ForestAir E-Tech Series User manual

MODELS
Air Handlers : FDAH-24HDC-AHU, FDAH-36HDC-AHU
FDAH-48HDC-AHU, FDAH-60HDC-AHU
Outdoor Units : FDAH-24HDC-CDU, FDAH-36HDC-CDU
FDAH-48HDC-CDU, FDAH-60HDC-CDU
Electric Heaters : ET-1500, ET-2000
Sunrise Tradex Corp.
Saint-Mathieu-de-Beloeil, Quebec, Canada
ETECH-FDAH-18011 © Copyright, Sunrise Tradex Corp., 2018
Thank you for choosing our product. Please read this owner’s manual
carefully before operation and retain it for future reference.
Installation Manual

2
© Copyright, Sunrise Tradex Corp., 2018
Installation Manual
WARNING
WARNING
WARNING
WARNING
Disconnect all power to the unit before installing or servicing. More than one disconnect
switch may be required to discharge the equipment. Hazardous voltage can cause severe
personal injury or death.
This document is the customer's property and must remain with the unit. These instructions do
not cover all the different system variations nor does it provide for every possible contingency
in regard to installation. All phases of this installation must comply with national, state and local
codes. If additional information is required, please contact your local distributor.
1.0 SAFETY
This is a safety alert symbol. When you see this symbol on labels or in manuals, be alert
to the potential for personal injury.
This is an attention alert symbol. When you see this symbol on labels or in manuals, be
alert to the potential for personal injury.
If removal of the blower assembly is required, all disconnect switches supplying power to
the equipment must be discharged and locked (if not in sight of unit) so the eld power wires
can be safely removed from the blower assembly. Failure to do so can cause electrical shock
resulting in personal injury or death.
Because of possible damage to equipment or personal injury, installation, service, and
maintenance should be performed by a trained, qualied service personnel. Consumer
service is recommended only for lter cleaning / replacement. Never operate the unit with the
access panels removed.
These instructions are intended as an aid to qualied, licensed service personnel for proper
installation, adjustment and operation of this unit. Read these instructions thoroughly before
attempting installation or operation. Failure to follow these instructions may result in improper
installation, adjustment, service or maintenance, possibly resulting in re, electrical shock,
property damage, personal injury or death.

3
© Copyright, Sunrise Tradex Corp., 2018
WARNING
WARNING
WARNING
The unit must be permanently grounded. Failure to do so can result in electrical shock
causing personal injury or death.
PROPOSITION 65: This appliance contains berglass insulation. Respirable particles of
berglass are known to cause cancer.
All manufacturer products meet current federal OSHA Guidelines for safety. California
Proposition 65 warnings are required for certain products, which are not covered by the
OSHA standards.
California’s Proposition 65 requires warnings for products sold in California that contain or
produce any of over 600 listed chemicals known to the State of California to cause cancer
or birth defects such as berglass insulation, lead in brass, and combustion products from
natural gas.
All “new equipment” shipped for sale in California will have labels stating that the product
contains and/or produces Proposition 65 chemicals. Although we have not changed our
processes, having the same label on all our productd facilitates manufacturing and shipping.
We cannot always know “when, or if” products will be sold in the California market.
You may receive inquiries from customers about chemicals found in, or produced by, some
of our heating and air conditioning equipment, or found in natural gas used with some of
our products. Listed below are those chemicals and substances commonly associated with
similar equipment in our industry and other manufacturers.
Glass Wool (Fiberglass)
Insulation Carbon Monoxide (CO)
Formaldehyde
Benzene
More details are available at the websites for OSHA (Occupational Safety and Health
Administration) at www.osha.gov and the State of California’s OEHHA (Ofce of
Environmental Health Hazard Assessment) at www.oehha.org. Consumer education is
important since the chemicals and substances on the list are found in our daily lives. Most
consumers are aware that products present safety and health risks, when improperly used,
handled and maintained.
Make sure the blower motor support is tight (3
motor mount bolts), then check to see if wheel is
secured to motor shaft before operating unit.
BLOWER MOTOR SHIPPING BOLT
Installation Manual

4
© Copyright, Sunrise Tradex Corp., 2018
WARNING
2.0 GENERAL
The unit can be positioned for bottom return air in the upow position, left and right return in the
horizontal position, top return in downow position.
This air handler provides the exibility for installation in any upow or downow horizontal
application. The direct drive motors provides a selection of air volume to match any application.
3-speed motors provide selections of airow to meet desired applications.
Top and side power and control wiring, accessible screw terminals for control wiring, all
combine to make the installation easy, and minimize installation cost. Please contact your local
distributor. See g. 1.
Installation Manual
WARNING
The rst 6 inches of supply air plenum and ductwork must be constructed of sheet metal
as required by NFPA 90B. The supply air plenum or duct must have a solid sheet metal
bottom directly under the unit with no openings, registers or exible air ducts located in
it. If exible supply air ducts are used, they may be located only in the vertical walls of
rectangular plenum, a minimum of 6 inches from the solid bottom. Metal plenum of duct may
be connected to the combustible oor base, if not, it must be connected to the unit supply
duct exposed to the supply air opening from the downow unit. Exposing combustible (non-
metal) material to the supply opening of a downow unit can cause a re resulting in property
damage, personal injury or death.
Exception warning to downow :
Installations on a concrete oor slab with supply air plenum and ductwork completely
encased must be not be less than 2 inches of concrete (see NFPA90A).

5
© Copyright, Sunrise Tradex Corp., 2018
2.1 UNIT DIMENSIONS
FIG. 1 DIMENSIONS
SUPPLY AIR
FLANGES ARE PROVIDED
FOR FIELD INSTALLATION
BREAKER SWITCH
(FOR ELECTRIC HEATER ONLY)
LIQUID COPPER LINE CONNECTION
AUXILIARY DRAIN CONNCECTION
19 mm (¾ in) female pipe thread (NPT)
AUXILIARY DRAIN CONNECTION
19 mm (¾ in) female pipe thread (NPT)
PRIMARY DRAIN CONNECTION
19 mm (¾ in) female pipe thread (NPT) UPFLOW UNIT SHOWN.
UNIT MAY BE INSTALLED UPFLOW, DOWNFLOW,
HORIZONTAL RIGHT, OR LEFT AIR SUPPLY.
NOTE: 63.5 CM (25") CLEARANCE IS REQUIRED IN THE FRONT
OF THE UNIT FOR FILTER AND COIL MAINTENANCE.
VAPOR COPPER LINE CONNECTION
LOW VOLTAGE CONNECTION
ELECTRICAL CONNECTIORS
MAY EXIT FROM THE TOP OR EITHER SIDE
HIGH VOLTAGE CONNECTIONS
22.23 mm, 9.12 mm & 18.26 mm knock outs
(7/8",1-23/64", 1-23/32")
Installation Manual
DIMENSIONAL DATA
MODEL "H" "W" "D" "A" UNIT WEIGHT /
SHIPPING WEIGHT
24 1050 mm
(41 ⅜ in)
460 mm
(18 ⅛in)
520 mm
(20 ½ in)
456 mm
(16 in)
48 kg / 54 kg
(106 lb / 119 lb)
36 1180 mm
(46 ½ in)
500 mm
(19 ⅝ in)
550 mm
(21 ⅝in)
456 mm
(18 in)
64 / 71 kg
(141 lb /156 lb)
48 1385 mm
(54 ½ in)
560 mm
(22 in)
610 mm
(24 in)
496 mm
(19 ½ in)
78 kg / 85 kg
(172 lb / 187 lb)
60 1385 mm
(54 ½ in)
560 mm
(22 in)
610 mm
(24 in)
496 mm
(19 ½ in)
78 kg / 85 kg
(172 lb / 187 lb)
262 mm
(10 5/16")

6
© Copyright, Sunrise Tradex Corp., 2018
FIG. 2 DIMENSIONS FOR FRONT CONNECTION COIL
3.0 APPLICATIONS
3.1 VERTICAL UPFLOW
▪ Vertical upow conguration is the factory set on all models (see g. 1).
▪ If return air is to be ducted, install duct ush with oor. Use reproof gaskets of 3.2 to 6.4 mm
(⅛ to ¼ inches) thick between the ducts, unit and oor. Set unit on the oor over the opening.
IMPORTANT : Torque applied to drain connections should not exceed 15 ft-lb (see g.1 and 2).
3.2 VERTICAL DOWNFLOW
Conversion from Vertical Upow to Vertical Downow : A vertical upow unit may be
converted to vertical downow. Remove the door and indoor coil and reinstall 180° from original
position (see g. 3).
IMPORTANT : To comply with certication agencies and the National Electric Code for
horizontal right application, the circuit breaker(s) on eld-installed electric heater kits must be
re-installed following the procedure below so that the breaker switch “ON” position and marking
is up, and “OFF” position and marking is down.
▪ To rotate breaker(s): Rotate one breaker set (circuit) at a time starting with the one on the
right. Loosen both lugs on the load side of the breaker. (Make sure that wires are identied
and are reinstalled into proper breaker). Wires are bundled with wire ties, one bundle going to
the right lug and one bundle going to the left lug.
Installation Manual
14.2 mm
(1 9/16")
74.6 mm
(2 15/16")
74.6 mm
(2 15/16")
71.4 mm
(2 13/16")
7.9 mm
(5/16")
7.9 mm
(5/16")
31.8 mm
(1 1/4")
34.9 mm
(1 3/8")

7
© Copyright, Sunrise Tradex Corp., 2018
3.3 HORIZONTAL
Horizontal right is the default factory conguration for the units.
Horizontal left isn’t the default factory conguration for the units.
Conversion from Vertical to Horizontal : A vertical upow unit may be converted to horizontal
left conguration by removing the indoor coil assembly and reinstalling the coil as detailed
below.
▪ Rotate the unit into the downow position, with the coil compartment on top and the blower
compartment on bottom (see g. 3).
▪ Reinstall the indoor coil 180° from original position. Make sure the retaining channel is fully
engaged unto the coil rail (see g. 3).
▪ Secondary drain pan kits are recommended.
▪ Using a screwdriver or pencil, lift the blue plastic tab with a hole away from the breaker until
the breaker releases from the mounting opening.
▪ With the breaker held in hand, rotate the breaker so that the “ON” position is up, and the
“OFF” position is down as with the default vertical mounting position. Insert the right wire
bundle into the top right breaker lug, making sure all strands of wires are inserted fully into the
lug, and no wire insulation is left in the lug.
▪ Tighten the lug as tightly as possible while holding the circuit breaker. Check wires and make
sure each wire is secure and none are loose. Repeat for the left wire bundle in the left top
circuit breaker lug.
▪ Reposition the breaker by inserting the breaker mounting tab opposite the white pull tab in the
opening, hook the mounting tab over the edge in the opening.
▪ With a screwdriver or pencil, pull the blue tab with a hole away from the breaker while setting
that side of the breaker into the opening. When the breaker is in place, release the tab,
locking the circuit breaker into place in the opening.
▪ Repeat the above operation for the remaining breaker(s) (if more than one is provided).
▪ Reposition the single point wiring jumper bar, if it is used, on the line side of breaker and tighten
securely.
▪ Double check the wires and lugs to make sure everything is secure and tight. Check to make
sure the unit wiring to the circuit breaker lugs match that shown on the unit wiring diagram.
Installation Manual
WARNING
When using the unit with electrical heater, the switch is used only for electrical heater on the
front of panel.

8
© Copyright, Sunrise Tradex Corp., 2018
FIG. 3 VERTICAL & HORIZONTAL APPLICATIONS
(lower front service panel removed)
FIG. 4 INDOOR COIL AND DRAIN PAN SETUP
AIRFLOW
AIRFLOW
DETAIL A
MAKE SURE THE RETAINING
CHANNEL IS FULLY ENGAGED
UNTO THE COIL RAIL.
HORIZONTAL ADAPTER KIT
AUXILIARY HORIZONTAL
DRAIN CONNECTION
PRIMARY DRAIN
CONNECTION
STRAPS
REAR WATER CATCHER
FRONT WATER
CATCHER
TOP AIR STOP
VAPOR LINE CONNECTION
LIQUID LINE CONNECTION
VERTICAL DRAIN PAN
AUXILIARY UPFLOW/DOWNFLOW
DRAIN CONNECTION
Installation Manual
RAILS
RAILS
A
1:4
A

9
© Copyright, Sunrise Tradex Corp., 2018
Installation Manual
WARNING
Horizontal units must be congured for right or left air supply. Horizontal drain pan must be
placed under indoor coil. Failure to use the drain pan can result in property damage.
WARNING
Disconnect all power to the unit before installing or servicing. More than one disconnect
switch may be required to discharge the equipment. Hazardous voltage can cause severe
personal injury or death.
Conversion in Horizontal Direction: Horizontal right air supply can be changed to horizontal
left air supply by removing the indoor coil and reinstalling 180° from original position.
3.4 INSTALLATION IN AN UNCONDITIONED SPACE
IMPORTANT : There are two pairs of coil rails in the air handler for default and counter ow
application. If the air handler is installed in an unconditioned space, the two unused coil rails
should be removed to minimize air handler surface sweating. The coil rails can be easily
removed by taking off the 6 mounting screws from both sides of the cabinet.
4.0 ELECTRICAL WIRING
Field wiring must comply with the National Electric Code (C.E.C. in Canada) and any applicable
local ordinance.
4.1 POWER WIRING
It is important that proper electrical power is available for connection to the unit model
being installed. See the unit nameplate, wiring diagram and electrical data in the installation
instructions.
▪ If required, install a branch circuit disconnect of adequate size, located within sight of, and
readily accessible to the unit.
▪ IMPORTANT : After the electric heater is installed, units may be equipped with one or two
30-60 amp circuit breakers. These breakers protect the internal wiring in the event of a short
circuit and serve as a disconnect. Circuit breakers installed within the unit do not provide
over-current protection of the supply wiring and therefore may be sized larger than the branch
circuit protection.
▪ Supply circuit power wiring must be 75. See Electrical Data in this section for ampacity, wire
size and circuit protector requirement. Supply circuit protective devices may be either fuses or
“HACR” type circuit breakers.
▪ Power wiring may be connected to either the right or left side, or top. Three concentric
knockouts are provided for connection of power wiring to the unit.
▪ Power wiring is connected to the power terminal block in the unit cabinet.

10
© Copyright, Sunrise Tradex Corp., 2018
Installation Manual
WARNING
The unit must be permanently grounded. Failure to do so can result in electrical shock
causing personal injury or death.
4.2 CONTROL WIRING
IMPORTANT : Low voltage Class 2 control wiring should not be run in the conduit with the
main power wiring and must be separated from the power wiring, unless class 1 wire of proper
voltage rating is used.
▪ Low voltage control wiring should be 18 AWG color-coded. For lengths longer than 30 meters
(100 ft), 16 AWG wire should be used.
▪ Low voltage control connections are made to low voltage pigtails extending from the top of the
air handler (upow position - see g. 3). Connections for the control wiring are made with wire
nuts. Control wiring knockouts (15.88 mm (⅝ in) and 22.23 mm (⅞ in) in diameter) are also
provided on the right and left side of the unit for side connection.
▪ See the wiring diagrams attached to indoor and outdoor sections to be connected.
▪ After the installation, make sure the separation of the control wiring and power wiring has
been maintained.
4.3 GROUNDING
▪ Grounding may be accomplished by grounding metal conduit when installed in accordance
with electrical codes to the unit cabinet.
▪ Grounding may also be accomplished by attaching a ground wire(s) to a ground lug(s)
provided in the unit wiring compartment.
▪ Ground lugs are located close to the wire entrance on the left side of the unit (upow). Lugs
may be moved to marked locations near the wire entrance on right side of the unit (upow) if
this alternate location is more convenient.
▪ Use of multiple supply circuits require grounding of each circuit to the lug(s) provided in the
unit.
4.4 ELECTRICAL DATA
MODEL VOLTAGE HERTZ HP RPM SPEEDS CIRCUIT AMP
MAXIMUM CIRCUIT
PROTECTOR
24 208 / 230 60 0.20 701 3 0.95 15 (A)
36 208 / 230 60 0.50 794 3 1.63 15 (A)
48 208 / 230 60 0.50 845 3 2.11 15 (A)
60 208 / 230 60 0.75 963 32.79 15 (A)

11
© Copyright, Sunrise Tradex Corp., 2018
Installation Manual
4.5 ELECTRIC KIT MCA/MOP DATA
HEATER
KIT
MODEL
AIR
HANDLER
MODEL
ELECTRIC
HEATER
(kW)
MINIMUM CIRCUIT
AMPACITY
MAXIMUM FUSE &
BREAKER (HACR)
AMPACITY
FAN SPEED
208 230 208 230 LOW MED HIGH
EHK05A
24
5 27.2 24.6 30 25 ● ●
EHK08A 7.5 40.8 36.9 45 40 ● ●
EHK10A 10 54.4 49.2 60 50 –●
EHK05A
36
5 27.2 24.6 30 25 ● ●
EHK08A 7.5 40.8 36.9 45 40 ● ●
EHK10A 10 54.4 49.2 60 50 ● ●
EHK15A 15 81 74 90 80 –●
EHK20A 20 108 98 110 100 – –
EHK05A
48
5 27.2 24.6 30 25 ● ●
EHK08A 7.5 40.8 36.9 45 40 ● ●
EHK10A 10 54.4 49.2 60 50 ● ●
EHK15A 15 81 74 90 80 –●
EHK20A 20 108 98 110 100 –●
EHK05A
60
5 27.2 24.6 30 25 ● ●
EHK08A 7.5 40.8 36.9 45 40 ● ●
EHK10A 10 54.4 49.2 60 50 ● ●
EHK15A 15 81 74 90 80 –●
EHK20A 20 108 98 110 100 –● ●
Heater kit suitable for AHU 4-way position installation ([●] means available, [–] means not available).
ELECTRIC HEATER KITS
HEATER
KIT
MODEL
DESCRIPTION AIR HANDLER
24 36 48 60
EHK05A 5 kW heat strip ●●●●
EHK08A 7.5 kW heat strip ●●●●
EHK10A 10 kW heat strip ●●●●
EHK15B 15 kW heat strip, double breaker panel –●●●
EHK20A 20 kW heat strip, double breaker panel –●●●
[●] means available, [–] means not available

12
© Copyright, Sunrise Tradex Corp., 2018
5.0 AIRFLOW PERFORMANCE
Airow performance data is based on cooling performance with a coil and no lter in place.
Selecting the appropriate unit size performance table for external static applied to the unit
allows operation within the minimum and maximum limits shown in the table below for both
cooling and electric heat operations.
AIRFLOW PERFORMANCE DATA
MODEL SPEED
CFM (W)
EXTERNAL STATIC PRESSURE - kPa (inch WC)
00.02
(0.1)
0.04
(0.16)
0.05
(0.2)
0.07
(0.3)
0.10
(0.4)
0.12
(0.5)
0.15
(0.6)
0.17
(0.7)
0.20
(0.8)
24
LOW
CFM 646 623 602 592 553 506 453 – – –
RPM 528 591 628 650 728 790 840 – – –
WATT 169.4 166.4 164.5 163 157.5 151.3 146.3 – – –
AMP 0.79 0.78 0.78 0.78 0.77 0.76 0.75 – – –
MED
CFM 815 802 786 771 733 681 613 – – –
RPM 658 701 732 743 790 841 888 – – –
WATT 218 216.6 215.9 214.4 211.4 207.4 203 – – –
AMP 0.96 0.95 0.95 0.95 0.94 0.93 0.92 – – –
HIGH
CFM 1043 993 965 947 920 866 780 695 607 515
RPM 741 769 788 802 837 876 919 956 986 1014
WATT 286.8 279.4 275.6 271.3 267.5 265.4 262.6 256.4 250.1 243
AMP 1.30 1.28 1.26 1.25 1.24 1.22 1.20 1.18 1.17 1.15
36
LOW
CFM 1129 1088 1061 1040 988 941 819 – – –
RPM 642 675 706 732 771 817 853 – – –
WATT 322 312 306 301 289 269 254 – – –
AMP 1.54 1.52 1.51 1.50 1.47 1.42 1.39 – – –
MED
CFM 1317 1268 1237 1217 1157 1111 1027 – – –
RPM 776 810 841 874 905 935 966 – – –
WATT 360 354 348 345 335 323 309 – – –
AMP 1.69 1.67 1.66 1.65 1.63 1.60 1.57 – – –
HIGH
CFM 1643 1581 1544 1518 1446 1356 1261 1123 915 812
RPM 868 883 895 906 931 955 978 1013 1028 1050
WATT 463 451 443 438 429 415 401 371 356 343
AMP 2.22 2.20 2.18 2.17 2.14 2.12 2.09 2.03 1.99 1.96
48
LOW
CFM 1471 1427 1395 1374 1316 1247 1180 – – –
RPM 694 732 753 769 803 833 864 – – –
WATT 381 376 372 370 364 357 349 – – –
AMP 1.66 1.64 1.63 1.62 1.60 1.58 1.55 – – –
MED
CFM 1729 1678 1646 1625 1558 1491 1402 – – –
RPM 790 817 833 845 876 898 920 – – –
WATT 485 477 473 470 460 451 440 – – –
AMP 2.14 2.12 2.09 2.08 2.06 2.03 1.99 – – –
HIGH
CFM 2045 1992 1951 1928 1847 1763 1677 1563 1450 1317
RPM 895 920 932 938 956 972 987 1002 1015 1030
WATT 641 627 617 612 596 582 566 546 528 507
AMP 2.86 2.82 2.80 2.78 2.73 2.68 2.64 2.57 2.52 2.45
60
LOW
CFM 1786 1740 1709 1688 1630 1562 1489 – – –
RPM 830 843 849 856 890 921 942 – – –
WATT 584 569 560 552 536 516 497 – – –
AMP 2.64 2.59 2.55 2.54 2.58 2.42 2.37 – – –
MED
CFM 2140 2071 2039 2006 1932 1799 1677 – – –
RPM 917 930 938 943 957 970 990 – – –
WATT 645 630 623 617 602 585 569 – – –
AMP 2.87 2.81 2.78 2.76 2.71 2.65 2.59 – – –
HIGH
CFM 2357 2276 2225 2188 2100 2004 1902 1764 1554 1393
RPM 964 976 982 990 1000 1012 1022 1032 1042 1063
WATT 754 733 718 710 693 673 650 630 607 575
AMP 3.34 3.27 3.22 3.19 3.12 3.05 2.98 2.91 2.83 2.71
Installation Manual

13
© Copyright, Sunrise Tradex Corp., 2018
The air distribution system has the greatest effect on airow. The duct system is totally
controlled by the contractor. For this reason, the contractor should use only industry-recognized
procedures.
Heat pump systems require a specied airow. Each ton of cooling requires between 350 and
450 cubic feet of air per minute (CFM), or 400 CFM nominally.
Duct design and construction should be carefully done. System performance can be lowered
dramatically through bad planning or workmanship.
Air supply diffusers must be selected and located carefully. They must be sized and positioned
to deliver treated air along the perimeter of the space. If they are too small for their intended
airow, they become noisy. If they are not located properly, they cause drafts. Return air grills
must be properly sized to carry air back to the blower. If they are too small, they also can cause
noise.
The installers should balance the air distribution system to ensure proper quiet airow to all
rooms in the home. This ensures a comfortable living space.
An air velocity meter or airow hood can give a reading of system CFM.
6.0 DUCTWORK
Field ductwork must comply with the National Fire Protection Association NFPA 90A, NFPA 90B
and any applicable local ordinances.
Sheet metal ductwork run in unconditioned spaces must be insulated and covered with a vapor
barrier. Fibrous ductwork may be used if constructed and installed in accordance with SMACNA
Construction Standard on Fibrous Glass Ducts. Ductwork must comply with National Fire
Protection Association as tested by U/L Standard 181 for Class I Air Ducts. Check local codes
for requirements on ductwork and insulation.
▪ Duct system must be designed within the range of external static pressure the unit is designed
to operate against. It is important that the system airow be adequate. Make sure the supply
and return ductwork, grills, special lters, accessories, etc. are accounted for in the total
resistance. See airow performance tables in this manual.
▪ Design the duct system in accordance with “ACCA” Manual “D” Design for Residential Winter
and Summer Air Conditioning and Equipment Selection. Latest editions are available from :
“ACCA” Air Conditioning Contractors of America, 1513 16th Street, N.W., Washington, D.C.
20036. If the duct system incorporates exible air duct, be sure pressure drop information
(straight length plus all turns) shown in the “ACCA” Manual “D” is accounted for in the system.
▪ Supply plenum is attached to the 19 mm (¾ in) duct anges supplied with the unit. Attach
anges around the blower outlet.
▪ IMPORTANT : If an elbow is included in the plenum close to the unit, it must not be smaller
than the dimensions of the supply duct ange on the unit.
▪ IMPORTANT : The front ange on the return duct if connected to the blower casing must not
be screwed into the area where the power wiring is located. Drills or sharp screw points can
damage insulation on wires located inside the unit.
▪ Secure the supply and return ductwork to the unit anges using proper fasteners for the type
of duct used, and tape the duct-to-unit joint as required to prevent air leaks.
Installation Manual
WARNING
Do not, under any circumstances, connect the return ductwork to any other heat producing
device such as a replace insert, stove, etc. Unauthorized use of such devices may result in
re, carbon monoxide poisoning, explosion, personal injury or property damage.

14
© Copyright, Sunrise Tradex Corp., 2018
7.0 REFRIGERANT CONNECTIONS
Keep the coil connections sealed until refrigerant connections are made. See the installation
instructions for the outdoor unit for details on line sizing, tubing installation, and charging
information. The coil is shipped at no charge. Evacuate the system before charging with
refrigerant. Install the refrigerant tubing so that it does not block the service access to the front of
the unit.
Nitrogen should ow through the refrigerant lines while brazing.
Use a brazing shield to protect the cabinet’s paint and a wet rag to protect the rubber grommet
from being damaged by torch ames. After the refrigerant connections are made, seal the gap
around the connections with pressure sensitive gaskets.
7.1 CONDENSATE DRAIN TUBING
Consult local codes for specic requirements.
1. When making drain tting connections to the drain pan, use a thin layer of teon paste,
silicone or teon tape to seal.
2. When making drain tting connections to the drain pan, do not overtighten. Overtightening
ttings can split the pipe connetions on the drain pan.
FIG. 5 CONDENSATE DRAIN TRAP
CONDENSATE DRAIN TRAP
DO NOT OPERATE UNIT WITHOUT A
CONDENSATE DRAIN TRAP.
UNIT
DO NOT OVERTIGHTEN DRAIN FITTING
UNIT MUST BE SLIGHTLY INCLINED TOWARD
DRAIN CONNECTION
TO APPROVED DRAIN
Installation Manual
76,2 mm
76,2 mm

15
© Copyright, Sunrise Tradex Corp., 2018
▪ Install drain lines so that they do not block the service access to the front of the unit. Minimum
clearance of 61 cm (24 inches) is required for lter, coil or blower removal and service access.
▪ Make sure the unit is leveled or pitched slightly toward the primary drain connection so that
water will drain completely from the pan (see g. 5).
▪ Do not reduce the drain line size less than the connection size provided on the condensate
drain pan.
▪ All drain lines must be pitched downward away from the unit a minimum of 3.2 mm (⅛ in) per
30.5 cm (1 ft) of line to ensure proper drainage.
▪ Do not connect the condensate drain line to a closed or open sewer pipe. Run the condensate
to an open drain or run the line to a safe outdoor area.
▪ The drain line should be insulated where necessary to prevent sweating and damage due to
condensate forming on the outside surface of the line.
▪ Make provisions for disconnecting and cleaning of the primary drain line should it become
necessary. Install a 76.2 mm (3 inch) trap in the primary drain line as close to the unit as
possible. Make sure that the top of the trap is below the connection to the drain pan to allow
the complete drainage of the pan (see g. 5).
▪ Auxiliary drain line should be run to a place where it will be noticeable if it becomes
operational. Homeowner should be warned that a problem exists if water should begin running
from the auxiliary drain line.
▪ Plug the unused drain connection with the plugs provided in the parts bag, using a thin layer
of teon paste, silicone or teon tape to form a water tight seal.
▪ Test the condensate drain pan and drain line after installation is complete. Pour water into the
drain pan, enough to ll the drain trap and line. Check to make sure the drain pan is draining
completely, no leaks are found in drain line ttings, and water is draining from the termination
of the primary drain line.
8.0 AIR FILTER (not factory-installed)
▪ External lter or other means of ltration is required. Units should be sized for a maximum of
1.524 m/s (300 ft/min) air velocity or what is recommended for the type lter installed.
Filter application and placement are critical to airow, which may affect the heating and cooling
system performance. Reduced airow can shorten the life of the system’s major components,
such as motor, limits, elements, heat relays, evaporator coil or compressor. Consequently,
we recommend that the return air duct system have only one lter location. For systems with
a return air lter grill or multiple lter grills, can have a lter installed at each of the return air
openings.
If adding high efciency lters or electronic air ltration systems, it is very important that the
airow is not reduced. If airow is reduced the overall performance and efciency of the unit will
be reduced. It is strongly recommended that a profesional installation technician is contacted to
ensure correct installation of such ltration systems.
IMPORTANT : DO NOT DOUBLE FILTER THE RETURN AIR DUCT SYSTEM. DO NOT
FILTER THE SUPPLY AIR DUCT SYSTEM. THIS WILL CHANGE THE PERFORMANCE OF
THE UNIT AND REDUCE AIRFLOW.
Installation Manual
WARNING
Do not operate the system without lters. A portion of the dust carried in the air may
temporarily lodge in the duct runs and at the supply registers. Any circulated dust particles
could be heated and charred by contact with the air handler elements. This residue could soil
ceilings, walls, drapes, carpets and other articles in the house. Soot damage may occur with
lters in place, when certain types of candles, oil lamps or standing pilots are burned.

16
© Copyright, Sunrise Tradex Corp., 2018
9.0 FILTER INSTALLATION DIMENSIONS
FIG. 6 EXTERNAL FILTER BASE
FILTER RAILS
FILTER
COVER
MANUAL
BOLT
RETURN AIR OPENING DEPTH
NOTE:
Air lter is factory supplied (optional)
Installation Manual
DIMENSIONAL DATA
MODEL FILTER SIZE WIDTH DEPTH HEIGHT RETURN AIR
WIDTH
RETURN AIR
LENGHT
24 406 x 508 mm
(16 x 20 in
426 mm
(16.8 in)
518 mm
(20.4 in)
25.4 mm
(1 in)
497.8 mm
(19.6 in) 375.9 mm (14.8 in)
36 457 x 508 mm
(18 x 20 in
466 mm
(18.3 in)
548 mm
(21.6 in)
25.4 mm
(1 in)
528.3 mm
(20.8 in)
414 mm
(16.3 in)
48 / 60 508 x 559 mm
(20 x 22 in
526 mm
(20.7 in)
608 mm
(23.9 in) 25.4 mm (1 in)
584.2 mm
(23 in)
477.5 mm
(18.8 in)
AIR FILTER REMOVAL
1. Remove bolts manually, remove air lter cover (see g. 6).
2. Hold the edge of the air lter and extract out.
3. Clean the air lter (vacuum cleaner or water may be used to clean the air lter). If the dust
accumulation is too heavy, use a soft brush and a mild detergent to clean the lter and leave it
out to dry in a cool place.

17
© Copyright, Sunrise Tradex Corp., 2018
1
230 V / 60 Hz
CONNECTING PIPE
WATERPROOF COVERSIGNAL CORD
DRAIN TUBE
The left side of the unit must be
have 45 to 50 cm (17 23/32" to
19 11/16") of clearance, 10 cm
(4") at the back
HIGH PRESSURE VALVE
LOW PRESSURE VALVE
SERVICE VALVE
10 cm
50 cm
Installation Master Plan

18
© Copyright, Sunrise Tradex Corp., 2018
24K / 36K OUTDOOR UNIT
Parts List
NO. PART QUANTITY
1 Top panel 1
2 Back grill 1
3 Outdoor fan 1
4 Condenser 1
5 Handle 1
6 Front grill 1
7 Front panel 1
8 Bottom plate 1
9Filter capacitor 1
10 Partition board 1
11 Reactor 1
12 Compressor jacket 1
13 Compressor 1
14 Outdoor fan 1
15 Reserving valve 1
16 Front panel 1
17 Gas valve 1
NO. PART QUANTITY
18 Liquid valve 1
19 Capillary 1
20 Rev valve coil 1
21 Side panel 1
22 Access plate 1
23 Capacitor clips 1
24 Compressor capacitor 1
25 Wire clip 1
26 Electric box 1
27 Fan motor capacitor 1
28 Outdoor PCB 1
29 Module 1
30 Radiator 1
31 Motor bracket 1
32 Electronic expansion valve 1
33 High & low pressure switch 1

19
© Copyright, Sunrise Tradex Corp., 2018
48K / 60K INDOOR UNIT
Parts List
NO. PART QUANTITY
1 Electric box 1
2 Side rail network 1
3 Back grill 1
4 Access plate 1
5 Side panel 1
6 Pipeline 1
7 Gas valve 1
8 Liquid valve 1
9Storage tank 1
10 Compressor 1
11 Compressor feet 3
12 Motor bracket 1
13 Outdoor motor 2
14 Outdoor fan 1
NO. PART QUANTITY
15 Handle 1
16 Front panel 1
17 Top panel 1
18 Control panel 1
19 Modules 1
20 Main board 1
21 Terminal 1
22 Electrical inductance 1
23 Gas valve 1
24 Liquid valve 1
25 Partition board 1
26 Chassis 1
27 Electronic expansion valve 1

20
© Copyright, Sunrise Tradex Corp., 2018
LED INDICATORS DESCRIPTION
COOLING MODE
HEATING MODE
VENTILATION MODE
DEHUMIDIFICATION MODE
AUTOMATIC MODE
Thermostat
