Advantech UNO-238 V2 Installation and operation manual

UNO-238 V2 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. UNO-238 V2 bare-bone system x 1
2. Startup manual EN\CN\TC for UNO-238 V2 1st Ed
P/N: 2044023800
3. 84W 12V adapter
P/N: XUNO-FSP084-DHAN3
4. Thermal pad (for CPU)
P/N: 1990040776N000
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note:  AcrobatReaderisrequiredtoviewanyPDFle.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
UNO-238 V2
Intel®12th Generation Core i Compact IoT Edge
Computer
Startup Manual
Caution: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER,
DISCARD USED BATTERIES ACCORDING TO
THE MANUFACTURER’S INSTRUCTIONS.
Attention:DANGER D’EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU
LE TYPE ÉQUIVALENT RECOMMANDÉ PAR
LE FABRICANT, JETTENT LES BATTERIES
UTILISÉES INSTRUCTIONS DE S SELON
FABRICANT DES’.
Processor System
• Intel®i7-1265UE 10 core, 1.7 GHz (up to 4.7 GHz)
• Intel®i5-1245UE 10 core, 1.5 GHz (up to 4.4 GHz)
• Intel®i3-1215UE 6 core, 1.2 GHz (up to 4.4 GHz)
Memory
• Supports dual channel DDR5 SODIMM-4800 MHz; Max.
capacity is 64 GB
Graphics
• Intel®Iris Xe®Graphics
Serial Ports
• 2 x RS-232/422/485 (50 to 115.2Kbps)
Ethernet
• LAN A: Intel®i226, 10/100/1000/2500Mbps
• LAN B: Intel®i219-LM, 10/100/1000Mbps
Storage
• 1 x M.2 B Key 2242 (PCIe x1/SATA, USB2.0)
• 1 x M.2 M Key 2280 (PCIe x4, Gen4 NVMe)
Expansion
• 1 x M.2 B-Key 3042/3052 (PCIe x1/SATA, USB 2.0)
• 1 x M.2 E-Key 2230 (PCIe x1, USB 2.0)
• 1 x M.2 M-Key 2280 (PCIe x4, Gen 4 NVMe)
External I/O
• Display: 1 x DP, 1 x HDMI
• USB:
4 x USB 3.2 (Gen2 10Gbps)
2 x USB Type-C (USB3.2 Gen2, supports DP1.4)
The Type-C one at rear side also supports Thunderbolt 4
• Serial: 2 x RS-232/422/485
• CANBus: 2 x CAN2.0 (Combo)
• Others: 1 x GPIO (8 bit)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for UNO-238 V2 at:
Register your products on our website and get 2
months extra warranty for Free at:
http://www.register.advantech.com
Part No. 2044023800 1st Edition
Printed in China September 2023
Packing List (Cont.)

2 UNO-238 V2 Startup Manual
Power Requirement
• Power type: ATX
• Power Input Voltage: 12VDC
• Power Connector: 1 x Terminal block
• Minimum Power Input: 12VDC 7A
ThisproductisintendedtobesuppliedbyaULcertied
powersupplyorULcertiedDCsourcerated12V
DC
7A
minimum. If you need further assistance, please contact
Advantech for further information.
Environmental
• Operational Temperature:
-20~60°Cwith0.7m/sairow
Note: With extended temperature peripherals, please
refer to the optional memory list in Datasheet.
• Storage Temperature: -40 ~ 85°C (-40 ~ 185°F)
• Relative Humidity: 95% @ 60°C (non-condensing)
Physical Characteristics
• Dimensions (W x H x D): 150 x 107 x 60 mm
• Weight: 1.8 kg (3.9 lb)
The board has a number of jumpers that allow you to con-
gureyoursystemtosuityourapplication.Thetablebelow
lists the function of each of the jumpers and connectors.
Connectors
Label Function
DP1 DP connector
HDMI1 HDMI connector
COM 1/2 RS-232/422/485
GPIO GPIO connector
USB 1-4 USB3.2
Type-C 1-2 Type-C
LAN A Intel i226
LAN B Intel i219-LM
CANBus 2 x CAN2.0 (combo)
DC 12V Power connector
The computer is supplied with a battery-powered real-time
clock circuit. There is a danger of explosion if the battery is
incorrectly replaced. Replace only with same or equivalent
type recommended by the manufacturer. Discard used bat-
teries according to the manufacturer’s instructions.
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion.
Specications(Cont.)
Declaration of Conformity
System I/O Interface
Battery
Jumpers and Connectors

UNO-238 V2 Startup Manual 3
Memory Installation
The UNO-238 V2 supports DDR5 SO-DIMM memory
modules. If you require a detailed list of compatible memory
modules, please get in touch with your distributor or sales
representative.
1. Unscrew (1930001241-11*4) and remove the bottom
cover (1960098469N011*1).
2. Unscrew (1930006647-01*4).
3. Unscrew (1930001241-11*4) and remove the top cover
(1960098692T011*1).
4. Apply a thermal pad (1990040776N00*1).
For DDR5 8GB or 16GB
Attach an “Up” thermal pad (1990026727N030*1)
and a “Down” thermal pad (1990040197N020*1).
Simple Maintenance Process Simple Maintenance Process (Cont.)

4 UNO-238 V2 Startup Manual
For DDR5 32GB:
Use an “Up” thermal pad (1990026727N010*1)
and a “Down” thermal pad (1990040197N000*1).
5. Install the top cover (1960098692T011*1) and lock
screws (1930001241-11*4).
6. Secure the lock screws (1930006647-01*4).
Simple Maintenance Process (Cont.)
7. Reinstall the bottom cover (1960098469N011*1) and
lock screws (1930001241-11*4).
Storage Installation
1. Unscrew (1930001241-11*4) and remove the bottom
cover (1960098469N011*1).
Simple Maintenance Process (Cont.)

UNO-238 V2 Startup Manual 5
2. Unscrew (19350304A0*1).
3. Insert the NVME Card and secure it with the lock screw
(19350304A0*1)
4. If using an M-key storage with a capacity greater than
1TB, apply a thermal pad (1990040412N000*1) to the
bottom cover.
5. Reinstall the bottom cover (1960098469N011*1) and
lock screws (1930001241-11*4).
M.2 B Key (LTE module) Installation
The UNO-238 V2 supports M.2 B key modules for both
3042 and 3052.
For B Key for 3052
1. Unscrew (1930001241-11*4) and remove the bottom
cover (1960098469N011*1).
Simple Maintenance Process (Cont.) Simple Maintenance Process (Cont.)

6 UNO-238 V2 Startup Manual
2. Remove the support bracket (1960102502T000) and
unscrew (19350304A0*1).
3. Insert the 5G module in the B key slot and secure it with
the lock screw (19350304A0*1).
4. Apply a thermal pad (1990040198N000*1) to the bot-
tom cover.
5. Reinstall the bottom cover (1960098469N011*1) and
lock screws (1930001241-11*4).
For B Key for 3042
1. Unscrew (1930001241-11*4) and remove the bottom
cover (1960098469N011*1).
2. Unscrew (19350304A0*1).
Simple Maintenance Process (Cont.) Simple Maintenance Process (Cont.)

UNO-238 V2 Startup Manual 7
3. Insert the storage module in the B key slot and secure it
with the lock screw (19350304A0*1).
4. Reinstall the bottom cover (1960098469N011*1) and
lock screws (1930001241-11*4).
Internal USB 2.0 M.2 E Key Installation
1. Unscrew (1930001241-11*4) and remove the bottom
cover (1960098469N011*1).
2. Unscrew (19350304A0*1).
3. Insert the WiFi module in the E key slot and secure it
with the lock screw (19350304A0*1).
4. Reinstall the bottom cover (1960098469N011*1) and lock
screws (1930001241-11*4).
Simple Maintenance Process (Cont.) Simple Maintenance Process (Cont.)

8 UNO-238 V2 Startup Manual
DIN-Rail Mount Installation
1. Take the mounting kit from the accessory box.
2. Secure the bracket to the bottom cover using 3 screws.
Wall Mount and Stand Mount
1. Read these safety instructions carefully.
2. Keep this Startup Manual for later reference.
3. Disconnect this equipment from any AC outlet before
cleaning. Use a damp cloth. Do not use liquid or spray
detergents for cleaning.
4. For plug-in equipment, the power outlet socket must
be located near the equipment and must be easily
accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installa-
tion. Dropping it or letting it fall may cause damage.
7. The openings on the enclosure are for air convection.
Protect the equipment from overheating. DO NOT
COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct
before connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on
it. Do not place anything over the power cord.
10. All cautions and warnings on the equipment should be
noted.
11. If the equipment is not used for a long time, disconnect
it from the power source to avoid damage by transient
overvoltage.
12. Never pour any liquid into an opening. This may cause
reorelectricalshock.
13. Never open the equipment. For safety reasons, the
equipmentshouldbeopenedonlybyqualiedservice
personnel.
14. If one of the following situations arises, get the equip-
ment checked by service personnel:
•The power cord or plug is damaged.
•Liquid has penetrated into the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well, or you cannot get
it to work according to the user’s manual.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRON-
MENT WHERE THE STORAGE TEMPERATURE
MAY GO BELOW -40°C (-40°F) OR ABOVE 85°C
(185°F). THIS COULD DAMAGE THE EQUIPMENT.
THE EQUIPMENT SHOULD BE IN A CONTROLLED
ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE RECOMMENDED
BY THE MANUFACTURER, DISCARD USED BAT-
TERIES ACCORDING TO THE MANUFACTURER’S
INSTRUCTIONS.
17. The sound pressure level at the operator’s position ac-
cording to IEC 704-1:1982 is no more than 70 dB (A).
18. RESTRICTED ACCESS AREA: The equipment should
only be installed in a Restricted Access Area.
19. DISCLAIMER: This set of instructions is given accord-
ing to IEC 704-1. Advantech disclaims all responsibility
for the accuracy of any statements contained herein.
Simple Maintenance Process (Cont.) Safety Instructions

UNO-238 V2 Startup Manual 9
IO Connectors

10 UNO-238 V2 Startup Manual
150.00
162.00
R2.00
R2.70
88.10 81.60 94.60
60.00
107.00
System Dimensions
