LITEMAX DLF1858-A User manual

LITEMAX Electronics Inc. Page 1
LITEMAX
DLF1858-A / DLH1858-A V1
Sunlight Readable 18.5” LED B/L LCD
User Manual
Approved by
Checked by
Prepared by
Ming
Jacky
Eric
LITEMAX Electronics Inc.
8F, No.137, Lane 235, Bau-chiau Rd.,
Shin-dian Dist., New Taipei City, Taiwan
R.O.C.
Tel : [phone]
Fax: [phone]
Homepage: http://www.litemax.com

LITEMAX Electronics Inc. Page 2
Record of Revision
Version and Date
Page
Old Description
New Description
Remark
July /20/2019
all
Initial release

LITEMAX Electronics Inc. Page 3
Contents
Record of Revision............................................................................................................................2
Contents............................................................................................................................................3
1General Description..................................................................................................................4
1.1 Features.............................................................................................................................4
1.2 General Specifications........................................................................................................4
1.3 Absolute Maximum Ratings................................................................................................5
2Electrical characteristics...........................................................................................................6
2.1 TFT LCD Module..............................................................................................................6
2.2 Signal Characteristic ..........................................................................................................8
2.3 The input data format.........................................................................................................9
2.4 Signal Description............................................................................................................10
2.5 Timing Characteristics......................................................................................................12
2.6 Timing Diagram...............................................................................................................12
2.7 Power ON/OFF Sequence.................................................................................................13
3Connector& PinAssignment..................................................................................................14
3.1 TFT LCD Module............................................................................................................14
3.2 PinAssignment................................................................................................................14
4Optical Specification...............................................................................................................15
5LED Driving Board Specifications..........................................................................................17
5.1 Operating Characteristics..................................................................................................17
5.2 Connector Socket.............................................................................................................18
5.3 Mechanical Characteristics ...............................................................................................19
6Mechanical Drawing...............................................................................................................20
7AD2662GDH Board & OSD Functions...................................................................................22
7.1 General Description .........................................................................................................22
7.2 Outline Dimensions..........................................................................................................23
7.4 OSD Function..................................................................................................................31
7.5 OSD Menu......................................................................................................................32
8Precautions.............................................................................................................................38
8.1 Handling and Mounting Precautions..................................................................................38
8.2 Storage Precautions..........................................................................................................38
8.3 Operation Precautions ......................................................................................................39
9Disclaimer...............................................................................................................................39

LITEMAX Electronics Inc. Page 4
1General Description
The DLF/DLH1858-A is a 18.5 inch industrial grade sunlight readable LCD, with high
brightness 1600 nits and high color saturation, it produce sharp images, crisp text and lifelike
colors. The Durapixel LED backlight technology ensures high reliability and low power
consumption, suitable for outdoor application, kiosk, factory automation, military,
transportation and gaming application.
1.1 Features
High Brightness 1600 nits
Sunlight Readable
Wide Viewing Angle of 178°(H), 178°(V)
Low Power Consumption
BL MTBF: 100,000 hours
1.2 General Specifications
Model Name
DLF1858-A / DLH1858-A V1
Description
18.5” TFT LCD, LED Backlight 1600 nits, FHD (1920x1080)
Screen Size
18.5”
Display Area (mm)
408.96(H) x 230.04(V)
Brightness
1600 cd/m2
Resolution
1920x1080
Aspect Ratio
16 : 9
Contrast Ratio
1100 : 1
Pixel Pitch (mm)
0.213(H) x 0.213(V)
Pixel Pre Inch (PPI)
119
Viewing Angle
178°(H),178°(V)
Color Saturation (NTSC)
83%
Display Colors
16.7M
Response Time (Typical)
20ms
Panel Interface
LVDS
AD Board Input Interface
VGA, DVI-D, HDMI
AD Board Input Power
DC12V
Power Consumption
34W (40W with AD Board)
OSD Key
4 Keys (Power Switch, Menu, +, -)
OSD Control
Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Dimensions (mm)
430.4 x 254.6 x 13,6
Bezel Size(U/B/L/R)
10.78/10.78/9.22/9.22 mm
Weight (Net)
1.5kg
Operating Temperature
-20 ˚C ~ 60 ˚C
Storage Temperature
-20 ˚C ~ 70 ˚C
DLF= Panel + LED Driving Board
DLH= Panel + LED Driving Board + AD Control Board

LITEMAX Electronics Inc. Page 5
1.3 Absolute Maximum Ratings
Absolute maximum ratings of the module are as following:
TFT LCD Module
Absolute Ratings of Environment
Note 1: With in Ta (25 oC)
Note 2: Permanent damage to the device may occur if exceeding maximum values
Note 3: For quality performance,please refer to Litemax IIS(Incoming Inspection Standard).
Note 4: Operation Temperature +70°C is defined as panel surface temperature.

LITEMAX Electronics Inc. Page 6
2Electrical characteristics
2.1 TFT LCD Module
Power Specificatio
Input power specifications are as follows:
Note 1: Measurement conditions:
The duration of rising time of power input is 470us.

LITEMAX Electronics Inc. Page 7
Signal Electrical Characteristics
Input signals shall be low or Hi-Z state whenVDD is off. Please refer tospecifications of
SN75LVDS82DGG(Texas Instruments) in detail
Characteristics of eachsignal are as follows:
Note 1: LVDS Signal Waveform

LITEMAX Electronics Inc. Page 8
2.2 Signal Characteristic
Pixel Format Image
Following figure shows the relationship of the input signals and LCD pixel format.

LITEMAX Electronics Inc. Page 9
2.3 The input data format
Note1: Normally DE mode only. VS andHS on EVEN channel are not used.
Note2: Please follow VESA.
Note3: 8-bits signal input.

LITEMAX Electronics Inc. Page 10
2.4 Signal Description
The module using a pair of LVDS receiver SN75LVDS82 / SN75LVDS83
(Texas Instruments) or compatible. LVDS is a differential signal technology for LCD interface and high
speeddata transfer device. Transmitter shall be SN75LVDS83(negative edge sampling) or compatible.
The first LVDS port(RxOxxx) transmits odd pixels while the secondLVDSport(RxExxx) transmits even
pixe

LITEMAX Electronics Inc. Page 11
Note1: Start fromleft side
Note2: Inputsignals of clock shall be the same timing.
Note3: Please follow TV VESAPin Assignment.

LITEMAX Electronics Inc. Page 12
2.5 Timing Characteristics
Note 1: Only DE mode operation.
The input of Hsync & Vsync signal does not have an effect upon the LCD normal operation.
Note 2: The performance of the electro-optical characteristics may be influenced by variance of the
vertical refresh rates.
Note 3: Horizontal period should be even.
2.6 Timing Diagram

LITEMAX Electronics Inc. Page 13
2.7 Power ON/OFF Sequence
VDD power and LED on/off sequence are as follows. Interface signals are also shown in the
chart.
Signals from any system shall be Hi-Z state or low level when VDD is off.

LITEMAX Electronics Inc. Page 14
3Connector & Pin Assignment
Physical interface is described as for the connector on module. These connectors are capable of
accommodating the following signals and will be following components.
3.1 TFT LCD Module
3.2 Pin Assignment

LITEMAX Electronics Inc. Page 15
4Optical Specification
Item
Symbol
Condition
Min.
Typ.
Max.
Unit
Note
Color chromaticity
Red
Rx
θx=0
θy=0
Klein K-10
0.608
0.638
0.668
-
Test Mode:
(1) (2) (3)
Ry
0.300
0.330
0.360
-
Green
Gx
0.241
0.271
0.301
-
Gy
0.595
0.625
0.655
-
Blue
Bx
0.114
0.144
0.174
-
By
0.032
0.062
0.092
-
White
Wx
0.236
0.266
0.296
-
Wy
0.268
0.298
0.328
-
Center Luminance of White
Lc
θx=0
θy=0
BM-7
1600
cd/m2
Uniform
Lu
85
%
Contrast Ratio
CR
θx=0
θy=0
Klein K-10
1100:1
-
Test Mode:
(1) (4)
Color Saturation
NTSC
83
%
Viewing Angle
Horizontal
θx+
CR ≥ 10
89
Deg
Test Mode:
(1) (3)
θx-
89
Vertical
θy+
89
θy-
89
TestMode：
(1) Definition of Viewing Angle (θx , θy):

LITEMAX Electronics Inc. Page 16
(2) Definition of Test Point:
BA C
2
1
3
Active Area
(3) BM-7 Measurement Setup:
(4) Klein K-10 Measurement Setup:

LITEMAX Electronics Inc. Page 17
5LED Driving Board Specifications
This specification is applied to LED converter unit for LED backlight.
5.1 Operating Characteristics
Item
Symbol
Conditions
MIN.
TYP.
MAX.
Unit
Remark
Input Voltage
Vin
10.0
12.0
14.0
V
Input Current
(LowBrightness)
IinL
VIN=12V,Vadj=5V
0.0
-----
-----
mA
Input Current
(High Brightness)
IinH
VIN=12V,Vadj=0V
1.95
1.79
1.68
A
(1)
5.1.1.1.1 LED
Current
(LowBrightness)
IoutL
VIN=12V,Vadj=5V
0.0
-----
-----
Arms
LED Current
(High Brightness)
IoutH
VIN=12V,Vadj=0V
0.83
0.88
0.93
A
Working Frequency
Freq
VIN=12V,Vadj=0V
350
400
450
KHZ
Brightness Control
DC mode
Vadj
Connection of
Voltage
0.2
-----
4.8
V
Vadj±5%
PWM mode
PWM
Connect to PWM
0
-----
100
%
Max ratio
1:100
1:100
Freq
-----
200
-----
Hz
(2)
ON/OFFControl
Von
Normal Operation
2
-----
5
V
Voff
Normal Operation
0
-----
0.8
V
Output Voltage
Vout
VIN=12V,Vadj=0V
31.2
31.7
32.2
V
Efficiency
η
VIN=12V,Vadj=0V
90.7
91.3
92.2
％
(3)
Remark:
(1) this data is based on the testing result of practical input voltage, Iin is measuredby related Vin.
(min, typ, max)
(2) Frequency canbe adjusted in accordance withdemand(120Hz minimum, or lights will be flickering)
(3) ηmax = Vout(max)*IoutH(max)/Vin(max)*IinH(min)
ηmin = Vout(min)*IoutH (min)/Vin(min)*IinH(max)

LITEMAX Electronics Inc. Page 18
5.2 Connector Socket
Input Connector:
J3(JST S9B-PH-SM3-TB orCompatible)
PIN No
Symbol
Description
1
Vin
DC+
2
Vin
DC+
3
Vin
DC+
4
GND
Ground
5
GND
Ground
6
GND
Ground
7
Brightness
Brightness Control
8
Control
ON/OFF Control
9
CL
PWM or DC selection (Low DC , Hi PWM)
Output Connector:
J2,J3(JST S2B-EHorCompatible)
PIN NO
Symbol
Description
1
Output
LED High Voltage( + )
2
Output
LED Low Voltage ( - )
DC or PWM Connector: JP1
PIN NO
Symbol
Description
1
DC
JUMP pin 1,2
LED driver is DC input
2
GND
JUMP pin 2,3
LED driver is PWM input
3
PWM

LITEMAX Electronics Inc. Page 19
5.3 Mechanical Characteristics
Dimension: 125mm*50mm*12.5mm
12.5mm

LITEMAX Electronics Inc. Page 20
6Mechanical Drawing
Unit:mm
