Zoning NETBOX WIFI User manual

NETBOX WIFI
Installation Manual
v22.06 [EN]
Technical Support Service
Tel. [phone]
The installation should be carried out by authorised personnel only. Perform the entire
installation without supply voltage. Protect the unit with the usual devices.

2
Cloud NetBox

3
Cloud NetBox
Description ................................................................................................................4
Incompatibilities .......................................................................................................4
Before Starting..........................................................................................................5
Access to the Internet ...................................................................................... 5
Activate Bluetooth & GPS................................................................................ 5
Mobile device with internet & Wi-Fi ................................................................ 5
Start-up......................................................................................................................5
Wiring diagram.................................................................................................. 5
Create account and APP installation ............................................................... 6
Add installation .........................................................................................................7
Delete installation or system ...................................................................................8
NetBox reset .............................................................................................................9
Most common errors ................................................................................................9
Technical characteristics ...................................................................................... 10
Guarantee ............................................................................................................. 10

4
Cloud NetBox
A. Description
The NetBox device allows the ZONING system to
connect with a WI-FI net and control the multi-
zone system through an user friendly remote
APP.
1. Control LED’s
• Power supply
• BT: Bluetooth
• SERVER: NetBox - Internet communication
• ACT485: NetBox - ZITY communication
2. Pairing button
3. Power supply 12Vdc
4. Communication port RS485/REM to ZITY
B. Incompatibilities
The NetBox communication interface, is compatible with the following control panels
& thermostats:
• ZITY-RC V7 or higher (V7/8 just unidirectional control)
• ZITY-W V7 or higher.
• ZOE-RC a V05 or higher (just unidirectional control)
• ZEBRA
• ZEUS-RC V3 (unidirectional & bidirectional control)
The features allowed by the Netbox device correspond to the ones allowed in the in-
stalled control panels.
The minimum requirements for the APP are :
• Android V4.4. or higher
• iOS 9.0 or higher.

5
Cloud NetBox
C. Before starting:
Before doing the start-up process, please ensure the availability of:
• Internet access : the internet connection is required by the Netbox during the
start-up and the normal function fo the device.
• Activate Bluetooth & GPS: Just during the registration process, the Bluetooth and
the Location need to be activated.
• Mobile device with internet & Wi-Fi . An Smartphone or Tablet with internet and
WIFI is required to use the Netbox device (1) .
1The related cost of the internet connection are not included in the Netbox device.
D. Start-up.
Before start using the Netbox is necessary to wire all the system and create the
user account. Follow the instructions below to complete the process.
• Wiring diagram: 4 wires should connected, 2 for the power supply and 2 for the
communication. Respect the polarity in both cases.
1. Connect the communication bus(Rs485) from the Netbox to the remote bus of
the ZITY (Shielded cable 2x0.5mm2)
2. Connect the power supply (12Vdc) in the DC Power Output of the ZITY control
panel (2). (Recommended cable 2x0.5mm2)

6
Cloud NetBox
• Create account and APP installation: First of all, the APP should be installed and
create a user account to grant access at the cloud service.
1. Download APP Zoning 2.0, at Playstore or Appstore
Zoning 2.0
(1) In the case of not receiving the confirmation e-mail, check the JUNK box and if the e-mail address is
correct. Otherwise re-submit the request.
2. Access to the APP and create an account
A. Register mail/password and press Create
An e-mail will be sent to confirm the account(1)
B. Once the account is created, introduce the mail &
password and press “Enter” to access to the APP.
C. Press “I Forgot the password” in case you forgot
it. Follow this steps(1)
D. Press “Demo” if you want to feel the experience
of how the system works. This will simulate a
“fake” installation. It is not necessary to have nor
user neither Netbox.
B
A
C
D

7
Cloud NetBox
E. Add installation: Once created the user, it should be linked with the installation to
control:
1. Add installation
Enter the name of the installa-
tion and press “Apply”
5
Establecer conexión
2. Link NetBox
Press over the created installa-
tion and press “link NetBox”.
Select “Normal” type of installa-
tion.
3. Find NetBox
Activate the Bluetooth and the
location in the mobile device.
Press the Pairing button for 1 s.
The ACT485 Led start flashing.
In the case that this warning comes
out, please allow permission to the
APP.
4. Link Netbox
Press over the detected Netbox.
The number of systems (ZITY)
and zones, should match with
the ones installed.
The BT led turns on, and the
ACT485 continue to flash.
5. Setup Wi-Fi
Select the WIFI where the Net-
box is to be connected (Band 2.4
GHz), and fill with the WIFI pass-
word.
Press “Apply”.
The BT led will turn off, and the
other Leds (SERVER and ACT485)
will flash.
From that moment on, we can
start enjoying the APP to control
our zoning system.

8
Cloud NetBox
E. Delete installation or existing systems
1. Delete installation
Press the ”Setting” button in the
installation screen
Press the “Bin” button of the
installation we want to delete.
Press “yes”. The installation
will be removed from the
active user.
1. Delete system
Press the ”Setting” button in the
system screen
Press the “Bin” button of the
system we want to delete.
Press “yes”. The system will
be removed from the active
user.
The Netbox will remain as default from the factory, if all the systems or installations are
deleted.

9
Cloud NetBox
F. Reseting the NetBox in case of changing the WIFI net, or removing from the installa-
tion, the Netbox can be reseted.
Press to “Pairing button” for 10 s. The Led’s SERVER, ACT785 will turn off and just
the Power led will remain turned on.
>10s
G. Most common errors
1. The POWER LED is turned off
• Check the wiring cable (12Vdc, +/-) from the ZITY to the NetBox.
2. The ACT485 led is turned off
• There is no communication between the NetBox and the ZITY control panel. Check the
wiring and polarity of the communication wire (RS485/Rem) from the ZITY to the Netbox.
3. SERVER Led flashing
• There is no communication with the server. Reset the power supply of the device and
check that the WIFI is working properly.
4. APP doesn’t recognize the user or the password
• Check that the e-mail address is correct.
• Check the password, and in case is continues not working, press “I forgot the password”
and follow the instructions.
5. Any zoning system is detected when scanning with the APP
• Check the wiring and polarity of the (RS485/Rem) wire from ZITY to the NetBox.

10
Cloud NetBox
NetBox
• Power supply 12 Vdc. (recommended wire S=2x0.5mm2)
• Consumption: 0.1A
• Bus RS485/Rem: Modbus protocol RTU 9600/8/N/1
• Dimensions (mm): 90 x 90 x 25
• Weight: 0.15kg
No desechar los Aparatos Eléctricos y Electrónicos, como desechos urbanos. Estos
aparatos deben ser retirados para poder ser reciclados. Actuar según la legislación en
vigor.
WEE (RAEE)
H. Technical characteristics
MADEL ATD hereby declares that NetBox complies with the essential requirements and any
other applicable or enforceable provisions of ElectroMagnetic Compatibility (EMC) standard for
radio equipment and services EN 301-489-17 - V3.2.3.
WARRANTY
MADEL ATD guarantees all its products against production defects for a period of two (2) years. This
period will start from the date of delivery of the goods to the DISTRIBUTOR. The warranty will only cover
replacement of defective products, not including labour, travel, replacement of other damaged products,
etc., or any other disbursement, expenses or consequential damages. The warranty will not cover the
damage incurred in the products due to iincorrect installation, h a n d l i n g or storage in p o o r
conditions.
The procedure to follow in the case of return of the Madel ZONING system under warranty is as follows: If
there is any problem, you should contact MADEL technical support service (902.550.290) who will try to
solve any problems and answer any questions about the installation. It is important to call from the place
where the equipment is installed in order to carry out the necessary tests to diagnose the equipment. If any
anomaly is detected, returning the equipment for factory inspection will be authorised. Our technical
support will provide a written authorisation for the return of the equipment under warranty. This authorisa-
tion can only be completed by Madel technical staff and should be affixed to the equipment. It will also
serve for monitoring its return, which should be made through your usual distributor.
All returned equipment must be in perfect conditions of use and must have all the initial additional compo-
nents, such as sensors, antenna, etc.
