not to require
regular general maintenance.
Warranty Information
All manuals and user guides at all-guides.com

Rev:
C
Revision Date:
07/01/2012
Page 20 of 25
MAN –FD220CV
Flight Display Systems warrants the FD220CV Ver HD/Ver HDVC5/Ver HDSDI/Ver HDCV
against material or manufacturing defects for a two-year period. Warranty begins on date of
installation. *The warranty registration card must be returned upon installation in order to
validate the two-year warranty. Any warranty registration not returned during this time
period will default to the date of purchase as the warranty start date.
If product support is required, please call our Technical Support team at 678-867-6717 to
obtain assistance. If the return of the unit to the factory is required, an RMA number will be
issued at that time. Flight Display Systems will, upon receipt of the failed hardware,
remanufacture or replace the unit at our discretion.
Flight Display Systems will pay Ground Shipping charges for warranted items. Charges for
express shipment will be the responsibility of the sender.
This warranty is not transferable. Any implied warranties expire at the expiration date of this
warranty. We shall not be liable for incidental or consequential damages.
This warranty does not cover a defect or failure that has resulted from improper or
unreasonable installation, use or maintenance, as determined by Flight Display Systems.
This warranty is void if there is any attempt to disassemble or open this product without
factory authorization.
Flight Display Systems shall not be held responsible for any labor charges associated with
the removal of product or related troubleshooting.
Appendix A
FD220CV Ver HD/ FD220CV Ver HDSDI - Pin out for P1 (DB-25 Receptacle)
Connector P/N: M24308/2-283 or Equivalent
All manuals and user guides at all-guides.com
