FLIGHTORY Mini Plank User manual

1
USER MANUAL
USER MANUAL
V.1
© 2023 Flightory by Szymon Wójcik All rights reserved.

Socials
USER MANUAL 2
Join Flightory Tech group on Facebook and create community with us.
Share progress of your builds. Any suggestions or questions welcome.
www.facebook.com/groups/flightory
Follow Instagram where I share more footage on a regular basis
www.instagram.com/flightory_
Check out the Youtube channel where you can find videos about my
projects: www.youtube.com/@FLIGHTORY

General Aircraft Data
USER MANUAL 3
General data
Wingspan
650mm
Wing
area 12.5 dm²
Lenght
370mm
Center of
Gravity 35mm from leading Edge
AUW
300-400g
Optimal
Cruise Speed 45-55 km/h
Airfoil
PW75
Root Chord
230mm
MAC
191mm
Aspect
Ratio 3.43
Wing
load 24 -32g / dm²

CFD Analysis
USER MANUAL 4
Geometry is designed to provide the best possible characteristics. Excellent
and well-tested PW75 airfoil was selected for this project. It is a reflex airfoil
designed specifically for planks. With the center of gravity located 35mm from
the leading edge, stability and the zero pitching moment at zero angle of attack
is maintained. Angles of attack for optimal CL/CD distribution are in the range
of 2 to 4 degrees. The optimal cruising speed is between 45 and 55 km/h.

Exploded view
USER MANUAL 5

Print Settings
USER MANUAL 6
Slicer software you need to use is Ultimater Cura. All elements from LW-PLA
are best printed with ready-made settings prepared in a profile that you can
download. Settings are prepared a standard 0.4mm nozzle. Download link is
available on Flightory Blog. Infill in this profile is set to 6%. For this project I
recommend changing it to 3%. This is sufficient filling
Main features of slicer LW-PLA profile
•layer height: 0,25 mm
•single wall 0,4mm thickness
•3% Gyroid infill.
•Temperature: 235 degrees,
•flow 60%
•fan speed: 0%
The rest of the detailed settings are
saved in the profile.
To print hard PLA or PET-G parts, use
a default profile in CURA called
Draft. Layer height is 0.2 mm, infill
is 20% Grid pattern. Set the
temperature around 220 degrees.
You can fine-tune these parameters
to suit your needs and your printer.

Parts Orientation
USER MANUAL 7
All parts are suitable for printing on any standard printer with a small
working area. I printed all parts on a 200 x 200mm area. The settings
are just a base that you can change and adjust as needed. The
following pages will list my recommended infill settings for each part.
All elements can be printed without supports, but your printer
may have a problem with some horizontal surfaces in some
places. Depending on the effects, you may then consider turning
on supports for some elements and cleaning the printed
elements afterwards.

Parts Orientation
USER MANUAL 8
Important thing is the correct orientation of the printed parts
to avoid overhangs, and not have to use supports.
Below is the recommended orientation of parts and infill settings.
FUS 1 - 3% gyroid infill
FUS 2 - 3% gyroid infill

Parts Orientation
USER MANUAL 9
FUS 3 - 3% gyroid infill
FUS 4 - 6% gyroid infill

Parts Orientation
USER MANUAL 10
NOSE - 3% gyroid infill
HATCH1 - 6% gyroid infill

Parts Orientation
USER MANUAL 11
HATCH2 - 6% gyroid infill
ROOT - 3% gyroid infill

Parts Orientation
USER MANUAL 12
WING - 3% cubic subdivision infill
WINGLET - 3% gyroid infill

Reccomended RC Equipment
USER MANUAL 13
Reccomended
electronics
Motor
T-Motor F1507 3800KV or similar size
Propeller
4x4
Flight Controller
Matek F405 WMN
GPS
Matek M10Q or similar GPS with compass
Servos
2x Corona 929MG Metal Gear
ESC
Little-Bee 20A BlHeliS
Battery
Li-on 3S1P 3000mAh or similar LiPo
Receiver
Matek R24-D ELRS
VTX
Digital or analog VTX

Required accessories
USER MANUAL 14
ITEM
QUANTITY
4x645mm Carbon
Tube (MAIN SPAR) 1
4x310mm Carbon
Tube (SECOND SPAR) 1
Thin
CA Glue 1
CA
Activator 1
M3
Threaded Insert (Outer Ø5mm,
height
5mm)
2
M3
screw 6
LW
-PLA About 150g
PLA
Small amount
Polyester
hinge 20x25mm 6
Pen spring
1
Adhesive
velcro 1

PARTS LIST - FUSELAGE
USER MANUAL 15
PART
MATERIAL
FUS 1
LW-PLA
FUS 2
LW-PLA
FUS 3
LW-PLA
FUS 4
LW-PLA
WING L
LW-PLA
WING R
LW-PLA
ROOT L
LW-PLA
ROOT R
LW-PLA
AILERON L
LW-PLA
AILERON R
LW-PLA
WINGLET L
LW-PLA
WINGLET R
LW-PLA
HATCH 1
LW-PLA
HATCH 1 WALKSNAIL
LW-PLA
HATCH 2
LW-PLA
NOSE FPV
LW-PLA
NOSE CLEAN
LW-PLA
LOCK 1
PLA
LOCK 2
PLA
FIREWALL
PET-G

STEP files
USER MANUAL 16
A few airframe parts are also available in STEP format. This way you
will be able to customize these items. For example, make a mount for a
custom camera, a mount for a VTX, GPS or change the size of the
servos used.
You can find these files in folders labeled STEP

Nose variants
USER MANUAL 17
There are 2 variants of the nose in the files. One of them is adapted for
a standard 19x19mm FPV camera. A clean version is relevant if you
don't want to mount an FPV camera. The nose file is also available in
STEP format for easier editing and customization.

Variant Selection
USER MANUAL 18

Fuselage assembly
USER MANUAL 19
Prepare all fuselage segments. Before gluing,
you can gently sand the surface of all
elements, especially the gluing surfaces.
It’s best to use thick CA glue.
You can use short pieces of 4mm carbon tube as pins
to strengthen the connection. This is an optional action

Fuselage assembly
USER MANUAL 20
It’s best to use thick CA glue.
After gluing all the fuselage segments together, attach the ROOT parts.
