Users Manual
FPM-320 Monitor
Copyright 2011 Forward View Displays 3311 N Kennicott Ave.
http://www.fvdnow.com Arlington Heights, IL 60004
+1.866.688.4035
Getting Familiar with the FPM-320 Monitor Controls
1. AC On/Off- located on right side of monitor (from front)
2. Remote Control Unit- provides access to user controls.
3. Local Switch control- buttons to provide the same functions as remote.
4. Input Panel- location for all video source inputs
#1 AC On/Off
Set Sound Set Video style
style
User control Navigation keys
while in OSD mode
Turn on OSD
Select input source
View input Change aspect ratio
source
#2 Remote Control Unit Local Remote control
Switch Control #3 receiving window
Operating the Monitor
1. Plug the monitor into a suitable AC source.
2. Turn the On/Off switch (#1) to On and note the green LED indicator in the Remote Control Receiving window.
3. With Remote Control Unit: Point the Remote Control Unit at the Remote Control Receiving Window and press
the On/Off button on the remote. Note that the green LED goes out and within 10-15 seconds the display lights
up.
4. With Local Switch Controls: Press either the CH – or CH + switch. Note that the green LED goes out and within
10-15 seconds the display lights up.
5. Connect all inputs to the correct locations at the Input Panel (#4).
6. Use the Source button on the Remote Control Unit and select the input which matches what was connected in
step 4.
7. Refer to the screen shots on the following page to decide the optimum setup for your monitor.
Rear of cabinet
USB Flash drive (photos, etc)
Right Audio Out
Right Audio Out
CVBS (Video) Out
Right Audio In
Left Audio In
Y Pb Pr (Component) In
HDMI 1 HDMI 2 PC CVBS Left Right PC
(VGA) (Video) Audio
Inputs

Users Manual
FPM-320 Monitor
Copyright 2011 Forward View Displays 3311 N Kennicott Ave.
http://www.fvdnow.com Arlington Heights, IL 60004
+1.866.688.4035
To Change or see which Source (Input) is selected
Press the Source button on the Remote or Local Switch Control.
This image will appear in the upper left corner of the display.
Use the UP and Down arrows to select the desired Input, then press OK.
On Screen Display (OSD) Menu Options
Picture Mode Contrast Brightness
Standard 50 50
Soft 40 47
Bright 60 53
Aspect Ratio Full- 16:9 4:3
Color Standard / Warm / Cool
Treble Bass
Sound Mode Standard 50 50
Movie 30 30
Music 65 65
Tools Mode Language
Duration 15 30 45 60 seconds
Transparency 0 – 100 %
Sleep Timer Off 15 30 45 60 90
120 240 Minutes
Recall ** Reset to Factory Defaults **
