USER'S MANUAL
FULLY BUILT-IN DISHWASHER S4000
cod. 2910 010

31
EN
CONTENTS
1/ FOR THE USER’S ATTENTION
• Safety instructions ______________________________________ 32
• Protection of the environment ____________________________ 32
• Economical, environmentally friendly washing ________________ 33
2/ DESCRIPTION OF YOUR APPLIANCE
• General presentation of the dishwasher ____________________ 34
• Presentation of the control panel __________________________ 35
3/ INFORMATION
• The water hardness______________________________________ 36
4/ ACTIONS BEFORE FIRST USE
• Measure the water hardness and select the detergent ________ 37
• Hardness table__________________________________________ 37
5/ DETERGENT PRODUCTS AND SETTING THE WATER SOFTENER
• For traditional products __________________________________ 38
• For multi-purpose products ________________________________ 38
6/ LOADING THE REGENERATING SALT __________________________ 40
7/ LOADING THE RINSING PRODUCT ____________________________ 41
8/ YOUR DISHWASHER’S EQUIPMENT
• The lower basket ________________________________________ 42
• The upper basket________________________________________ 43
• The cutlery basket ______________________________________ 44
9/ THE DISHWASHER’S SAFETY SYSTEMS________________________ 45
10/ WASHING PROGRAMMES __________________________________ 46
11/ PROGRAMMING __________________________________________ 48
12/ CLEANING YOUR APPLIANCE
• Cleaning the waste filters ________________________________ 50
13/ IF OPERATING ANOMALIES OCCUR __________________________ 52
14/ AFTER-SALES SERVICE ____________________________________ 57
15/ INDICATIONS FOR THE TESTING LABORATORIES ______________ 58

32
EN
1/ FOR THE USER’S ATTENTION
Important :
Keep this user’s manual with your appli-
ance. If the appliance is sold or transferred to
someone else, ensure that the manual is with
it. Please take note of these instructions
before installing and using your appliance.
They have been drawn up for your own and
other people’s safety.
• SAFETY INSTRUCTIONS
• Installation
— When you receive your appliance, unpack it
or have it unpacked immediately. Check that it
has not suffered any damage during transport.
Express any reservations in writing on the
delivery note, of which you keep a copy. Never
connect up a damaged machine. If your appli-
ance is damaged, please contact your dealer.
— Before proceeding to connect up your
machine, please refer to the instructions in
your Installation Guide.
— Your dishwasher must be kept disconnected
from the mains supply throughout the whole
of the installation process.
— The electrical connection details on your
appliance’s description plate must comply
with those for the mains supply.
— The socket must still be accessible once
your appliance has been installed.
— Do not alter or attempt to alter the appli-
ance’s characteristics. This could put you at
risk.
— If your installation has to be altered, only
entrust the electrical and plumbing work to a
qualified electrician or plumber respectively.
— Your appliance is designed for normal
domestic use. Do not use it for industrial or
commercial purposes or for any other purpose
than that for which it has been designed.
— The dishwasher’s walls must not be pierced
under any circumstances.
• Children’s safety
— This appliance is not intended for use by
young children or infirm persons unless they
have been adequately supervised by a respon-
sible person to ensure that they can use the
appliance safely.
— This appliance must only be used by adults.
Ensure that children do not touch it and do not
use it as a toy. Ensure that they do not operate
the appliance’s controls.
— Keep young children away from the appli-
ance when it is operating.
— Detergents contain irritant and abrasive sub-
stances. These products can have caustic
effects on the eyes, the mouth or the throat.
They can be extremely dangerous if ingested.
Avoid any contact with the skin and the eyes.
Ensure that the appliance’s detergent contain-
er is empty at the end of the washing cycle.
— Place detergents out of children’s reach and
do not put any detergent in the machine until
just before you start the washing programme.
— The water in your dishwasher is not drinking
water; this is why children must not go near
the appliance when its door is open.
— Do not let your children play or sit on the
door when it is open.
— Once you have unpacked your appliance,
place the packaging out of children’s reach.
— Keep all the packaging materials (e.g. plastic
bags, polystyrene, etc.) out of children’s reach
because they can be dangerous for children
(ie. risk of suffocation).
• Use
— This appliance is not intended for use by per-
sons (including children) with reduced physi-
cal, sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concern-
ing use of the appliance by a person responsi-
ble for their safety.
— When machine is running, do not open door.
This may provoke steam leakage or splattering
of water.

33
EN
1/ FOR THE USER’S ATTENTION
— Only use products specially designed for your dishwasher (water softening salt, detergent and
rinsing products).
— As far as possible, avoid opening the dishwasher’s door when it is operating, and in particular
during the heating phases, because scalding steam may escape or you may be splashed with hot
water. The machine is fitted
with a safety system that immediately blocks the dishwasher’s operation if the door is opened.
— Never use chemical solvents in your appliance because these could cause an explosion.
— Always close your appliance’s door after loading or removing your items.
— Do not lean or sit on your appliance’s door when it is open.
— You are strongly advised to disconnect the machine after use and turn off the water supply.
— Unplug your machine before carrying out any technical work on it.
— Avoid placing your machine immediately next to a cooking or heating appliance to prevent any
risk of heat damage;
— Do not place any items in your machine, which are not certified as dishwasher safe.
— If you have removed an item before the end of the washing programme, it is important to rinse it
carefully to remove any residual washing products.
— If your appliance breaks down, never attempt to repair it yourself. Any repairs made by non-qual-
ified personnel can cause significant damage or lack of control.
— The machine complies with applicable safety regulations. Any repairs should be carried out by
qualified technicians. Repairs or changes that do not conform may be dangerous for the users. In
case of replacement, only use original parts.
— If the machine malfunctions due to other causes than those mentioned in this booklet, disconnect
the machine (remove the plug) or break the circuit concerned and contact after-sales service.
•
ENVIRONMENTAL PROTECTION
This appliance’s packaging material is recyclable. Help recycle it and protect the environment by
dropping it off in the municipal receptacles provided for this purpose.
Your appliance also contains a great amount of recyclable material. It is marked with this
label to indicate that in countries that are a members of the European Union the used
appliances should not be mixed with other waste. This way, the appliance recycling orga-
nised by your manufacturer will be done under the best possible conditions, in compliance
with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment. Contact your
town hall or your retailer for the used appliance collection points closest to your home.
We thank you doing your part to protect the environment.
• ECONOMICAL, ENVIRONMENTALLY FRIENDLY WASHING
— Remove any food residue from your crockery (bones, pips, etc.)
— Do not pre-wash your items by hand (useless waste of water).
— Utilise your dishwasher’s capabilities to the full for an economical, environmentally friendly wash.
— Always select a washing programme suitable for the crockery type and how dirty they are.
— Avoid overdosing with detergent, regenerating salt and rinsing liquid. Follow the recommenda-
tions in this guide (pages 39-40-41) and the instructions on the product packs.
— Ensure that the water softener is correctly set (see page 38).

34
EN
2/ DESCRIPTION OF YOUR APPLIANCE
Control panel
Upper basket
Washing products dispenser
Anti-blocking gauge wire
Lower sprinkler arm
Regenerating salt tank
Waste filter
Main filter
Rinsing product dispenser
Description plate (After-Sales Ref)
JJ
II
HH
GG
FF
EE
DD
CC
BB
AA
• GENERAL PRESENTATION OF THE DISHWASHER
Advice :
This user’s guide is applicable to several models. There may be some slight differences
in the details and the equipment between your appliance and the descriptions provided here.
Fig. 01
BB
CC
DD
EE
FF
GG
HH
II
JJ
AA

35
2/ DESCRIPTION OF YOUR APPLIANCE
EN
On/ Off :
Press this button to start your dishwasher :
the screen lights up.
DCS : “Dirt Control System”
This exclusive concept gives a direct access to
3 types of dishes only, but offers a large
choice of programs by adjustment of your
dirty mark level estimation. (See 10 / Washing
programmes).
Choosing a programme: briefly
press one button or the other in succession to
select your programme.
Set :
• Set the water softerner.
(See 5/ Detergent products and setting the
water softener).
- Activate or deactivate use of “regenerating
salt”, “rinsing product” or “4-in-1” (depending
on the water softener setting on the next page).
• Setting the audible signal.
(See 11/ Programming).
Delayed programme start
Press this button to delay the programme by 1
to 12 hours.
Start / C : Briefly press this button to
start your programme.
If you make an error, to cancel a selection or
cancel a programme while it is running, hold
down this button for 3 seconds.
The indicator lights :
SSaalltt:
lit; indicates lack of regenerating salt.
Rinsing liquid:
lit; indicates lack of rinsing product.
washing product:
lit; indicates that your dishwasher is set to use
“2, 3 4-in-1” pellets.
In progress
lit; indicates that your programme is running.
End :
lit; indicates that your programme has finished
FF
EE
DD
CC
BB
AA
Advice :
A short audible signal (beep) confirm the button’s selection, except for the “On/Off” button.
(See 10/ Washing Programmes).
• PRESENTATION OF THE CONTROL PANEL
Fig. 02
On/Off
SET
End
QuickBio
Auto
DCS
Dirty
Start / C
CC
AADDEEFF
BB

36
3/ INFORMATIONS
EN
Important:
For your dishwasher to provide impec-
cable washing and drying results with no
marks, you must set it correctly using the
water softening system, which uses regene-
rating salt.
• THE WATER HARDNESS
•Lime: rainwater filtering through the
ground picks up mineral salts; some minerals
are found in solid form commonly termed
lime. This reduces the washing detergent’s
performance, furs up the dishwasher and lea-
ves white marks on the crockery.
The more lime there is in the water, the more the
water is called “hard”.
Use the most suitable products for the level of
water hardness in your town.
There are several types of products; how to
choose:
For impeccable results, preferably
use a combination of traditional pro-
ducts:
①①
Washing detergent to clean the
crockery perfectly (powder, liquid or stan-
dard tablets).
②②
Regenerating salt to enable your dis-
hwasher’s water softener to operate cor-
rectly.
③③
Rinsing liquid to assist drying and to
eliminate marks from water droplets.
Important:
Never use washing-up liquid.
For ease of use and only in certain
water hardness conditions < 35°F,
multi-purpose products may make the
use of rinsing liquid or salt unnecessary.
• “Two-in-one” products contain
detergents, rinsing liquid or an agent acting
as the salt.
• “Three-in-one” products contain
detergents, rinsing liquid and an agent acting
as the salt.
• “Four-in-one” products also
contain additives that prevent wear on poor
quality glasses and /or prevent the risks of
the stainless steel corroding.
Important:
Follow the instructions for using the
multi-purpose product and the recommenda-
tions on the pack.
NB:
If in any doubt, please contact the
detergent manufacturer if the crockery is
very wet at the end of the programme or if
chalky deposits appear.

37
4/ ACTIONS BEFORE FIRST USE
EN
Possible to use
traditional products ➊
Use of traditional products
only ➊
First of all, in one simple action, you can test the lime content in your water using the testing strip
supplied with your dishwasher or you can contact your local water utility to find out how hard your
water is.
— Turn on the tap and let the water run for a few minutes.
— Fill a glass with water.
— Take the testing strip out of its casing and immerse it for 3 seconds.
— Wait 1 minute, shake the strip and look at the colours to find out how hard your water is.
• MEASURE THE WATER HARDNESS AND SELECT THE TYPE OF DETER-
GENT: TRADITIONAL OR MULTI-PURPOSE
TTeessttiinnggssttrriipp
HHaarrddnneessss0-10°F 10-25°F 25-40°F 40-55°F 55-70°F > 70°F
WWaatteerrSoft Slightly hard Slightly hard Hard Hard Very hard
SSoofftteenniinnggaanndd
uusseeooffssaalltt
Optional
Essential if
using traditio-
nal products
Essential if
using traditio-
nal products
Essential Essential Essential
• HARDNESS TABLE
R
+
oorr
oorr➋ multi-purpose products
+
➊TTrraaddiittiioonnaallpprroodduuccttss::
PP: PPowder detergent or LL: LLiquid detergent + SS: regenerating SSalt + RR: RRinsing product
➋MMuullttii--ppuurrppoosseepprroodduuccttss::“multi-purpose” tablets.
➋
➊
R
+
oorr+

38
5/ DETERGENT PRODUCTS AND SETTING THE WATER SOFTENER
EN
• FOR TRADITIONAL PRODUCTS
Important:
It is very important to set your water softener correctly.
- If the setting is too low, there is a risk of chalky marks
- If the setting is too high, there is the risk of the glasses becoming cloudy
If you move house, re-adjust the setting on your water softener.
• Traditional tablets
Place tablets that are not multi-purpose in the external compartment (Fig 04)
or, for optimum operation, pull out the distributor’s drawer and lay the tablet there. (Fig 05)
• Powder or liquid in the distributor’s drawer (Fig 03)
Fill at least up to the minimum mark for slightly dirty crockery and up to the maximum mark for dirty
crockery. If the crockery is very dirty or for programmes with pre-wash, we recommend that you
add 5g of detergent (a dessertspoonful) to the tub in accordance with the programmes table.
Important:
Keep these products in a dry place, out of children’s reach.
Only use products specially designed for dishwashers.
• Your appliance must be specially set to use traditional products .
• Proceed as follows to adjust the water softener
on the control panel:
— Access setting mode by holding down the “Set ” button until
you hear a double audible signal (long beep).
— The screen displays “SEt” to indicate that you are in Setting
mode.
— To adjust and alter the setting to suit the water hardness, keep on briefly pressing one of the
keys or the other. The screen shows you the setting H0, H1, H2 etc...
— The setting is validated automatically after 10 seconds if the
“Set” button in not pressed again.
Fig. 04 Fig. 05Fig. 03
Factory setting: H4.
SET
End
QuickBio
DCS
Dirty
TTeessttiinnggssttrriipp
HHaarrddnneessss0-10°F 10-18°F 18-25°F 25-40°F 40-55°F 55-70°F > 70°F
0-1mmol/l 1-1.8 mmol/l 1.8-2.5 mmol/l 2.5-4 mmol/l 4-5.5 mmol/l 5.5-7 mmol/l > 7 mmol/l
TTrraaddiittiioonnaall
pprroodduuccttHIH0 H2 H3 H4 H5 H6

Important :
The multi-purpose products setting enables you to deactivate the rinsing and salt warning
lights only on H0 and “4-in-1”.
• Loading multi-purpose tablets
To make loading the detergent easier, the distributor is located on the front of the upper basket; it
is compatible with all the products recommended for your dishwasher.
• Place the tablet in the external compartment (Fig 04 on previous page) or
or, for optimum operation, pull out the distributor’s drawer and lay the tablet there. (Fig 05 on pre-
vious page).
- Close the distributor.
39
5/ DETERGENT PRODUCTS AND SETTING THE WATER SOFTENER
EN
• FOR MULTI-PURPOSE PRODUCTS: OPTION
• Proceed as follows to adjust the water softener on the control panel:
— Access setting mode by holding down the “Set ” button until
you hear a double audible signal (long beep).
— The screen displays “SEt” to indicate that you are in
Setting mode.
TToouusseemmuullttii--ppuurrppoosseettaabblleettss,,yyoouummuussttsseelleeccttsseettttiinngg HH00 oorr
HHII oorr HH22 ,,ddeeppeennddiinnggoonntthheewwaatteerrhhaarrddnneessss..To do this, keep on briefly pressing one or other of the
keys until you reach the desired setting.
• Proceed to set the option, if necessary
(Light unlit) : deactivates the “4 en 1” option
(Light flashing)
: corresponds to activation of the
“4 en 1” function with the setting for “Sparkling Clean”. This enables you to prioritise a
brilliant finish for your crockery.
(Light permanently lit) : corresponds to activation of the
“4 en 1” function with the setting for “Extra Dry”.
““EExxttrraaddrryy””enhances the drying results if performance is reduced.
— The setting is validated automatically after 10 seconds if the
“Set” button in not pressed again.
• Your appliance can be specially set to use multi-purpose if the water hardness is
< 25°F or < 2,5 mmo/l.
Advice:
To provide better coverage of the wide range of multi-purpose products available, your
dishwasher’s “4-in-1” option has two possible settings, accessible via the “Set” button.
“Extra Dry” improves the drying results in the event of reduced performance from the “2-in-1”, “3-in-1”
or “4-in-1” types of multi-purpose product.
“Sparkling Clean” enables you to prioritise the sparkle of your crockery whatever the type of
multi-purpose product used.
SET
End
QuickBio
DCS
Dirty
TTeessttiinnggssttrriipp
HHaarrddnneessss0-10°F 10-18°F 18-25°F
0-1mmol/l 1-1.8 mmol/l 1.8-2.5 mmol/l
FFuunnccttiioonnDDeeaaccttiivvaatteedd
MMuullttii--ppuurrppoosseepprroodduuccttss
““SSppaarrkklliinnggCClleeaann””
MMuullttii--ppuurrppoosseepprroo--
dduuccttss““
EExxttrraaDDrryy””
H0
H0
H0
HI
HI
HI
H2
H2
H2
SET
HI

40
6/
LOADING THE REGENERATING SALT
EN
EAU
SEL
AA
BB
CC
Fig. 06
•Loading the regenerating salt
(Fig. 06)
Important :
Only use special dishwasher regener-
ating salt. Do not use table salt or any type
of cooking salt: this could damage your
appliance’s water softener.
Unscrew and remove the stopper on the
salt tank.
Fill the tank with rreeggeenneerraattiinnggssaallttspe-
cially designed for dishwashers.
Use the funnel supplied with your dis-
hwasher. The first time, top up with water up
to the rim of the tank.
• Regenerating salt indicator :
This illuminates when salt must be added.
After the tank has been filled with regenerat-
ing salt, the indicator light may remain lit until
the salt has dissolved sufficiently, usually after
one cycle (of if the tank has not been filled
completely; for example, when first putting the
machine into service using the sample).
This can be deactivated as indicated in the
paragraph “For multi-purpose products” set-
ting table.
Important :
If the salt overflows when filling the
tank, to avoid oxidization of the tub it is
advisable to remove the salt crystals or to
run a Soaking programme.
CC
BB
AA

41
7/ LOADING THE RINSING PRODUCT
EN
Adjustment lever
Fig. 07
1
2
3
1
2
3
AA
BB
CC
• The rinsing product (Fig. 07)
Important:
Use a special dishwasher rinsing product;
this will give you dry, sparkling crockery.
Before switching on the appliance, fill
the rinsing product container until the level is
flush with the top of the setting lever.
Adjust, if necessary; the original setting is 2. If
you experience poor drying or residual marks
after a few cycles, increase the setting by turning
the lever (fig 07 : marking 3 to increase it)
• Checking the level of rinsing liquid
:
This lights when rinsing liquid must be added.
It can be deactivated as shown in the para-
graph “For multi-purpose products” setting
table.
Important:
If any rinsing liquid overflows onto the
door when filling the container, sponge away
the excess to avoid foam forming.
CC
BBAA

42
8/ YOUR DISHWASHER’S EQUIPMENT
EN
Fig. 09
Very important :
Items not suitable for washing in a dishwasher
- Wooden cutting boards,
- Stainless steel utensils or plastic utensils that are not heat-resistant,
- Copper or pewter items,
- Glued crockery and cutlery,
- Cutlery with wooden, horn or mother-of-pearl handles,
- Antique or hand-painted porcelain.
When purchasing crockery, glasses or cutlery, ensure that it is dishwasher-safe.
• THE LOWER BASKET
Arrange your items so that the water can cir-
culate freely and spray over all the utensils.
Place large diameter dishes and pans at the
sides.
Do not intersperse, jam together or superim-
pose flat plates and concave dishes (Fig. 08).
The folding spikes make it easier to arrange
your large dishes (Fig. 09) (depending on the
model).
Advice :
When you re-insert the lower basket,
ensure that nothing catches on the upper
basket’s gauge wire to avoid blocking the
rotor.
Unloading your items
First of all empty the lower basket to avoid
drips from the upper basket falling onto the
lower basket.
Fig. 08

43
8/ YOUR DISHWASHER’S EQUIPMENT
EN
Fig. 11
Fig. 10
• THE UPPER BASKET
This basket is particularly designed to take:
glasses, cups, ramekins, small salad bowls,
bowls, saucers, etc...
Arrange your items methodically to save on
space (arranging glasses, cups or bowls
together, etc.)
You can also arrange cups, ladles, etc. on the
retractable supports (Fig. 10)
Advice :
Position the cavities of glasses, cups
or bowls facing downwards.
Cutlery basket
• Adjusting the height of the upper
basket (depending on the model)
For large dishes to be loaded in the lower bas-
ket, the upper basket must be set in to high
position. This can be done with the basket
fully loaded (Fig. 11)
①①Setting in HIGH POSITION :
Gently raise your basket on each side until it
engages.
②②Setting in LOW POSITION :
Raise your basket completely on both sides to
unlock it and then lower it to the low position.
Important :
Check that the two slides are set to the
same height and the basket is horizontal.

44
8/ YOUR DISHWASHER’S EQUIPMENT
EN
Fig. 13
• THE CUTLERY BASKET
The cutlery basket slides to allow for modu-
lable loading.
It can be placed anywhere in the lower basket.
You can therefore make a variety of loads
depending on the items (Fig. 12).
If your cutlery items or your dishes are too
large, alter the height setting for the upper
basket (if it can be adjusted, depending on the
model).
Movable grills are available for if you wish to
load your cutlery in an orderly manner (Fig.
13).
For optimum washing and drying, use these
separation grills partially or totally.
Point the handles on the cutlery downwards.
Important :
For safety reasons, we recommend
that you place knives with pointed ends with
the point facing downwards in the cutlery
basket (to avoid the risk of an accident).
Long-bladed knives and other sharp kitchen
utensils must be placed flat in the upper bas-
ket.
Avoid washing cutlery with horn handles in
your dishwasher.
Separate silverware from other metals using
the separation grill.
Fig. 12

45
9/ THE DISHWASHER’S SAFETY SYSTEMS
EN
•Anti-overflow system
This system automatically activates the drain pump if the water level in the tub reaches an abnor-
mal height.
•Anti-leak system
This system interrupts the water supply if a leak is detected under the appliance.
•Total safety
This supply pipe is fitted with a device to cut off the water supply directly at the tap if there is a leak.
• If an anomaly occurs
The “End” light flashes rapidly.
The screen shows the anomaly code: please refer to the table on page 51.

46
10/ WASHING PROGRAMMES
EN
TTyyppeeooffiitteemmss::
--ppoorrcceellaaiinn,,ppaannss,,
ccuuttlleerryy,,ggllaasssseess,,
eettcc..
QQuuaannttiittyy,,ttyyppeeaanndd
aammoouunnttooffffoooodd
rreessiidduuee..
PPrrooggrraammmmeess
PPrrooggrraammmmee
sseeqquueennccee
AAssaanniinnddiiccaattiioonn
oonnllyy::
DDuurraattiioonniinnmmiinn..
WWaatteerr((ll..))
EEnneerrggyy((kkWWhh))
• PROGRAMMES TABLE
120’ - 140’
14,5 - 16,5
1,7 - 1,8
90’ - 120’
14,5 - 16,5
1,5 - 1,6
60’ - 75’
13,5
0,95
NNoorrmmaallllyyddiirrttyy
Washing at low tem-
perature,
economical and par-
ticularly
suitable for
compact –
enzymatic
detergents
Hot rinse
Rinse
NNoorrmmaall
****
Drying
Mixed
Washing at 60°C
Pre-wash
VVeerryyddiirrttyy
large dishes and
pans, with baked on
residue, grease,
cooked cheese,
sauce, etc.
IInntteennssiivv
Drying
Resistant
Hot rinse
Rinse
Washing at 70°C
Hot pre-wash
GGllaasssseess
Drying
Delicate
FFoorrggllaasssseessaanndd
ddeelliiccaatteeccrroocckkeerryy
Meaning a smaller
quantity of not very
sticky residues.
Hot rinse
Rinse
Washing at 45°C
DCS DCS
Dirty Dirty Dirty
DCS
These values refer:
- to normal usage conditions with separated products (detergents, salt, rinsing product).
- only to multifunction product usage conditions
They may vary depending on the load, the water temperature, the softener setting, the presence of rins-
ing product and the supply voltage.

47
10/ WASHING PROGRAMMES
EN
100’ - 130’
14,5 - 16,5
1,4 - 1,6
160’ - 165’
12 - 14
1,05 - 1,30
30’
11
0,8
15’
4,5
0,02
Drying
Mixed
AAuuttoommaattiicc
ddeetteeccttiioonnoofftthhee
aammoouunnttooffrreessiidduuee..
Optimises the
results and
prioritises
energy savings.
Mixed
Hot rinse
Drying
Hot rinse
Drying
VVeerryysshhoorrtt3300--mmiinnuuttee
wash
specially designed
for a small amount
of daily items with a
limited amount of
non-greasy residue,
not dried on
Hot rinse 60°C
Mixed
Mixed
SSooaakk
Very short cycle
(with no
detergent) for rins-
ing and
re-dampening the
items while
waiting for a wash
expected the follow-
ing day or even the
day after
Rinse Rinse Rinse
Washing at 55/65°C
Washing at 50°C Washing at 45°C
Pre-wash
**
NNoorrmmaallllyyddiirrttyy
A normal amount of
dried-on and greasy
residue on
everyday items.
Faster, but
consumes more
energy.
Cold pre-wash
Quick
Bio
Recommended programme:
**EN50242
****IEC 436/DIN 44990

48
11/ PROGRAMMING
EN
Advice :
Consult the Programmes table on the preceding pages to determine the programme you
need for the type of items, the quantity and the amount of food residue.
End of programme
Remaining time
Programme length
Waiting for delayed start
• Immediate programme start
Press “OOnn/Off” , to switch on your
appliance and select your programme by
pressing one button .
— When a programme is selected, the associa-
ted light illuminates.
Press “Start/C” , the “In progress”
light illuminates. Close the door and the pro-
gramme starts.
A short audible signal (beep) confirm the
button’s selection, except for the “On/Off”
button.
• Delayed programme start
Delay your programme by 1 to 12 hours by
keeping on briefly pressing, or holding down,
the “Delayed Start”
button, as you prefer.
Confirm by pressing “Start/C”.
The screen counts down the hours until the
programme starts.
EE
FF
AA
Fig. 02
On/Off
SET
End
QuickBio
Auto
DCS
Dirty
Start / C
CC
AADDEEFF
BB
End of programme
Remaining time for
programme
Remaining time

49
11/ PROGRAMMING
EN
•Cancelling a programme
Hold down the “Start/CC” button for a few seconds.
•Stopping the appliance
When the programme has finished, press the “On/Off” button .
• Setting the audible signal
The setting enables you to activate or de-activate the beep at the end of the programme.
— Access the setting by holding down “Set” juntil you hear a double audible signal (long beep). Select
your preference by pressing the “Delayed Start” button :
- Beep activated : an audible signal is heard and the “End” light flashes. The screen shows BBIIPP..
- Beep de-activated : no audible signal and the “End” light is unlit.
The setting is confirmed automatically after approximately 10 seconds.
EE
AA
FF
Press DDCCSSkey to adjust the program according to dirty
mark of your dishes :
- Very dirty (++), or Dirty for ““IInntteennssiivv””
- Very dirty (++), or Not very dirty (--) for ““
NNoorrmmaall””
- Dirty or Not very dirty (--) for ““GGllaasssseess””program.
• L’OPTION “DCS” DIRT SYSTEM CONTROL
BB
This option is available for all ««IInntteennssiivv»»««NNoorrmmaall»»««GGllaasssseess»»pprrooggrraammss..
Dirty
DCS
