Fortinet fortigate 90d User manual
July 05, 2013
01-500-199105-20130705
Copyright© 2013 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, and FortiGuard®, are registered trademarks of Fortinet, Inc., and other Fortinet
names herein may also be trademarks of Fortinet. All other product or company names may be trademarks of their respective owners. Performance metrics
contained herein were attained in internal lab tests under ideal conditions, and performance may vary. Network variables, different network environments
and other conditions may affect performance results. Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties,
whether express or implied, except to the extent Fortinet enters a binding written contract, signed by Fortinet’s General Counsel, with a purchaser that
to performance in the same ideal conditions as in Fortinet’s internal lab tests. Fortinet disclaims in full any guarantees. Fortinet reserves the right to change,
modify, transfer, or otherwise revise this publication without notice, and the most current version of the publication shall be applicable.
FortiGate/FortiWiFi 90D
QuickStart Guide
Register your Fortinet product to receive:
• Technical Support
• New product features
• Protection from new threats
Vous devez enregistrer le produit pour
recevoir:
• Support technique
• Nouvelles fonctionnalitées du produit
• Protection contre de nouvelles menaces
La reistrazione ti permette di usufruire di:
• Supporto Tecnico
• Nuove funzionalita
• Proteezione dalle ultime minaccce
Register for Support
Debe registrar el producto para recibir:
• Apoyo técnico
• Nuevas funcionalidades del producto
• Protección contra ataques
登録のお願い
本日、フォーティネット製品の登録をしてください。
登録すると次のメリットがあります。
テクニカルサポート•新機能の追加•新しい脅威
への防御
请马上注册
您的飞塔产品
您在注册以后才能得到技术支持、新产品特
点信息、最新威胁防护
http://support.fortinet.com/
Toll free: 1 866 648 4638
Phone: 1 408 486 7899
Fax: 1 408 235 7737
Email: [email protected]
5
Box Includes
4
USB Cable Ethernet Cable
Power Cable
2 Wireless Antennae
(Wireless models only)
Power Adapter
Before You Begin
It is normal to not require a hostname
but your ISP may require it.
Hostname
Write down details that you may need from your network administrator or ISP.
T1/E1, Static broadband, Cable, or DSL with a static IP
IP Address Subnet Mask
Cable Modem DHCP
Default Gateway Primary/Secondary DNS
DSL PPPoE
Username
Password
QuickStart Guide Video
http://forti.net/vqsg
76
A
https://
Basic Connections
Connect your device to a power outlet and an Internet connection.
This is usually a modem, but could also be another device on your network.
1
Power Connection
WAN1
Internet
LAN port 14
Web-based Manager
1. Connect the Ethernet cable.
2. Visit 192.168.1.99 in your web browser.
3. Login using username “admin” and no password.
4. Click “Wizard” in the top right corner.
5. and save your settings.
6. Register your device from the dashboard page.
Web Browser with Ethernet cable
FortiGate Setup Options
2
Web Browser
Setup Wizard (p.7) With FortiExplorer (pp.8-9)
(pp.12-13)
OS X
AB
CTerminal Emulation
(p.10-11)
D
98
B
USB MGMT
FortiExplorer Setup Wizard
1. Follow prompts or click “Register” to register your device with FortiCare.
2. Click “Setup Wizard”.
3. Login using username “admin” and no password.
4. Follow Setup Wizard steps.
5. Click to complete the setup of your device.
Windows/OS X with USB
Microsoft Windows Install
2. Connect the USB cable and launch
FortiExplorer if it does not appear
automatically.
Mac OS X Install
2. Double-Click the and drag
the FortiExplorer icon to the Applications
folder.
3. Connect the USB cable.
4. Click the FortiExplorer icon to launch
the application.
1. Download FortiExplorer from http://forti.net/fexp.
10 11
CTerminal Emulation with Console Cable
To Connect to the CLI (Console Models Only)
1. Connect the FortiGate unit console port to the management computer using a standard
console cable (not provided).
2. Start a terminal emulation program on the management computer.
Use the following settings:
Baud Rate: 9600
Data bits: 8
Parity: None
Stop bits: 1
Flow Control: None
3. Press Enter on your keyboard to connect to the CLI.
4. Login using username “admin” and no password. You can now proceed with
A list of commands can be found at http://forti.net/cli.
Get started by typing “?” for a list of available commands.
Begin typing a command and type “?” for a list of available ways to complete.
For example
A comprehensive reference guide with all commands can be found at http://forti.net/cli.
1312
USB Port
http://forti.net/fexp-ios
http://forticlient.com
iPhone/iPad/iPod Touch with Apple USB cable
FortiExplorer App
1. Download the iOS FortiExplorer App to your device from http://forti.net/fexp-ios.
2. Use your Apple USB cable to connect to the USB port.
3. Launch the FortiExplorer App and select the device model.
4. Login using username “admin” and no password.
D
14 15
Status
Booting up
Operating normally
PWR
On
Off
WAN 1 & 2
Connected at 1Gbps
Transmitting & receiving data at 1Gbps
Connected at 10/100Mbps
Transmitting & receiving data at 10/100Mbps
No link established
LAN Ports 1 - 14
Connected at 1Gbps
Transmitting & receiving data at 1Gbps
Connected at 10/100Mbps
Transmitting & receiving data at 10/100Mbps
No link established
WiFi (Wireless models only)
Connected
No connection
Alarm
Major alarm
Minor alarm
No alarm
HA
Operating
HA disabled
USB
(USB A)
USB MGMT
(USB mini-B)
LAN Ports 1 - 14 (RJ-45)
Gigabit Ethernet 14-port switch
connection for the internal network
WAN 1 & 2 (RJ-45)Power Connection
12V DC, 2.5A
100-240V AC, 50-60Hz adapter
WAN1
WAN2
USB
DC+12V
5 1
2
3
4
USB
MG MT 681012
91113
14
7
Device Guide
FortiGate/FortiWiFi 90D
Internet
POWER STATUS ALARM HA WIFI
W AN 1
W AN 2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CONSOLE
Console (Console models only)
Optional connection to the
management computer.
Provides access to the CLI
16
More Information
16
FortiGate Cookbook
Advanced installing and setup, networking, security policies
Authentication, Logging and reporting.
http://forti.net/cookbook
Training Services
Course descriptions, availability, schedules, and locations of
training programs in your area.
http://forti.net/training
CLI Reference
http://forti.net/cli
FortiOS Handbook
http://forti.net/handbook
Industry Canada Equipment Standard for Digital Equipment (ICES) – Canada
CAN ICES-3 (B) / NMB-3 (B)
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d’Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux
conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé
avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.
Caution: The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems. High-
power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/
or damage to LE-LAN devices.
Avertissement:
de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de
radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars
pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
This device has been designed to operate with an antenna having a maximum gain of 2dbi, 3dbi for 2.4GHz and 1dbi, 2dbi, 4.5dbi, 6dbi for 5GHz. Antenna having a
higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary for successful communication.
Ce dispositif a été conçu pour fonctionner avec une antenne ayant un gain maximal de 2dbi, 3dbi for 2.4GHz and 1dbi, 2dbi, 4.5dbi, 6dbi for 5GHz. Une antenne à gain
plus élevé est strictement interdite par les règlements d’Industrie Canada. L’impédance d’antenne requise est de 50 ohms.
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peutfonctionner avec une antenne d’un type et d’un gain maximal (ou inférieur)
approuvé pourl’émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectriqueà l’intention des autres utilisateurs, il faut choisir le type
d’antenne et son gain de sorte que lapuissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l’intensité nécessaire àl’établissement d’une communication
satisfaisante.
European Conformity (CE) - EU
This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to your local regulations.
IMPORTANT: Switzerland: Annex 4.10 of SR814.013 applies to batteries.
Rack mount instructions
Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room
the manufacturer.
Reduced Air Flow -
Mechanical Loading - Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to uneven mechanical loading.
Circuit Overloading - Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have
on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.
Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct
connections to the branch circuit (e.g. use of power strips).
Grounding: Ensure your Fortinet product is connected and properly grounded to a lightning and surge protector.
WAN or LAN connections that enter the premises from outside the building should be connected to an Ethernet CAT5 (10/100 Mb/s) surge protector.
Shielded Twisted Pair (STP) Ethernet cables should be used whenever possible rather than Unshielded Twisted Pair (UTP).
Do not connect or disconnect cables during lightning activity to avoid damage to your Fortinet product or personal injury.
Electrostatic discharge (ESD) can damage Fortinet equipment. Only perform the procedures described in this document from an ESD workstation. If no such station is
available, you can provide some ESD protection by wearing an anti-static wrist strap and attaching it to an available ESD connector or other bare metal object.
Operating temperature: 0 - 40°C (32 - 104°F)
Storage temperature: -25 - 70°C (-13 - 158°F)
Humidity: 20 to 90% non-condensing
Operating Altitude: <2250m (7400ft)
Regulatory Notices
Federal Communication Commission (FCC) – USA
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received; including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if
it is not installed and used in accordance with the instruction manual, it may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNING:
equipment.
Radiation Exposure Statement (Wireless models only):
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Caution: Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
UL/cUL & CE/CB
Safety Cautions and Warnings
Fortinet.com
