Forcepoint V20000 G1 User manual

Quick Start Guide
Forcepoint V20000 G1
Forcepoint V10000 G4R2
Web or Email Security Appliance
See the Rack Installation Instructions included in the
Sliding Ready Rail kit.
Contact Forcepoint Technical Support if any items are missing.
Optional 10GbE NIC Expansion Kit available. Contact your Forcepoint
account representative.
Bezel (faceplate)
Power Cables (2) Ethernet Cables (4)
Accessory Kit
1
Sliding Ready Rail Kit
2
• Left Ready Rail
• Right Ready Rail
• Velcro Straps (2)
• Rack Installation Instructions
Cable Management Arm Kit
3
• Cable Management Arm
• Static Support Tray
• Cable Tie Wraps
• CMA Installation Instructions
2
1
1. Connect to the appliance via serial port or KVM in order to access the command line interface for
initial configuration. Serial port settings are: 9600 baud, 8 bits, no parity.
2. Secure power cables using velcro straps and plug power
cables into an appropriate power source.
5Connect Input Device
Rack Appliance
Power on the appliance and check the following indicators:
Contact Forcepoint Technical Support if any indicators are not
illuminated correctly.
Front
• Power button is illuminated.
• Hard drive LEDs are green.
Rear
• Power supply LEDs are green.
• LEDs for connected interfaces (NICs) are green.
• System status indicator (LED left of power supplies) is solid
blue.
6Power On Appliance
Please refer to the Forcepoint Appliances Getting Started guide
for more details.
Initial Configuration
Firstboot Script
• Configure security mode.
• Configure the appliance management communication
interface (C).
• Configure NTP servers/system time.
Appliance Command Line
• Configure applicable network interfaces.
• Configure other settings as desired.
Web Mode
Forcepoint Security Manager
• Enter subscription key, update Master Database, configure
Network Agent, and configure policies in Forcepoint
Security Manager.
• Requires Windows Server 2008 R2, or Windows Server 2012
or 2012 R2, or Windows Server 2016.
Content Gateway Manager (proxy)
• Configure user authentication and select protocols.
Email Mode
Forcepoint Security Manager
• Complete configuration wizard, enter subscription key, and
configure policies in the Email Security module. Configure
email DLP policies in the Data Security module.
• Requires Windows Server 2008 R2, or Windows Server 2012
or 2012 R2, or Windows Server 2016.
7Configuration Overview
Verify Contents
Plan your deployment before setting up the appliance. See the
back of this guide for a deployment overview and reference sheet.
Before you begin...
The appliance supports the following security modes:
3Determine Security Mode
Based on your subscription and deployment plan, determine the appropriate security mode for this
appliance.
• Web (Forcepoint Web Security)
• Email (Forcepoint Email Security)
Cat 5E cables (or better) are required.Do not use crossover network cables. If optional 10GbE optical
NIC is selected, please refer to 10GbE PCI NIC Installation Guide.
4Connect Network Cables
QSGV640-100_RevA
Serial Cable
©2018 Forcepoint LLC. All rights reserved.
iDRAC Serial Port KVM

Deployment Reference SheetAppliance Deployment Overview
You can deploy one or more appliances on your network. The diagram below illustrates a basic appliance deployment.
A separate computer with Windows Server is required for running Forcepoint Security Manager. See the Forcepoint
Appliances Getting Started guide for details.
* P2 is optional and may be connected to a router or switch.
** Connect to bidirectional span, monitor, or mirror port if sending blocking information through N.
Internet
Firewall
Clients
Windows Server 2008 R2
Windows Server 2012 or 2012 R2
Windows Server 2016
Router
*
** Switch
Forcepoint Security Manager
Email
Web SQL Server
Policy Server IP: IP Address:
Log Server IP: User Name:
Subscription Key: Password:
Log Server IP:
Authentication Mode:
Network Configuration
Network Agent Interface (N)
Forcepoint Email/Web Security Interfaces (P1 & P2)
NIC Teaming Failover (E1 & E2)
P1
E1 (Bonded with P1)
P2
E2 (Bonded with P2)
Appliance Management Communication Interface (C)
IP Address: Primary DNS:
Subnet Mask: Secondary DNS:
Default Gateway: Tertiary DNS:
IP Address: Primary DNS:
Subnet Mask: Secondary DNS:
Default Gateway: Tertiary DNS:
IP Address: Default Gateway:
IP Address: Default Gateway:
Subnet Mask: Primary DNS:
Subnet Mask: Primary DNS:
IP Address:
IP Address:
Secondary DNS:
Secondary DNS:
Subnet Mask:
Subnet Mask:
Tertiary DNS:
Above settings apply to P1 and P2
Tertiary DNS:
Above settings apply to E1 and E2
Getting Started Guide
support.forcepoint.com/documentation
Online Support and Contact Information
support.forcepoint.com
Support & Resources
Appliance Information
C Interface IP: Hostname:
admin is the default user name for the Appliance CLI, Forcepoint Security Manager, and Content Gateway Manager.
See the Forcepoint Appliances Getting Started guide for details.
