CONFIDENTIAL
ISSUED:28.OCT.2008
VERSION:1.0
LCD‐TW‐008‐001
SHARP










42”/46”LCDTV
SERVICEMANUAL
MODEL:LC‐42D63T/LC‐46D63T
PANEL:42”LCDTV(LK420D3LZ50Z)
46”LCDTV(LK460D3LZ30Z)










CONTENTS

1. LC‐42D63T/LC‐46D63TFUNCTIONDESCRIPTION
2. SPECIFICATION
3. FACTORYRESET
4. FIRMWAREUPDATE
5. BLOCKDIAGRAM
6. PCBARSPL
7. EXPLODEDVIEW
8. PACKAGINGLIST

















LC‐42D63T/LC‐46D63TFUNCTIONDESCRIPTION








LC‐42D63T/LC‐46D63TFUNCTIONDESCRIPTION







LC‐42D63T/LC‐46D63TFUNCTIONDESCRIPTION






SPECIFICATIONFORLC‐42D63TLCDTV

PRODUCT :42 INCH LCD TV
CUSTOMER :1. SHARP/Taiwan
MODELNO.

:1. LC‐42D63T
REV.NO.:V1.22008/10/17

THE PRODUCT SPECIFICATION IS ISSUED FROM THE ELECTRONICS
DEVICE
BUSINESS UNIT R&D DIVISION

AUTHORIZED SIGNATURE
DATE(M/D/Y) ISSUED
MARKING

PREPAREDBY:Pen Chien Lin

10/17/2008

(ENGINEER)

REVIEWEDBY:JESS–LIN

10/17/2008

(MANAGER)

APPROVEDBY:Chris Chang

10/17/2008

(DIRECTOR) 

THE PRODUCT SPECIFICATION IS ISSUED TO THE FOLLOWING
DEPARTMENTS:
PRODUCTPLANNINGDOMESTICSALES
NORTHAMERICASALESPRODUCTIONENGINEERING
INTERNATIONALSALESQUALITYRELIABILITY
EUROPESALESQUALITYASS

SPECIFICATIONFORLC‐42D63TLCDTV

1.POWERSOURCE
a. Operatingvoltage
b. Inputcurrent
c. Inrushcurrent
d. Powerconsumption
e. Stand‐by


100‐240~Vac,50/60Hz
1.9ATyp.(at110Vac)
60Ap‐pTyp.(at230Vac)
240W(atDymanic(fix)AVmodel)
0.8WMax.(at110Vac)


2.PANEL42.0”TFTtype
0.4845(H)X0.4845(V)mmPixelPitch
Anti‐Glare,Hard‐Coating3H
NormallyBlack

3.DISPLAYRESOLUTION1920X1080Typical

4.DISPLAYCOLORS16.7MColors

5.ACTIVEDISPLAYAREA930.24mm(H)X523.26mm(V)

6.BRIGHTNESS(Center)450cd/m²(Typ.)

7.CONTRASTRATIO2000:1(Typ.)

8.LCDRESPONSETIME6.0ms(Typ.),RiseTime
6.0ms(Typ.),FallTime
1920X1080Typical

9.VIEWINGANGLE(CR>=10)Horizontal:176degree(Typ.)
Vertical:176degree(Typ.)


SPECIFICATIONFORLC‐42D63TLCDTV
10.INPUTSIGNAL
RGBSignal(D‐typex1)

AudioSignal(3.5ψmicJACK x1,L/R)
HDMISignal(TypeAx2)
DVISignal(SameHDMI)
AudioSignal(3.5ψmicJACK x1,L/R)
RFInput(FConnectorx1)
RFInput(FConnectorx1)
CompositeVideo(RCAJackx3)
S‐video(MiniDin4‐pinx1)
ComponentVideo(RCAJackx2)
Audio(RCAJackx3,L/R)


Video:Analog0.7Vp‐p/75ohms
Sync.:TTLLevel,P/N,SeparateSync.
Audio:1.0 Vp-p
HDMI/DVI:REV1.3/REV1.0
Digital:SingleTMDS(1.0Vp‐p)
Audio:1.0Vp‐p

RFSignalx1(Analog)
RFSignalx1(Digital)


Video:1.0 Vp-p / 75 ohms
Y:1.0Vp‐p/75ohms,C:0.286Vp‐p
Y:1.0Vp‐p/75ohms,CB/CR:0.7Vp‐p
Audio:1.0Vp‐p
Remark:1.Input1ComponentandCVBSAuto:PriorityComponent
2.Input2ComponentandCVBSAuto:PriorityComponent
3.Input3S‐VideoandCVBSAuto:PriorityS‐Video
4.Input4HDMIorDVIDVI:ConnectablewithPCandSTB
5.Input5HDMIHDMIOnly
6.Input6D‐SubForPC
11.OUTPUTSIGNAL

Audio(RCAJackx1,L/R)


1.0Vp‐p(Fixed&Var.Select)


SPECIFICATIONFORLC‐42D63TLCDTV
12.CONNECTOR





INPUT1:
COMPONNETRCAjackX1(3P)
CVBS/AUDIOL/RJackX1(3P)
INPUT2:
COMPONNETRCAjackX1(3P)
CVBS/AUDIOL/RJackx1(3P)
INPUT3:
S‐VIDEOJackx1(MiniDin4PIN)
CVBS/AUDIOL/RJackX1(3P)
INPUT4:
HDMIX1(19PIN)
3.5ψPhonejackX1
INPUT5:
HDMIX1(19PIN)
INPUT6:
RGBX1(15PIND‐SUB)

RS232X1(9PIN)forservice
USBX1forDVB‐Tservice

OUTPUT
SPDIFX1
AUDIOL/RJackX1(2P)

13.FREQUENCY
(AutomaticallyScale)
H‐Sync.:15~68KHz
V‐Sync.:50~70Hz
(Upto60HZat1920X1080Mode)


SPECIFICATIONFORLC‐42D63TLCDTV
14.SOUND
14.1SoundOutput(Distortion10%)

14.2HarmonicDistortion
14.3ResidueSound
14.4FrequencyResponse
(1KHzO/P:50mW,0dB
InStandardmode,surroundoff)

15W+15W(Typ.),4Ohm

<0.5%
<3mW
100Hz+5dB±3dB,
10kHz‐1dB±3dB


-
15.COLORTEMPERATURE:
a. ColortemperatureHigh(16800K)
b. ColortemperatureMid‐high(15300K)
c. Colortemperaturemid(13660K)
d. Colortemperaturemid‐low(12600K)
e. Colortemperaturelow(10640K)

atcenterblockwhitepattern100% 
x=0.270±0.03,y=0.267±0.03 
x=0.2774±0.03,y=0.276±0.03
x=0.2854±0.03,y=0.286±0.03
x=0.297±0.03,y=0.299±0.03
x=0.318±0.03,y=0.320±0.03 



16.PINASSIGNMENTSFOR15PIND‐TYPECONNECTOR
Pin1:RedPin6:RReturnPin11:N.C.
Pin2:GreenPin7:GReturnPin12:DDCData
Pin3:BluePin8:BReturnPin13:HSync
Pin4:N.C.Pin9:5VSupplyPin14:VSync
Pin5:GNDPin10:GNDPin15:DDCClock



17.PLUG&PLAY

DDC2B






SPECIFICATIONFORLC‐42D63TLCDTV
18.RGBMODESTIMING
VESA MODES
 HorizontalVertical
Mode No Resolution Nominal
Frequency
+/‐0.5KHz
Nominal
Frequency
+/‐1Hz
Nominal
Pixel
Clock(MHz)
VGA1640X480@60Hz 31.469 59.94025.175
SVGA2800X600@60Hz 37.879 60.31740.000
XGA31024X768@60Hz 48.363 60.00465.000
SXGA41280X1024@60Hz 63.981 60.020108.000
WXGA51360X768@60Hz 47.712 60.00085.500
 
DOS6720X400@70Hz 31.469 70.08728.322
 




19.PINASSIGNMENTSFORHDMI19PINTYPE‐ACONNECTOR
Pin1:TMDSData2+Pin2:TMDSData2shield
Pin3:TMDSData2‐ Pin4:TMDSData1+
Pin5:TMDSData1shieldPin6:TMDSData1‐
Pin7:TMDSData0+Pin8:TMDSData0shield
Pin9:TMDSData0‐ Pin10:TMDSClock+
Pin11:TMDSClockshieldPin12:TMDSClock‐
Pin13:CECPin14:Reserved(NCondevice)
Pin15:SCLPin16:SDA
Pin17:DDC/CECGroundPin18:+5VPower
Pin19:HotPlugDetect



SPECIFICATIONFORLC‐42D63TLCDTV
20.HDMITYPE‐A&DVIMODESTIMING
 HorizontalVerticalPixelClockMode
Mode No Resolution Nominal
Frequency
+/‐0.5KHz
Nominal
Frequency
+/‐1Hz
Nominal
Frequency
(MHz)
H
D
M
I
D
V
I
VGA1640X480@60Hz 31.469 59.940 25.175‐ ●
SVGA2800X600@60Hz 37.879 60.317 40.000‐ ●
XGA31024X768@60Hz 48.364 60.004 65.000‐ ●
SXGA41280X1024@60Hz 63.981 60.020 108.000‐ ●
WXGA51360X 768@60Hz 47.712 60.000 85.500‐ ●
WUXGA61920X1080@60Hz 67.500 60.000 148.500● ●
 
DOS7720X400@70Hz 31.469 70.087 28.322‐ ●
 

OTHER
(VIDEO)
8720X480I@60Hz 15.734 59.940 13.500●‐
9720X480P@60Hz 31.469 59.940 27.000● ●
101280X720P@60Hz 45.000 60.000 74.250● ●
111920X1080I@60Hz 33.750 60.000 74.250● ●




 









SPECIFICATIONFORLC‐42D63TLCDTV
21.ANALOGTUNER
21.1.ChannelCoverage
21.1.1.AirChannel
VHF‐Low(CH02–CH06)
VHF‐High(CH07–CH13)
UHF‐(CH14–CH69)
21.1.2.CableChannel
CH02–CH06
CH07–CH13
CH14–CH22
CH23–CH64
CH65–CH94
CH95–CH99
CH100–CH125


54–88MHz
174–216MHz
470–806MHz

72–88MHz
174–216MHz
120–174MHz
216–468MHz
470–650MHz
90–120MHz
650–806MHz

21.2.RFSensitivity(Peak)
21.2.1.Air(CH02–CH69)
21.2.2.Cable(CH2–CH125)

30dBMax
30dBMax

21.3.RejectionRatios
21.3.1.PictureI.F.Rejection
21.3.1_1.Air(CH02–CH69)
21.3.1_2.Cable(CH2–CH125)

21.3.2.PictureImageRejection
21.3.2_1.Air(CH02–CH69)
21.3.2_2.Cable(CH2–CH125)


50dBMin
50dBMin


50dBMin
50dBMin

21.4.CVBSSignalToNoiseRatio40dBMin

21.5.AudioSignalToNoiseRatio50dBMin
 
22.DIGITALTUNER
22.1InputFrequencyRange
UHF:
AIRChannel
470–860MHz

SPECIFICATIONFORLC‐42D63TLCDTV
22.2signalLevel

‐10dBm~80dbm
22.3ChannelBandwidth6MHz

22.4InputImpedance75Ohm

22.5OFDMSpectrum2k,8kandNon‐Hierarchical
(DVB‐TCompliant)

22.6ModulationModesQPSK,16QAM,64QAM

22.7GuardIntervalModes1/32,1/16,1/8 , 1/4 
activesymbolduration

22.8FECModesRate=1/2 , 2/3 , 3/4 , 5/6 , 7/8 

22.9OutputFormatMPEG‐4TransportStream
(TTLCompliant)
22.10SupportH.264


23.OTHER
23.1OSDLanguage‐English/Chinese
23.2WithoutPIP/POPFunction,
23.3WithOPCFunction
23.4PictureAspect–TV/AV/SVWith16:9,4:3,PanoramaMode
Component/HDMIWith16:9,4:3Mode
24.MECHANICALREQUIREMENTS
21.1.PackagingandWeight
Unitdimension(w/ostand):W1004.0xD95.0xH646.0mm
Unitdimension(withstand):W1004.0xD305.0xH708.5mm
Packagingdimension:W1120.0xD290.0xH760.0mm
Grossweightofunit(w/ostand):22.2kg
Grossweightofunit(withstand):27.2kg
Totalweightofunit(withpacking):32.5kg 

SPECIFICATIONFORLC‐42D63TLCDTV
25.VIBRATION&DROP
25.1. Vibration
Frequency:5‐50‐5Hz
Acceleration:1.0G
Sweeptime:3minutes
Amplitude:19.8~0.2mm
CycleTime:Upanddown,60minutes,rightandleft,15minutes,
forwardandback,15minutes.Total 90minutes.
VibrationTestDatashallbesubmittedforapprovaltoSharppriortoPilotRun.


25.2.Drop 
Height:32cm(face),25cm(edge,corner)
Dropdirection:1corner,3edge,5faces,total:9times
Remark:Non‐operatingtest


26.ENVIRONMENTALREQUIREMENTS
26.1.Non‐operating
a. Ambienttemperature ‐20degreeCto60degreeC(14degreeFto140degreeF)
b. Relativehumidity10%RHto85%RH(non‐condensing)
c. Altitude10,000feet

26.2.Operating
a. Ambienttemperature0degreeCto40degreeC(32degreeFto104degreeF)
b. Relativehumidity20%RHto85%RH(non‐condensing)
c. Altitude10,000feet
27.ESD
Operating:>8KV,nohardwareerrorallowed 
Nonoperating:<15KV,nohardwareerrorallowed
28.AClineNoiseTest
FORCISPR24


SPECIFICATIONFORLC‐42D63TLCDTV
29.ThunderSurgeTest
ACLINE+/‐12KV(C),SURGEWAVE:1.2KVx50us
ACLINE+/‐12KV(CR),SURGEWAVE:1.2KVx50us
30.ACLeakagecurrent
Touch current＜0.7mA , 110 Vac/ 60Hz 

31.WithstandVoltageTest
AC3000V/5mA/1min.(forCNS14408)

32.InsulationResistorTest
InsulationResistorspec:DC500V ,> 4MΩ 
33.MTBF(MeanTimeBetweenFailure) 
35000hours(excludeback‐light&LCDPanel)
60000hours(back‐light)
34.REGULATORYREQUIREMENTS(Safety&EMC&DTVrequirement.)
The unit shall conform to the following regulatory standards.
a.SafetyCNS14408
b.EMCCNS13439
c.DTVCNS14409+CNS14676‐3+CNS14676‐4+CNS14676‐5&Performance
Remark:DTVPerformance:地面數位電視接收機基本技術規範










SPECIFICATIONFORLC‐46D63TLCDTV

PRODUCT :46 INCH LCD TV
CUSTOMER :SHARP/Taiwan
MODELNO.

:LC‐46D63T
REV.NO.:V1.22008/10/17

THE PRODUCT SPECIFICATION IS ISSUED FROM THE ELECTRONICS
DEVICE
BUSINESS UNIT R&D DIVISION

AUTHORIZED SIGNATURE
DATE(M/D/Y) ISSUED
MARKING

PREPAREDBY:Pen Chien Lin

10/17/2008

(ENGINEER)

REVIEWEDBY:JESS_LIN

10/17/2008

(MANAGER)

APPROVEDBY:Chris Chang

10/17/2008

(DIRECTOR) 

THE PRODUCT SPECIFICATION IS ISSUED TO THE FOLLOWING
DEPARTMENTS:
PRODUCTPLANNINGDOMESTICSALES
NORTHAMERICASALESPRODUCTIONENGINEERING
INTERNATIONALSALESQUALITYRELIABILITY
EUROPESALESQUALITYASS

SPECIFICATIONFORLC‐46D63TLCDTV
1.POWERSOURCE
f. Operatingvoltage
g. Inputcurrent
h. Inrushcurrent
i. Powerconsumption
j. Stand‐by


100‐240~Vac,50/60Hz
2.5ATyp.(at110Vac)
60Ap‐pTyp.(at230Vac)
315W(atDymanic(fix)AVmodel)
0.8WMax.(at110Vac)


2.PANEL46.0”TFTtype
0.530(H)X0.530(V)mmPixelPitch
Anti‐Glare,Hard‐Coating3H
NormallyBlack

3.DISPLAYRESOLUTION1920X1080Typical

4.DISPLAYCOLORS16.7MColors

5.ACTIVEDISPLAYAREA1018.08mm(H)X572.67mm(V)

6.BRIGHTNESS(Center)450cd/m²(Typ.)

7.CONTRASTRATIO2000:1(Typ.)

8.LCDRESPONSETIME6.0ms(Typ.),RiseTime
6.0ms(Typ.),FallTime
1920X1080Typical

9.VIEWINGANGLE(CR>=10)Horizontal:176degree(Typ.)
Vertical:176degree(Typ.)


SPECIFICATIONFORLC‐46D63TLCDTV
10.INPUTSIGNAL
RGBSignal(D‐typex1)

AudioSignal(3.5ψmicJACK x1,L/R)
HDMISignal(TypeAx2)
DVISignal(SameHDMI)
AudioSignal(3.5ψmicJACK x1,L/R)
RFInput(FConnectorx1)
RFInput(FConnectorx1)
CompositeVideo(RCAJackx3)
S‐video(MiniDin4‐pinx1)
ComponentVideo(RCAJackx2)
Audio(RCAJackx3,L/R)

Video:Analog0.7Vp‐p/75ohms
Sync.:TTLLevel,P/N,SeparateSync.
Audio:1.0 Vp-p
HDMI/DVI:REV1.3/REV1.0
Digital:SingleTMDS(1.0Vp‐p)
Audio:1.0Vp‐p

RFSignalx1(Analog)
RFSignalx1(Digital)


Video:1.0 Vp-p / 75 ohms
Y:1.0Vp‐p/75ohms,C:0.286Vp‐p
Y:1.0Vp‐p/75ohms,CB/CR:0.7Vp‐p
Audio:1.0Vp‐p
Remark:1.Input1ComponentandCVBSAuto:PriorityComponent
2.Input2ComponentandCVBSAuto:PriorityComponent
3.Input3S‐VideoandCVBSAuto:PriorityS‐Video
4.Input4HDMIorDVIDVI:ConnectablewithPCandSTB
5.Input5HDMIHDMIOnly
6.Input6D‐SubForPC
11.OUTPUTSIGNAL

Audio(RCAJackx1,L/R)


1.0Vp‐p(Fixed&Var.Select)


SPECIFICATIONFORLC‐46D63TLCDTV
12.CONNECTOR

INPUT1:
COMPONNETRCAjackX1(3P)
CVBS/AUDIOL/RJackX1(3P)
INPUT2:
COMPONNETRCAjackX1(3P)
CVBS/AUDIOL/RJackx1(3P)
INPUT3:
S‐VIDEOJackx1(MiniDin4PIN)
CVBS/AUDIOL/RJackX1(3P)
INPUT4:
HDMIX1(19PIN)
3.5ψPhonejackX1
INPUT5:
HDMIX1(19PIN)
INPUT6:
RGBX1(15PIND‐SUB)

RS232X1(9PIN)forservice
USBX1forDVB‐Tservice

OUTPUT
SPDIFX1
AUDIOL/RJackX1(2P)

13.FREQUENCY
(AutomaticallyScale)
H‐Sync.:15~68KHz
V‐Sync.:50~70Hz
(Upto60HZat1920X1080Mode)

14.SOUND
14.1SoundOutput(Distortion10%)

14.2HarmonicDistortion
14.3ResidueSound
14.4FrequencyResponse
(1KHzO/P:50mW,0dB
InStandardmode,surroundoff)

15W+15W(Typ.),4Ohm

<0.5%
<3mW
100Hz+5dB±3dB,
10kHz‐1dB±3dB


